Sanuvox SABER PRO WIRELESS 24V User manual

Sanuvox Technologies Inc, © 2019 All rights reserved. January 2020 EN v.1
Instruction Manual
Photos illustrating products are non contractual.
SABER PRO WIRELESS 24V
UV COIL CLEANER WITH WIRELESS LCD DISPLAY
Residential Model
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE USING THIS PRODUCT.
Read and follow all instructions contained in
this manual before using the product. Failure
to comply with these instructions may result
in personal injuries or damage to the unit or
system.
1. Installation and servicing of air conditioning
and related equipment can be hazardous due
to systems pressure and electrical components.
Only trained and qualied service personnel
should install, repair or service equipment.
2. Untrained personnel can perform basic
maintenance functions such as replacing
lamp(s) and/or lter(s). All other operations
should be performed by trained service
personnel.
3. When working on the unit or system, observe
precautions in the literature, tags and labels
attached to the unit or system, and all other
safety precautions considered as best practices
in the HVAC industry.
4. When applicable, local regulation may
comprise more restrictive installation and/or
certication requirements. The afore mentioned
requirements prevail on those of this document
and the installer agrees to conform to these at
his own expense.
5. Follow all the safety instructions outlined in this
document and respect all local and national
codes applicable.
6. Never expose eyes or skin to ultraviolet light
from any source. Therefore, before installing
or performing maintenance on the unit or
system, TURN OFF AND DISCONNECT the
unit or system from all power sources (there
may be more than one switch to disconnect).
CAUTION: Electrical shock may cause
personal injuries or possibly death.
7. UV rays may destroy certain types of lters
(polymer or plastic); please keep the unit or
system light away from shining directly on
plastic.
8. When installing or performing maintenance on
the UV unit or system, it is recommended to
wear safety glasses and gloves. In order to
avoid reduced performance of lamp(s), do not
touch lamp glass without gloves.
9. UV lamps contain a small quantity of mercury:
if a lamp breaks, clean and dispose of with
care. UV lamps can be disposed/recycled after
use, as any other uorescent lamps. Contact
and follow your local and national authorities’
specic instructions.
10. Use only specied SANUVOX branded
replacement UV lamps with your unit or
system. Use of any other lamps will void your
warranty and can result in damage to the unit,
system and/or lamp(s).
11. Most UV units or systems are not waterproof.
DO NOT INSTALL OUTDOORS unless
specied otherwise.
SAVE THESE INSTRUCTIONS
Installation Date: _______________ Installed by: _________________
Installer Contact Info.: _________________________________________
REGISTER
YOUR WARRANTY
ONLINE AT
www.sanuvox.com

2
Instruction Manual for SABER PRO WIRELESS 24V
1-888-726-8869www.sanuvox.com
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS 1
TABLE OF CONTENTS 2
ABOUT THE PRODUCT 3
COMPONENTS 3
How it Works 3
ACCESSORIES & KITS 3
SETUP & INSTALLATION 4
What you will need 4
What’s included 4
Step by Step Setup & Installation 4
OPERATION 7
How to Operate your Product 7
How to Read the Ballast Display 7
How to Read the LCD Wireless Display 7
How to Reset your Product and its Lamp Timer 8
Step by Step Product and Lamp Timer Reset 8
MAINTENANCE 8
How to Replace Lamp(s) 8
Step by Step Lamp Replacement 8
How to Clean your Product 9
STORAGE 9
ULTRAVIOLETS: UVC 9
ELECTRICAL RATINGS, POWER CONSUMPTION & AVAILABLE VOLTAGE 9
Regulations of the LCD Wireless Display 9
TROUBLESHOOTING 10
What you will need 10
Problems & Solutions Table 10
A. Step by Step UV Lamp Continuity Test 11
B. Step by Step Pairing of the LCD Wireless Display 11
WARRANTY 12
CUSTOMER SERVICE 12

A
D
B
E
C
F
3
Instruction Manual for SABER PRO WIRELESS 24V
1-888-726-8869www.sanuvox.com
ABOUT THE PRODUCT
The SABER PRO WIRELESS 24V coil cleaner prevents and destroys mold and other microbial growth on the coil and its
surrounding areas.
For information or recommendations on how to size your specic application, please call SANUVOX at 1-888-726-8869.
COMPONENTS
How it Works
When a bio-lm (a coating of microbial growth) covers a coil, it acts as an adhesive, attracting dirt and coating the ns of the
coil. This results in an odor emanating from the equipment and a loss in energy efciency as the equipment must work harder
to provide the same air temperature. Installed on the air conditioning’s evaporator coil, the SABER PRO WIRELESS 24V keeps
the system running at top efciency, saving you electricity and preventing the coil from becoming a source of bad air quality and
bad odor.
A. 16" UVC Lamp
B. Main Bracket
C. Magnetic Multi-Bracket
D. Lamp Retaining Ring
E. Ballast
F. LCD Wireless Display
ACCESSORIES & KITS
The following optional accessories and/or kits work great with your product (sold separately).
Step Down Transformer (AC)
A transformer to convert a regular outlet (120 VAC) to
24 VAC.
For instruction manuals or information about your optional accessories and/or kits, please call SANUVOX at 1-888-726-8869
or visit www.sanuvox.com.

4
Instruction Manual for SABER PRO WIRELESS 24V
1-888-726-8869www.sanuvox.com
SETUP & INSTALLATION
What you will need
A utility knife to unpack all components, a Phillips # 2 screwdriver, a nut driver or socket ¼", a measuring tape, a marker and a
power drill with a metal bit.
CAUTION: Handle your product with care to avoid breaking parts. Make sure you have a free and safe space to unpack,
install and setup your product. Conrm you have access to the necessary power source for the product requirements (see unit
or system label). If you have any questions regarding the installation instructions, call SANUVOX at 1-888-726-8869.
What’s included
The ballast, the LCD wireless display with 2 AA batteries, 2 UV lamps and a basic installation kit.
The installation kit includes: a UV caution decal, a maintenance decal, a pair of cotton gloves, screws, a plastic view port, the
main bracket, a magnetic multi-bracket and a lamp retainer ring.
Step by Step Setup & Installation
Check out Sanuvox Technologies YouTube Channel
for the SABER PRO WIRELESS 24V
installation video!
1. Prepare the SABER PRO WIRELESS 24V for installation.
Remove the contents from packaging.
CAUTION: Before installing or performing maintenance on the unit
or system, TURN OFF AND DISCONNECT the HVAC unit or system
from all power sources (there may be more than one switch to
disconnect).
2. Check install location of the ballast, so that there is sufcient cable to
attach to the UV lamp when it is installed.
STEP 1
STEP 2

5
Instruction Manual for SABER PRO WIRELESS 24V
1-888-726-8869www.sanuvox.com
3. The main bracket can be mounted to the side of the duct allowing the
UV lamp to be inserted in-between or over the A coil.
Drill a 1" diameter hole in the sheet metal to allow the UV lamp to pass,
and mount the main bracket to the side of the duct using the 2 included
sheet metal screws. Once installed, use the round metal washer to lock
the lamp in place. Then tighten the 2 screws with care.
4. Plug the connector onto the lamp pins. The plug is designed so that
it can only be installed one way. You may have to rotate the socket 90°
to line up the pins with the holes.
STEP 3
STEP 4
STEP 5
STEP 6
5. Drill a 0.25" hole on the outside of the plenum and install the view port.
When the lamp is ON, the glow of the lamp will be visible through this port.
6. Connect the two black wires to the 24 VAC terminals on the HVAC
equipment.
NOTE: Make sure that the HVAC equipment can at least supply 20 VA.
If not, we recommend the use of a dedicated transformer that provides
24 VAC with a minimum of 20 VA, otherwise it will not be sufcient to power
the ballast and lamp. An alternative is to use a step down transformer
24 to 27 VA on a 120V plug.
STEP 7
7. And nally, reconnect power to the HVAC unit or system, or plug in the
transformer in a power outlet.
