Sanus Systems EFVS-II User manual

Assembly Instructions for Model: EFVS-II
Thank you for choosing the Sanus Systems Model EFVS-II. Every effort has
been made to ensure that your Sanus Systems furniture is perfect. If you have
questions or feel that there is a problem of any kind, please contact us at
800-359-5520 or at www.sanus.com. We can quickly help with any issues
regarding assembly or missing parts. Replacement parts for Sanus systems
products purchased through authorized dealers will be shipped directly to you.
Supplied Parts List: (Threaded fasteners are shown full size)
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 2.07.06 (100014)
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com
Shelf Connector - C
Qty. 5
8˝ Pillar - A
Qty 5
Video Shelf - B
Qty. 1
Wire Bushing - D
Qty. 2

NOTE: Step 1 is necessary only if the EFAV-II assembly has been previously completed.
Step 1 - Remove existing Top Video Shelf
Remove the ve Top Bolts and Top Video Shelf. Place the Video Shelf on a smooth soft surface, such a carpeted oor.
Diagram 1
C
Top Bolt
Step 2 - Install Shelf Connectors
Thread a Shelf Connector (C) securely into the ve 8˝ Pillars.
Diagram 2
Top Bolt
8˝ Pillar
Top Video Shelf
C
C
8˝ Pillar
8˝ Pillar

Step 3 - Place a Video Shelf on 8˝ Pillars
Place the next Video shelf on the 8˝ Pillars.
Thread a new 8˝ Pillar (A) onto each Shelf Connector (C) and rmly hand tighten.
Diagram 3
A
Video
Shelf
C
Step 4 - Secure new Top Video Shelf to 8” Pillars
Place the new Video Shelf (B) on the new 8˝ Pillars (A); then, using an Allen Key and the ve Top Bolts, secure the new
Video Shelf to the new 8˝ Pillars.
Install the two new Wire Bushings (D).
Diagram 4
8˝ Pillar
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 2.07.06 (100014)
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com
Top
Bolt
D
A
B
Top
Bolt
A
