Assembly Instructions for Model: AFDV
Thank you for choosing the Sanus Systems Model AFVD. The AFVD three
shelf audio stand is designed for basic systems. Every effort has been made to
ensure that your Sanus Systems furniture is perfect. If you have questions or
feel that there is a problem of any kind, please contact us at 800-359-5520 or
at www.sanus.com. We can quickly help with any issues regarding assembly
or missing parts. Replacement parts for Sanus systems products purchased
through authorized dealers will be shipped directly to you.
Supplied Parts List:
Top Bolt - F
Qty. 4
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 1.18.06 (100004)
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com
Wire Hole Bushing - D
Qty. 2
9” Pillar - A
Qty. 8
3” Pillar - B
Qty. 4
Foot Pad - C
Qty. 4
Shelf Connector - E
Qty. 8
Top Shelf - G
Qty. 1
Allen Key - I
Qty. 1
Lower Shelf - H
Qty. 2

Step 1 - Assemble the four 3” Pillars
Hand thread a Foot Pad (C) into each of the four 3” Pillars (B); then, hand thread one Shelf Connector (E) into each 3”
Pillar.
C
E
B
Step 2 - Insert four 3” Pillars into Lower Shelf
Insert the four 3” Pillars from Step - 1 into one Lower Shelf (H).
Diagram 2
H
3” Pillar
3” Pillar

Step 3 - Assemble four 9” Pillars
Hand thread one Shelf Connector (E) into four of the 9” Pillars (A).
Diagram 3
A
E
Step 4 - Assemble Lower Shelves
Hand thread the 9” Pillars (A) with Shelf Connectors (E) onto the threaded portion of the Leg Assemblies.
Place a Shelf (B) onto the four 9’’ Pillars.
Screw the 9” Pillars (A) with without Shelf Connectors (E) onto the threaded portion of the 9 “ Leg Assemblies..
Diagram 4
A
H
A
H
A
A
A
E
H
E
H

Step 5 - Add Top Shelf
Place the Top Shelf (G) on the four 9” Pillars (A); then, using the four Top Bolts (F), secure the Top Shelf to the 9” Pillars.
Diagram 5
Step 6 - Install Wire Hole Bushings
Press a Wire Hole Bushing (D) into each of the holes in the back of the Lower Shelves (H).
Diagram 6
