S&P Africa ELEKTRA Health+ K800 User manual

D
Read these instructions before use and keep them safe. If you pass the
appliance on, pass on the instructions too. Remove all packaging, but keep
it until you are satisfied.
Thank you for purchasing an Elektra Health Thermometer.
This thermometer has been designed for measuring the forehead temperature
and eardrum temperature.
Features:
-Easy to read digital LCD (liquid crystal display).
-Compact, accurate and durable LSI (large scale integration) device.
-Temperature can be taken under the tongue (oral use) or under the arm
(axillary use).
-It is suggested that rectal temperatures be taken on infants only when
axillary use is difficult.
-Fast 10 second readout.
-Auto shut off in approximately 9 minutes.
-Small, lightweight unit.
-Ideal for the whole family.
-Low battery indicator: when the symbol “ ”appears, the battery needs to
be replaced.
-The unit is water resistant.
BATTERY REPLACEMENT:
1. When the symbol “ ” appears, the battery needs to be replaced.
2. Remove the battery cover as shown in the diagram.
3. Use a toothpick or similar object to remove the battery. Avoid using any
sharp metal objects.
4. Place a new battery in the chamber.
5. Replace the battery cover securely.
D
Battery
Cover
D

Note:
1. Remove batteries when not in use for a period of time.
2. Do not dispose of batteries in fire.
3. Dispose of batteries in accordance with local regulations, and in an
environmentally responsible manner.
KNOW YOUR ELEKTRA HEALTH THERMOMETER
OPERATING YOUR THERMOMETER
1. Disinfect the probe with isopropyl (rubbing) alcohol before using.
2. Depress the on/off button. A short beep will sound, and the LCD display will
read .
3. Release the power switch. The last reading will be shown for 2 seconds.
4. The thermometer will run a self-check test , the display will show self-test
temperature of 37°C.
5. When the sign “Lo” and a flashing “°C” display, the thermometer is ready for
use.
6. Place the probe in the appropriate position (oral, auxiliary or rectal).
7. Once the degree sign °C on the display has stopped flashing, the
temperature is indicated.
8. The unit will automatically turn off in approximately 9 minutes.
9. To prolong battery life, please turn the thermometer off once you have
finished using it.
Operating Features
Normal Temperature Alarm
An alarm will sound when the temperature has registered and is ready-to-read
again. The “Normal Temperature” alarm (ten quick beeps followed by a pause)
will sound repeatedly for approximately10 seconds.
Thermo-
Sensor
LCD
ON / OFF
Button
Battery
Compartment
Thermometer
Tip

Last-Temperature Memory Recall
Switch the thermometer on, a short beep will sound.
The last reading will appear automatically on the LCD for 2 seconds. The reading
is only over-written when a new temperature value is recorded.
Fever Alarm
If the temperature registers higher than 37.8°C, the fever alarm (a quick beeping
sound which occurs continuously for about 10 seconds) will sound.
NOTE:
1. Always disinfect the thermometer before use.
2. If the temperature is below than 32 °C, it will be displayed with Lo °C.
If the temperature is higher than 42.9 °C, it will be displayed with Hi °C.
3. You may put a sanitary plastic probe shield on the sensor tip to help prevent
cross-infection and contamination.
4. Use of the probe cover may result in a 0.1 °C difference from actual
temperature.
5. Dispose of used probe shields, do not reuse.
TAKING BODY TEMPERATURES:
Change in body temperature is one of the most important indicators of illness. It
is important that accurate temperatures be taken. Even though the digital
thermometer is used in a similar manner to the glass thermometer, it is important
that the simple instructions for use of this thermometer be followed closely and
that the person taking the temperature understands body temperatures.
BODY TEMPERATURE:
A person's body temperature may be lower in the morning than it is in the late
afternoon. To determine what your normal body temperature is you should take
your temperature both in the early morning and in the late afternoon over several
days. Children have the same normal temperature range as do adults. A fever for
both children and adults is typically defined as a temperature over 37.5 °C (oral
reading). Exercise excessive, clothing, hot bath, hot weather, warm food and
drink can cause mild elevations in oral temperature. If you suspect one of these
to be the cause of an elevated reading, eliminate the possible cause and retake
the temperature half an hour later.

ORAL USE:
Place the probe well under the patient's tongue. Instruct the patient to keep their
mouth closed while the thermometer is reading. A normal temperature by this
method is usually considered between 36.0 °C to 37.5 °C.
RECTAL USE:
If rectal temperature is recommended by your doctor, you may use a probe
shield. Insert thermometer into the probe shield. Lubricate the probe cover with a
water soluble jelly for easier insertion. Do not use petroleum jelly. Insert the tip of
probe no more than 1/2 inch into rectum. STOP if you meet any resistance. The
sensing unit is on the very tip of the probe and there is no need to insert the
probe deep into the rectum. In general, the rectal temperature is around 0.5 to
1.0 °C higher than oral temperature.
AXILLARY USE:
Wipe the armpit with a dry towel. Place the probe in the patient's armpit and keep
the patient's arm pressed firmly against the body. In general, the axillary
temperature is around 0.5 to 1.0 °C lower than oral temperature. Note, in order to
achieve a better auxiliary temperature reading, a minimum measuring time of
3~5minutes is recommended regardless of the beep sound.
NOTE: Children should be attended by an adult during the entire temperature
recording process. After use, the digital thermometer should be stored in a safe
place, out of reach of children. If you compare temperatures between two
thermometers, it is possible to have two different readings even if both
thermometers are within their accuracy tolerances. Differences in how you take
each reading and the thermometer's tolerance range can account for nearly 0.1
°C changes.
Heat
Pocket
Heat
Pocket
Place probe
tip
37.1°C
37.1°C
36.9°C
36.9°C
36.6°C
36.6°C
36.5°C

Specifications
Range: 32.0 ~42.9 °C
Below 32.0 °C displays Lo °C
Above 42.9 °C displays Hi °C
Resolution: 0.1 °C
Accuracy: ±0.1 °C: 34.0~42.0 °C
±0.2 °C: other range
Display: Liquid crystal display 3 1/2 digits
Battery (included): One Micro Alkaline battery 192/384/392 or
LR41/SR41 (1.55V)
Power Consumption: 0.15 milliwatts in measurement mode
Battery Life: More than 200 hours of continuous operation
Beeper: Approx.10 sec. sound signal when peak temperature
reached
Working Conditions: Temperature: 10~40 °C
Relative Humidity: 15~95% non-condensing
Storage Conditions: Temperature -25 ~ 55°C
Guarantee of Quality: Certification ISO 13485, Conformity EN12470-3,
EN60601-1, ASTM-E1112
PRECAUTIONS:
1. Do not boil the probe. Rather clean the unit by wiping it with a dry cloth and
disinfect the probe with isopropyl (rubbing) alcohol.
2. Do not drop the thermometer. The unit is not shock proof.
3. Do not bend or bite the probe.
4. Do not store the unit in direct sunlight, at high temperatures, in areas of high
humidity or dust. Performance may be affected.
5. Stop using the thermometer if it operates intermittently or if the display
malfunctions.
6. Keep out of reach of children.
7. Clean the thermometer probe before storing.
8. Do not attempt to disassemble the unit except to replace the battery.
9. If the thermometer has been stored at below-freezing temperatures, allow
the thermometer to warm naturally to room temperature before using.
10.Performance of the device may be affected if operated or stored outside the
stated temperature and humidity ranges, or if the patient's temperature is
below the ambient room temperature.

CLEANING INSTRUCTIONS:
To clean the thermometer, wash the tip with a solution of mild detergent and cool
water. Disinfect the thermometer by wiping the sensor and lower stem with a
cloth dipped in a household antiseptic solution such as rubbing alcohol.
After Sales Service
The appliance is not user-serviceable. If it is not working properly check:
1. You have followed the instructions properly.
2. The batteries have been installed correctly.
If the appliance still does not work, contact the Service Centre.
Guarantee
Any defect affecting the functionality of the appliance which becomes apparent
within one (1) year of its purchase, will be corrected by free repair or
replacement, provided that the appliance has been used and maintained in
accordance with the instructions, and has not been altered/modified, abused or
misused in anyway, and is accompanied with a Proof of Purchase to validate the
age of the appliance.
The Environment
Please consider the environment when disposing of packaging.
Recycle wherever possible.
When you want to dispose of this appliance please do so responsibly, or contact
us to assist with the disposal, or disposal advice.
8 Palala Street, Protec Park, Terenure Ext. 42,
Kempton Park, South Africa, 1610
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.sp-africa.com
