Samsung GT-I8910 User manual

GSM TELEPHONE
GT-i8910
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions
GSM TELEPHONE CONTENTS

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
●Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test, because the specification of cellular phone is sensitive for
surrounding interference(RF noise).
●Be careful to use akind of magnetic object or tool, because performance of parts is damaged by the
influence of magnetic force.
●Surely use astandard screwdriver when you disassemble this product, otherwise screw will be worn
away.
●Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
●Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
●Take specially care of soldering, because Land of PCB is small and weak in heat.
●Surely tune on/off while using AC power plug, because arepair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembling charger.
●Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
●Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
●Use earthed soldering steel when you connect or disconnect ESD.
●Use soldering removing tool to break static electricity. ,otherwise ESD will be damaged by
static electricity.
●Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
●You must maintain electric contact between ESD and place due to be set up until ESD is connected
completely to the proper place or acircuit board.

SAMSUNG Proprietary-Contents may change without notice
2. Specification
This Document can not be used without Samsung's authorization
2-1
EGSM 900 DCS 1800 PCS 1900 WCDMA 900 WCDMA 2100 W1900
Freq.
Band[MHz]
Uplink/Downlink
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
824~849
869~894
1920~1980
2110~2170
1850~1910
1930~1990
ARFCN range 0~124 &
975~1023 512~885 512~810 UL:4132~4233 DL:4357~4458
UL:9612~9888
DL:10562~10838
UL9262~9538:
DL:9662~9938
Tx/Rx spacing 10MHz 20MHz 20MHz 45MH 190MHz 80MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
3.84Mcps
(chip rate)
3.84Mcps
(chip rate)
3.84Mcps
(chip rate)
Time Slot
Period/
Frame Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Frame length :
10ms
Slot length :
0.667ms
Frame length :
10ms
Slot length :
0.667ms
Frame length :
10ms
Slot length :
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HPSK
QPSK
HPSK
QPSK
HPSK
MS Power 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm 24dBm~-50dBm 24dBm~-50dBm 24dBm~-50dBm
Power Class 4
(max +33dBm)
1
(max +30dBm)
1
(max +30dBm)
3
(max +24dBm)
3
(max +24dBm)
3
(max +24dBm)
Sensitivity -102dBm -100dBm -100dBm -104.7dBm -106.7dBm -103.7dBm
TDMA Mux 888 - - -
Cell Radius 35Km 2Km 2Km 2Km 2Km 2Km
2-1. GSM General Specification

SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2-2
TX Power
control level PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level
GSM850
GSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3 dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM TX power class

SAMSUNG Proprietary-Contents may change without notice
3. Product Function
3-1
This Document can not be used without Samsung's authorization
Main Function
•HSUPA 5.76Mbps /HSDPA 7.2MBps /Quad(850/900/1800/1900) , UMTS (900/1900/2100)
•Bluetooth v2.0 +EDR
•Wi-Fi (802.11 b/g)
•USB v2.0 HS compatible
•8M
CMOS (AF, Power LED) +CIF
-Face Detection, Smile Detection, Eye Blink Detection, Panorama Shot, Mosaic Shot, OCR/BCR
•FM Radio Receiver
•A-GPS, S-GPS, GPS+, Navigation
•DivX Codec
•Accelerometer /Compass
•Instant Messaging capability
•E-mail
•Featured applications provide alarms, calendar, calculator, record audio, converter, timer, stopwatch,
and world time.
•File viewer (MS office, PDF)
•Multimedia Message Service (MMS)
•Multimedia capability (with included Media player)
•Photo caller ID
•Speakerphone capability
•WEB/WAP browser (HTMS, xHTML, WML)
•VT H.263 +ARM NB
•Movinand 8GB/16GB +microSD card
•3.7"
AMOLED

SAMSUNG Proprietary-Contents may change without notice
4. Array course control
4-1
This Document can not be used without Samsung's authorization
4-1. Software Adjustments
Test Cable (GH39-01160A)
Test Jig (GH99-36900A)
RF Test Cable (GH39-00985A) Adapter (GH99-38251A)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-2
This Document can not be used without Samsung's authorization
4-2. Software Download
4-2-1. Pre-requisite for Download
i. Symbian ROM Flashing Tool v.1.45 (Or the upper version)
ii. ACME USB Driver
①PDA :SSDN_V1.1.808.7165_SETUP_whql.exe
②MODEM(BASEBAND) :SAMSUNG Mobile USB DRIVER(4.40.7.0) v1.6.zip
iii. MS xml parser :Msxml.msi
iv. USB Cable
v. I8910 phone with almost fully charged battery(more than 3battery bars)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-3
This Document can not be used without Samsung's authorization
4-2-2. Concepts &cautions.
i. Binary is devided for 2images, PDA and Modem. PDA image consists of
CODE and CSC.
ii. Do Not power off the phone or disconnect the usb connection during
download.
iii. Use right version of Downloader tool written in Release Note.
iv. Version of CODE, CSC and Modem(BaseBand) should be matched correctly
according to ‘Release Note’when you download. If the combination is wrong,
phone may not work well.
v. When you download Modem(BaseBand) binary, after ‘Binary Downloading
100%’ is displayed in Progress Info box, ‘CP Flashing…‘message will be
displayed .After this message is flashing, ‘Download Complete!’message
will be shown up.
Detach the phone after this complete
message.

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-4
This Document can not be used without Samsung's authorization
4-2-3. USB Driver installation
Execute SSDN_V1.1.808.7165_SETUP_whql.exe to setup PDA Driver
Unzip SAMSUNG Mobile USB DRIVER(4.40.7.0) v1.6.zip, setup Mdem Driver with setup.
exe
4-2-4 How to Downlaod
!!! Make sue CODE, CSC, MODEM(BASEBAND) mapping in ‘Release Note’, and then
download with the correct version. After download, press *#1234#and check CODE, CSC
and MODEM version. This is very important. !!!
i. CODE +CSC +MODEM(BASEBAND) Download(Full Release)
1. In myProject, download CODE, CSC and MODEM(BaseBand) binary.
2. Launch ‘Symbian Rom Flashing Tool’, press button to select
MODEM(BASEBAND) binary.
3. Press button to select CODE xml. (ex:CODE_I8910XXIB5.xml)
4. Press button to select CSC xml. (ex: CSC_I8910AUTIB5.xml)
5. Confirm CODE and CUSTOM version
6. Power on the phone with Hold +Side Volume Up Key pressed
(PDA DOWNLOAD mode)
7. When you connect phone to PC with USB, PDA is attached
8. Select the type of binary which you want to download in Multi-ROFS Option box.
9. Set the download option like this.
10. Press button to start download.

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-5
This Document can not be used without Samsung's authorization
11. After finishing downloading PDA, Modem is downloaded.
See in Progress Info box.
Do Not disconnect aUSB cable before ‘Download Complete!’message!!
ii. MODEM(BASEBAND) Download Only
1. Proceed from step ‘i.-1 to i-2’.
2. Turn on the device with Hold +Side Up Key pressed (PDA Download Mode)
3. Do step ‘i.-7’.
4. Check only MODEM box.
5. Press button to start download.
6. Wait until this message is displayed!!
iii. CODE +CSC Download Only
1. Unzip CODE and CSC binary.
2. Do step ‘i.3~i.7’.
3. Select the type of binary which you want to download in Multi-ROFS Option box.
4. Press button to start download.
5. Wait until this message is displayed!!
iv. CODE Download Only
1. Unzip CODE Release.

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-6
This Document can not be used without Samsung's authorization
2. Do step‘i.-3, i.-6, i.-7’.
3. Select the type of binary which you want to download in Multi-ROFS Option box.
4. Select any Country without Blackhole.(Example of selecting Country )
Wrong example of Country(BlackHole) )
5. Press button to start download.
v. CSC Download Only
1. Unzip CSC release.
2. Do step ‘i.4~i.7’.
3. Select the type of binary which you want to download in Multi-ROFS Option box.
4. Press button to start download.

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-7
This Document can not be used without Samsung's authorization
4-2-5. Troubleshooting
A. If the device is not attaced after the Driver installation,
i.Change USB cable and phone.
ii.Try with another PC.
B. Download stops in the middle
i. Close and launch Symbian Rom Flashing Tool again then try again.
ii. Check the phone is charged enough.
C. Download doesn’t start
i. Check the connection between Symbian Rom Flashing Tool and aphone.
ii. Select an image again.
iii. Check mapping of CODE, CSC and Modem is right.(See Mapping Table)
iv. CheckSymbian Rom Flashing Tool version matches with the image.
v. Check Bootloader version displayed on the phone screen. Start right steps
accordingtotheversion.
D. Phone doesn’t boot up after downloading
i. Check CODE, CSC and Modem version.

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-1
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View
QRE01
QCA01
QCA02
QMP01
QSH02
QAR01
QSP 01
QCR09
QCR60
QRE04
QRF03
QVO01
QCK02
QSD01
QCR97
QME01
QIF01
QAN02
QCK01
QFR01
QKP01
QMI03
QSP02
QCR60
QSH01
QSH03
QME07
QBA00
QMO01
QME03
QLC01

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC Design LOC SEC CODE
QAR01 AUDIO-RECEIVER 3009-001357
QBA00 ASSY COVER-BATT GH98-13202A
QCA01 CAMERA MODULE-GT-I8910 8M GH59-06979A
QCA02 ASSY CAMERA-GT-I8910 CIF GH96-03632A
QCR09 SCREW-MACHINE 6001-001670
QCR60 SCREW-MACHINE 6001-002005
QCR60 SCREW-MACHINE 6001-002005
QKP01 ASSY KEYPAD-(EU/SILVER) GH98-11648A
QLC01 ASSY LCD-MODULE ASSY(GT-I8910) GH96-03638A
QME03 TOUCH/PANEL-GT-I8910(EU) GH59-07251A
QME07 MODULE-FLASH LED MODULE (MIC) GH59-07043A
QMI03 RMO RUBBER-HOLDER MIC GH73-12919A
QMO01 MOTOR LINEAR VIBRATION-GT-I8910 GH31-00472A
QMP01 A/S ASSY-PBA MAIN GT-I8910 SVC(SWC) GH82-03619A
QRE04 ASSY DECO-REAR GH98-13068A
QSH01 ICT SHIELD-CAN AGH70-04831A
QSH02 ICT SHIELD-CAN BGH70-04832A
QSH03 ICT SHIELD-CAN CGH70-04833A
QSP01 MODULE-UPPER SPK ASSY(DSL) GH59-07097A
QSP02 MODULE-LOW SPK ASSY(DSL) GH59-07096A
QME01 KEY FPCB-3-DOME KEY FPCB(MIC) GH59-06995A
QRE01 ASSY CASE-REAR GH98-11647A
QAN02 INTENNA-GT_I8910(BT,WIFI) GH42-01919A
QFR01 ASSY CASE-FRONT GH98-11645A
QCR97 SCREW-MACHINE 6001-002262
QIF01 PMO COVER-IF GH72-52115A
QCK02 PMO KEY-HOLD GH72-52120A
QSD01 PMO COVER-MICRO_SD GH72-53778A
QRF03 PMO COVER-EAR V2 GH72-53779A
QVO01 ASSY KEY-VOLUME GH98-13022A
QCK01 ASSY KEY-CAMERA GH98-13023A
5-2. Cellular phone Parts list

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-1
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
0202-001602 R403 Short Pad
0202-001602 R527 Short Pad
0202-001602 R718 Short Pad
0202-001602 R991 Short Pad
0202-001602 R994 Short Pad
0403-001749 D402 Diode
0406-001223 ZD512 Diode
0406-001223 ZD513 Diode
0406-001254 ZD700 Diode
0406-001254 ZD701 Diode
0406-001254 ZD702 Diode
0406-001254 ZD703 Diode
0406-001254 ZD705 Diode
0406-001254 ZD706 Diode
0406-001254 ZD707 Diode
0406-001256 ZD301 Diode
0406-001256 ZD401 Diode
0406-001256 ZD402 Diode
0406-001329 ZD200 Diode
0406-001329 ZD201 Diode
0406-001329 ZD500 Diode
0406-001329 ZD501 Diode
0406-001329 ZD503 Diode
0406-001329 ZD504 Diode
0406-001329 ZD505 Diode
0406-001329 ZD506 Diode
0406-001329 ZD509 Diode
0406-001329 ZD510 Diode
0406-001329 ZD600 Diode
0406-001329 ZD602 Diode
0406-001329 ZD603 Diode
0406-001329 ZD604 Diode
0406-001329 C521 Diode
0406-001329 C595 Diode
0407-001002 D400 Diode
0407-001002 D401 Diode
0407-001007 U408 Diode

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
0504-001113 TR400 Transistor
0504-001113 TR401 Transistor
0504-001113 TR403 Transistor
0504-001113 TR404 Transistor
0505-001165 TR402 Transistor
0801-002321 U808 Logic IC
0801-003013 U302 Logic IC
0801-003016 U301 Logic IC
0801-003016 U405 Logic IC
0801-003016 U901 Logic IC
0801-003016 U903 Logic IC
0801-003052 U300 Logic IC
0801-003052 U902 Logic IC
0801-003079 U404 Logic IC
0801-003129 U407 Logic IC
0801-003200 U305 Logic IC
0902-002434 UCP900 Digital Signal Processor IC
1001-001336 U603 Logic IC
1001-001461 U607 Logic IC
1001-001476 U612 Logic IC
1001-001481 U609 Logic IC
1001-001483 U806 Logic IC
1001-001488 U617 Logic IC
1003-002047 U601 Logic IC
1003-002132 U807 Logic IC
1003-002216 U709 Analog Switch
1003-002216 U710 Analog Switch
1003-002216 U810 Analog Switch
1107-001827 UME900 Memory IC
1108-000248 UCP900UP MCP Memory
1108-000260 SIP300 MCP Memory
1201-002577 PAM102 Amplifier
1201-002581 LNA200 Amplifier
1201-002671 PAM100 Amplifier
1201-002733 U501 Amplifier
1201-002733 U502 Amplifier
1201-002781 PAM101 Amplifier

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
1202-001079 U613 Comparator
1202-001079 U614 Comparator
1203-003643 U705 Power Supply Circuit
1203-003643 U801 Power Supply Circuit
1203-003924 U403 Power Supply Circuit
1203-004607 U604 Power Supply Circuit
1203-004621 U503 Power Supply Circuit
1203-004776 U600 Power Supply Circuit
1203-004818 U800 Power Supply Circuit
1203-004978 U803 Power Supply Circuit
1203-005097 U401 Power Supply Circuit
1203-005250 U802 Power Supply Circuit
1203-005362 U805 Power Supply Circuit
1203-005373 U615 Power Supply Circuit
1203-005396 U906 Power Supply Circuit
1203-005443 U402 Power Supply Circuit
1203-005478 U804 Power Supply Circuit
1203-005485 U704 Power Supply Circuit
1203-005485 U750 Power Supply Circuit
1203-005503 U605 Power Supply Circuit
1204-002924 U200 IF/FM/AM Circuit IC
1205-003297 RFT100 Telecommunication Circuit
1205-003467 U304 Telecommunication Circuit
1205-003582 UCP300 Telecommunication Circuit
1209-001823 U608 Accelerator IC
1209-001872 U602 Compass IC
1404-001221 TH300 Thermistor
2007-000137 R306 R-CHIP
2007-000138 R330 R-CHIP
2007-000138 R331 R-CHIP
2007-000138 R332 R-CHIP
2007-000138 R335 R-CHIP
2007-000138 R415 R-CHIP
2007-000138 R450 R-CHIP
2007-000138 R626 R-CHIP
2007-000138 R628 R-CHIP
2007-000138 R630 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-4
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2007-000138 R631 R-CHIP
2007-000138 R633 R-CHIP
2007-000138 R801 R-CHIP
2007-000138 R906 R-CHIP
2007-000138 R908 R-CHIP
2007-000138 R909 R-CHIP
2007-000140 R610 R-CHIP
2007-000148 R205 R-CHIP
2007-000148 R301 R-CHIP
2007-000148 R303 R-CHIP
2007-000148 R304 R-CHIP
2007-000148 R305 R-CHIP
2007-000162 R319 R-CHIP
2007-000162 R401 R-CHIP
2007-000162 R416 R-CHIP
2007-000162 R603 R-CHIP
2007-000162 R608 R-CHIP
2007-000162 R609 R-CHIP
2007-000162 R613 R-CHIP
2007-000162 R701 R-CHIP
2007-000162 R714 R-CHIP
2007-000162 R750 R-CHIP
2007-000162 R809 R-CHIP
2007-000165 R400 R-CHIP
2007-000169 R621 R-CHIP
2007-000170 R312 R-CHIP
2007-000170 R433 R-CHIP
2007-000170 R602 R-CHIP
2007-000170 R612 R-CHIP
2007-000173 R618 R-CHIP
2007-000173 R619 R-CHIP
2007-000173 R931 R-CHIP
2007-000173 R992 R-CHIP
2007-001119 R414 R-CHIP
2007-001290 R325 R-CHIP
2007-001292 R300 R-CHIP
2007-001292 R320 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-5
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Description
2007-001292 R931 R-CHIP
2007-001292 R992 R-CHIP
2007-001298 R118 R-CHIP
2007-001298 R321 R-CHIP
2007-001303 R107 R-CHIP
2007-001303 R108 R-CHIP
2007-001313 R204 R-CHIP
2007-001339 R703 R-CHIP
2007-002970 R106 R-CHIP
2007-002970 R112 R-CHIP
2007-007014 R404 R-CHIP
2007-007014 R406 R-CHIP
2007-007014 R926 R-CHIP
2007-007107 R311 R-CHIP
2007-007107 R313 R-CHIP
2007-007137 R502 R-CHIP
2007-007137 R503 R-CHIP
2007-007137 R504 R-CHIP
2007-007137 R505 R-CHIP
2007-007137 R202 R-CHIP
2007-007137 R607 R-CHIP
2007-007193 R110 R-CHIP
2007-007193 R111 R-CHIP
2007-007306 R307 R-CHIP
2007-007306 R802 R-CHIP
2007-007306 R803 R-CHIP
2007-007309 R434 R-CHIP
2007-007310 R411 R-CHIP
2007-007316 R317 R-CHIP
2007-007317 R412 R-CHIP
2007-007317 R525 R-CHIP
2007-007317 R526 R-CHIP
2007-007317 R900 R-CHIP
2007-007317 R901 R-CHIP
2007-007317 R929 R-CHIP
2007-007317 R930 R-CHIP
2007-007468 R402 R-CHIP
