Assembly Instructions for SFV49
Thank you for choosing the Steel Furniture line from Sanus Systems. If you have any questions regarding this or any other Sanus
Systems product, please contact us at 800.359.5520 or visit us at www.sanus.com. Our customer service representatives can assist you
quickly with any issues regarding assembly or missing parts. Check carefully to make sure none of the parts are missing or defective.
Never use defective parts. Replacement parts for products purchased from an authorized dealer will be shipped directly to you. Please
call Sanus Systems before returning products to retail stores.
Parts and Hardware:
(1) Front Frame - a
(1) Upper Brace Bar - e
(1) Back Frame - b
(4) Lower Brace Bar - f
(1) Top Glass Shelf - c
(2) Glass Shelf - d
Step 4: Installing Glass Shelves
Evenly place 4 Glass Protectors (k) along the top, 3 along the middle crossbar and 3 more along the bottom crossbar of the Front Frame
(a) as shown in the Detailed View of Diagram 4. Next, place a Glass protector on the back of each Lower Brace Bars (f). Then, evenly
place 4 Glass protectors on the top of the Back Frame (b). Next, place the Top Glass Shelf (c) on the top of the Front and Back Frame.
Finally, place the two Glass Shelves (d) so they rest on the Lower Brace Bars and the crossbars on the Front Frame. See Diagram 4 for
assistance.
Detailed View
c
k
a
Diagram 4
c
k
k
crossbar
d
k
Sanus Systems 2221 Hwy 36 West. St. Paul, MN 55113
800.359.5520 www.sanus.com 8.06.04
Sanus Systems 2221 Hwy 36 West. St. Paul, MN 55113
800.359.5520 www.sanus.com 8.06.04

Hardware: Shown at actual size
(10) Short Allen Bolt - g (5) Long Allen Bolt - h (5) Washer - i
(4) Foot - j (18) Glass Protector - k (1) Allen Key - l
Step 1: Install Feet
Thread 2 Feet (j) into the bottom of the Front Frame (a) as shown in Diagram 1. Thread the remaining two Feet into the bottom of the
Back Frame (b). Thread all 4 feet in until they bottom out in the frame.
Note: Once the stand is assembled, the Feet can be adjusted to level the stand if needed
Diagram 1
Detailed View
a
j
Step 2: Attach Brace Bars to Front Frame
Thread a Short Allen Bolt (g) through each hole in the Upper Brace Bar (e) until the bar is secured to the top of the Front Frame (a).
See Detailed View A of Diagram 2 for assistance. Proceed to thread a Short Allen Bolt through each hole in the Lower Brace Bars (f)
so each bar is secured to the Front Frame. See Detailed View B of Diagram 2 for assistance. Do not fully tighten the Short Allen Bolts
at this time.
Detailed View A
Diagram 2
a e g
Detailed View B
a f g
Step 3: Attach Back Frame
Thread a Long Allen Bolt (h) through a Washer (i), the Back Frame (b), and into the back of the Brace Bar (e,f) as seen in Diagram 3.
Repeat process for each of the four remaining Long Allen Bolts. Make sure the stand is square and level. Once everything is positioned
correctly, proceed to tighten all of the Long Allen Bolts as well as the Short Allen Bolts (g) from Step 2 with the Allen Key (l) until they
are tight.
Diagram 3
i h
