Samsung sm-r750 User manual

N
Wireless Device
SM-R750
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
Wireless Device CONTENTS

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2014. 09. Rev.1.0
ⓒ

2. Specification
2-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2-1. GSM General Specification
EGSM900 DCS1800 WCDMA
2100 WCDMA 900
Freq.
Band[MHz]
Uplink/
Downlink
880~915
925~960 1710~1785 1805~1880 1922~1977 2112~2167 882~912 927~957
ARFCN range 0~124 & 975~1023 512~885 UL:
9612~9888
DL:
10562~10838
UL:
2712~2863
DL:
2937~3088
Tx/Rx spacing 45MHz 95MHz 190MHz 45MHz
Mod. Bit rate/
Bit Period 236.8kbps 236.8kbps 42.2Mbps(DL)
5.76Mbps(UL) 42.2Mbps(DL)
5.76Mbps(UL)
Time Slot Period/
Frame Period 576.9us 4.615ms 576.9us 4.615ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
WCDMA
10ms/0.667ms
HSPA
2ms/0.667ms
Modulation GMSK
8PSK GMSK 8PSK
QPSK
HPSK
16QAM
64QAM
QPSK
HPSK
16QAM
64QAM
MS Power 33dBm~5dBm 30dBm~0dBm 24dBm~
-50dBm 24dBm~ -50dBm
Power Class 4(GMSK)
E2(8PSK) 1(GMSK) E2(8PSK) 33
Sensitivity -102dBm -100dBm -106.7dBm -103.7dBm
TDMA Mux 8 8 - -
Cell Radius 35Km 2Km 2Km 2Km

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-2
2-2. GSM Tx Power Class
TX Power
control level EGSM900
5 33±2 dBm
6 31±2 dBm
7 29±2 dBm
8 27±2 dBm
9 25±2 dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
0 30±3 dBm
1 28±3 dBm
2 26±3 dBm
3 24±3 dBm
4 22±3 dBm
5 20±3 dBm
6 18±3 dBm
7 16±3 dBm
8 14±3 dBm
9 12±4 dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

3. Operation Instruction and Installation
3-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Main Function
•Tizen OS
•HSPA+ 21Mbps /HSUPA 5.7Mbps
•2.0"OCTA S-AMOLED (360*480)
•GPS /BT v4.1 /USB v2.0 /WiFi (802.11 b/g/n)
•Sensors: Accelerometer, Gyro, Magnetic, Barometer, Light, UV, HRM Sensor
•4GBytes (eMMC) + 512M Bytes (LPDDR3) Memory
•IP67
•Additional :
-1.2
GHz Quad Core CPU
-SHealth, SVoice, Navigator, Music Player, Find My Deive
-Schedule, Running, New Briefing, Weather, Alarm, Gallery, Notification

1. Safety Precautions
1-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of
the low margin of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use asoldering iron with apower rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replac
ement parts may not function properly.

Safety Precautions
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
1-2
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discha
rge and can be easily damaged by it. We recommend protecting these components with cond
uctive anti-static bags when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are
properly connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

5. MAIN Electrical Parts List
5-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
SEC-CODE Design LOC Description
0403-001972 ZD400 DIODE-ZENER
0404-001887 D402 DIODE-SCHOTTKY
0404-001887 D403 DIODE-SCHOTTKY
0406-001375 ZD501 DIODE-TVS
0406-001506 ZD200 DIODE-TVS
0406-001506 ZD201 DIODE-TVS
0406-001553 C458 DIODE-TVS
0406-001592 ZD202 DIODE-TVS
0406-001592 ZD203 DIODE-TVS
0406-001592 ZD404 DIODE-TVS
0406-001596 ZD402 DIODE-TVS
0406-001596 ZD403 DIODE-TVS
0505-002652 TR400 FET-SILICON
0903-001959 U504 IC-MICROCONTROLLER
1108-000556 UCP300UP IC-MCP
1201-003699 U100 IC-POWER AMP
1201-003701 U103 IC-POWER AMP
1201-003729 U106 IC-GPS AMP
1203-004818 U518 IC-POSI.FIXED REG
1203-007000 U509 IC-POSI.FIXED REG
1203-007294 U511 IC-POSI.FIXED REG
1203-008037 U203 IC-POSI.FIXED REG
1203-008057 U400 IC-POWER SUPERVISOR
1203-008200 U500 IC-DC/DC CONVERTER
1203-008204 U403 IC-POWER SUPERVISOR
1203-008261 U204 IC-POSI.FIXED REG
1203-008261 U401 IC-POSI.FIXED REG
1203-008287 U404 IC-VOL. DETECTOR
1203-008355 U532 IC-SWITCH REG.
1204-003527 U202 IC-AUDIO PROCESSOR
1205-004833 U201 IC-CODEC
1205-004931 UCP300 IC-MODEM
1205-005079 U104 IC-TRANSCEIVER
1209-002227 U506 IC-PRESSURE SENSOR

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-2
1209-002245 U510 IC-MAGNETIC SENSOR
1209-002303 U502 IC-ETC SENSOR
1209-002308 U507 IC-ACCEL./GYRO SENSOR
1404-001724 TH100 THERMISTOR-NTC
1404-001724 TH300 THERMISTOR-NTC
1404-001724 TH500 THERMISTOR-NTC
2007-007315 R307 R-CHIP
2007-007943 R439 R-CHIP
2007-008052 R418 R-CHIP
2007-008052 R501 R-CHIP
2007-008052 R503 R-CHIP
2007-008055 R440 R-CHIP
2007-008055 R504 R-CHIP
2007-008419 R448 R-CHIP
2007-008420 R223 R-CHIP
2007-008420 R224 R-CHIP
2007-008420 R225 R-CHIP
2007-008420 R232 R-CHIP
2007-008420 R404 R-CHIP
2007-008483 R510 R-CHIP
2007-008516 R207 R-CHIP
2007-008516 R314 R-CHIP
2007-008516 R406 R-CHIP
2007-008516 R408 R-CHIP
2007-008516 R449 R-CHIP
2007-008516 R509 R-CHIP
2007-008588 R409 R-CHIP
2007-008588 R500 R-CHIP
2007-008774 R414 R-CHIP
2007-008774 R455 R-CHIP
2007-008786 R413 R-CHIP
2007-008798 R421 R-CHIP
2007-008806 R101 R-CHIP
2007-009157 R319 R-CHIP
2007-009157 R400 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-3
2007-009157 R402 R-CHIP
2007-009212 R502 R-CHIP
2007-009408 R300 R-CHIP
2007-009408 R301 R-CHIP
2007-009954 R100 R-CHIP
2007-009954 R410 R-CHIP
2007-011378 R324 R-CHIP
2007-011378 R326 R-CHIP
2007-011378 R328 R-CHIP
2007-011378 R363 R-CHIP
2007-011541 R505 R-CHIP
2007-011541 R506 R-CHIP
2007-011541 R514 R-CHIP
2007-011541 R515 R-CHIP
2007-011541 R516 R-CHIP
2007-011541 R517 R-CHIP
2007-011541 R518 R-CHIP
2007-011541 R519 R-CHIP
2007-011544 R329 R-CHIP
2007-011544 R330 R-CHIP
2007-011546 R316 R-CHIP
2007-011546 R317 R-CHIP
2007-011546 R318 R-CHIP
2007-011548 R427 R-CHIP
2007-011548 R436 R-CHIP
2007-011551 R438 R-CHIP
2007-011585 R452 R-CHIP
2007-011586 R200 R-CHIP
2007-011586 R201 R-CHIP
2007-011586 R202 R-CHIP
2007-011586 R203 R-CHIP
2007-011586 R204 R-CHIP
2007-011591 R302 R-CHIP
2007-011591 R303 R-CHIP
2007-011591 R304 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-4
2007-011591 R305 R-CHIP
2007-011591 R507 R-CHIP
2007-011591 R508 R-CHIP
2007-011591 R520 R-CHIP
2007-011591 R521 R-CHIP
2007-011598 R102 R-CHIP
2007-011614 R310 R-CHIP
2007-011615 R104 R-CHIP
2007-011615 R105 R-CHIP
2203-000311 C166 C-CER,CHIP
2203-000311 C178 C-CER,CHIP
2203-005682 C120 C-CER,CHIP
2203-005682 C124 C-CER,CHIP
2203-005682 C131 C-CER,CHIP
2203-005682 C133 C-CER,CHIP
2203-005682 C174 C-CER,CHIP
2203-005682 C182 C-CER,CHIP
2203-005682 C449 C-CER,CHIP
2203-005682 C479 C-CER,CHIP
2203-005682 C481 C-CER,CHIP
2203-005682 C482 C-CER,CHIP
2203-005682 C490 C-CER,CHIP
2203-005682 C491 C-CER,CHIP
2203-005682 C492 C-CER,CHIP
2203-005682 U102 C-CER,CHIP
2203-005725 C111 C-CER,CHIP
2203-005725 C157 C-CER,CHIP
2203-005725 C172 C-CER,CHIP
2203-005731 C243 C-CER,CHIP
2203-005731 C244 C-CER,CHIP
2203-005734 C234 C-CER,CHIP
2203-005734 C245 C-CER,CHIP
2203-005736 C100 C-CER,CHIP
2203-005736 C101 C-CER,CHIP
2203-005736 C103 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-5
2203-005736 C132 C-CER,CHIP
2203-005736 C151 C-CER,CHIP
2203-005736 C155 C-CER,CHIP
2203-005736 C457 C-CER,CHIP
2203-005736 L105 C-CER,CHIP
2203-005789 C109 C-CER,CHIP
2203-005789 C126 C-CER,CHIP
2203-005806 C354 C-CER,CHIP
2203-005806 C400 C-CER,CHIP
2203-005806 R401 C-CER,CHIP
2203-006121 C170 C-CER,CHIP
2203-006121 C241 C-CER,CHIP
2203-006121 C242 C-CER,CHIP
2203-006208 C519 C-CER,CHIP
2203-006348 C542 C-CER,CHIP
2203-006348 C543 C-CER,CHIP
2203-006400 C173 C-CER,CHIP
2203-006400 C246 C-CER,CHIP
2203-006410 C236 C-CER,CHIP
2203-006423 C104 C-CER,CHIP
2203-006423 C207 C-CER,CHIP
2203-006423 C209 C-CER,CHIP
2203-006423 C210 C-CER,CHIP
2203-006423 C213 C-CER,CHIP
2203-006423 C216 C-CER,CHIP
2203-006423 C239 C-CER,CHIP
2203-006423 C412 C-CER,CHIP
2203-006423 C444 C-CER,CHIP
2203-006562 C540 C-CER,CHIP
2203-006562 C541 C-CER,CHIP
2203-006674 C123 C-CER,CHIP
2203-006838 C361 C-CER,CHIP
2203-006838 C362 C-CER,CHIP
2203-006839 C107 C-CER,CHIP
2203-006839 C125 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-6
2203-006839 C455 C-CER,CHIP
2203-006841 C460 C-CER,CHIP
2203-007194 C150 C-CER,CHIP
2203-007194 C154 C-CER,CHIP
2203-007210 C355 C-CER,CHIP
2203-007210 C356 C-CER,CHIP
2203-007271 C405 C-CER,CHIP
2203-007271 C406 C-CER,CHIP
2203-007271 C407 C-CER,CHIP
2203-007271 C408 C-CER,CHIP
2203-007317 C128 C-CER,CHIP
2203-007317 C419 C-CER,CHIP
2203-007317 C420 C-CER,CHIP
2203-007317 C421 C-CER,CHIP
2203-007317 C424 C-CER,CHIP
2203-007317 C425 C-CER,CHIP
2203-007317 C429 C-CER,CHIP
2203-007317 C430 C-CER,CHIP
2203-007317 C431 C-CER,CHIP
2203-007317 C432 C-CER,CHIP
2203-007317 C433 C-CER,CHIP
2203-007317 C434 C-CER,CHIP
2203-007317 C436 C-CER,CHIP
2203-007317 C510 C-CER,CHIP
2203-007317 U101 C-CER,CHIP
2203-007391 C414 C-CER,CHIP
2203-007391 C520 C-CER,CHIP
2203-007393 C105 C-CER,CHIP
2203-007393 C203 C-CER,CHIP
2203-007393 C206 C-CER,CHIP
2203-007393 C212 C-CER,CHIP
2203-007393 C415 C-CER,CHIP
2203-007393 C526 C-CER,CHIP
2203-007449 C211 C-CER,CHIP
2203-007449 C215 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-7
2203-007449 C217 C-CER,CHIP
2203-007449 C218 C-CER,CHIP
2203-007449 C300 C-CER,CHIP
2203-007449 C308 C-CER,CHIP
2203-007449 C310 C-CER,CHIP
2203-007449 C410 C-CER,CHIP
2203-007449 C418 C-CER,CHIP
2203-007449 C422 C-CER,CHIP
2203-007449 C423 C-CER,CHIP
2203-007449 C426 C-CER,CHIP
2203-007449 C427 C-CER,CHIP
2203-007449 C428 C-CER,CHIP
2203-007449 C435 C-CER,CHIP
2203-007449 C478 C-CER,CHIP
2203-007449 C480 C-CER,CHIP
2203-007449 C517 C-CER,CHIP
2203-007449 C518 C-CER,CHIP
2203-007449 C544 C-CER,CHIP
2203-007503 C504 C-CER,CHIP
2203-007544 C494 C-CER,CHIP
2203-007621 C134 C-CER,CHIP
2203-007621 C135 C-CER,CHIP
2203-007621 C139 C-CER,CHIP
2203-007621 C140 C-CER,CHIP
2203-007621 C141 C-CER,CHIP
2203-007621 C142 C-CER,CHIP
2203-007621 C143 C-CER,CHIP
2203-007621 C144 C-CER,CHIP
2203-007621 C145 C-CER,CHIP
2203-007621 C146 C-CER,CHIP
2203-007621 C147 C-CER,CHIP
2203-007621 C148 C-CER,CHIP
2203-007621 C301 C-CER,CHIP
2203-007621 C302 C-CER,CHIP
2203-007621 C303 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-8
2203-007621 C304 C-CER,CHIP
2203-007621 C305 C-CER,CHIP
2203-007621 C306 C-CER,CHIP
2203-007621 C307 C-CER,CHIP
2203-007621 C309 C-CER,CHIP
2203-007621 C311 C-CER,CHIP
2203-007621 C312 C-CER,CHIP
2203-007621 C313 C-CER,CHIP
2203-007621 C314 C-CER,CHIP
2203-007621 C315 C-CER,CHIP
2203-007621 C316 C-CER,CHIP
2203-007621 C319 C-CER,CHIP
2203-007621 C320 C-CER,CHIP
2203-007621 C321 C-CER,CHIP
2203-007621 C322 C-CER,CHIP
2203-007621 C323 C-CER,CHIP
2203-007621 C324 C-CER,CHIP
2203-007621 C325 C-CER,CHIP
2203-007621 C327 C-CER,CHIP
2203-007621 C328 C-CER,CHIP
2203-007621 C329 C-CER,CHIP
2203-007621 C330 C-CER,CHIP
2203-007621 C332 C-CER,CHIP
2203-007621 C333 C-CER,CHIP
2203-007621 C334 C-CER,CHIP
2203-007621 C335 C-CER,CHIP
2203-007621 C337 C-CER,CHIP
2203-007621 C338 C-CER,CHIP
2203-007621 C342 C-CER,CHIP
2203-007621 C343 C-CER,CHIP
2203-007621 C345 C-CER,CHIP
2203-007621 C346 C-CER,CHIP
2203-007621 C347 C-CER,CHIP
2203-007621 C349 C-CER,CHIP
2203-007621 C350 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-9
2203-007621 C351 C-CER,CHIP
2203-007621 C352 C-CER,CHIP
2203-007621 C525 C-CER,CHIP
2203-007621 C528 C-CER,CHIP
2203-007621 C547 C-CER,CHIP
2203-007781 C516 C-CER,CHIP
2203-007795 C108 C-CER,CHIP
2203-007795 C413 C-CER,CHIP
2203-007795 C448 C-CER,CHIP
2203-007795 C493 C-CER,CHIP
2203-007795 C500 C-CER,CHIP
2203-007795 C501 C-CER,CHIP
2203-007795 C502 C-CER,CHIP
2203-007795 C503 C-CER,CHIP
2203-007795 C515 C-CER,CHIP
2203-007796 C130 C-CER,CHIP
2203-007796 C149 C-CER,CHIP
2203-007796 C205 C-CER,CHIP
2203-007796 C214 C-CER,CHIP
2203-007796 C240 C-CER,CHIP
2203-007796 C326 C-CER,CHIP
2203-007796 C331 C-CER,CHIP
2203-007796 C344 C-CER,CHIP
2203-007796 C348 C-CER,CHIP
2203-007796 C353 C-CER,CHIP
2203-007796 C445 C-CER,CHIP
2203-007796 C446 C-CER,CHIP
2203-007796 C450 C-CER,CHIP
2203-007796 C452 C-CER,CHIP
2203-007796 C453 C-CER,CHIP
2203-007796 C454 C-CER,CHIP
2203-007796 C459 C-CER,CHIP
2203-007796 C461 C-CER,CHIP
2203-007796 C474 C-CER,CHIP
2203-007796 C506 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-10
2203-007796 C507 C-CER,CHIP
2203-007796 C508 C-CER,CHIP
2203-007796 C509 C-CER,CHIP
2203-007796 C524 C-CER,CHIP
2203-008097 C204 C-CER,CHIP
2203-008097 C511 C-CER,CHIP
2203-008097 C512 C-CER,CHIP
2203-008097 C513 C-CER,CHIP
2203-008097 C514 C-CER,CHIP
2203-008097 C521 C-CER,CHIP
2203-008097 C529 C-CER,CHIP
2203-008199 BAT400 C-CER,CHIP
2203-008242 C336 C-CER,CHIP
2203-008242 C505 C-CER,CHIP
2203-008242 C545 C-CER,CHIP
2203-008312 C403 C-CER,CHIP
2203-008312 C404 C-CER,CHIP
2203-008400 C527 C-CER,CHIP
2203-008463 C127 C-CER,CHIP
2203-008463 C357 C-CER,CHIP
2203-008463 C358 C-CER,CHIP
2203-008463 C359 C-CER,CHIP
2203-008463 C360 C-CER,CHIP
2203-008654 C456 C-CER,CHIP
2203-008876 C110 C-CER,CHIP
2203-008876 C122 C-CER,CHIP
2203-008885 C440 C-CER,CHIP
2203-008885 C441 C-CER,CHIP
2203-009025 R103 C-CER,CHIP
2203-009076 C438 C-CER,CHIP
2203-009076 C439 C-CER,CHIP
2203-009076 C442 C-CER,CHIP
2203-009076 C443 C-CER,CHIP
2703-001868 L404 INDUCTOR-SMD
2703-002958 L100 INDUCTOR-SMD

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-11
2703-002960 L301 INDUCTOR-SMD
2703-002960 L302 INDUCTOR-SMD
2703-002960 L303 INDUCTOR-SMD
2703-002960 L304 INDUCTOR-SMD
2703-003686 L300 INDUCTOR-SMD
2703-003754 L503 INDUCTOR-SMD
2703-004012 L103 INDUCTOR-SMD
2703-004013 C121 INDUCTOR-SMD
2703-004032 L111 INDUCTOR-SMD
2703-004035 L129 INDUCTOR-SMD
2703-004037 L104 INDUCTOR-SMD
2703-004037 L110 INDUCTOR-SMD
2703-004193 L207 INDUCTOR-SMD
2703-004259 L125 INDUCTOR-SMD
2703-004286 L122 INDUCTOR-SMD
2703-004289 L120 INDUCTOR-SMD
2703-004301 L102 INDUCTOR-SMD
2703-004302 L106 INDUCTOR-SMD
2703-004328 L114 INDUCTOR-SMD
2703-004328 L130 INDUCTOR-SMD
2703-004338 L200 INDUCTOR-SMD
2703-004362 L115 INDUCTOR-SMD
2703-004366 L118 INDUCTOR-SMD
2703-004366 L131 INDUCTOR-SMD
2703-004371 L112 INDUCTOR-SMD
2703-004371 L113 INDUCTOR-SMD
2703-004644 L403 INDUCTOR-SMD
2703-004730 L400 INDUCTOR-SMD
2703-004730 L401 INDUCTOR-SMD
2703-004764 L109 INDUCTOR-SMD
2703-004775 L402 INDUCTOR-SMD
2703-005056 L500 INDUCTOR-SMD
2703-005056 L501 INDUCTOR-SMD
2703-005056 L502 INDUCTOR-SMD
2801-005352 OSC400 CRYSTAL-SMD

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-12
2901-001690 C317 FILTER-EMI SMD
2901-001690 C318 FILTER-EMI SMD
2901-001690 C339 FILTER-EMI SMD
2901-001798 F500 FILTER-EMI/ESD
2901-001798 F501 FILTER-EMI/ESD
2904-002132 F103 FILTER-SAW
2904-002136 F100 FILTER-SAW
2904-002211 F106 FILTER-SAW
2910-000214 F101 DUPLEXER-SAW
2910-000215 F102 DUPLEXER-SAW
3301-001659 L124 BEAD-SMD
3301-001812 L202 BEAD-SMD
3301-001812 L203 BEAD-SMD
3301-001885 L205 BEAD-SMD
3301-001885 L208 BEAD-SMD
3301-001895 L126 BEAD-SMD
3301-002035 L405 BEAD-SMD
3301-002235 L504 BEAD-SMD
3301-002235 L505 BEAD-SMD
3301-002235 L506 BEAD-SMD
3301-002242 L209 BEAD-SMD
3301-002242 L210 BEAD-SMD
3301-002242 L406 BEAD-SMD
3705-001708 RFS100 CONNECTOR-COAXIAL
3709-001854 SIM402 CONNECTOR-CARD EDGE
3711-008740 HDC500 HEADER-BOARD TO BOARD
3711-008800 HDC200 HEADER-BOARD TO BOARD
3711-008824 HDC401 HEADER-BOARD TO BOARD
3711-008841 BTC400 CONNECTOR-BATTERY
3712-001528 ANT101 CONNECTOR-TERMINAL
3712-001528 ANT201 CONNECTOR-TERMINAL
3712-001528 POGO400 CONNECTOR-TERMINAL
3712-001528 POGO401 CONNECTOR-TERMINAL
3712-001528 POGO402 CONNECTOR-TERMINAL
3712-001528 POGO403 CONNECTOR-TERMINAL

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-13
3712-001528 POGO404 CONNECTOR-TERMINAL
3712-001528 SPK201 CONNECTOR-TERMINAL
3712-001528 SPK202 CONNECTOR-TERMINAL
4709-002306 U200 W-LAN MODULE
GH31-00686A MOT500 MOTOR DC-SMD CYLINDER MOTOR
GH62-00035A CN100 PAD GAP-SMD GASKET
GH62-00035A CN101 PAD GAP-SMD GASKET
GH62-00035A CN102 PAD GAP-SMD GASKET
GH80-03320A C168 SOLDER-CREAM
GH80-03320A C179 SOLDER-CREAM
GH80-03321A L211 SOLDER-CREAM
GH80-03321A R205 SOLDER-CREAM
GH80-03321A R206 SOLDER-CREAM
GH80-03321A R226 SOLDER-CREAM
GH80-03321A R227 SOLDER-CREAM
GH80-03321A R228 SOLDER-CREAM
GH80-03321A R229 SOLDER-CREAM
GH80-03321A R230 SOLDER-CREAM
GH80-03321A R306 SOLDER-CREAM
GH80-03321A R308 SOLDER-CREAM
GH98-34680A SC100 ASSY SHIELD CAN-TOP
GH98-34681A SC300 ASSY SHIELD CAN-BTM A
GH98-34682A SC101 ASSY SHIELD CAN-BTM B
Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.
