Samsung SGH-Z220 User manual

* Depending on the software installed or your service provider or country, some of the descriptions
in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the
illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 12/2005. Drf. 1.0.

SGH-Z220
User’s Guide
Draft
2005.12.23
(Version:Z220XAEL2)

Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving.
Park the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference.
Using them in an aircraft is both illegal and
dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be
using equipment that could be sensitive to
external radio frequency energy. Follow any
regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.

1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 77.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.

2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
 Indicates that you can get more
information on the referenced page.
→ Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[
] Indicates a key on the phone. For
example, []
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, < Msg . >
• 3G
Your phone is capable of operating
in a 3G environment, allowing
much greater data transfer speed,
video streaming, and video
conferencing.
Special features of your phone
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
• Media player
Play media files on your phone. You
can enjoy high quality videos and
music.
•Webbrowser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.

3
Special features of your phone
• Bluetooth
Send photos, images, videos, and
other personal data, and connect to
other devices using free, wireless
Bluetooth technology.
• Contacts
Store home, office, or cellular
phone numbers for your contacts.
•
Get personal with photo caller
ID
See who’s calling you with their
very own photo displays.
•
Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
•
Multimedia Message Service (MMS)
Deliver MMS messages with a combination of
text, images, and audio.
•E-mail
Deliver e-mails with image, video, and audio
attachments.
•
Java
Enjoy Java ™ -based embedded
games and download new games.
•
Organiser
Keep track of your daily, weekly,
and monthly schedule.
• Alarm
Use your phone as an alarm clock
to wake you up in the morning or
notify you of an impending event.
•
Voice recorder
Record memos or sounds.

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone.............................. 7
Power on or off ................................................ 8
Keys and display .............................................. 9
Access menu functions.................................... 11
Customise your phone..................................... 12
Make/Answer calls.......................................... 14
Step outside the phone 15
Begin with your camera, the media player, the web, and
other special features
Use the camera.............................................. 15
Play media files.............................................. 16
Browse the web.............................................. 17
Use Contacts ................................................. 18
Send messages.............................................. 19
View messages .............................................. 21
Use Bluetooth................................................ 21
Switch applications......................................... 22
Enter text 23
ABC, T9, Number, and Symbol mode
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 76
Help and personal needs
Health and safety information 77
Index 93

5
1 Call log  p. 29
1 Missed calls
2 Dialled calls
3 Received calls
4 Current contacts
5 Delete all
6 Data calls
7 Calls cost
*
8 Calls time
 p. 29
 p. 29
 p. 29
 p. 29
 p. 30
 p. 30
 p. 30
 p. 30
2 Contacts  p. 31
1 Search contact
2 New contact
3 Groups
4 Speed dial
5 My name card
6 Copy all
7 Own number
8 Service number
*
9 Settings
0 Memory status
 p. 31
 p. 31
 p. 32
 p. 33
 p. 33
 p. 34
 p. 34
 p. 34
 p. 34
 p. 34
3 Applications  p. 34
1 SAT *
2 Media player
3 Voice memo
4 World clock
5 Calculator
6 Converter
 p. 34
 p. 35
 p. 36
 p. 37
 p. 38
 p. 38
4 Internet  p. 39
1 Go to homepage
2 Enter URL
3 Favourites
4 History
5 Browser settings
6 Network settings
 p. 39
 p. 40
 p. 40
 p. 40
 p. 40
 p. 41
5 Messages  p. 41
1 Create new
2 Inbox
3 Drafts
4 Outbox
5 Sent box
6 Email inbox
7 Templates
8 Broadcast
9 Delete all
0 Settings
Memory status
 p. 41
 p. 43
 p. 44
 p. 45
 p. 45
 p. 45
 p. 46
 p. 47
 p. 48
 p. 48
 p. 52
6 File manager  p. 52
Images
Videos
Music
Sounds
Games & More
Other files
 p. 53
 p. 54
 p. 55
 p. 56
 p. 57
 p. 57
7 Organiser  p. 58
1 Alarm
2 Calendar
3 Week view
4 Today’s events
5 Schedule
6 Anniversary
7 Task
8 Memo
9 Missed event alarm
0 Memory status
 p. 58
 p. 58
 p. 60
 p. 60
 p. 60
 p. 60
 p. 61
 p. 61
 p. 61
 p. 61
8 Camera  p. 61
9 Settings  p. 65
1 Profiles
2 Time & date
3 Phone
4 Display
5 Call
6 Connectivity
7 Application settings
8 Security
9 Memory status
0 Reset settings
 p. 65
 p. 66
 p. 67
 p. 67
 p. 68
 p. 70
 p. 74
 p. 74
 p. 75
 p. 75
* Shows only if supported by your SIM card.
Overview of menu functions
To access Menu mode, press [ OK ] in Idle mode.

6
Unpack
Make sure you have each item
You can obtain various accessories
from your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your
phone and the accessories
available at your Samsung
dealer may vary, depending
on your country or service
provider.
Your phone
Buttons, features, and locations
Microphone
Navigation keys
(Up/Down/Left/
Right)
Earpiece
Display
Video call key
Delete key
Special
function keys
Power On/Off/
Menu exit key
Right soft key
Camera
key
External
display
Headset
jack
Camera
lens
Dial key
Volume keys
Left soft key
Menu access/
Confirm key
Application
switch key
Alphanumeric
keys

7
Get started
First steps to operating your phone
USIM/SIM card information
When you subscribe to a cellular network, you
receive a plug-in SIM (Subscriber Identity Module)
card loaded with your subscription details, such as
your PIN and available optional services. For 3G
services, you can purchase a USIM card.
Install and charge the phone
Remove the battery.
If the phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
Install the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.

Get started
8
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Power on
Do not turn on the
phone when
mobile phone use
is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn
on the phone.
3. If necessary, enter the PIN
and press < Confirm >.
Power off 1. Open the phone.
2. Press and hold [ ].

9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favourite
menus directly.  p. 67
In Menu mode, scroll through menu
options.
In Idle mode, access Menu mode.
In Menu mode, select the highlighted
menu option or confirm input.
Open the application switch window to
access other applications without
exiting the current application.
Make a video call.
Make or answer a call.
In Idle mode, retrieve numbers
recently dialled, missed, or received.
Delete characters from the display, or
an item in an application.
End a call.
Press and hold to switch the phone on
or off.
In Menu mode, cancel input and return
the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1 ] to
access your voicemail. Press and hold
[ 0 ] to enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to
activate or deactivate the Silent profile.
Press and hold [ ] to enter a pause
between numbers.
Adjust the phone volume.
In Idle mode, with the phone open,
adjust the keypad tone volume. With
the phone closed, press and hold to
turn on the external display.
In Idle mode, press and hold to turn on
the camera.
In Camera mode, take a photo or
record a video.

Get started
10
Display
Layout
Icons
Received signal strength
Accessing services in a 2.5G
network; when transferring
data, this icon animates
Accessing services in a 3G
network; when transferring
data, this icon animates
Roaming network
Voice call in progress
Out of your service area; you
cannot send or receive voice
calls
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the two soft keys.
Icons
display various icons.
Msg. Contacts
Icons
(continued)
Video call in progress
Out of your service area; you
cannot send or receive video
calls
Bluetooth active
Connected to Bluetooth hands-
free car kit or headset
Connected to PC via USB port
Browsing the Internet on PC
using the phone as modem
Connected to secured web
page
New message:
•:SMS
• : MMS
•:E-mail
•:Voicemail
•:WAPpush
• : Configuration message

11
Get started
Access menu functions
Icons
(continued)
Inbox full:
•:SMS
• : MMS
•:E-mail
•:Voicemail
• : Configuration message
Sound profile setting:
•:Normal
•:Meeting
•:Car
•:Silent
•:Outdoor
Battery power level
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current
role.
In each main menu, one of the
most popular submenu is
assigned to the left soft key.
This allows you to quickly
access the most popular
menus.
Press the left soft
key to select the
highlighted
option.
Press the right soft
key to return to
the previous menu
level.
Select Back

Get started
12
Customise your phone
Select an
option
1. Press the appropriate soft
key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press < Select > or [ OK ] to
confirm the function
displayed or option
highlighted.
4. To exit, choose either of the
following methods:
• Press <
Back > to move
up one level.
• Press [ ] to return to
Idle mode.
Use shortcuts Press the number key
corresponding to the option you
want.
1. In Idle mode, press [ OK ] and
select Settings → Phone →
Language → Screen text .
2. Select a language.
3. Press < Save >.
You can change the call ringer by
changing the properties of the
currently active sound profile.
To change the profile properties:
1. In Idle mode, press [
OK ] and
select Settings → Profiles .
2. Scroll to the sound profile you
are using.
3. Press < Options > and select
Edit .
4. Select Voice call ringtone
and select a ringtone for
voice calls.
5. Select Video call ringtone
and select a ringtone for
video calls.
6. Press < Options > and select
Save .
Display
language
Call ringer
melody

13
Get started
To change the sound profile:
1. In Idle mode, press [ OK ] and
select Settings → Profiles .
2. Select the profile you want.
You can set wallpaper for the idle
screen on each display.
For the main display:
1. In Idle mode, press [ OK ] and
select Settings → Display →
Wallpaper .
2. Scroll to an image folder .
3. Select an image and press
< Set >.
Idle mode
Wallpaper
For the external display:
1. In Idle mode, press [ OK ] and
select Settings → Display →
Cover LCD .
2. Select an image type.
3. For Clock , scroll to a clock
type and press < Save >.
For
Cover title , enter a
greeting and press <
Save >.
For
Wallpaper , press
<
Change > and select an
image. Adjust the image area
to be displayed and press
[
OK ].
4. Press [
OK ].
You can set the Navigation keys
to function as shortcuts to access
your favourite menus.
1. In Idle mode, press [
OK ] and
select Settings → Phone →
Shortcuts .
2. Select a key.
3. Select a menu to be assigned
to the key.
Menu
shortcuts

Get started
14
Make/Answer calls
You can activate the Silent profile
to avoid disturbing other people.
Press and hold [ ] in Idle mode.
You can protect the phone
against unauthorised use with a
phone password. The phone will
require the password on
power-up.
1. In Idle mode, press [
OK ] and
select Settings → Security
→ Change phone
password .
2. Enter the default password,
00000000 , and press
< Confirm >.
3. Enter a new 4- to 8-digit
password and press
< Confirm >.
4. Enter the new password
again and press < Confirm >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and press
< Confirm >.
Silent profile
Phone lock
To make a voice call:
1. Enter an area code and
phone number.
2. Press [ ].
3. To end the call, press [ ].
To make a video call:
1. Enter an area code and
phone number.
2. Press [ ] and if their phone
is compatible, the other
person appears on the
screen.
1. When the phone is ringing,
press [ ].
2. For a video call, press
<
Show me > to allow the
other person to see you.
3. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call

15
Step outside the phone
Begin with your camera, the media player, the web, and
other special features
Use the camera
1. Open the phone.
2. In Idle mode, press and hold
[ ] to turn on the camera.
3. Adjust the image by rotating
the camera lens and aiming it
at the subject.
4. Press [ OK ] to take a photo.
The photo is saved
automatically.
5. Press [ OK ] to take another
photo.
Take a photo
1. In Idle mode, press [ OK ] and
select File manager →
Images .
2. Select the photo you want
from the Pictures folder.
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [
1 ] to switch to Record
mode.
3. Adjust the image by rotating
the camera lens and aiming it
at the subject.
4. Press [ OK ] to start recording.
5. Press [ OK ] to stop recording.
The video is saved
automatically.
6. Press [ OK ] to record another
video.
View a photo
Record a video

Step outside the phone
16
Play media files
1. In Idle mode, press [ OK ] and
select File manager →
Videos .
2. Select the video you want
from the Videos folder.
Use these methods:
• Download from the wireless
web
 p. 39
• Download from a computer
using the optional Samsung
PC Studio
 Samsung PC
Studio User’s Guide
• Receive via Bluetooth
 p. 70
Play a video
Copy media
files to the
phone
1. In Idle mode, press [ OK ] and
select Applications → Media
player .
2. Press < Options > and select
Open play list .
3. Press < Options > and select
Add → Folder or Files .
4. Press [ OK ] to select the files
you want or scroll to the
folder you want.
5. Press < Add > or < Select >.
6. Press < Back > to return to
the media player screen.
Create a play
list

17
Step outside the phone
Browse the web
Using a built-in web browser, you can easily access
to the wireless web to get a variety of up-to-date
services and information to download web content.
1. From the media player
screen, press [ OK ].
2. Select the file you want.
3. During playback, use the
following keys:
•
OK : pauses or resumes
playback.
• Left: moves back to the
previous file. Moves
backward in a file when
held down.
• Right: skips to the next
file. Skips forward in a file
when held down.
• Up: opens the play list.
• Down: stops playback.
•/:adjuststhevolume.
Play media files
In Idle mode, press [ OK ] and
select Internet → Go to
homepage .
• To scroll through browser
items, press [Up] or [Down].
• To select an item, press [ OK ].
• To return to the previous
page, press <
Back >.
• To access options, press
<
Options >.
Launch the
web browser
Navigate the
web
