High Resolution WDR V/F Dome Camera SID-562 User Guide
ENGLISH

This installation should be made by a qualified service person and
should conform to all local codes.
The lightning flash with an arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the manufacturer
could void the user ’ s authority to operate the equipment.
WARNING - To prevent electric shock and risk of fire hazards:
◆Do NOT use power sources other than that specified.
◆Do NOT expose this appliance to rain or moisture.
Before operating the camera, confirm the camera model and proper input power
voltage. In order to that you can understand this manual thoroughly, we'll introduce our
model description.
n SID-562 SERIES
 •NTSCMODEL •PALMODEL
 SID-562(W)N SID-562(W)P
nMODEL DESCRIPTION
 •SID-562(W)X
_ _
 •SIGNALSYSTEM
  NNTSCMODEL
  PPALMODEL
 •CAMERACOLOR
SILVERCOLOR
  WIVORYCOLOR
SIGNALSYSTEM
CAMERACOLOR

COLOR DOME CAMERA User Guide
4
COLOR DOME CAMERA User Guide
5
Contents
Contents Features
Excellent Sensitivity
AdoptingaDiagonal6mm(1/3"),highlysensitive
CCDanddigitalsignalprocessingtechnology,itcan
clearly distinguish the outline and color of a
subject in an extremely low luminance
environment even, for example, under starlight.
Sincesurveillanceispossibleinplaceswherethe
light is poor, the camera is appropriate for day and
night surveillance outdoors or on the outside of
buildings.
Day & Night
The camera identifies whether it is day or night
and automatically switches to the appropriate
mode, depending on its environment. By day, the
camera switches to color mode in order to
maintainoptimalcolor.Atnight,itswitchestoB/W
mode so as to obtain better picture definition.
DIS (Digital Image Stabilizer)
TheDISfunctioncompensatesforanycamera
movement, to produce more stable pictures.
3-Axis camera mechanism
TheSID-562isespeciallyincrediblyflexibletoinstall
withits3-axiscameraconstruction,whichmakes
the camera wall or slope mountable.
Miscellaneous Functions
SENS-UP,FLIP(H/V-REV),D-ZOOM,SHARPNESS,
MOTIONDETECTIONandPRIVACYfunctionsare
provided.
RS-485 Communication
Control Support
RemoteOSDmenucontrolviaanRS-485interface
is supported.
OSD
The camera control is convenient by using 9
differentforeignlanguageO.S.D.
- NTSC:Korean,English,Spanish,Japanese,French,
Portuguese
- PAL:English,French,German,Spanish,Italian,
Chinese,Portuguese
Wide Dynamic Range (WDR):
ByadoptingaproprietarySV-IVDSPchip,the
camera delivers clear, high quality pictures even in
backlight, by increasing exposure in dark areas
while decreasing it in bright areas; a corrected
image with clear details results.
SSNR (Samsung Super Noise
Reduction) Function
ThehighperformanceSV-IVDSPchipdramatically
reduces the gain noise in digital image processing,
producing clear, sharp images in low lighting
environments.
Ultra High Resolution
Byadopting adouble-speed 410,000pixel(NTSC),
470,000(PAL)pixelSonyCCD,thecameraproduces
clear picture quality with a horizontal resolution of
560TVlinesforcolor,and700TVlinesforB/W.
• Precautions …………………………………………………………………… 7
• Components and Accessories …………………………………………… 9
• Overview ………………………………………………………………………… 9
• Installation ……………………………………………………………………… 10
nInstallation
 
nAdjustthepanningandtilting,rotatingwhilewatchingthemonitor   
• Connection ……………………………………………………………………… 13
nConnectingToMonitor
  

nConnectingToPower
 

nRS-485communicationcontrol
 
• Operating Your Camera ……………………………………………………… 15
nMenuConfiguration
 

nMenuSetup
  

•LENS
 

•EXPOSURE
 

•WHITEBALANCE
  

•BACKLIGHT
 

•SSNR
 

•DAY/NIGHT


•IMAGEADJ


•SPECIAL
 

•EXIT
 
• Troubleshooting ……………………………………………………………… 28
• Specification …………………………………………………………………… 29
• Dimension ……………………………………………………………………… 30

COLOR DOME CAMERA User Guide
6
COLOR DOME CAMERA User Guide
7
Do not install under extreme
temperature conditions.
Do not install in high humidity
environment.
The lens is the most important component of
the camera. Be careful not to smear it with
fingerprints.
Severe lighting changes or flickering may hinder
normal camera operation.
May lower image quality.Use only under temperature conditions between
-10ºC and +50ºC. Provide good ventilation when
using in high temperature conditions.
Avoid touching the camera lens.
Do not drop the camera or subject
it to physical shock.
May damage the CCD.May cause a product malfunction.
Never keep the camera face to
strong light directly.
Do not install under unstable
lighting conditions.
Warning/Attention/Special Mark Messages
SamsungTechwincaresfortheenvironmentatallproductmanufacturing
stages to preserve the environment, and is taking a number of steps to provide
customerswithmore environment-friendly products.The Eco markrepresents
SamsungTechwin’swilltocreateenvironment-friendlyproducts,andindicates
thattheproductsatisfiestheEURoHSDirective.
This information is provided to ensure your safety and to prevent any losses, financial or
otherwise.Pleasereaditcarefullyandusetheproductaccordingly.
 *Forproductinquiries,pleasecontacttheretailshopwhereyouboughtthecamera.Theuseofequipmentsuchasan
aerialladderwhileprovidingafter-salesserviceshallbeatyourexpense.
 *Separatethepowerplugwhenthundercrashesorlightingflashes.
 *Thisproductissupportequipmentforsurveillancesystem.Therefore,wecan'tcompensateformateriallossand/or
personal injuries by robbery, fire, natural disaster or something like this type.
Ignoring this information may
resultinmateriallossand/or
serious personal injuries including
death.
Indicates“NeverAllowed.”
Ignoring this information may
resultinmateriallossand/ora
slight injuries.
Indicates “NoDisassembling.”
Warnings & Cautions
Precautions

COLOR DOME CAMERA User Guide
8
COLOR DOME CAMERA User Guide
9
Do not expose the camera to
radioactivity.
If it is exposed to radioactivity, For heated CCD, it
will be out of order.
•Ifthecameraisexposedtospotlightorobjectreflecting stronglight,smearor
blooming may occur.
•Pleasecheckthat the powersatisfies the normalspecificationbefore connecting
the camera.
Notes
Precautions
❶ SID-562 2 Instruction Manual

3 M4 Tapping Screw 4EA
4 M4 Machine Screw 4EA

5 Adapter plate

6 Installation Video Output Cable

❶5
6
2
Components and Accessories
Overview
⓫
⓬
8 7 6
4
1
2
3
9❿
5
3 4

COLOR DOME CAMERA User Guide
10
COLOR DOME CAMERA User Guide
11
•Theinstallationshouldbedonebyqualifiedservicepersonnelorsysyteminstallers.
•Iftheceilingmaterialis notstrongenough toholdtheinstallationscrews,the
cameramayfalloff.Reinforcetheceilingasneeded.
Notes
Installation
1) Separate the dome cover by counterclockwise rotation.
2) Separate the shield case by pulling from the camera
body.
Latch
Lockingdirection
[Figure-1]
Unlockingdirection
(Counterclockwise)
* To install the dome cover on the camera body, turn the
latches in locking direction as shown in the figure 1.
Lockingdirection
(Clockwise)
MainBody
(Camera)
ShieldCase
Domecover
Overview
Installation
Installation
 Place the bracket provided on the installation
surface and fix it with the M4 tapping screws
(provided).
(Select either 85X85 or 83.5X46)
 When placing the camera body on the plate,
insert the plate pin into the mounting hole on
the body as shown in figure-1 and fix it by
turning clockwise.
 When placing the camera body on the plate,
make sure the power and the BNC cables
pass through their respective designated
holes.(When placing the cable through its
side, thread it through the hole at the
bottom.)
 After installation and adjustment of the
camera are complete, secure the dome cover
by turning it clockwise.
[Figure-1]
Locking
direction
Platepin
Unlockingdirection
•Pleaselocateanarrowonbracketforinstallingdirectionthatyouwishtoobserve
AreaandthenfixitwiththeM4tappingscrews.
Notes
Unlocking
direction
M4tapping
screw (provided)
Domecover
adapter plate
Anarrowforinstallingdirections
CAMERA
Locking
direction
When installing on a adapter plate
❶ Pan Base : control panning angle of camera
2 Rotate Base : control rotating angle of camera
3 X3.6 Vari-focal Lens Module
4 Rotate Base Holding Screw : fix rotated position
5 Pan Base Holding Screws (Color : Silver) : fix panned position
6 RS-485 Control Cable : The detailed description refers to p14
7 Power Input Jack 8 Video Output Jack
9 Function Setup switch :
Display the menu on the screen and move the cursor to four directions to confirm
status or after changing a selected item.
❿Video Output Terminal to Monitor
⓫Shield Case ⓬Dome Cover

COLOR DOME CAMERA User Guide
12
COLOR DOME CAMERA User Guide
13
Adjust the panning and tilting, rotating while watching the monitor
1) You can adjust camera to any direction by using Pan,Tilt, Rotate mechanism.
 •PanBasemovesby170˚toeachsidedirectionand340˚onthewhole.
 •TiltBasecoverstotal146˚angle(73˚toeachside).
 •AnglerangeofRotateBaseisthesameasthatofPanBase.Butonesiderangeis195˚
andanotheris145˚
2) Methods of adjustment
•Thecaseofwallinstallation
1 Aftermountingthecameraonawall,adjustingthepanninganglesothatthecameracan
face the direction to monitor when tilting.
2 Andthenadjustthetiltinganglebyrotatingthetiltbase.
3 Loosentherotatebaseholdscrewandadjustrotatebaseforthebestmonitoring.
4 Tighten the rotate base hold screw.
•Thecaseofceilinginstallation
1 Aftermountingthecameraonaceiling,adjustingthepanningangleforbettermonitoring
area by rotating the pan base.
2 Andthenadjustthetiltinganglebyrotatingthetiltbase.
3 Loosentherotatebaseholdscrewandadjustrotatebaseforthebestmonitoring.
4 Tighten the rotate base hold screw.
73˚
-170˚
145˚ 195˚
170˚
Pan Base
Tilt Base
Rotate Base
Connect the adaptor to the power input connector as shown in the figure below. The
recommended adaptor specification for SID-562N/SID-562P is AC 24V / 300mA or DC 12V /
500mA.
Connect the VIDEO-OUT jack to the VIDEO-IN jack of monitor.
• As the connecting method varies with the instruments, refer to the manual supplied with the
instrument.
• If necessary, you can connect the monitor to the REMOTE jack on the back of your camera.
• Only connect the cable when the power is turned off.
• Set the 75Ω / Hi-Z selection switch as shown below if you have an intermediate device.
CCTVCamera
Intermediate End monitor
CCTVCamera Monitor
Connecting to Power
Installation Connection
Connecting to Monitor

COLOR DOME CAMERA User Guide
14
COLOR DOME CAMERA User Guide
15
• As shown in the table above, voltage decreases as the wire gets longer. Therefore use of
an excessively long adaptor output line for connection to the camera may affect the
performance of the camera.
*Standard voltage for camera operation :AC 24V ±10% or DC 12V ±10%
*There may be some deviation in voltage drop depending on the type of wire and the manufacturer.
When the resistance value of copper wire is at [20˚C(68˚F)]
RS-485 communication control
Using a RS-485 communication, it will be able to control the OSD menu at the SAMSUNG
TECHWIN System Controller or DVR.
(1) The case which it controls from the PC
Using a RS-485 converter, It connects to RS-485 control cable outside camera and serial cable
EX)SERIALPORTOFTHEPC(COM1) → SERIALCABLE → RS-485CONVERTER → RS-485CONTROLCABLE
(2) The case which it controls from the DVR or System Controller
It connects the RS-485 control cable in the connection terminal of 485 control boards which
are connected with the DVR or System Controller.
Copper wire size (AWG) #24(0.22mm2)#22(0.33mm2)#20(0.52mm2)#18(0.83mm2)
Resistance (Ω/m) 0.078 0.050 0.030 0.018
Voltage Drop (V/m) 0.028 0.018 0.011 0.006
485 Control Board Connection Port RS-485 Control Port
(+) CONNECTION TERMINAL RED (TRX+)
(- ) CONNECTION TERMINAL WHITE (TRX-)
CONTROL CABLE SPEC
RED (TRX+) RS-485+
WHITE(TRX-) RS-485-
* RS-485 Communication establishment initial value
Menu Configuration
Item Camera ID BAUD RATE UART MODE PET PKT
Initial value 19600 8-NONE-1 ENABLE
Setup Menu
LENS
 DC
EXPOSURE
 SHUTTER  AGC  SENS-UP
 RETURN
WHITE BALANCE
 ATW  MANUAL  AWC → SET
 OUTDOOR  INDOOR
BACKLIGHT

OFF

WDR

BLC

HLC
SSNR

ON

OFF
DAY/NIGHT

COLOR

B/W

AUTO
IMAGE ADJUSTMENT
(IMAGE ADJ.)
 V-REV  H-REV  D-ZOOM
 SHARPNESS  RETURN
SPECIAL
 CAMTITLE  SYNC  MOTION DET
 PRIVACY  DIS  COMM ADJ
 LANGUAGE  RESET  RETURN
EXIT
•Besuretoconnectpoweronlyafteralltheinstallationiscomplete.
•NotethatAC/DCadaptorisnotsuppliedwithcamera.
•GroundshouldbeconnectedtotheGNDterminal.
•UsetheULlisted,class2powertransformerofAC24Vadaptor.
Notes
Operating Your Camera
Connecting to RS-485 Control Cable
•Whenyouconstructexternalcontrolsystemsforacameracontrol,pleaseusetotheSAMSUNG
TECHWINPROTOCOLorPELCO-DPROTOCOL.
•WhenyouconnectingtoRS-485controlcable,pleasepeelofftheouterskininsidetheRS-485
control cable.
•IncaseofSCC-101connection,changecommunicationmodeto8-E-1at Communication
configurationmenu.(Formoreinformation,refertoSCC-101manual.)
Notes
Connection
Use the Function Setup switch on the main body of the camera.
Menu Setup
FunctionSetupswitch

COLOR DOME CAMERA User Guide
16
COLOR DOME CAMERA User Guide
17
1. Press the Function Setup switch.
• Main setup menu is displayed on the monitor screen.
2. Select a desired function using the Function Setup switch.
• Place the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4.To finish the setting, select ‘EXIT’ and press the Function Setup switch.
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
9.EXIT
Selectthefunctionby
moving up or down direction
of function setup switch.
Changethestatusby
moving right or left direction
of function setup switch.
DC : Select Auto Iris Lens
• When DC is selected, you can control screen
brightness. The range of brightness control is
between 1 and 70. Adjust the brightness
appropriately for optimal screen brightness.
1.When the SETUP menu screen is displayed, select
’EXPOSURE‘ by using the Function Setup switch so that
the arrow indicates ’EXPOSURE‘.
2. Select a desired mode using the Function Setup switch.
•Anitemwiththe icon also has sub menus. To select a sub menu, select an item with the icon
andpresstheFunctionSetupswitch.
•Anitemwiththe---iconisunavailableduetofunctionsettings.
Notes
Operating Your Camera
EXPOSURE
Using this function, you can control screen brightness.
1.When the SETUP menu screen is displayed, select ’LENS‘ by using the Function Setup
switch so that the arrow indicates ’LENS‘ .
SHUTTER : Because of using built-in dc lens, shutter speed is fixed at 1/60(PAL:1/50)
basically.
- A.FLK : Select this when you experience picture flicker, which can happen when
there is a clash with the frequency of the installed lighting.
LENS
MAIN SETUP
1.LENS DC
2.EXPOSURE
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
•To producebetter resultswithA.FLK,do notuseit inconjunctionwith theWDR
modeoftheBACKLIGHTmenu.
Notes
AGC (AUTO GAIN CONTROL) :
The higher the gain level, the brighter the screen - but the higher the noise.
  -OFF:DeactivatestheAGCfunction.
  -LOW:Allowsautomaticgaincontrolfrom5.3dBto30dB.
  -HIGH:Allowsautomaticgaincontrolfrom5.3dBto42dB.

COLOR DOME CAMERA User Guide
18
COLOR DOME CAMERA User Guide
19
RETURN :
Select this to save the changes in the EXPOSURE menu and return to the SETUP menu.
SENS-UP :
When it is night or dark, the camera automatically detects the light level and
maintains a clear picture if this mode is activated.
  -OFF:DeactivatestheSENS-UPfunction.
  -AUTO:ActivatestheSENS-UPfunction.
Select one of the following 5 modes, as appropriate for your purpose.
ATW : Select this when the color temperature is between 1,800ºK and 10,500ºK.
INDOOR :
Select this when the color temperature is between 4,500 ºK and 8,500 ºK .
OUTDOOR : Select this when the color temperature is between 1,800ºK and
10,500ºK. (sodium light inclusion)
AWC SET : To find the optimal setting for the current luminance environment in this mode,
set the point the camera towards a sheet of white paper and press the
Function Setup switch. If the environment changes, readjust it.
MANUAL : Select this to fine-tune White Balance
manually. Set White Balance first by using the
ATW or AWC mode. After that switch to
MANUAL mode, fine-tune the White Balance
and then press the Function Setup switch.
Operating Your Camera
•IfyoupresstheFunctionSetupswitchin‘AUTO’mode,Youcanadjustbrightnessby
increasingordecreasingtheshutterspeed.(x2~x256)
•Notethatthehigherthezoomlevel,thebrighterthescreen,butthemorelikelyitis
thatanafter-imagewillappear.
•AlthoughNoise, Spots,andWhitishsymptomsmay occurinSENS-UP operation
when the zoom level is increased, this is normal.
Notes
Use the White Balance function to adjust the screen color.
1.When the SETUP menu screen is displayed, select ’White Bal.‘ by using the Function
Setup switch so that the arrow indicates ’White Bal.‘ .
2. Select a desired mode using the Function Setup switch.
White Balance (White Bal.)
•WhiteBalancemaynotworkproperlyunderthefollowingconditions.InthiscaseselecttheAWC
mode.
1
Whenthecolortemperatureofenvironmentsurroundingthesubjectisoutofthecontrolrange
(e.g. clear sky, or sunset)
2
Whentheambientilluminationofthesubjectisdim.
3
If the camera is directed towards a fluorescent light or is installed in a place where illumination
changesdramatically,theWhiteBalanceoperationmaybecomeunstable.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
This camera is designed so that it delivers a distinctive subject and background at the
same time, even when the subject is in backlight, unlike conventional cameras, by
adopting a proprietary SV-IV DSP chip.
1.When the SETUP menu screen is displayed,
select ‘BACKLIGHT’ by using the Function
Setup switch so that the arrow indicates
‘BACKLIGHT‘.
2. Select a desired mode using the Function
Setup switch depending on the camera
purpose .
BACKLIGHT
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON

COLOR DOME CAMERA User Guide
20
COLOR DOME CAMERA User Guide
21
Operating Your Camera
OFF : Not being used.
3. Select a desired mode using the Function Setup switch and press the switch.
WDR OFF
• Select ‘WDR’to adjust the WDR LIMIT and LEVEL.
HLC(High Light Compensation) :
If the scene contains extremely bright light areas such as;
from car headlight, the light can mask out much of the
on-screen detail.
- DAY : In normal daylight conditions, the HLC is not
activated.
- NIGHT : lf a high light that is larger than a certain size is present on the screen,
HLC is activated to remove the high light.
- HLC : Enable a user to select a mask color of high light area from a picture.
- LIMIT :Adjust the WDR sensitivity by selecting LOW,
MIDDLE, or HIGH.
- LEVEL :Adjust the WDR brightness by controlling the
bar from 1 to 100.
• The WDR compensates for backlight more effectively than previous models, by
applying an optimum fusion ratio when combining the high speed shutter used in
bright areas and the low speed shutter used in dark areas.
•Sincethe followingsymptoms may occuraccording tothe ambientilluminationwhen
WDRisselected,setittoOFF.
❶Colororscreenchangesunnaturally.
2Noiseappearsinthebrightpartofthescreen.
•SincetheperformanceoftheWDRfunctionmaybeaffectedbytheareaofthebrightpart
ofthescreen,optimizetheinstallationangleforthebestWDRperformance.
•IfyouincreaseLIMIT,theimagemaybedistorted.
•In adark environment,the HLCis onlyactivated whena highlight thatis largerthana
certain area is present.
•TheHLCisnotactivatedinlightoroverlydarkconditions.
• Ifthe Color Rolling symptomis occurred whileusingWDRfunction, change syncmode to
L/L (FormoreinformationaboutSYNCfunction,refertopage25.)
Notes
BLC : Enables a user to directly select a desired area from a
picture, and to view the area more clearly.
• Select ‘BLC’to adjust the area to be enhanced and
enhancement level.
WDR :When there are both bright and dark areas at the
same time, this mode makes both areas distinctive.
Operating Your Camera
2. Select a desired mode using the Function Setup switch.
OFF : Deactivates SSNR so that noise is not reduced.
ON :Activates SSNR so that noise is reduced.
3. Set the SSNR mode to ’ON‘ and press the Function Setup
switch.Then you can adjust the noise reduction level.
This function reduces the background noise in a low luminance environment.
1.When the SETUP menu screen is displayed, select ’SSNR‘ by using the Function
Setup switch so that the arrow indicates ’SSNR‘.
SSNR
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
•YoucannotsettheSSNRto‘ON’or‘OFF’whentheAGCmodeoftheEXPOSURE
menuis‘OFF’.
• WhenadjustingthenoisereductionleveloftheSSNRmode,rememberthatthehigherthe
level set, the more the noise level will be reduced but that after image may also occur.
Notes

COLOR DOME CAMERA User Guide
22
COLOR DOME CAMERA User Guide
23
COLOR :The picture is always displayed in color.
B/W :The picture is always displayed in black and white.
Please press Function Setup switch to turn on or off
the burst signal on B/W mode.
AUTO :The mode is switched to ‘Color’in a normal
environment, but switches to ‘B/W’mode when
ambient illumination is low. To set up the switching
time or speed for AUTO mode, press the Function
Setup switch.
- DWELL TIME : You can select the duration time about
changing the day/night mode.
5s, 7s, 10s, 15s, 20s, 30s, 40s, 60s
You can display pictures in color or black and white.
1. When the SETUP menu screen is displayed, select ‘DAY/NIGHT’ by using the
Function Setup switch so that the arrow indicates ’DAY/NIGHT‘.
DAY/NIGHT
Operating Your Camera
• YoucannotcontroltheDAY/NIGHTmenuwhenAGCintheEXPOSUREmenuis‘OFF’.
Atthistime,theexchangebetweenDAYmodeandNIGHTmodeoperatesaslikeselecting‘COLOR’mode.
•The OSD keydoesnotworkfor 3secondswhenswitchingto ColororB/W,toensurestable
camera operation.
• The camera may focus less well under infrared illumination than under normal illumination.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
2. Select a desired mode using the Function Setup switch according to the picture display
you want.
IMAGE ADJ.
2. Select a desired mode using the Function
Setup switch.
1. When the SETUP menu screen is displayed,
select ‘IMAGE ADJ.’ by using the Function
Setup switch so that the arrow indicates
‘IMAGE ADJ.’
V-REV :You can flip the picture vertically on the screen.
H-REV : You can flip the picture horizontally on the screen.
D-ZOOM : You can use a digital zoom of x2 ~ x10.
SHARPNESS :
As you increase this value, the picture outline becomes
stronger and clearer. Adjust this value appropriately
depending on the sharpness of the picture.
PED LEVEL : Please use this menu item when using a
LCD monitor other than standard ones. You
can change PED LEVEL.
RETURN : Select this to save the settings for the IMAGE
ADJ. menu and to return to the SETUP menu.
•WhentheV-REVorH-REVmodeisenabled,thetextonthescreendoesnotflip.
•IfyouincreasetheSHARPNESSleveltoohigh,thepicturemaybecomedistortedor
noise may appear.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
IMAGE SETUP
1. V-REV OFF
2. H-REV OFF
3. D-ZOOM OFF
4. SHARPNESS ON
5. PED LEVEL 0
6. RETURN

COLOR DOME CAMERA User Guide
24
COLOR DOME CAMERA User Guide
25
Operating Your Camera
1.When the SETUP menu screen is displayed, select ’SPECIAL‘ by using the Function
Setup switch so that the arrow indicates ’SPECIAL‘.
SPECIAL
2. Select a desired mode using the Function Setup switch.
CAM TITLE : If you enter a title, the title will appear on the monitor.
 
If the SPECIAL menu screen is displayed, use the Function Setup switch so
that the arrow indicates ’CAM TITLE‘.
Set it to ’ON‘ by using the Function Setup switch.
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
9.EXIT
SPECIAL
1. CAM TITLE OFF
2. SYNC INT
3. MOTION DET OFF
4. PRIVACY OFF
5. DIS OFF
6. COMM ADJ
7. LANGUAGE ENGLISH
8. RESET
9. RETURN
•IfyoumovethecursortoCLRandpresstheFunctionSetupswitch,alltheletters
are deleted. To edit a letter, change the cursor to the bottom left arrow and press
theFunctionSetupswitch.Movethecursoroverthelettertobeedited,movethe
cursortothelettertobeinsertedandthenpresstheFunctionSetupswitch.
Notes
 
Press the Function Setup switch.
•WhentheCAMTITLEmenuis‘OFF’,notitle
will be displayed on the monitor screen
even if you enter one.
•OnlyEnglishisavailableinthismode.
 
Use the Function Setup switch to move
to a desired letter and select the letter
by pressing the Function Setup switch.
Repeat this to enter multiple letters.
You can enter up to 15 letters.
 
Enter a title, move the cursor to ‘POS’ and press the
Function Setup switch. The entered title appears on
the screen. Select the position to display the title on
the screen by using the Function Setup switch and
press the Function Setup switch. When the position is
determined, select ‘END’ and press the Function
Setup switch to return to the SPECIAL menu.
FRONT DOOR
SPECIAL
1. CAM TITLE OFF
2. SYNC INT
3. MOTION DET OFF
4. PRIVACY OFF
CAMERA TITLE SETUP
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcdefghijklm
nopqrstuvwxyz
-.0123456789
CLR POS END
Notes
SYNC: In areas where the AC power is at 60Hz, you can
sync hronize the output phase of multiple cameras
using the power synchronization function (Line-Lock)
without using a synchronization signal generator.
 -INT:InternalSynchronizationType
 -L/L:PowerSynchronizationType,Line-Iock
 •PresstheFunctionSetupswitch.
 •Youcanselectadesiredphasefrom0to359whenselect'phase.'
 • Youcandecidethesynchronizationbetweenluminanceandcolorsignalwhenselectthe
'Mode'toTRACE.

COLOR DOME CAMERA User Guide
26
COLOR DOME CAMERA User Guide
27
Operating Your Camera
• MDareasshowonlyMOTIONDETmenu.Therefore,MDareasdon’tdisplayonthe
monitor screen.
• Whenmotionisdetected,“MOTIONDETECTION”expressionisdisplayedonthescreen.
Notes
• WhenusingACpowerat60Hz(PAL:50Hz)frequency,youcanusetheL/Ltypesynchronization.
• WhenthepowerisDC12V,theSYNCmenuisfixedtothe'INT'mode.
Notes
PRIVACY : Hide an area you want to hide on the screen.
  
When the SPECIAL menu screen is displayed, using
the Function Setup switch so that the arrow
indicates ‘PRIVACY’.
  
Set up the mode using the Function Setup switch.
MOTION DET :You can monitor activity more efficiently,
because a signal is generated by the camera
whenever motion is detected.
 
When the SPECIAL menu screen is displayed, press the Function
Setup switch so that the arrow indicates ’MOTION DET‘.
  
Set up the mode using the Function Setup switch.
  -SENSITIVITY: Youcanselectupto8MDareas.WhenSENSITIVITYnumberishigh,motion
detection sensitivityisincreasedtorecognizeevensmallmovement.
  -AREAMODE:DetermineswhethertousetheMDareaselectedinSENSITIVITY.
  -SELPOS:Determineswhichofthe4verticesofeachMDareaistobeused.
  -YPOS:DeterminesthecoordinateoftheverticalaxisforSELPOS.
  -XPOS:DeterminesthecoordinateofthehorizontalaxisforSELPOS.
- FILL SET: Fills in a selected MD area. The color of filling is sequentially selected as brown,
orange, blue, cyan, yellowish green, yellow, magenta and red.
  -RETURN:SelectthistosavetheMOTIONDETmenusettingsandreturntotheSPECIALmenu.
 -AREASEL:Youcanselectupto8PRIVACYareas.
 -AREAMODE:Determineswhethertousethearea
selectedintheAREASEL,andthesizeand
position of the area.
- MASKCOLOR:Determineareacolor.YoucanselectGray,
Green,Red,Blue,Black,White.
• ThechanceofresolutiondecreaseisexistedbecauseDISfunctionusesthedigitalzoom.
• DISdoesn’toperatewhenbackgroundilluminationistoolow.
• DISdoesn’toperatewhenobjectpatternismonotonicaslikeskyorwhitewall.
•IfDISisenabled,thedigitalzoomisnotconfiguredtolessthan46level.
Notes
COMM ADJ (Communication Adjustment):
This function sets up the camera communication
status when controlling the camera through an
external control device.
  
When the SPECIAL menu screen is displayed,
press the Function Setup switch so that the arrow
indicates ‘COMM ADJ’.
  
Set up the mode using the Function Setup switch.
  -CAMID:Determinesthecamera'sidentificationnumber(between0and255).
  -BAUDRATE:Youcanselect2400/4800/9600/19200/38400/57600bps.
  -UARTMODE:YoucanselectNONE,EVENorODDfortheparitybits.
  -RETPKT:Determineswhetherto sendacommandback tothecontrollerdevice
when a communication control command is sent to the camera.
  -DISPCAMID:Displaycameratitleontopleftcornerofthescreen.
Press the Function Setup switch in the EXIT menu to save the current settings and exit the
MAIN SETUP menu.
LANGUAGE :You can select the menu language according to your
requirements.
RESET : Resets the camera settings to the factory defaults.
RETURN :
Select this to save the SPECIAL menu settings and return to the MAIN SETUP
menu.
EXIT
 -TRANSP:Determinethetransparencyofselected area as
controllingnumberfrom0to3.
 -RETURN:SelectthistosavethePRIVACYmenu
settingsandreturntotheSPECIALmenu.
DIS (Digital Image Stabilizer) :
This function mitigates any picture movement due to external factors such as wind.

COLOR DOME CAMERA User Guide
28
COLOR DOME CAMERA User Guide
29
SID-562(W)N SID-562(W)P
ELECTRICAL
Input Voltage AC 24V / DC 12V
Power Consumption Max 3.5W
VIDEO
Imaging Device Diagonal 6mm (1/3") Sony DS CCD
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Effective Pixels 768(H) x 494(V) 752(H) x 582(V)
Scanning System 2:1 Interlace
Synchronization Internal / Line Lock
Frequency H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50.00Hz
Horizontal Resolution Color : 560TV lines (Min.) / B/W : 700TV lines (Min.)
Min. Illumination Color : 0.3Lux (50 IRE @F1.2), 0.001Lux (SENS-UP x256)
S/N (Y Signal) 52dB
Video Output CVBS : 1.0Vp-p / 75Ω
LENS
Zoom Ratio 3.6x (Manual)
Focal length 2.8 ~ 10.0mm (F1.2)
Min. Objecy Distance 1:1.2(Wide) ~ 2.8(Tele)
PAN / TILT / ROTATE
Pan / Tilt / Rotate Range 0° ~ 340° / 0° ~ 146° / 0° ~ 340°
OPERATIONAL
Electronic Shutter Speed ESC (1/60 ~ 1/120,000sec) / Manual / A.FLK ESC (1/50 ~ 1/120,000sec) / Manual / A.FLK
On Screen Display NTSC : Korean, English, Spanish, Japanese, French, Portuguese
PAL : English, French, German, Spanish, Italian, Chinese, Portuguese
Backlight Compensation WDR(52dB) / BLC / HLC / Off
Day & Night COLOR / B/W / AUTO (Electrical)
Gain Control Low / High / Off
White Balance ATW /AWC / Manual / Indoor / Outdoor
SENS-UP (frame Integration) Auto / Off (Selectable limit x2~ x256)
Motion Detection On / Off (8 Programmable zones)
Privacy Masking On / Off (8 Programmable zones)
3D Noise Filter (SSNRII) On / Off (1 ~ 32 Level)
Digital Zoom On / Off (x2 ~ x10)
Digital Image Stabilization(DIS) On / Off
Sharpness On / Off
Camera Title On / Off
Flip / Mirror On / Off
Communication RS-485 (Baudrate 2400, 4800, 9600, 19200, 38400, 57600 bps Selectable)
Protocol Samsung Techwin protocol, Pelco-D protocol
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +50°C / 20% ~ 80% RH
MECHANICAL
Dimension / Weight Ø141.2 x 105.5mm / 545g
※SID-562WN, SID-562WP : Ivory color base model
Refer to the following table if you are experiencing trouble with your camera.
Contact an authorized technician if the table does not provide you with a
solution to the trouble.
* RS-485 Communication establishment initial value
Item Camera ID BAUD RATE UART MODE RET PKT
Initial value 19600 8-NONE-1 ENABLE
485 Control Board Connection Port RS-485 Control Port
(+) CONNECTION TERMINAL (TRX+) 485+
( -) CONNECTION TERMINAL (TRX-) 485-
●
Nothing appears on the screen.
▶ Check that the power cord and line connection between the camera and monitor are fixed properly.
▶ CheckthatyouhaveproperlyconnectedVIDEOcabletothecameraVIDEOoutputjack.
● The image on the screen is dim.
▶ Is lens stained with dirt? Clean your lens with soft, clean cloth.
▶ SetthemonitororDVRtopropercondition.
▶ If the camera is exposed to too strong light, change the camera position.
● The image on the screen is dark.
▶ AdjustthecontrastfeatureofthemonitororDVR.
▶ Ifyouhaveanintermediatedevice,setthe75Ω/Hi-zproperly.
● The camera is not working properly, and the surface of the camera is hot.
▶ Check that you have properly connected the camera to an appropriate power source.
● The DAY/NIGHT menu does not work.
▶ CheckthatAGCofEXPOSURESETUPmenuis‘OFF’.
● The SENS-UP function does not work.
▶ CheckthatAGCofEXPOSURESETUPmenuis‘OFF’.
▶ CheckthatSHUTTERofEXPOSURESETUPmenuis'A.FLK'.
● The Motion Detection function does not work.
▶ CheckthatMOTIONDETofSPECIALSETUPmenuis‘OFF’.
● Color is not correct.
▶ CheckthesettingofWHITEBALSETUPmenu.
● The screen flickers continually.
▶ Check that direction of camera turns toward the Sun.
● RS-485 communication fails.
▶ CheckthepolaritybetweenRS-485ControlPortandRS-485cable.
▶ ChecktheRS-485Communicationestablishmentinitialvalue
▶ We recommendthat you makeground connect betweencamera andcontroller inorder to maintain
safety communication control.
Troubleshooting
Specifications

COLOR DOME CAMERA User Guide
30
COLOR DOME CAMERA User Guide
31
DECLARATION OF CONFORMITY
ApplicationofCouncilDirective(s) 89/336/EEC
Manufacturer'sName SAMSUNGTECHWINCO.,LTD
Manufacturer'sAddress SAMSUNGTECHWINCO.,LTD
 42,SUNGJU-DONGCHANGWON-CITY,
 KYUNGNAM,KOREA,641-716
EuropeanRepresentativeName
EuropeanRepresentativeAddress
EquipmentType/Environment CCTVCamera
ModelName SID-562P/WP
BeginningSerialNO. S8110001
YearofManufacture 2008.12.01
Conformanceto EN50081-1:1992
 EMC-Directive89/336EECand92/31/EEC
 EN50130-4:1996
We,the undersigned,herebydeclarethat the equipmentspecifiedaboveconforms
totheaboveDirective(s).
Manufacturer SAMSUNGTECHWINCO.,LTD LegalRepresentativeinEurope
Signature  Signature
FullName BONJENGGU FullName
Position QUALITYCONTROLMANAGER Position
Place CHANGWON,KOREA Place
Date 2008.12.01 Date
Ø141.2
R48
108mm
105.5mm
Dimension

P/No. : Z6806-0899-01D
VAN 09. 10
www.samsungtechwin.com
www.samsungcctv.com
•SAMSUNG TECHWIN CO., LTD.
145-3, Sangdaewon 1-dong, Jungwon-gu, Seongnam-si Gyeonggi-do, Korea, 462-703
TEL : [phone]~8 FAX : [phone]
•SAMSUNG TECHWIN EUROPE CO., LTD.
Samsung House, 1000 Hillswood Drive, Hillswood Business
Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS
TEL : [phone] FAX : [phone]
•SAMSUNG TECHWIN AMERICA Inc.
1480 Charles Willard St, Carson, CA 90746, UNITED STATES
Tol Free : [phone] FAX : [phone]
www.samsungcctvusa.com
SALES NETWORK
