SanDisk MLC NAND User manual

SanDisk®pSSD™
Solid State Drive
Rugged & Reliable
Cost Effective
High Performance
SanDisk® pSSD™ solid state drive introduces all the
benets of ash memory to the exciting, new net-
book market. Rugged and reliable, SanDisk pSSD solid
state drive is the right storage module for netsurng
and wireless communication on ultra low cost PC
(ULCPC) netbooks. With up to 16GB* multi-level cell
(MLC) NAND ash, it is a fraction of the weight and
cost of a hard disk drive. An advanced controller, rep-
resenting the best of the company’s years of expertise
with the parallel ATA (PATA) interface, makes SanDisk
pSSD solid state drive both fast and power-efcient.
SanDisk pSSD solid state drive. Everything that ash
storage should be for today’s mobile PC lifestyle.
A Perfect Match for ULCPCs
SanDisk pSSD PATA-based solid state drive was
designed especially to meet the requirements of
ULCPCs. These small laptops must be lightweight,
rugged and reliable for mobile users in the consumer
market, giving them easy Internet access and making
wireless communication fun.
Rugged and Reliable
SanDisk pSSD solid state drive has no moving parts,
making it far more reliable than a HDD. It withstands
the wear-and-tear of people on the go, and operates
soundlessly in environments where noise is a nui-
sance, such as classrooms. SanDisk patented ash
management technology brings high data integrity
to its pSSD solid state drives. Dynamic bad block
management, dynamic and static wear-leveling, and
robust error detection and correction code (EDC/ECC)
ensure data reliability.
Fast and Power Efcient
SanDisk pSSD solid state drive boots fast and
keeps working at high speed, without the need to
spin up into action or to seek les like a conven-
tional HDD. SanDisk pSSD solid state drive achieves
an industry-leading sustained read speed as high
as 39MB/sec and a sustained write speed of up to
17MB/sec with multi-level cell (MLC) NAND ash
technology. Solid-state operation also extends bat-
tery life, critical for ULCPC users.
Low Cost and Lightweight
With MLC NAND technology, SanDisk pSSD solid state
drive gives users just the amount of memory they
need at a cost they can afford. A case-less module,
SanDisk pSSD solid state drive is one-tenth the weight
of a typical 1.8" HDD. SanDisk pSSD solid state drive
enables sleek and slim ULCPC industrial design to
meet worldwide consumer demands.

USA
[email protected]
Japan
[email protected]
Taiwan
[email protected]
China
[email protected]
Korea
[email protected]
Europe
[email protected]
For more information, please
visit www.sandisk.com/pssd
Product not available
until August 2008.
SanDisk and the SanDisk logo are trademarks of SanDisk Corporation registered in the United States and other countries.
SanDisk pSSD is a trademark of SanDisk Corporation. Other brand names mentioned herein are for identication purposes
only and may be trademarks of their respective holder(s).
©2008 SanDisk Corporation. 6/08 80-11-01576 Rev. 2
* 1 gigabyte (GB) = 1 billion bytes; 1 megabyte (MB) = 1 million bytes; speed based on internal testing;
performance may be lower depending on host device. Some capacity not available for data storage.
** Based on internal testing. The MTTF calculation does not take into account the disk endurance limita-
tion. For the disk endurance, please refer to the endurance section in the product specication.
Specications
High Reliability
• Unlimited read cycles
• SMART feature supported
• Dynamic and static wear-leveling
• Dynamic bad block management
• Advanced EDC/ECC
• No preventive maintenance
• Up to 4M mean time to failure
(MTTF)** hours
High Performance
• Transfer modes supported: UMDA
0-4, Multiword-DMA 0-2, PIO 0-4
• Sustained read: 39MB/s
• Sustained write: 17MB/s
Characteristics
• Interface: Parallel ATA (PATA)
• MLC NAND ash capacity:
4GB, 8GB, 16GB
Electrical Specications
• DC supply voltage: 3.3V ±5%
• Standby current: 300μA (typical)
• Active current (typical):
Read = 130mA, Write= 120mA
Environmental Specications
• Operating temperature: 0°C to +70°C
• Storage temperature: –25°C to +85°C
• Operating altitude: up to 80,000 feet
• Humidity: 5% to 90% non-condensing
• Shock: 1,000G
• Acoustic noise: 0dB
• Vibration: 15G (peak to peak)
Physical Specications
• Connector: 40-pin ZIF connector
• Weight: 4.9g (4GB), 5.5g (8GB),
7.0g (16GB)
• Dimensions:
54mmx32mmx2.5mm (4GB, 8GB)
54mmx32mmx3.75mm (16GB)
Regulations and Compliance
• RoHS, China RoHS, SGS RoHS, UL,
FCC, CE
OS Support
• XP, Linux
