Hardware: Shown as actual size
(16) Cam Pin - a (6) Dowel Pin - c (16) Dowel - d (32) Shelf Pin - e
(16) Cam - b
(8) Wood Screw - f
(6) Spacer - g (4) Phillips Bolt - h (2) Door Handle - i*
(8) Hinge Screw - j (8) Hinge Plate Screw - k
Parts: Not Shown as actual size (4) Hinge - l* (4) Hinge Plate - m*
(4) Front Stretcher - o (4) Back Stretcher - p
(1) Top - n
Assembly Instructions for Model: WFAV44
Thank you for choosing Sanus Systems Woodbrook Furniture. The Woodbrook Furniture is
constructed of real hardwood and resonance dampening MDF.
Safety Warning: If you do not understand these directions, or have any doubts about the
safety of the installation, please call a qualied contractor or contact Sanus at 800.359.5520 or
www.sanus.com. Check carefully to make sure that there are no missing or defective parts. Our
customer service representatives can quickly assist you with installation questions and missing
or damaged parts. Replacement parts for products purchased through authorized dealers will be
shipped directly to you. Never use defective parts. Improper installation may cause damage or
serious injury. Do not use this product for any purpose that is not explicitly specied by Sanus
Systems. Sanus Systems can not be liable for damage or injury caused by incorrect assembly, or
incorrect use. Please call Sanus Systems before returning products to the point of purchase.
Required Tools: Phillips screw driver
Supplied Parts and Hardware: Some parts may be pre-assembled together*
Sanus Systems 2221 Hwy 36 West, St. Paul, MN 55113 12.28.05
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com

Parts List (Cont)
(2) Bottom Shelf - q (6) Mid Shelf - r
(2) Door - s (2) Wood Panel Insert - t (2) Back Panel - u
(1) Left Side Panel - v (1) Right Side Panel - w (1) Center Panel - x
Step 1: Prepare the Side Panels and Center Panel
Thread a Cam Pin (a) into each of the smaller holes in each Panel (v,w,x). Tighten each Cam Pin with a Phillips screw driver. Insert a
Dowel (d) into the larger adjacent hole in the Panels. See Diagram 1 for assistance. Note: Center Panel not shown in Diagram 1.
Detailed View Diagram 1
v
a
d

Step 2: Prepare Stretchers
Add a Cam (b) to each Front Stretcher (o) and Back Stretcher (p). Make sure the arrow in each Cam faces the hole on the side of the
Stretchers. See Diagram 2 for assistance.
Diagram 2
Detailed View
o
a
arrow
p
Step 3: Add Stretchers
Add the Front and Back Stretchers (o,p) to the Side Panel (v), by aligning the Cam Pin (a) with the hole which the Cams (b) point to
and the Dowel (d) goes into the adjacent hole. Make sure the stretchers are oriented so the Cams face inward. Tighten each Cam closest
to the Side Panel in a clockwise motion until the stretchers are secured. Note: Front stretchers attach to the same side as the
hinge holes are on.
Diagram 3 Detailed View
v
d
b
hinge a
holes
p

Step 4: Add Center Panel
Press t the Center Panel (x) against the Stretchers (o,p) so the Cam Pin (a) goes into the hole which the Cams (b) point to. The Dowel
(d) ts into the adjacent hole. Tighten each Cam in a clockwise motion until the Stretchers are secured to the Center Panel. See Diagram
4 for assistance. Note: Make sure the hinge holes on the Center Panel are on the same side as the Front Stretchers.
Diagram 4 Detailed View
p
b
a
o
x
hinge d
holes
Step 5: Add Stretchers
Add the Front and Back Stretchers (o,p) to the Center Panel (x), by aligning the Cam Pin (a) with the hole which the Cams (b) point to.
The Dowel (d) goes into the adjacent hole. Make sure the stretchers are oriented so the Cams face inward. Tighten each Cam closest to
the Center Panel in a clockwise motion until the stretchers are secured. Note: Front stretchers attach to the same side as the
hinge holes are on.
Diagram 5 Detailed View
x
a
b
d
hinge
holes p

Step 6: Add Side Panel
Press t the Side Panel (w) against the Stretchers (o,p) so the Cam Pin (a) goes into the hole which the Cams (b) point to. The Dowel (d)
ts into the adjacent hole. Tighten each Cam in a clockwise motion until the Stretchers are secured to the Side Panel. See Diagram 6 for
assistance. Note: Make sure the hinge holes on the Side Panel are on the same side as the Front Stretchers.
Diagram 6
Detailed View
p
b
a
o
w
Step 7: Add Shelf Pins and Bottom Shelf
Thread the Shelf Pins (e) into the bottom hole in the line of holes in each Panel (v,w,x). Tighten Shelf Pins with a Phillips screw driver.
Add the Bottom Shelf (q) by inserting it into the assembly and press t it onto the Shelf Pins. Make sure the Bottom Shelf is ush against
the Front Stretcher (o). If there is a gap in the front, the shelf may be backward. See Diagram 7 for assistance. Note: Diagram 7 is a Back
View.
Detailed View
Diagram 7
x
w
v
e
q

Step 8: Add Top
Gently tap a Dowel Pin (c) into the holes on the top of each Panel (v,w,x). Slide a Spacer (g) over each Dowel Pin. Press t the Top (n)
so it ts onto the Dowel Pins. See Diagram 8 for assistance.
Diagram 8 Detailed View
n
c
g
w
Step 9: Prepare Doors
Insert each Phillips Bolt (h) through the Door (s) and into they Door Handle (i). Tighten with a Phillips screw driver. See Diagram 9a
for assistance. The Door Panels can be interchanged by removing and re-installing the plastic border from the perimeter of the Door’s
back side.
Insert a Hinge Screw (j) through the Hinge (l) and thread it into the Door (s). Tighten each with a Phillips screw driver. Repeat process
until each Hinge Assembly is secure. See Diagram 9b for assistance.
Diagram 9a Diagram 9b
Detailed View Detailed View
h
i
s s l j

Step 10: Door Install
Position the Door (s) so the holes in the Hinge Plate (m) line up with the front pair of holes in the Side Panel (v,w). Insert a Hinge Plate
Screw (k) through the Hinge Plate and thread it into each hole in the Side Panel. Tighten with a Phillips screw driver. Repeat process so
each Hinge Assembly is secured. See Diagram 10 for assistance.
Detailed View
Diagram 10
s
m
k
v
Step 10: Add Mid Shelves
Thread a Shelf Pin (e) into the desired location in the Panels (v,w,x). For each shelf, four Shelf Pins will be required. Insert each Mid
Shelf (r) into the assembly and press t onto the Shelf Pins. Make sure the wood strip on each shelf is facing toward the front. See Dia-
gram 10 for assistance. Note: Diagram 10 is a Back View.
Detailed View Diagram 10
v x
w
e
r
