Samsung CLP-510 - Color Laser Printer User manual

S ETUP G UIDE
2
CONTENTS
Step 1. Unpacking ............................................. 3
Step 2. Understanding Your Printer ................... 5
Step 3. Installing the Transfer Belt and Toner Cartridges 7
Step 4. Loading Paper ..................................... 14
Step 5. Connecting a Printer Cable .................. 17
For Local Printing ......................................17
For Network Printing ..................................18
Step 6. Turning the Printer On ........................ 19
Step 7. Printing a Demo Page .......................... 20
Step 8. Changing the Display Language .......... 20
Step 9. Installing the Printer Software ............ 21
Installing Printer Software in Windows ..........22
Reinstalling Printer software ........................26
Removing Printer Software .........................27
Changing the Display Language ...................28
Step 10. Viewing the User’s Guide ................... 29
In Windows ..............................................29
In Macintosh .............................................29
In Linux ...................................................30

S ETUP G UIDE
3
English
Step 1. Unpacking
1 Remove the printer and all of the accessories from the
packing carton. Make sure that the printer has been packed
with the following items:
N OTES :
• If any items are missing or damaged, notify your dealer
immediately.
• Components may differ from one country to another.
• The CD-ROM contains the printer driver, the User’s Guide, and
the Adobe Acrobat Reader program.
• The power cord may be different depending on your country.
C AUTION : This printer weighs 32kg including developer cartridge
and cassette. Use safe lifting and handling techniques. If you need
to move the printer it should be moved by two people. Use the
lifting handles located, as shown in the diagram (see page 5). Back
injury could result if a single person attempts to lift the printer.
Toner Cartridges Power Cord
Quick Install Guide CD-ROM
Optimum Setup Guide
SyncThru CD-ROM
(CLP-510N only) SyncThru Quick Guide (CLP-510N only)

S ETUP G UIDE
4
2 Carefully remove all of the packing tape from the printer.
3 Pull the paper tray out of the printer and remove the
packing tape from the tray.
4 Select a location for the printer:
•Leave enough room to open the printer trays, covers, and
to allow for proper ventilation.
•Provide the proper environment:
– A firm, level surface
– Away from direct airflow of air conditioners, heaters, or
ventilators
– Free of temperature, sunlight, and humidity extremes or
fluctuations
– Clean, dry, and free of dust
C AUTION : You must place your printer on a level surface. If you
do not, print quality problems can occur.

S ETUP G UIDE
5
English
Step 2. Understanding Your Printer
These are the main components of your printer:
N OTE : The surface of the output tray may become hot if you print
a large number of pages at once. Please make sure that you don’t
touch the surface, and prevent children from approaching it.
Top Cover
(Open to install the
transfer belt.)
Output Support
Control Panel
(Refer to
Chapter 2 in the
User’s Guide on
the CD-ROM.)
Paper Output Tray
Front Cover
(Open to replace
the waste toner
container.)
Left Cover
(Open fully to install toner
cartridges and to press the top
cover release button.)
Tray 1
(250-sheet paper feeder)
Top Cover
Release Button
Optional Tray 2
(500-sheet paper feeder)
Handle
(Use it to lift the
printer.
Lifting handles are
located at the lower
edge of both sides
of the printer.)

S ETUP G UIDE
6
Optional Tray 2 Jam Cover
(Open to remove jams from the optional tray 2.)
Muti-purpose Tray
(Open to load special print materials.)
Right Cover
(Open to remove paper jams.)
Power Switch
USB Port
Power Receptacle
Control Board
Cover
(Open to install optional
accessories.)
Wireless Network
Antenna
*
Network Port **
* A wireless network card is not supplied with the printer. It is an option that must be purchased and
installed separately.
** The network port is fitted as standard on the CLP-510N. CLP-510 users can purchase and install an
optional network card separately. For details, see the User's Guide of the printer in the CD-ROM.
Handle
(Use it to lift the printer.)

S ETUP G UIDE
7
English
Step 3. Installing the Transfer Belt and Toner
Cartridges
1 Using the handle, completely open the left cover until it is at
right angles to the main frame.
C AUTION : If the left cover is not completely open, the top cover
release button will remain locked.
2 Press the top cover release button to unlatch the top cover and
open it all the way. Remove the label on the transfer belt.
Top cover
release
button

S ETUP G UIDE
8
3 Take the transfer belt out of the printer.
N OTE : The image unit is already installed in your printer.
4 Remove the protective devices on both side of the transfer
belt.

S ETUP G UIDE
9
English
5 Locate the transfer belt slots inside the printer, one on each
side.
C AUTION : To prevent damage, do not expose the imaging unit to
light for more than a few minutes. Close the top and left covers
should the insallation need to be halted for any reason.
6 Holding the handle on the transfer belt, align it with the
slots on either side of the inside of your printer.
N OTE : Keep the transfer belt level. Do not turn the transfer belt
over, or loose toner may be spilled.

S ETUP G UIDE
10
7 Slide the transfer belt down into the printer and press it
firmly into place.
8 Firmly push the lock levers on each side toward the top
cover, as shown below, to lock the transfer belt into place.
C AUTION : If you leave the left cover open for more than a few
minutes, the imaging unit can be exposed to light. This causes
damage to the imaging unit. Close the left cover should the
installation need to be halted for any reason.

S ETUP G UIDE
11
English
9 After making sure that the left cover is open, close the top
cover. Make sure that it is securely latched.
C AUTION : Do not try to close the left cover with the top cover
open. This may cause damage to the printer.
10 Take the toner cartridges out of their packages.
C AUTION : Do not use sharp objects, such as a knife or scissors,
to open the toner cartridges packages. You could damage the
surface of the toner cartridges.

S ETUP G UIDE
12
11 Holding both sides of each of the toner cartridges, gently
roll them from side to side to evenly distribute the toner.
12 Place the toner cartridges on a flat surface, as shown, and
remove the paper covering the toner cartridge by removing
the tape.
N OTE : If toner gets on your clothing, wipe it off with a dry cloth
and wash it in cold water. Hot water sets toner into fabric.
13 On the right hand side of the toner cartridge slot is a label
that identifies which color cartridge goes into each slot.
C
M
Y
K
Black
Yellow
Magenta
Cyan

S ETUP G UIDE
13
English
14 Holding each toner cartridge with both hands, insert them
into their corresponding positions in the following order:
Cyan, Magenta, Yellow, and then Black. Then use the
handle to fully slide the cartridge in.
When the toner cartridges are correctly installed, the yellow
and black cartridges will not be fully inserted. These will
automatically move into place when you close the left cover.
15 Close the left cover. Make sure that it is securely latched.
If you have installed the toner cartridges incorrectly, the left
cover will not close properly. Check again to make sure the
cartridge colors correspond to those marked on the right
hand side. Never force the cover closed.
N OTE : When printing text at 5% coverage, you can expect a toner
cartridge life of about 3,000 pages or 7,000 pages for black and
2,000 pages or 5,000 pages for color. However, the toner cartridge
that is shipped with the printer prints 3,000 pages for black and
white, 2,000 pages for color.
M
Y
K
C
Grip here.

S ETUP G UIDE
14
Step 4. Loading Paper
The tray (Tray 1) can hold a maximum of 250 sheets of plain
paper. You can use A4 and letter-sized paper.
To load paper:
1 Pull the tray out of the printer.
2 Push down on the metal plate until it locks into position.
3 Flex the paper sheets back and forth to separate the pages
and then fan them while holding one edge. Tap the edges of
the stack on a flat surface to even it up.

S ETUP G UIDE
15
English
4 Load paper with the print side facing up .
Make sure that all four corners are flat in the tray and under
the corner brackets, as shown below.
5 Do not exceed the maximum stack height. Overfilling the
tray may cause a paper jam.

S ETUP G UIDE
16
6 Squeeze the paper guide, as shown, and side it to the stack
of paper until it lightly touches the side of the stack. Do not
press the guide too tightly against the edge of the paper as
it will cause the paper to bend.
N OTE : If you want to change the size of the paper in the tray,
refer to your printer’s User’s Guide on the CD-ROM.
7 Slide the tray back into the printer.
N OTES :
• Do not push the width guide far enough to cause the material to
warp.
• If you do not correctly adjust the width guide, it may cause a
paper jam.

S ETUP G UIDE
17
English
Step 5. Connecting a Printer Cable
For Local Printing
To print from your computer in a local environment, you need to
connect your printer to the computer with a Universal Serial Bus
(USB) cable.
N OTE : Connecting the printer to the USB port of the computer
requires a certified USB cable. You will need to buy a USB 2.0
compliant cable that is 3m or less in length.
1 Make sure that both the printer and the computer are
turned off.
2 Plug the USB printer cable into the connector on the back of
the printer.
3 Connect the other end of the cable to the USB port on your
computer.
See your computer’s User’s Guide, if you need help.
N OTE : To print using the USB interface, you must run Windows
98/Me/2000/2003/XP. See “Installing Printer Software in Windows”
on page 22.

S ETUP G UIDE
18
For Network Printing
You can attach your CLP-510 or CLP-510N printer to a network
using an Ethernet cable (UTP cable with RJ.45 connector).
The CLP-510N has a built-in network interface card. If you are a
CLP-510 user, you need to install an optional network interface card.
If you want to use the printer in both wired and wireless network
environments, you need to install an optional wired/wireless
network interface card. For details about installing the card, see
your printer’s User’s Guide on the CD-ROM.
Using an Ethernet cable
1 Make sure that both the printer and the computer are
turned off.
2 Plug one end of the Ethernet cable into the Ethernet
network port on the printer.
3 Plug the other end of the cable into a network LAN
connection.
For details about installing a network card, see your
printer’s User’s Guide on the CD-ROM.
To the network
LAN connection

S ETUP G UIDE
19
English
Using a network antenna
If you install a wired/wireless network card, you can use your
printer in a wireless environment.
For details about installing a wired/wireless network card, see
your printer’s User’s Guide on the CD-ROM.
N OTE : After connecting the printer, you need to configure the
network parameters on the control panel. See your printer’s User’s
Guide. You can use the software supplied with the card. Refer to
the software User’s Guide.
Step 6. Turning the Printer On
1 Plug the power cord into the power receptacle on the back
of the printer.
2 Plug the other end into a properly grounded AC outlet and
turn on the power.
C AUTIONS :
• Some parts inside of the printer may be hot when power is on, or
after printing. Be careful not to burn yourself when working
inside the printer.
• Do not disassemble the printer when it is turned on or plugged
in. Doing so may give you an electric shock.
2
1

S ETUP G UIDE
20
Step 7. Printing a Demo Page
Print a demo page to make sure that the printer is operating
correctly.
To print a demo page:
In ready mode, press and hold the
Upper Level button ( ) on
the control panel for 2 seconds to print a demo page.
A demo page showing the printer’s features and capabilities is
printed.
Step 8. Changing the Display Language
To change the language that is displayed on the control panel,
take the following steps:
1 In ready mode, press the Menu button ( ) on the control
panel until you see “Setup” on the bottom line of the
display.
2 Press the Enter button ( ) to access the menu.
3 Press the Enter button ( ) when “LCD Language” displays
on the bottom line of the display.
4 Press the scroll button ( or ) until the language you
want to use is displayed.
5 Press the Enter button ( ) to save the selection.
6 Press the On Line/Continue button ( ) to return to
ready mode.
