SANJIANG F161 User manual

version 603500171115
1
F161rangeof0 100%LELCombustibleGasDetectors
Manual
----- Pleasereadthismanualcarefullywheninstallorusethisproduct -----
GeneralIntroduction
F161rangeof0 100%LELstandalonecombustiblegasdetector(hereinafterreferredtoasthedetector)hasahighqualityscreenprintingthick
filmmetaloxidesemiconductorsgassensors(long-life,sensorisunaffectedevenshockedbyhighconcentrationgas),usedformonitoringthe
leakageofcombustiblegasesintheplacesofhousehold,factories,hotels,apartments,etc.
Features
ThisproductisusingthesemiconductorgassensorandtheCortex-M3MCUwithexcellentperformance,thedetectorisstable,long-lifespan,
easytoinstall.Intheaspectofinteraction,usingLCDscreenprovidesacalendar,detectorsurroundingtemperaturedisplay.Ifgasleaks,it
providesconcentrationreal-timedisplayandthedisplayinterfacechangesalongwiththeconcentrationaccordinglysothatitcancreateamore
friendlyandcomfortablealarmprompt.Italsohasrealhumanvoicepromptalarmfunction,thevoicecontentwillbevarywiththeleakedgas
density,sothatyoucanprocesstheleakageaccidentmoresafe,convenientandrapid.Additionally,throughthelowpowerconsumptiondigital
intelligentpyroelectricinfrared(hereinafterreferredtoasthePIR)sensortorealizethehumandetectionandthencontroltheLCDdisplay,which
makesthedetectormoreintelligentandenergysaving.
TechnicalSpecifications
1. WorkingVoltage: AC110/220V
2. PowerConsumption: Normalmonitoring 3W;Poweronandalarmstatus 6W
3. OperatingTemperature: 0℃～55℃
4. RelativeHumidity: 95%,noncondensation
5. ApplicableGas: Methane(Naturalgas)
6. AlarmSettingValue: 5%LEL
7. TheWholeMeasuringRange: 0%LEL～15%LEL
8. AlarmVolume: 70dB～115dB
9. ResponseTime: 30S,self-recovery
10. WorkingLife: ≥5years(incleanair)
11. Weight: Around130g
12. OutlineDimension: 93mm×93mm×51mm(refertotheimagebelow),housingmaterial: plastic
13. InstallationMethod: Wall-mounted
Outlinestructureandconnectionmethod
1. Detectoroutlineanddimension(unit:mm)
2. Detectorconnectionmethod
Thedetectordoesnotneedtheotherconnection,onlyneedtoplugintheAC110/220Vpowersourcetowork,whichissimpleandconvenient.
Instructionsforuseandinstallation
1. Instructionsforuseandinstallation
lPoweron:Pleaseconfirmifthedecorationoftheuseplaceiscompletelyfinished(Pleasepayattentiontothatdonotputthedetectorinthe
decorationenvironment,otherwisethesensormaybedamaged);Afterdecorationisfinished,plugthedetectorinAC110/220Vpower
socket,thenappearvoiceprompt “welcometousetheproductsofFanhaiSanjiang”andtheLCDdisplaysthebootinterface.
lPreheatstatus:Thedetectorentersintopreheatstatusafterpoweron.Atthisstage,theindicatorlampblinksandthepreheatstatuslasts
forabout20minutes.
lNormalworking:Afterpreheatstatusfinished,detectorentersintonormalworkingstatus;Atthisstage,powerindicatorlampisalwayson
andLCDscreendisplaysworkinginterface.
lFault:Onceasensorfailureisdetectedbydetector(suchasshortcircuit,opencircuitetc.),thefaultindicatinglampisalwaysonandmakes
asound “dididi”periodically.(perperiod/oneminuteapproximately).
lAlarm:Oncethegasdensityreachestothesettingalarmvalue,thedetectorwillbetriggeredalarmprompt.Thealarmlampisalwayson
duringthisstageandwillenterintothreestagesbelowalongwiththeincreasingleakageofgasdensity.
1)Note!Gasleaking,pleasecheck!
2)Warning!Gasleakisdetected,opendoorsandwindows,keepventilated,checkwithqualifiedpeople,disperseassoonaspossible!
3)Danger!Gasleakingseriously,don’tfire,don’tturnonorofflight,pleasesendalarmanddisperseassoonaspossible!
lAlarmrecovery:Whenthegasdensityreducestothesettingalarmvalue,thedetectorwillberecoveredtothenormalworkingstatus.
lSelf-checking:Pressthe “TEST”buttonshortly.Thedetectorentersintoself-checkingstatus;Atthisstage,therelatedvoice,light,LCDwill
bechecked.Thedetectorentersintonormalworkingstatusafterself-checkingfinished.
lEnergy-savingcontrol ThedetectorconfiguredwithinfraredsensortofurthercontrolthestartandstopofLCD.Iftheinfraredsensordidnot
detectanymovingobjectsforalongtime(around3minutes),theLCDwillstopdisplaying.Ifamovingobjectisdetectedbyinfraredsensor,
LCDscreenwillopentodisplayandextendthedisplaytime.Thedetectordoesnotmakeenergy-savingcontrolwhenitalarms.
2. Installationlocationdescription
Installationpositionofdetector(asshownbelow)shouldbedecidedbytheanalysisonthebasisoftheactualsituationofthelocationsoftheuse
ofgasandstove.Butitshouldcomplywiththefollowingprinciples:
1) Thedetectorshouldbeinstalledinthesameroomwiththestove;
2) Thedetectorismountedatahorizontaldistance1.5metersto4metersofgasstoveorgassource;
3) Verticalheightofdetector:theinstallationfromthecombustionairoranoven(above)theverticaldistanceislargerthanorequalto0.5
meters,fromtheceilingof0.3metersplace(becausetheproportionofthegasislighterthanair);

2
4) Schematicdiagramofinstallationshowsbelow:
5) Inordertopreventtheoccurrenceofthedetectorfailure,pleasedonotinstallthedetectorinthefollowingpositions:
a.Theplaceswhicharedirectlyinfluencedbyexhaust,fumes,steam,etc;
b.Closetotheairinlet,exhaustfan,doorandwindowetc.withalargeairflowplace;
c.Nearthebathroom,thewatervapor,thehotwaterroomandtheplacewithpoweroutageatnight;
d.Anti-explosionplace;
e.Wherethetemperatureisbelow0degreescelsiusorabove55oroutdoor.
Clocksetting
1. Longpress “TEST”button(around3seconds),enterintoclock(24hoursdisplay)calibrationstatus.Thefirsttwodigitsoftheyearcannot
beset,onlythelasttwodigitscanbeset.Inotherwords,theminimumyearstartsfrom2000.Thethirddigitoftheyearchangestogreen
colourandincreases “1”asacycleautomatically.Pleaseshortpress “self-checking”buttonuntilthethirddigitoftheyearchangestothe
defaultvalueandthenitwillbesaved.Nexttheinterfacewilljumptothefourthdigitoftheyear.
2. Thefourthdigitoftheyear:itchangestogreencolourandincrease “1”asacycleautomatically.Pleaseshortpress “self-checking”button
untilthefourthdigitoftheyearchangestothedefaultvalueandthenitwillbesaved.Nexttheinterfacewilljumptothefirstdigitofthe
month.
3. Similarly,accordingtoabovesteps,youcanfinishthesettingoffirstandseconddigitsofamonth,aday,anhourandaminute.Theywillbe
savedandjumptotheconfirmationinterface.
4. Settheconfirmationinterface:Atconfirmationinterface,theyear,month,day,hourwillchangetogreencolour.Ifthetimeiscorrect,long
press “self-checking”button(around3seconds)andthesettingwillbesavedandthenquitclockcalibration.Ifthetimeisincorrect,short
press “self-checking”buttonandresetfromthethirddigitofayear.
5. Thesystemwillquitclocksettingonconditionthatnotoperateforabout30secondsandtheoperationwillbeinvalid.
Failureanalysisandtroubleshooting
Item Faultphenomenon Faultcauses Troubleshootingmethods Remarks
1Novoicepromptwhenpower-on,fault,
alarm,self-checking
Buzzerorinternalhardware
circuitisdamaged
Needtoreturntofactoryforrepairing
2
Alarmorgivefaultmessageduring
preheatingprocess
Thesensorisnotstableand
needtopreheat
Waitandconfirmifitstillalarmsor
givesfaultmessageafterpreheating
process
Ifitstillalarmsorgivesfaultmessage
afterpreheatingprocess,itneedsto
returntofactoryforrepairing
3Thecorrespondinglampisnotonwhen
power-on,fault,alarm,self-checking
Thelamporinternalhardware
circuitisdamaged
Needtoreturntofactoryforrepairing
4LCDisalwaysblankscreenandcan
notbeawakenedbyinfraredsensor
hardwarecircuitisdamaged Needtoreturntofactoryforrepairing
5Abnormaldisplayofablurredscreen
andbrokenscreenforLCD
LCDexistsexception Needtoreturntofactoryforrepairing
RepairandMaintenance
Incaseoffailure,pleasedonotremovethedetectorwithoutpermission,theusercannotifyourcompanyorlocalofficeofourcompany,wewill
serveyouassoonaspossible.
Do sandDon t
1. Thisproductshallnotbestoredorusedintheenvironmentcontainingcorrosivegases(suchaschlorine,etc.);
2. Donotputthedetectorinthedecorationenvironment.Pleaseinstallthedetectorinplaceuntilcompletelyfinishtherenovation;
3. Pleasedonotusethenoncalibrationconcentrationofthegastotesttheproductsinceultra-highconcentrationofgas,notonlyaffectthe
lifetimeofthedetectorbutalsoendangerhuman’shealth;
4. Longtermwithoutthepowerofthedetectorneedtopowerrecoverymorethan5hourstonormalapplication;
5. Foryoursafety,pleasecontactthedealer/provider/manufacturertoinspectregularlyonceayearaccordingtotheprovisionsofthegas
samplingandconcentration;Neverusetesttoolswithveryhighpressure(suchaslighter,lightersupplementarygas)todoatesttoavoid
damagingsensor’smoleculesmembranebyover-pressure.
Specialannouncement
1. Pleasereplaceittimelywhentheproductofthesensorexceedstheservicelife(5years).
2. Ourcompanydoesnotundertakeanyresponsibilityforthewarrantywhenoneofthefollowingcircumstancesoccurs:
1) Failuretoinstallandusetheproductnotinaccordancewiththerequirementsofthisspecification;
2) Damageduetoexcessivepowergridvoltageoropeningthehousingwithoutpermission;
3) Damageduetotheuseunderdrench,strongexternalforceorintheenvironmentwhereisnotinconformitywiththespecificationof
environmentaltemperatureorhumidity,highdust;
4) Anyotherdamagescausedbyimproperuse.
SHENZHENFANHAISANJIANGELECTRONICSCO.,LTD
Add:3F,GuangcaiXinTianDiBuilding,NanshanRoad,
NanshanDistrict,Shenzhen,518054,P.R.China
Fax:[phone] Web: www.sanjiang-security.com
E-mail:[e-mail]
