Sante4Life TFT-001 User manual

TM
S
A
N
T
E
4
LIF
Touchless Forehead Thermometer
Model TFT-001

Contact Information
Sante4Life
122–6045 Creditview Road
Mississauga, Ontario
Canada L5V 0B1
Website: http://www.sante4life.com
E-mail: techsuppor[email protected]om
Telephone: [phone] (Toll Free)
[phone] (Greater Toronto Area)
Contents
Safety Precautions ................................................................ 1
Sante4Life Touchless Forehead Thermometer .......... 2
Body Temperature ................................................................ 3
Product Description ............................................................. 5
Using the S4L Touchless Forehead Thermometer .... 6
Key Features ........................................................................... 8
Battery Replacement .......................................................... 10
Care and Cleaning ................................................................ 11
Limited Lifetime Warranty ................................................. 12
Technical Specications...................................................... 14
Ownership Registration ..................................................... 16

1
Safety Precautions
READ THIS USER MANUAL CAREFULLY BEFORE USING THIS DEVICE
* This device must only be used for the purpose described in this
user manual
* This device must be used within its operational temperature
range (10 - 40 oC / 50 -104 oF)
* This device must always be kept and operated in a clean and
dry environment
* DO NOT expose this device to electric shocks
* DO NOT expose this device to extreme temperature conditions
( greater than 50 oC / 122 oF or less than -20 oC / -4 oF)
* DO NOT expose this device to an environment with non-con-
densing humidity higher than 85%
* DO NOT touch the protective glass of the infrared lens with
your ngers or any hard object
* DO NOT expose this device under direct sunlight
* DO NOT submerge this device under water
* DO NOT drop this device as the impact will damage its high
quality precision sensors
* DO NOT attempt to open, repair or calibrate this device

2
Sante4Life Touchless Forehead Thermometer
The Sante4Life Touchless Forehead Thermometer utilizes the latest
advanced infrared technology and is tested in accordance with
international standards. It scans temperature and displays results in
less than one second.
The thermometer scans infrared heat waves released by the tem-
poral artery, which runs across the forehead just below the skin, to
determine body temperature. The thermometer does not touch the
forehead: it scans at a distance of about 3-5 centimetres or 1.2-2
inches away from the forehead. The thermometer does not require
disposable parts because of the non-contact technology.
With one-click scanning, this non-invasive method of scanning tem-
perature is suitable for all ages. It is equipped with many features:
* Large backlit LCD display
* Memory feature to save up to 32 scans
* Audio alarm indicating the end of the temperature scan
* Temperatures scale displayed in either Fahrenheit or Celsius
* Automatic shut-o
The Sante4Life Touchless Forehead Thermometer oers safe, fast and
hygienic scanning. It is accurate, environmentally friendly, easy to
use, and also comes with limited lifetime warranty.

3
Body Temperature
Body temperature taken from dierent sites of the body varies
throughout the day. It is also inuenced by other factors such as
age, sex, gender, and skin tone. If in doubt, seek medical advice
from your physician and mention the temperature taken from the
forehead. The following tables provide the normal temperature
range for sites and age.
Temperature from dierent sites should not be directly compared.
Normal temperature ranges by site:
Site Celsius (oC) Fahrenheit (oF)
Auxiliary 34.7 – 37.3 94.5 – 99.1
Oral 35.5 – 37.5 95.9 – 99.5
Rectal 36.6 – 38.0 97.9 – 100.4
Tympanic 35.8 – 38.0 96.4 – 100.4
Temporal (Sante4Life) 35.8 – 37.8 96.4 – 100.0
Normal temperature according to age:
Age Celsius (oC) Fahrenheit (oF)
0-2 36.4 – 38.0 97.5 – 100.4
3-10 36.1 – 37.8 97.0 – 100.0
11-65 35.9 – 37.6 96.6 – 99.7
> 65 35.8 – 37.5 96.4 – 99.5

4
Note:
* As a person grows older, his or her normal temperature range
tends to decrease.
* Take consideration of physiological variations when evaluat-
ing the results: body temperature increases by 0.5 oC / 0.9 oF
between 6 a.m. and 3 p.m.
* Women, on average, have higher temperatures of around 0.2
oC / 0.36 oF. Their temperature also varies in accordance with
their ovarian cycle. It rises by 0.5 oC / 0.9 oF in the second half of
the cycle and in the early stages of pregnancy.
* Scanning body temperature in a sitting position versus a
standing position could result in temperatures lowered by as
much as 0.3-0.4 oC / 0.54-0.72 oF.

5
Product Description
S
A
N
T
E
4
L
I
F
E
T
M
1
2
34
6
5
SN:00000000
Sante
4
Life
Touchless Forehead Thermometer
TFT-001
2xAA(DC 3V)
3-5 cm / 1.2-2 in
Doisy Enterprises Inc.
TM
Made in China
Model No:
Rating:
Operating Range:
Mississagua, ON L5V 0B1
1
6
10
7
9
8
11
12
13
14
15
16
1Infrared sensor protective glass 9 Speaker
2 Large LCD display 10 Battery compartment
3 Memory recall buttons 11 Temperature
4oC-oF selection button 12 Celsius indicator
5 Scan button 13 Fahrenheit indicator
6 Audio alarm button 14 Memory icon
7 Lable (Model No.) 15 Battery icon
8 Serial number 16 Sound icon

6
Using the S4L Touchless Forehead Thermometer
1. Push back hair and wipe away any perspiration or cosmetics
from forehead
2. Avoid any drafts in the area (e.g. from nasal specs, air condi-
tioning, hot air ow, etc.)
3. Position the thermometer in front of the
forehead over the temporal site, from a
distance of about 3-5 centimetres or
1.2-2 inches
4. Press the SCAN button and wait for
the immediate beep sound
5. Read the temperature on the LCD
display. The scanned temperature is
saved in the device memory (up to
32 scans)
The LCD display automatically shuts o after 5 seconds.
Caution:
* The reliability of the scan may not be accurate if the temper-
ature is taken from another part of the body (e.g. arm, torso,
etc.)
* When there is a signicant or sudden change in the ambient
temperature, this device may take up to 20 minutes to acclima-
tize to the new ambient temperature.
* It is recommended to have a one minute interval between
scans.
* After replacing the batteries, wait 10 minutes before use.

7
* High, prolonged fever requires medical attention, especially in
young children. Contact your physician should this occur.
* Temperature scans must not be taken after vigorous physical
activity, such as immediately after exercise or bathing, and the
room temperature must be moderate.
* Health Canada issued an advisory that the use of infrared
thermometer in children under two years is not recomended.
For older children infrared thermometers should not be used
to manage important health concerns.

8
Key Features
Abnormal Body Temperature Alarms
For scanned body temperature
over 42.9 oC or 109.2 oF, the LCD
displays“Hi” with 5 audio beeps.
For scanned body temperature
under 32oC or 89.6oF, the LCD dis-
plays“Lo” with 1 audio beep.
Audio Alarm
Pressing the side button of the thermometer can
turn the audio alarm on or o. The audio
alarm sounds once the temperature scanning is
completed.
oC-oF Scale
Pressing the oC/oFbutton will change the temper-
ature reading to Celsius and Fahrenheit as desired.
Automatic Shut-O
The LCD display automatically shuts o after 5 seconds to save bat-
tery power.
oC/oF
M
M

9
Memory Recall
The thermometer comes with a memory capacity able to store up
to 32 scanned temperatures. Once the memory is full, the memory
will automatically cycle.
Pressing Mbutton displays the most recent
stored temperature. Pressing it again will display
the second most recent scanned temperature, and
so on.
Pressing Mbutton displays the earliest or rst
stored temperature. Pressing it again will display
the second stored temperature, and so on.
o
C/oF
MM

10
Battery Replacement
If LCD displays the low battery icon, or there is no response or dis-
play on the LCD, the battery must be replaced:
1. Open the battery cover at the bottom of the thermometer
2. Remove the old batteries for disposal
3. Replace with 2 new AA alkaline batteries
4. Slide battery cover back until it snaps in place
Wait 10 minutes before using thermometer
Note:
* The thermometer comes with two AA alkaline batteries.
* Use new single usage AA alkaline batteries only. Do not use
re-chargeable batteries.
* Remove the batteries when thermometer is not used for an
extended period of time.
* To protect the environment, dispose of used
batteries at appropriate collection sites accord-
ing to national or local regulations.
+
-
-
+
1
2
3
1
2
OPEN CLOSE

11
Care and Cleaning
The protective glass is the most fragile part of the thermometer,
and great care must be taken when cleaning the glass. With normal
use, it is not required to be clean regularly unless it is contaminated
by touching or spilling. If this is the case, following the cleaning
procedure:
* Very gently wipe the glass with cotton cloth or swab, mois-
tened with alcohol (95% isopropyl)
* Use a soft, dry cloth to clean the thermometer display and
exterior. Do not use abrasive cleansers. Never submerge the
thermometer in water or any other liquid
* Store the thermometer in a dry location free from dust and
contamination and away from direct sunlight

12
Limited Lifetime Warranty
Sante4Life (S4L) warrants this product to be free from defects in
workmanship and material, under normal household use, for the
life of the original owner. A purchase receipt or other proof of date
of original purchase is required before warranty service is per-
formed. S4L’s obligation under this warranty is limited to replacing
or repairing, at S4L’s option, the product through its service center.
This warranty does not cover normal wear of parts or damage re-
sulting from a negligent use or misuse of the product, use contrary
to the operating instructions, failure to provide reasonable and
necessary maintenance, or disassembly, repair or alteration the
product. Further, the warranty does not cover damage resulting
from Acts of God, such as re, ood, hurricanes and tornadoes. For
warranty service, S4L is not responsible for shipping cost and there
is a handling charge for replacement. Please visit S4L website for
more details.
Limitation and Exclusions
To the extent permitted by applicable law, the liability of S4L, if any,
for any allegedly defective product or part shall be limited to repair
or replacement of the product or part and shall not exceed the
purchase price of a comparable replacement product or part. THE
PROVISIONS OF THIS WARRANTY ARE YOUR SOLE AND EXCLUSIVE
REMEDY WITH RESPECT TO THE PRODUCT(S) COVERED BY THIS
WARRANTY. ALL IMPLIED WARRANTIES WITH RESPECT TO THE
PRODUCTS(S) INCLUDING, BUT NOT LIMITED TO, IMPLIED WAR-
RANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE HEREBY EXPRESSLY EXCLUDED.
S4L is not responsible or liable for indirect, special or consequential
damages arising out of or in connection with the use or perform-

13
ance of the product or damages with respect to any economic loss,
loss of property, loss of revenues or prots, loss of enjoyment or use,
costs of removal, installation or other consequential damages of
whatsoever nature. Some provinces/states do not allow the exclu-
sion or limitation of incidental or consequential damages. Accord-
ingly, the above limitation may not apply to you.
Warranty Service
If you have any question regarding this warranty or would like to
obtain warranty service, please following these steps:
1. Consult with the store that you purchased your product
2. Visit our website to obtain more information of the product:
http://www.sante4life.com
3. Email our technical support team at techsupport@sante4life.
com or write a letter explaining the problem with the following
information - your name, address, contact telephone number,
email address, and a copy of the original receipt
4. Call us on our toll free number 1 [phone] or 1 (905) 267-
2384 (Greater Toronto Area)
You the buyer may have other rights and remedies under your
state’s or province’s applicable laws, which are in addition to any
right or remedy may be available under this limited warranty.

14
Technical Specications
Display Range
Body 32.0 - 42.9 oC 89.6 - 109.2 oF
Display resolution 0.1 oC 0.1 oF
Precision
32.0 - 35.9 oC
89.6 - 96.7 oF±0.3 oC ± 0.6 oF
36.0 - 39.0 oC
96.8 -102.2 oF±0.2 oC ± 0.4 oF
39.1 - 42.9 oC
102.4 -109.2 oF±0.3 oC ± 0.6 oF
Operating ambient
temperature range 10 - 40 oC 50 - 104 oF
Scan distance 3 - 5 cm 1.2 - 2.0 in.
Functional
Auto Power O 5 seconds
Scanning Completion Alarm 1 beep
High Body Temperature Alarm 5 beeps
Low Body Temperature Alarm 1 beep
Power
Battery 2 AA batteries
Range 3V DC
Consumption < 150mW

15
Physical
Size (L x W x H) 175 x 50 x 52
mm
6.9 x 2.0 x 2.0
in.
Weight (with batteries) 148 g 5.2 oz
Weight (without batteries) 100 g 3.5 oz
International standards
(Certied or Approved)
• ISO 13485:2003 CMDCAS
• CE
• ASTM Standard 1965-1998
(2009)
• IEC60601-1-2 (EMC)
• EN60601-1 (Safety)

16
Ownership Registration
Please register online at:
http://sante4life.com/register/
The registration will enable Sante4Life to
inform you in the unlikely event of a product
safety notication, to update you with addi-
tional product information, and to provide a
warranty service. By registering online, you
acknowledge that you have read and understood the instructions
for use, and warnings set forth in the accompanying instructions.
To register, you need:
* Serial number of your thermometer
* Model number
* The store name where you purchased the thermometer
* Your name, address, e-mail address, and contact phone
number(s)
* Date of purchase
