Sanyo DWM-4500 User manual

FILE NO.
Service Manual
CONTENTS
DVD Home Theater
System
DWM-4500 (US)
DC-TS830WL (CA)
PRODUCT CODE No.
129 712 00 US
129 712 04 CA
REFERENCE No. SM5810712
Laser beam safety precaution .......................................... 1
DVD Mechanism Replacement ........................................ 1
Service mode ................................................................... 2
Important Note ................................................................. 4
How to load software for MPEG P.W.Board .................... 4
Cautions for PWB or IC assy exchange ........................... 4
How to attach gear rack ................................................... 4
How to take out a disk ...................................................... 4
Tuner adjustment ............................................................. 5
Exploded View (Cabinet & Chassis Main unit) ................. 6
Parts List .......................................................................... 7
Exploded View (Cabinet & Chassis Rear speaker) .......... 12
Parts List .......................................................................... 13
Exploded View (Cabinet & Chassis Subwoofer speaker) 16
Parts List .......................................................................... 17
Wiring Connection ........................................................... 22
IC Block Diagram & Description ....................................... 25
Schematic Diagram .......................................................... 38
Wiring diagram ................................................................. 52

- 1 -
LASER BEAM SAFETY PRECAUTION
• Pick-up that emits a laser beam is used in this CD player section.
1. Cautionary instructions in handling the assy
(Safety instructions)
Optical pickup
The laser beam used in the pickup is classified as "class 2". Ex-
posing your eyes or skin to the beam is harmful. Take care not to
do so.
(Caution against static electricity and leakage voltage)
Ground securely the work tables, tools, fixtures, soldering irons
(including those made of ceramic) and measuring instruments used
in the production lines and inspection departments that handle load-
ers. The workers shall also be grounded.
(Cautionary instructions in handling)
Do not touch the object lens when handling a loader, or the lens
will be stained, resulting in inadequate playability.
There is no power supply protection circuit provided for this prod-
uct or adjustment/inspection device. Short-circuiting may lead to
fire or damage.
Take care so as to protect from exposure to water, the entry of
metallic pieces or dew condensation.
In particular, a strong magnet adjacent to the pickup will not only
get inoperative but can damage the pickup if a small metallic piece,
such as a screw or swarm, enters.
The loader edge can cause injury if inadvertently handled.
Do not touch a rotating disk, or injury may result.
This product is a precision device. Handle carefully.
A shock or dropping will cause misalignment or destruction. If it
should occur, refer to clause 2.
This product is so designed as to endure an initial shock equiva-
lent to a drop from a height of approx. 90 cm under the packed
condition.
After the initial shock, the resistivity will still remain at a level of 50
to 60 G, but the mechanical robustness will weaken.
Do not place in a dusty location.
The entry and deposition of dirt into or on the pickup lens or mov-
ing section will cause malfunction or degradation.
(Connectors)
Do not connect or disconnect while power is on.
Connecting or disconnecting signal wires or the main power cord
when the power is on may destruct the unit or fixture.
When connecting, push all the way in securely.
An insufficient insertion may cause a bad contact, leading to an
erroneous operation.
Do not connect or disconnect roughly by an excessively strong
force, or a broken wire or bad contact may result.
Semiconductors are connected. Do not touch connector terminals
directly.
DVD MECHANISM REPLACEMENT
If the worker is grounded, there is nothing to worry about static
electricity, but the rust on the connector terminal surface caused
by the touch may result in bad contact.
(Caution)
Before disconnecting FFC
cable from mechanism, make
it "SHORT" as shown left.
After connecting FFC
cable to mechanism, make it
"OPEN" as shown left.
Before disconnecting FFC
cable from main p.w.b, make
it "SHORT" as shown left.
After connecting FFC
cable to main p.w.b, make it
"OPEN" as shown left.
INTERFACE P.W.BOARD
(Power source)
The power source need be good in quality (free from instantaneous
interruptions or noises).
A low quality power source may well cause malfunction.
(Storage)
Do not place or store in a dusty place or a place where dew con-
densation is possible.
The entry and deposition of dirt or dust into or on the pickup lens or
moving section will cause malfunction or degradation.
Also, dew condensation causes rust; the rust penetrate into the
precision part of a pickup, causing malfunction, or degrading the
optical quality of the internal lens and reflector, which also leads to
malfunction.
OPEN
SHORT
CAUTION :
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE
LASER OUTPUT.......... 0.6 mW Max. (CW)
WAVELENGTH ............. 790 nm
F- F+
T+
T-
C
DCD/DVD
RF
A
B
F
VC
VCC
E
VR-CD
CR-DVD
LD-CD
MD HFM
LD-DVD
GND
JCX-TS800
INTERFACE PWB
CN661 CN662
CAN
CAN
Short
Open

- 2 -
SERVICE MODE
Region1 MarketWM
Back end Version
S40723A0
LoaderVersion 03.01.20.28
of Service mode displayVersion
Vaddis 6
Screen of Iinternal Setup
Internal Setup
Market WM
Region 1
Exit
00-WM 01-SFC 02-CA 03-EUR 04-EUS
05-EUC 06-DER 07-DES 08-DEC 09-AU
10-SS 11-PA 12-NTX 13-CN 14-JP
00
Market Setting
Internal Setup
Market 00
Region 1
Exit
00-WM 01-SFC 02-CA 03-EUR 04-EUS
05-EUC 06-DER 07-DES 08-DEC 09-AU
10-SS 11-PA 12-NTX 13-CN 14-JP
13
A. Market / Region SETUP
In the initial condition for this model, Market and Region
information are undefined.
In the following cases, be sure to set up Market/Region.
1. When updating the system using CD-R
(Part code : 0PRADC9705--AC).
2. When replacing a DVD substrate.
While Market/Region information are undefined,
the message "Region Undefined" is displayed on the screen.
NOTE: Even if the condition is not under 1 or 2 above, if the
message "Region Undefined" is displayed, be sure to
set up Market/Region.
B. How to enter Service Mode.
1. Using the buttons on the main unit
1-1. Display on "No Disc" by Function button.
1-2. Immediately (within one second) after pushing
stop button both and power buttons
simultaneously , push play button.
RegionUndefined
Undefined Market/Region display
C. Setup Procedures
1. Displaying SERVICE MODE screen
Display Service Mode screen following the instructions
"How to enter Service Mode" above.
2. Displaying Internal Setup screen
Push PRESET+/NEXT button within three seconds
after operating the
Service Mode display.
On the Internal Setup screen shown on the right,
set up Market and Region.
3.1. While a highlighted indicator is displayed on the right
side of the Market denotation, push numeric buttons
on the remote controller.
When you push wrong number , push CLEAR button.
(The indicator reset to "00")
Be sure to input by double figures.
Market code of WM model is "00", and CA model is "02".
3.2. Specify the code of the model in accordance with the
Market/Region Setup Table above.
3.3 Once the desired code is displayed, push button to
move the highlighted indicator to the Region input area.

- 3 -
SERVICE MODE
Region Setting
Internal Setup
Market 00
Region 1
Exit
00-WM 01-SFC 02-CA 03-EUR 04-EUS
05-EUC 06-DER 07-DES 08-DEC 09-AU
10-SS 11-PA 12-NTX 13-CN 14-JP
1
Internal Setup
Market 00
Region 1
00-WM 01-SFC 02-CA 03-EUR 04-EUS
05-EUC 06-DER 07-DES 08-DEC 09-AU
10-SS 11-PA 12-NTX 13-CN 14-JP
Exit
Save of Setting Data
Region1 Market WM
Back end Version S40726A6
LoaderVersion 03.01.20.28
SettingVersion of
display
Vaddis6
4. Setting REGION code
4.1 While a highlighted indicator is displayed on the right
side of the Region denotation, push ENT, and each
button on the remote controller. With each push the
indicator will advance as shown below.
1 <-> 2 <-> 3 <-> 4 <-> 5 <-> 6
4.2 Set up the region coder currently displayed on the set.
4.3 Once the desired number is displayed, push button to
move the highlighted indicator to Exit area.
5. Saving settings
5.1 Make sure that the Market and Region settings are
properly set.
(If any of the settings are incorrect, you can make a
change by moving the indicator using button, and
following procedures 3 and 4 above. )
5.2 After ensuring that the settings are all correct, push
ENT button while the indicator is on Exit area.
The settings are now saved.
6. Finishing settings
6.1 After a few seconds, the Internal Setup screen
disappears, and then the Service Mode screen is
displayed again for three seconds as shown on the right.
You should check the settings.
6.2 Power OFF.
Backendversion S 40726 A 6
Brand (S : SANYO , F : FISHER)
Version ( 2 0 0 4. 7. 26 )
Sub Version (A,B,......Z)
Region ( 0 : Region undefined
1 ~ 6 : Region defined )
The region coder of US and CA is 1.
4.2 Set up the region coder currently displayed on the set.4.2 Set up the region coder currently displayed on the set.

- 4 -
SERVICE MODE
D. IMPORTANT NOTE
1. Once the "Market/Region" settings are written into EEPROM (IC810) on the DVD substrate, they cannot be reset.
(However, updating the system using CD-R enables you to make new settings.)
2. While the Internal Setup screen is displayed, pushing the Power button enables you to terminate the operations without
making any settings.
HOW TO LOAD SOFTWARE FOR MPEG P.W.BOARD
1. Power on, then open tray.
2. It take on CD-ROM for UPDATE software to the tray, and tray close.
3. TV screen display “Reading”and FL display “UPDATING”
4. For the time being, tray open and FL display "GOOD-BYE".
(caution) The update is not completed though the tray opens.
5. When software loading finished, "GOOD-BY" on a FL display disappears.
6. Next, set up market code and region code by "SERVICE MODE"
CD-ROM part code is "0PRADC9687--A".
CAUTIONS FOR PWB OR IC ASSY EXCHANGE
After an MAIN board(614 332 3860) or IC ASSY(410 531 3201) exchange should carry out loading of the software by the newest
CD-R, and should check operation.
How to attach gear rack
Slide gear is slid, and the position
of a hole is united.
The tooth of gear is
united as shown in a
figure.
How to take out the disc.
Main unit
Pushing cylindrical thing

- 5 -
Input Output
IC231 3-22Pin
TP24,25
TP11 (H)
TP12 (E)
90.0MHz
106.1MHz
0.0±0.05V
1.1±0.1V
FM Ant
SG=66dBµV
87.5MHz
98.0MHz XF233
Remark
SG
Frequency
IF
Adjustment
1
Adjustment
---
1. FM
Step Adjusting
Circuit
Connection
108.0MHz
Tracking3
2 Cover
< 9.0V
L2103
TP13 (L)
TP14 (R)
TP15 (E)
FM Ant
SG=8dBµV L2102 Max.
TUNER ADJUSTMENT
Antenna : 75Ωunbalanced direct, Modulation : 1 kHz
Dev. : ±22.5kHz(MONO), ±22.5kHz(STEREO),±6.75kHz(PILOT)
RF Level : dBuV EMF
Output Level : about 100mV at TP13, TP14, TP15
•Use a plastic screw driver for adjustments. •MODE : ST (Stereo)
•Speaker impedance : 8 ohms •TUNING FM : 87.5 - 108MHz
1
10
12
13 20 24
50 40 30
26
25 20 10
1
14
10
8
CEM-3 F01
94V-0
5
4
1AD4B10D2762AA
XF222
XF233
CN201
XF211
L2104
R2101
R2109
L2103
XF221
IC211
VT
GND
Q2201
R2203
R2202
OV_ADJ
SH201
VR230
L2102
IC231
IC141
IC142
IC403
IC231
R2399 C2310
C2315
R2308 C2320 C2319
C2321 C2305
C2306
R2306
C2330
C2322
R2305
Q2451
R2456
C2103
C2104
C2203
C2317C2307
C2303
C
2311
R2330
C
1
C1421
C1422
C1423
C1415
R4267R4268
C4266
R4168R4167
C4166 C4042
R4271
R4170 R4171
R4270
R4269
R4169
C
4
C
4
R4162
Q41
6
Q42
6
R4262
R4411
R4412
XF233 L2103 L2102
91
1
FM_ANT
CANCAN
R2302 C2323 R2307 C2309 C2316
C2312
C2313
R2304
C2304
D2455
CAN
CAN
R2358
R2801
R2701
R2812
R2712
TU_R TU_L
A.GND
A.GND1
CAN
R2111
C2105
C2107R2102
R2103
D2104
C2101
C2102
R2107
C2110 C2111
C2109
R2105
R2120 C2106
R2108
R2106
C2112
C2113
C2114 R2110
C2115
D2101
D2102
C2116
C2130
C2131
CAN
SG201
R2201
R2204
C2302
R2331
C8015
R1901
C4123 R4126 R4124
R4123
C4121
R412
R4710 R4709
Q4125
R4186
TP12
TP11
TP25
TP24
TP13
TP14
TP15

- 6 -
EXPLODED VIEW (CABINET & CHASSIS MAIN UNIT)
Y02
Y02
Y12
Y13
Y14
Y15
Y17
Y17
Y22
Y22
Y18
Y21
Y18
Y16
Y04
Y04
Y05
Y06
Y06
Y07
Y10
Y10
Y10
Y07
Y08
Y05
Y03
9
10
52
53
71
54
56
57 58
72
74
73
51
15
16
28
27
16
35
37
38
39
36
33
76
75
60 61
40
34
12
13
14
10
51 51
52
: Not available as service parts.
45
46
42
49
48
50
47
Y23
Y24
41
7
7

- 7 -
PARTS LIST
CAUTION :Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL !
!! IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY !
!! , USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT
ARE DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE
MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE PRODUCT TO THE CUSTOMER.
REF.NO. PART NO. DESCRIPTION
MAIN UNIT PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 245 0055 ANTENNA
645 073 6582 CABLE,AUDIO
645 018 6080 CABLE,VIDEO
614 333 5481 CARTON CASE(CA)
614 333 7294 CARTON CASE(US)
614 333 7300 CUSHION,PAD
614 333 7317 CUSHION,PAD,LEFT
614 333 7324 CUSHION,PAD,RIGHT
614 333 5504 INSTRUCTION MANUAL(CA)
614 333 0356 INSTRUCTION MANUAL(US)
614 333 0349 INSTRUCTION SHEET,
QUICK GUIDE(US)
645 066 4410 POLY BAG-0250X0350*NC,
INST MANUAL
645 073 9668 POLY SHEET-0700X0450*NC,SET
645 075 7587 REMOCON,RB-DWM4500MT
51 614 333 5344 ASSY,BOX,SPEAKER,
FRONT SPEAKER L/R(CA)
51 614 333 5320 ASSY,BOX,SPEAKER,
FRONT SPEAKER(US)
52 614 333 5375 ASSY,BOX,SPEAKER,
CENTER SPEAKER(CA)
52 614 333 5351 ASSY,BOX,SPEAKER,
CENTER SPEAKER(US)
645 076 4424 CABLE,MULTI-POLE 25P,UL
or 645 077 8049 CABLE,MULTI-POLE 25P,W/O UL
645 075 6528 CORE,CLAMP,SPEAKER WIRE
or 645 075 6528 CORE,CLAMP,SYSTEM CABLE
MAIN UNIT CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
7 614 331 3502 HOLDER,DOOR
9 614 333 5450 ASSY,CABINET,FRONT(CA)
9 614 333 0264 ASSY,CABINET,FRONT(US)
10 614 331 3113 DEC,LIGHTING(CA)
10 614 333 3845 DEC,LIGHTING(US)
12 614 331 9078 ASSY,BUTTON,LEFT
13 614 331 9085 ASSY,BUTTON,RIGHT
14 614 327 5541 SPRING,COMP,FRONT PWB
15 614 331 3045 COVER,PICK-UP
16 614 332 9459 SPACER,MECHA
27 614 331 3496 GEAR,RACK
28 614 331 3588 SHAFT,GEAR
33 614 331 3168 MOUNTING,SOCKET
35 614 331 3267 SHIELD,TOP,TU
36 614 332 9244 COVER,SOCKET,TU
37 614 331 3243 SHIELD,BOTTOM
38 614 333 7164 CABINET,REAR
39 614 331 3236 STAND,ARM
40 614 331 3151 LID,SOCKET
41 614 331 9795 SPRING,WIRE,DVD,DVD MECHA
42 614 331 9160 ASSY,STAND
45 614 333 7508 ASSY,DOOR,LEFT
46 614 333 7515 ASSY,DOOR,RIGHT
47 614 330 6627 ASSY,MECHA,MSA10B BASE,
MECHANISM ASSY
48 614 331 9146 ASSY,MOUNTING,MOTOR
49 614 331 9153 ASSY,MOUNTING,BOTTOM
50 614 331 9139 ASSY,MOUNTING,
TOP
MAIN UNIT FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 161 7409 SCR S-TPG BIN 2X5,DOOR L/R
Y02 411 192 2404 SCR S-TPG BIN 2X4,HOLDER DOOR
Y03 411 191 4409 SCR S-TPG PAN 2.3X6,
DEC WINDOW FRONT
Y04 411 187 2808 SCR S-TPG BIN 2.3X8,DEC LIGHTING
Y05 411 184 0906 SCR S-TPG BIN 2.3X10,FRONT PWB
Y06 411 188 3200 WASHER Z 2.6X10X0.5,DVD MECHA
Y07 411 184 0906 SCR S-TPG BIN 2.3X10,DVD MECHA
Y08 411 184 0906 SCR S-TPG BIN 2.3X10,
DVD MECHA PWB
Y10 411 021 3404 SCR S-TPG BIN 3X10,
ASSY MOUNT TOP
Y12 411 098 1006 SCR S-TPG BIN 3X6,MOUNT SOCKET
Y13 411 021 2605 SCR S-TPG BIN 2.6X6,SYSTEM
Y14 411 098 1006 SCR S-TPG BIN 3X6,SYSTEM PWB
Y15 411 098 1006 SCR S-TPG BIN 3X6,SHIELD TOP TU
Y16 411 098 1006 SCR S-TPG BIN 3X6,
COVER TU/BOTTOM
Y17 411 098 1006 SCR S-TPG BIN 3X6,
MAIN PWB/BOTTOM
Y18 411 187 2808 SCR S-TPG BIN 2.3X8,BOTTOM/REAR
Y19 411 098 1006 SCR S-TPG BIN 3X6,BOTTOM/REAR
Y21 412 070 1908 SPECIAL SCREW,ASSY STAND
Y22 411 184 0906 SCR S-TPG BIN 2.3X10,
CABINET/REAR
Y23 411 191 4409 SCR S-TPG PAN 2.3X6,
SPRING WIRE DVD
Y24 411 188 3200 WASHER Z 2.6X10X0.5,
SPRING WIRE DVD
MAIN UNIT ELECTRICAL-PARTS
REF.NO. PART NO. DESCRIPTION
34 645 051 0649 CORE,FERRITE,SOCKET-MAIN
or 645 031 7637 CORE,FERRITE,SOCKET-MAIN
51 614 331 9443 ASSY,WIRE,FRONT-DOOR SW
52 614 331 9405 ASSY,WIRE,MAIN-FRONT
53 614 331 9450 ASSY,WIRE,FRONT-MOTOR
54 645 071 4467 FLEXIBLE FLAT CABLE,MAIN-FRONT
56 645 071 4481 FLEXIBLE FLAT CABLE,
MECHA-INTERFACE
57 614 331 9429 ASSY,WIRE,MAIN-MECHA
58 645 071 4474 FLEXIBLE FLAT CABLE,
MAIN-INTERFACE
60 645 071 4498 FLEXIBLE FLAT CABLE,MAIN-SOCKET
61 614 331 9412 ASSY,WIRE,MAIN-SOCKET

- 8 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
645 051 0656 CORE,FERRITE,FRONT-MAIN
or 645 042 8999 CORE,FERRITE,FRONT-MAIN
645 051 0649 CORE,FERRITE,INTERFACE-MAIN
or 645 031 7637 CORE,FERRITE,INTERFACE-MAIN
614 333 7287 SHIELD,MPEG
REF.NO. PART NO. DESCRIPTION
MAIN UNIT FRONT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 332 3853 ASSY,PWB,FRONT(Only initial)
BRC61 614 331 3038 COVER,LED
BRH61 614 331 3137 HOLDER,LCD
BRH62 614 331 3144 HOLDER,LED
BRH63 614 331 3144 HOLDER,LED
BRR61 614 327 7989 REFLECTOR,LCD
BRS61 614 327 1512 DEC,SHEET,LCD
CN601 645 061 4576 SOCKET,FPC 30P
CN602 614 310 2649 PLUG,8P
or 645 006 0953 PLUG,8P
CN620 614 310 2618 PLUG,5P
or 645 006 0922 PLUG,5P
CN621 614 310 2588 PLUG,2P
or 645 006 0908 PLUG,2P
D6100 407 244 8609 LED SELS6E14C-M
D6101 407 244 8609 LED SELS6E14C-M
D6103 407 244 8500 LED SELU2E10C-P
D6104 407 221 6505 ZENER DIODE KDZ5.6V
or 407 208 9703 ZENER DIODE UDZS5.6B
or 407 179 4608 ZENER DIODE UDZ5.6B
D6110 407 149 0807 DIODE 1SS355
D6111 407 149 0807 DIODE 1SS355
D6112 407 149 0807 DIODE 1SS355
D6114 407 149 0807 DIODE 1SS355
D6115 407 149 0807 DIODE 1SS355
D6116 407 149 0807 DIODE 1SS355
DS601 407 232 4002 PHOTO DIODE SPS-440-1-VG
IC601 410 564 1007 IC LC87F74C8A-F54Z5-E
or 410 567 8102 IC LC877B48A-55N9-E
IC602 410 448 8405 IC S524A40X21-SCT0
or 410 448 8504 IC S524A40X21-SCB0
or 410 429 7908 IC AT24C02N-10SI-2.7
IC603 409 645 0602 IC PST3640U
IC604 409 441 4507 IC TA7291S(M)
L6000 645 001 4550 INDUCTOR,10U K
LCD61 645 069 2529 LCD
Q6001 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q6100 405 177 7607 TR KRC111S
or 405 144 5209 TR DTC114TKA
Q6101 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q6102 405 177 7607 TR KRC111S
or 405 144 5209 TR DTC114TKA
Q6103 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q6104 405 177 7607 TR KRC111S
or 405 144 5209 TR DTC114TKA
Q6105 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q6200 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q6201 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q6203 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
R6200 !
!! 402 099 5001 FUSIBLE RES 4.7 JA 1/4W
S6080 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6081 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6082 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6083 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6090 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6091 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6092 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6093 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
S6094 645 006 5958 SWITCH,PUSH 1P-1T
or 614 220 5471 SWITCH,TACT
or 614 240 1002 SWITCH,TACT
SG600 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
X6100 645 059 1570 OSC,CERAMIC 8.00MHZ
or 645 053 4393 OSC,CERAMIC 8.00MHZ
MAIN UNIT INTERFACE P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
72 614 331 9207 ASSY,PWB,INTERFACE(Only initial)
CN661 645 069 5032 SOCKET,FPC 24P
CN662 645 069 5032 SOCKET,FPC 24P
LUG03 645 023 8987 FIXER
LUG04 645 023 8987 FIXER
MAIN UNIT DOOR SW P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 331 0471 ASSY,PWB,DOOR SW(Only initial)
CN650 614 310 2618 PLUG,5P
or 645 006 0922 PLUG,5P
S6500 645 070 9012 SWITCH,MICRO 1P-1T
S6501 645 070 9012 SWITCH,MICRO 1P-1T
S6502 645 070 9012 SWITCH,MICRO 1P-1T
S6503 645 070 9012 SWITCH,MICRO 1P-1T
MAIN UNIT MOTOR P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
74 614 332 3846 ASSY,PWB,MOTOR(Only initial)
CN671 614 310 2588 PLUG,2P
or 645 006 0908 PLUG,2P
MAIN UNIT SOCKET P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
75 614 331 0495 ASSY,PWB,SOCKET(Only initial)
CN302 645 063 8718 SOCKET,FPC 22P
CN351 645 069 2451 SOCKET,MULTI-POLE 25P
CN391 614 310 2618 PLUG,5P
or 645 006 0922 PLUG,5P
L3500 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3501 645 034 7887 INDUCTOR,1000 OHM

- 9 -
PARTS LIST
REF.NO. PART NO. DESCRIPTIONREF.NO. PART NO. DESCRIPTION
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3502 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3503 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3504 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3505 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3506 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3507 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3508 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3509 645 020 1905 INDUCTOR,120 OHM
L3510 645 020 1905 INDUCTOR,120 OHM
L3511 645 020 1905 INDUCTOR,120 OHM
L3512 645 020 1905 INDUCTOR,120 OHM
L3515 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3516 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3517 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L3518 645 020 2131 INDUCTOR,600 OHM
MAIN UNIT MAIN P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
76 614 332 3860 ASSY,PWB,MAIN(Only initial)
C2457 403 259 0508 NP-ELECT 1U M 50V
C2902 403 215 2201 CERAMIC 0.01U K 50V
C4901 !
!! 403 373 9302 ELECT 100U M 25V
C4904 !
!! 403 373 8305 ELECT 100U M 10V
CN110 614 310 2496 PLUG,8P
or 645 005 8134 PLUG,8P
CN120 645 037 6207 SOCKET,FFC 24P
or 645 057 2951 SOCKET,FPC 24P
CN130 614 310 2472 PLUG,6P
or 645 005 8127 PLUG,6P
CN201 645 057 1893 TERMINAL,TUNER
CN401 645 061 4446 SOCKET,FPC 30P
CN402 645 063 8695 SOCKET,FPC 22P
CN451 645 053 5215 JACK,PHONE D3.6
CN491 614 310 2465 PLUG,5P
or 645 005 9292 PLUG,5P
D1200 407 221 1807 DIODE KDS120E
or 407 179 1805 DIODE DAP222
D2101 407 241 2907 VARACTOR DI SVC230
D2102 407 241 2907 VARACTOR DI SVC230
D2104 407 149 0807 DIODE 1SS355
D2301 407 099 5402 ZENER DIODE MTZJ6.2B
D2451 407 149 0807 DIODE 1SS355
D2452 407 153 7502 ZENER DIODE GZS3.0B
D2455 407 149 0807 DIODE 1SS355
D4060 407 012 4406 DIODE 1SS133
D4901 !
!! 408 044 6208 DIODE SB240L 19C2-105
D4902 407 063 9108 ZENER DIODE MTZJ6.8B
D4903 407 063 9108 ZENER DIODE MTZJ6.8B
D4904 407 063 9108 ZENER DIODE MTZJ6.8B
D4905 407 099 5204 ZENER DIODE MTZJ5.1B
D4931 407 099 6805 ZENER DIODE MTZJ13B
IC110 409 607 8004 IC ZR36768
IC120 409 607 8103 IC ZR36707TQC
IC130 !
!! 409 438 7207 IC BA5954FP
IC132 409 168 9106 IC BA10358F
or 409 528 3805 IC NJM12904M
IC141 410 530 7804 IC M12L16161A-7TG
or 410 530 7705 IC EM636165TS-7G
or 410 530 7903 IC HY57V161610ETP-7
IC142 410 530 7804 IC M12L16161A-7TG
or 410 530 7705 IC EM636165TS-7G
or 410 530 7903 IC HY57V161610ETP-7
IC160 409 540 1605 IC LC708746V
IC161 409 543 6409 IC KRX101U
IC171 409 505 0803 IC PST3627U
IC172 410 448 8405 IC S524A40X21-SCT0
or 410 448 8504 IC S524A40X21-SCB0
or 410 429 7908 IC AT24C02N-10SI-2.7
IC211 409 016 0200 IC LA1186N-AUDIO
IC231 409 474 3201 IC LA1844ML
IC241 409 439 4502 IC LC72121M-D
IC401 409 607 8202 IC NJW1153FG1
IC402 409 426 1903 IC KIA4558F
or 409 039 7804 IC NJM4558M
IC403 409 542 9609 IC NJM2058V
IC404 409 357 2901 IC NJM4556AL
IC405 409 542 9609 IC NJM2058V
IC406 409 543 6409 IC KRX101U
IC490 !
!! 409 609 3908 IC SI-8050RD
IC491 !
!! 409 568 4602 IC PQ05DZ1U
IC492 !
!! 409 612 1403 IC PQ050DZ01Z
IC493 !
!! 409 608 0908 IC UPC37M31TJ-AZ
IC494 !
!! 409 561 6801 IC PQ12DZ5
IC810 410 531 3201 IC ASSY
(IC SST39VF800A-70-4C-EK,D)
L1101 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1102 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1103 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1104 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1105 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1106 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1107 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1108 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1115 645 020 2131 INDUCTOR,600 OHM
L1116 645 020 2131 INDUCTOR,600 OHM
L1117 645 020 2131 INDUCTOR,600 OHM
L1118 645 020 1851 INDUCTOR,1000 OHM
L1119 645 020 1851 INDUCTOR,1000 OHM
L1120 645 020 2131 INDUCTOR,600 OHM
L1121 645 020 2131 INDUCTOR,600 OHM

- 10 -
PARTS LIST
L1122 645 020 2131 INDUCTOR,600 OHM
L1130 645 019 0988 INDUCTOR,1000 OHM
or 645 020 2001 INDUCTOR,1000 OHM
L1131 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1132 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1133 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1201 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1202 645 020 1851 INDUCTOR,1000 OHM
L1203 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1204 645 020 1851 INDUCTOR,1000 OHM
L1205 645 020 1967 INDUCTOR,75 OHM
L1410 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1420 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1600 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L1601 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
L2102 645 018 0163 COIL,AIR
L2103 645 018 0255 COIL,AIR
L2104 645 002 1534 INDUCTOR,8.2U K
L2451 645 001 4581 INDUCTOR,100U K
L4080 645 001 4550 INDUCTOR,10U K
L4081 645 001 4550 INDUCTOR,10U K
L4082 645 001 4550 INDUCTOR,10U K
L4181 645 001 4550 INDUCTOR,10U K
L4281 645 001 4550 INDUCTOR,10U K
L4900 !
!! 645 048 4469 INDUCTOR,22U
L4901 !
!! 645 048 4469 INDUCTOR,22U
L4902 !
!! 645 069 3977 INDUCTOR,165U
L4903 !
!! 645 048 4469 INDUCTOR,22U
L4904 645 058 3315 INDUCTOR,1U M
L4905 645 034 7887 INDUCTOR,1000 OHM
or 645 020 1813 INDUCTOR,1000 OHM
or 645 045 7869 IMPEDANCE,1000 OHM P
LUG01 645 023 8987 FIXER
LUG02 645 023 8987 FIXER
Q1200 405 158 5905 TR KTA1505-Y
or 405 035 5509 TR 2SA1036K-R
Q1201 405 158 5905 TR KTA1505-Y
or 405 035 5509 TR 2SA1036K-R
Q1202 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q1204 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q1205 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q1600 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q2201 405 151 4202 TR KTC3193-O
or 405 151 4103 TR KTC3193-Y
or 405 016 0806 TR 2SC2839-E
Q2451 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q4020 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q4050 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q4125 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4131 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4151 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4161 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4180 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4181 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4225 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4231 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4251 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4261 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4280 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4281 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4331 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4431 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4531 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4631 405 166 7007 TR KTD1304
or 405 021 2307 TR 2SD1048-X6
or 405 021 2406 TR 2SD1048-X7
Q4931 !
!! 405 141 3604 TR KTA1273-Y
or !
!! 405 009 5207 TR 2SB927-S
or !
!! 405 009 5306 TR 2SB927-T
R4905 !
!! 402 095 4206 RESISTOR 150 J- 1W
R4906 !
!! 402 095 4206 RESISTOR 150 J- 1W
R4909 !
!! 402 085 2601 RESISTOR 2.2 J- 2W
S4701 645 043 7250 SWITCH,SLIDE 2P-2TX4
SG111 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG112 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG113 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG114 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION

- 11 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
SG115 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG116 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG117 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG120 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG130 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG160 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG161 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG165 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG201 645 055 3202 SURGE-ABSORBER
SG408 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG409 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG418 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SG428 !
!! 645 055 3202 SURGE-ABSORBER,SURG_X
SH201 614 325 5796 SHIELD,FM ANT
VR230 645 003 5586 VR,SEMI,22K N
X1100 645 045 8293 OSC,CRYSTAL 27.000MHZ
X2451 645 023 4965 OSC,CRYSTAL 7.2MHZ
XF211 645 026 2975 FILTER,BP 108MHZ
or 614 252 1045 FILTER,LC
or 645 059 0047 FILTER,BP
XF221 645 010 7665 CERAMIC FILTER 10.70MHZ
or 645 054 1223 CERAMIC FILTER 10.70MHZ
or 614 231 0199 FILTER
or 614 030 5074 I.F FILTER
XF222 645 010 7665 CERAMIC FILTER 10.70MHZ
or 645 054 1223 CERAMIC FILTER 10.70MHZ
or 614 231 0199 FILTER
or 614 030 5074 I.F FILTER
XF233 645 039 9923 TRANS,IF 10.7MHZ
or 645 040 9981 TRANS,IF 10.7MHZ

- 12 -
EXPLODED VIEW (REAR SPEAKER)
4
5
11
54
56
57
54
13
51
52
53
14
15
12
16
9
10
8
58
71
74
72
73
75
Y02 Y06
Y06
Y08
Y09
Y12
Y12
Y13
Y13
Y14
Y15 Y16
Y16
Y16
Y16 Y17
Y18
Y19
Y20
Y20
Y20
Y21
Y22
Y10
Y11
Y06 Y06
Y07
Y05
Y02
1
: Not available as service parts.
59
60

- 13 -
CAUTION :Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL !
!! IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY !
!! , USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE
DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO
DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE
PRODUCT TO THE CUSTOMER.
REF.NO. PART NO. DESCRIPTION
PARTS LIST
REAR SPEAKAER PACKING
REF.NO. PART NO. DESCRIPTION
614 333 7331 CUSHION,LEFT,REAR SP
614 333 7348 CUSHION,RIGHT,REAR SP
614 188 3793 INSPECTION SHEET
645 075 2315 POLY SHEET-0150X0150*NC,
ANTENNA
645 065 8846 POLY SHEET-0650X0650*NC
REAR SPEAKER CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 332 8216 ASSY,CABINET,TOP
4 614 332 8292 ASSY,NET,LEFT(US)
4 614 333 8543 ASSY,NET,LEFT(CA)
5 614 332 8308 ASSY,NET,RIGHT(US)
5 614 333 8550 ASSY,NET,RIGHT(CA)
8 614 332 8254 ASSY,CABINET,BOTTOM
10 614 332 3310 COVER,SWITCH
11 614 332 1804 MOUNTING,SP,LEFT
12 614 332 1811 MOUNTING,SP,RIGHT
13 614 332 1781 HOLDER,POWER,TRANS
14 614 332 1842 SHIELD,AMP,PWB
15 614 332 1798 MOUNTING,AMP,PWB
16 614 333 5160 ASSY,PANEL REAR(CA)
16 614 332 1828 PANEL,REAR(US)
REAR SPEAKER FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y02 411 021 3404 SCR S-TPG BIN 3X10,
CABINET TOP-GRILLE
Y05 411 021 3404 SCR S-TPG BIN 3X10
Y06 411 098 0801 SCR S-TPG BIN 3X14,
CABINET TOP-CABINET BOTT
Y07 411 098 0801 SCR S-TPG BIN 3X14,
CABINET BOTTOM-MOUNTING
Y08 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM- PWB DG
Y09 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM- PWB LED
Y10 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM- PWB DG
Y11 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM- PWB ANNT
Y12 411 193 8603 SCR S-TPG BRZ+FLG 3X10,
SPEAKER-MG SPEAKR
Y13 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM-MG SPEAKR
Y14 411 027 3507 SCR S-TPG BIN 4X6,HOLDER P.T-P.T
Y15 411 021 7204 SCR S-TPG BIN 4X10,
CABINET BOTTOM-HOLDER P.
Y16 411 098 4205 SCR S-TPG BIN 3X8,
SHIELD-MOUNTING PWB AMP
Y17 411 098 4205 SCR S-TPG BIN 3X8,
PWB AMP-MOUNTING PWB AM
Y18 411 021 3404 SCR S-TPG BIN 3X10,
CABINET BOTTOM-MOUNTING
Y19 411 123 9106 SCR S-TPG BIN 3X20,P.REAR
(BOTTOM)
Y20 411 021 3404 SCR S-TPG BIN 3X10,P.REAR
(BOTTOM)
Y21 411 098 0801 SCR S-TPG BIN 3X14,P.REAR
Y22 411 021 3404 SCR S-TPG BIN 3X10,P.REAR -ELEC
REAR SPEAKER ELECTRICAL-PARTS
REF.NO. PART NO. DESCRIPTION
9 645 051 0656 CORE,FERRITE,FOR DG-MAIN
or 645 042 8999 CORE,FERRITE,FOR DG-MAIN
51 !
!! 423 027 4903 FUSE 125V 2A
52 !
!! 645 066 9965 CORD,POWER-1.76MK
53 645 071 5518 ANTENNA,ROD
54 645 072 7504 SPEAKER,4
or 645 076 7210 SPEAKER,4
56 !
!! 645 072 1526 TRANS,POWER
57 614 332 1927 ASSY,WIRE RX-DG
58 614 332 1934 ASSY,WIRE
59 614 332 1958 ASSY,WIRE,LCH
60 614 332 9947 ASSY,WIRE,RCH
74 645 071 4559 UNIT,WIRELESS RECEIVER
645 051 0656 CORE,FERRITE
645 042 8999 CORE,FERRITE
REAR SPEAKER POWER SW P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
71 614 332 8117 ASSY,PWB,SW,POWER SW(Only initial)
C3900 !
!! 403 349 3303 CERAMIC 0.01U M 250V
or !
!! 403 366 7803 CERAMIC 0.01U M 250V
C3901 !
!! 404 088 7409 MT-POLYEST 0.1U K 250V
or !
!! 404 080 8206 MT-POLYEST 0.1U K 250V
or !
!! 403 376 2409 MT-POLYEST 0.1U M 250V
CN390 !
!! 645 005 9315 PLUG,2P
FPC01 645 006 4760 HOLDER,FUSE
or 645 031 7903 HOLDER,FUSE
FPC02 645 006 4760 HOLDER,FUSE
or 645 031 7903 HOLDER,FUSE
L3900 !
!! 645 038 7364 INDUCTOR,70U
R3900 !
!! 402 087 3408 RESISTOR 3.3M J- 1/2W
or !
!! 402 099 6206 RESISTOR 3.3M J- 1/2W
or !
!! 402 078 9501 CARBON 3.3M J- 1/2W
or !
!! 402 078 8108 CARBON 3.3M J- 1/2W
S3900 !
!! 645 072 1496 SWITCH,PUSH POWER
WR390 !
!! 614 017 6964 TERMINAL BOARD
WR391 !
!! 614 017 6964 TERMINAL BOARD
REAR SPEAKER LED P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
72 614 332 1583 ASSY,PWB,LED(Only initial)
CN370 614 035 4911 SOCKET,DIP 2P
CN372 614 332 1941 ASSY,WIRE
D3700 407 245 2309 LED SMLA12BC4T

- 14 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
REAR SPEAKER DG P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 332 8100 ASSY,PWB,DG(Only initial)
C3005 403 325 2207 ELECT 3300U M 35V
C3006 403 325 2207 ELECT 3300U M 35V
C3011 403 325 0302 ELECT 2200U M 25V
C3012 403 323 5408 ELECT 1000U M 25V
CN301 645 006 1998 PLUG,5P
CN302 614 310 2526 PLUG,11P
or 645 005 8165 PLUG,11P
D3001 !
!! 407 196 5800 DIODE 1N5402BD82
D3002 !
!! 407 196 5800 DIODE 1N5402BD82
D3003 !
!! 407 196 5800 DIODE 1N5402BD82
D3004 !
!! 407 196 5800 DIODE 1N5402BD82
D3005 !
!! 407 098 3300 DIODE RL153-BF-S2
D3006 !
!! 407 098 3300 DIODE RL153-BF-S2
D3007 !
!! 407 097 8009 DIODE MPG06G
D3008 !
!! 407 097 8009 DIODE MPG06G
D3100 407 099 6805 ZENER DIODE MTZJ13B
D3101 407 099 5303 ZENER DIODE MTZJ5.6B
D3102 407 099 6805 ZENER DIODE MTZJ13B
HS310 614 331 8750 HEAT SINK
IC310 !
!! 409 605 0604 IC KIA7810API
PR301 !
!! 423 031 8607 FUSE 125V 10A
or !
!! 645 066 9774 PROTECTOR,10A 125V
PR302 !
!! 423 031 8607 FUSE 125V 10A
or !
!! 645 066 9774 PROTECTOR,10A 125V
PR303 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR304 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR310 !
!! 645 066 9651 PROTECTOR,0.25A 125V
or !
!! 645 042 2522 PROTECTOR,0.25A 125V
PR311 !
!! 645 066 9644 PROTECTOR,0.2A 125V
or !
!! 645 042 2515 PROTECTOR,0.2A 125V
PR312 !
!! 645 066 9644 PROTECTOR,0.2A 125V
or !
!! 645 042 2515 PROTECTOR,0.2A 125V
Q3100 405 141 3208 TR KTC3198-Y
or 405 141 3307 TR KTC3198-GR
or 405 019 2708 TR 2SC536-F-NP
or 405 019 3804 TR 2SC536-G-NP
Q3101 405 141 3505 TR KTA1266-Y
or 405 141 3406 TR KTA1266-GR
or 405 004 4502 TR 2SA608-F-NP
or 405 004 5004 TR 2SA608-G-NP
Q3102 405 141 3208 TR KTC3198-Y
or 405 141 3307 TR KTC3198-GR
or 405 019 2708 TR 2SC536-F-NP
or 405 019 3804 TR 2SC536-G-NP
SCR31 411 098 1006 SCR S-TPG BIN 3X6
REAR SPEAKER POWER P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
75 614 332 1576 ASSY,PWB,POWER(Only initial)
C3405 403 185 0306 MT-POLYEST 0.68U J 50V
C3406 403 185 0306 MT-POLYEST 0.68U J 50V
C3407 403 185 0306 MT-POLYEST 0.68U J 50V
C3505 403 185 0306 MT-POLYEST 0.68U J 50V
C3506 403 185 0306 MT-POLYEST 0.68U J 50V
C3507 403 185 0306 MT-POLYEST 0.68U J 50V
C3604 403 374 0516 ELECT 1000U M 35V
C3605 403 390 5707 CERAMIC 0.1U K 50V
C3606 403 386 2406 CERAMIC 0.1U K 100V
C3607 403 374 0516 ELECT 1000U M 35V
CN322 614 310 2298 PLUG,2P
or 645 004 2683 PLUG,2P
CN330 645 072 9898 JACK,PHONE D3.6
CN331 614 310 2632 PLUG,7P
or 645 006 0946 PLUG,7P
CN332 614 310 2670 PLUG,11P
or 645 006 0984 PLUG,11P
CN341 645 006 1875 PLUG,2P
CN342 645 072 1489 TERMINAL,SPEAKER 2P
CN351 645 006 1875 PLUG,2P
D3201 407 099 6102 ZENER DIODE MTZJ10B
D3202 407 149 0807 DIODE 1SS355
D3300 407 149 0807 DIODE 1SS355
D3301 407 149 0807 DIODE 1SS355
D3400 407 241 7704 DIODE US1D-LF
D3401 407 241 7704 DIODE US1D-LF
D3402 407 241 7704 DIODE US1D-LF
D3410 407 149 0807 DIODE 1SS355
D3411 407 149 0807 DIODE 1SS355
D3500 407 241 7704 DIODE US1D-LF
D3501 407 241 7704 DIODE US1D-LF
D3502 407 241 7704 DIODE US1D-LF
D3600 407 241 7704 DIODE US1D-LF
HS300 614 328 5038 HEAT SINK
IC321 409 575 1908 IC PST3645U
IC330 409 521 9606 IC CD4066BCM
IC331 409 426 1903 IC KIA4558F
or 409 039 7804 IC NJM4558M
IC333 409 543 7208 IC KTC801U-Y
IC340 !
!! 409 563 1101 IC TA2022
L3301 645 006 9864 INDUCTOR,80U
L3302 645 006 9864 INDUCTOR,80U
L3305 645 006 3602 INDUCTOR,1.1UH
L3306 645 006 3602 INDUCTOR,1.1UH
L3307 645 006 3602 INDUCTOR,1.1UH
L3311 645 020 1851 INDUCTOR,1000 OHM
L3312 645 020 1851 INDUCTOR,1000 OHM
L3313 645 020 1851 INDUCTOR,1000 OHM
L3314 645 020 1851 INDUCTOR,1000 OHM
L3315 645 020 1851 INDUCTOR,1000 OHM
L3400 645 063 5144 INDUCTOR,10U M
L3401 645 075 6467 INDUCTOR,270 OHM/20MHZ
L3500 645 063 5144 INDUCTOR,10U M
L3501 645 075 6467 INDUCTOR,270 OHM/20MHZ
L3600 645 063 5137 INDUCTOR,100U K
Q3200 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q3201 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q3202 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q3203 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q3204 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q3205 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q3206 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q3207 405 146 1704 TR KTA1504-Y
or 405 146 9700 TR KTA1504-GR
or 405 134 5905 TR 2SA1037AK-R
or 405 002 0308 TR 2SA1037K-R
or 405 005 5508 TR 2SA812-M6
Q3208 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q3301 405 146 1407 TR KRC104S
or 405 138 6700 TR DTC144EKA
Q3410 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR

- 15 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q3411 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
R3413 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
R3513 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
RY340 !
!! 614 224 4531 RELAY
RY341 !
!! 614 224 4531 RELAY
S3410 645 067 1982 SWITCH,SLIDE 1P-2T
SCR32 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR33 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR34 411 187 2808 SCR S-TPG BIN 2.3X8
SCR35 411 187 2808 SCR S-TPG BIN 2.3X8
SG330 645 055 3202 SURGE-ABSORBER
SG341 645 055 3202 SURGE-ABSORBER
SG342 645 055 3202 SURGE-ABSORBER
SG351 645 055 3202 SURGE-ABSORBER
SG352 645 055 3202 SURGE-ABSORBER
SVR34 645 006 5347 VR,SEMI,47K N
SVR35 645 006 5347 VR,SEMI,47K N

- 16 -
EXPLODED VIEW (SUBWOOFER SPEAKER)
1
71
3
73
74
72
7
9
11
75
57
54
55
56
76
10
8
53
4
5
2
51
52
Y01
Y02
Y05
Y05
Y04
Y05 Y05 Y07
Y05
Y05
Y05
Y08
Y9 Y10
Y15
Y16
Y17
Y18
Y19
Y20
Y10
Y13
Y14
Y12
Y12
Y12

- 17 -
PARTS LIST
CAUTION :Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
N.S.P : Not available as service parts.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL !
!! IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY AND
PERFORMANCE CAN BE OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY !
!! , USE ONLY THE
REPLACEMENT PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE
DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO
DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE
PRODUCT TO THE CUSTOMER.
SUBWOOFER SPEAKER PACKING
REF.NO. PART NO. DESCRIPTION
614 332 3778 CUSHION,BOTTOM
614 332 3761 CUSHION,TOP
645 056 9173 POLY BAG-0150X0200*NC,AC CODE
645 075 2315 POLY SHEET-0150X0150*NC,
ANTENNA
645 073 9651 POLY SHEET-1200X0600*NC,WOOFER
SUBWOOFER SPEAKER CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 333 0530 ASSY,BOX,SPEAKER
2 614 331 3519 HOLDER,POWER,TRANS
3 614 331 3526 MOUNTING,AMP,PWB
4 614 331 3601 SHIELD,AMP,PWB
5 614 327 8498 HOLDER,PWB,DG PWB
7 614 333 1872 SHIELD,REAR(CA)
7 614 333 0561 SHIELD,REAR(US)
9 614 333 0554 PANEL,REAR
10 614 332 2108 HOLDER,PWB,TRANSMITTER
11 614 332 2115 HOLDER,PWB,SWITCH
SUBWOOFER SPEAKER FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 191 4607 SCR S-TPG BIN 4X16,
HOLDER P.T-SP.BOX
Y02 411 027 3507 SCR S-TPG BIN 4X6,HOLDER P.T-P.T
Y04 411 098 4205 SCR S-TPG BIN 3X8,
AMP PWB-MOUNTING
Y05 411 098 4205 SCR S-TPG BIN 3X8,
SHIELD-MOUNTING AMP PWB
Y07 411 098 4205 SCR S-TPG BIN 3X8,
DG PWB-HOLDER PWB
Y08 411 021 3404 SCR S-TPG BIN 3X10,
PANEL REAR-SHIELD REAR
Y09 411 021 2605 SCR S-TPG BIN 2.6X6,SYSTEM
Y10 411 021 3404 SCR S-TPG BIN 3X10,
E.PARTS-P.REAR
Y12 411 193 7705 SCR S-TPG BIN 3X16,P.REAR-SP.BOX
Y13 411 021 3404 SCR S-TPG BIN 3X10,
HOLDER P.T-P.REAR
Y14 411 021 7204 SCR S-TPG BIN 4X10,
PANEL REAR-HOLDER TRANS
Y15 411 021 3404 SCR S-TPG BIN 3X10,HOLDER PWB
Y16 411 021 3404 SCR S-TPG BIN 3X10,
PANEL REAR-AC CODE FIXER
Y17 411 021 3404 SCR S-TPG BIN 3X10,HOLDER PWB
Y18 411 021 3404 SCR S-TPG BIN 3X10,
PANEL REAR-SHIELD REAR
Y19 411 098 4205 SCR S-TPG BIN 3X8,ANNTENA
Y20 412 070 7801 SPECIAL SCREW,FAN
SUBWOOFER SPEAKER ELECTRICAL-PARTS
REF.NO. PART NO. DESCRIPTION
8 645 051 0656 CORE,FERRITE,FOR TRANSMITTER
or 645 042 8999 CORE,FERRITE,FOR TRANSMITTER
51 !
!! 645 069 4349 TRANS,POWER
52 !
!! 423 027 5306 FUSE 125V 4A
53 !
!! 645 037 7747 CORD,POWER-1.845MK
or !
!! 645 032 7537 CORD,POWER-1.86MK
54 614 332 2405 ASSY,WIRE,MAIN-INTERFACE
55 614 332 9220 ASSY,WIRE,TX-INTERFACE
56 645 071 5518 ANTENNA,ROD
57 !
!! 645 075 2018 MOTOR,FAN DC 1.2W
72 !
!! 614 332 9268 PWB,HOLD
76 645 071 4542 UNIT,WIRELESS TRANSMITTER
645 051 0656 CORE,FERRITE WIRE,
MAIN-INTERFACE
645 042 8999 CORE,FERRITE WIRE,
MAIN-INTERFACE
645 051 0656 CORE,FERRITE,FOR SPEAKER-WIRE
or 645 042 8999 CORE,FERRITE,FOR SPEAKER-WIRE
SUBWOOFER SPEAKER POWER AMP P.W.BOARD
ASSY
REF.NO. PART NO. DESCRIPTION
71 614 332 2368 ASSY,PWB,POWER AMP(Only initial)
C4707 403 386 2307 ELECT 1000U M 50V
C4710 403 386 2307 ELECT 1000U M 50V
C4723 403 185 0207 MT-POLYEST 0.56U J 50V
C4724 403 185 0306 MT-POLYEST 0.68U J 50V
C4725 403 185 0306 MT-POLYEST 0.68U J 50V
C4726 403 185 0207 MT-POLYEST 0.56U J 50V
C4727 403 185 0306 MT-POLYEST 0.68U J 50V
C4728 403 185 0306 MT-POLYEST 0.68U J 50V
C4804 403 185 0306 MT-POLYEST 0.68U J 50V
C4805 403 185 0306 MT-POLYEST 0.68U J 50V
C4806 403 185 0207 MT-POLYEST 0.56U J 50V
C4807 403 185 0306 MT-POLYEST 0.68U J 50V
C4808 403 185 0306 MT-POLYEST 0.68U J 50V
C4809 403 184 9805 MT-POLYEST 0.22U J 50V
C4812 403 386 2307 ELECT 1000U M 50V
C4815 403 386 2307 ELECT 1000U M 50V
CN492 645 008 4522 PLUG,HOUSING 2P
CN493 645 072 1953 TERMINAL,SPEAKER 3P
CN494 645 040 1206 SOCKET,13P
CN495 645 006 1912 PLUG,6P
CN496 614 310 2298 PLUG,2P
or 645 004 2683 PLUG,2P
CN497 645 072 9898 JACK,PHONE D3.6
D4700 407 241 7704 DIODE US1D-LF
D4701 407 241 7704 DIODE US1D-LF
D4702 407 241 7704 DIODE US1D-LF
D4703 407 241 7704 DIODE US1D-LF
D4704 407 241 7704 DIODE US1D-LF
D4705 407 241 7704 DIODE US1D-LF

- 18 -
PARTS LIST
REF.NO. PART NO. DESCRIPTION
D4706 407 241 7704 DIODE US1D-LF
D4800 407 241 7704 DIODE US1D-LF
D4801 407 241 7704 DIODE US1D-LF
D4802 407 241 7704 DIODE US1D-LF
D4803 407 241 7704 DIODE US1D-LF
D4804 407 241 7704 DIODE US1D-LF
D4805 407 241 7704 DIODE US1D-LF
D4880 407 012 4406 DIODE 1SS133
D4901 407 012 4406 DIODE 1SS133
D4902 407 012 4406 DIODE 1SS133
D4906 407 099 6805 ZENER DIODE MTZJ13B
HS400 614 328 5038 HEAT SINK
HS401 614 328 5038 HEAT SINK
HS403 614 331 8750 HEAT SINK
IC470 !
!! 409 563 1101 IC TA2022
IC480 !
!! 409 563 1101 IC TA2022
IC491 409 575 1908 IC PST3645U
L4700 645 063 5137 INDUCTOR,100U K
L4701 645 070 9609 INDUCTOR,10U M
L4702 645 070 9609 INDUCTOR,10U M
L4703 645 006 3602 INDUCTOR,1.1UH
L4704 645 006 3602 INDUCTOR,1.1UH
L4730 645 076 6428 LINE FILTER
L4731 645 076 6428 LINE FILTER
L4732 645 075 6467 INDUCTOR,270 OHM/20MHZ
L4733 645 075 6467 INDUCTOR,270 OHM/20MHZ
L4800 645 070 9609 INDUCTOR,10U M
L4801 645 070 9609 INDUCTOR,10U M
L4802 645 006 3602 INDUCTOR,1.1UH
L4803 645 006 3602 INDUCTOR,1.1UH
L4831 645 076 6428 LINE FILTER
L4832 645 076 6428 LINE FILTER
L4833 645 075 6467 INDUCTOR,270 OHM/20MHZ
L4834 645 075 6467 INDUCTOR,270 OHM/20MHZ
L4900 645 006 9864 INDUCTOR,80U
L4901 645 006 9864 INDUCTOR,80U
PR490 !
!! 645 066 9644 PROTECTOR,0.2A 125V
or !
!! 645 042 2515 PROTECTOR,0.2A 125V
Q4780 405 064 9202 TR 2SD1757K-S
Q4900 405 064 9202 TR 2SD1757K-S
Q4901 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4902 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4903 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4904 !
!! 405 158 2102 TR KTC2026-Y
or !
!! 405 138 6403 TR KTD2058Y
Q4905 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4906 405 151 6107 TR KRA107S
or 405 141 5707 TR DTA114YKA
Q4907 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4908 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
R4725 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
R4726 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
R4802 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
R4803 !
!! 402 095 2202 RESISTOR 6.2 J- 2W
RY470 614 224 4531 RELAY
RY480 614 224 4531 RELAY
SCR42 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR43 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR44 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR45 411 191 4201 SCR S-TPG BRZ+FLG 3X12
SCR48 411 187 2808 SCR S-TPG BIN 2.3X8
SCR49 411 187 2808 SCR S-TPG BIN 2.3X8
SCR50 411 187 2808 SCR S-TPG BIN 2.3X8
SCR51 411 187 2808 SCR S-TPG BIN 2.3X8
SCR54 411 098 1006 SCR S-TPG BIN 3X6
SG470 645 055 3202 SURGE-ABSORBER
SG471 645 055 3202 SURGE-ABSORBER
SG480 645 055 3202 SURGE-ABSORBER
SVR90 645 006 5347 VR,SEMI,47K N
SVR91 645 006 5347 VR,SEMI,47K N
SVR92 645 006 5347 VR,SEMI,47K N
SVR93 645 006 5347 VR,SEMI,47K N
REF.NO. PART NO. DESCRIPTION
SUBWOOFER SPEAKER MAIN P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 332 2351 ASSY,PWB,MAIN(Only initial)
C4011 403 325 0302 ELECT 2200U M 25V
C4018 403 419 1703 ELECT 3300U M 50V
C4019 403 419 1703 ELECT 3300U M 50V
C4020 403 325 2108 ELECT 3300U M 25V
C4032 403 325 0302 ELECT 2200U M 25V
C4037 403 325 0302 ELECT 2200U M 25V
C4038 !
!! 404 088 7409 MT-POLYEST 0.1U K 250V
or !
!! 404 080 8206 MT-POLYEST 0.1U K 250V
or
!
!!
403 376 2409 MT-POLYEST 0.1U M 250V
C4041 !
!! 404 097 5304 CERAMIC 4700P M 400V
C4624 403 325 2108 ELECT 3300U M 25V
CN400 645 069 2451 SOCKET,MULTI-POLE 25P
CN411 645 006 1998 PLUG,5P
CN412 614 310 2748 PLUG,3P
or 645 004 2898 PLUG,3P
CN413 !
!! 645 005 9315 PLUG,2P
CN414 614 310 2625 PLUG,6P
or 645 006 0939 PLUG,6P
CN421 645 071 1329 JACK,RCA-3
CN450 645 071 4573 JACK,RCA-2
CN453 645 071 5815 TERMINAL,BOARD
CN455 645 040 1206 SOCKET,13P
CN456 645 006 1912 PLUG,6P
D4009 407 099 6805 ZENER DIODE MTZJ13B
D4010 407 099 6805 ZENER DIODE MTZJ13B
D4013 !
!! 407 219 1703 DIODE GBU8JL-BU04
D4017 !
!! 407 107 6001 DIODE RL203-BD80
D4018 !
!! 407 097 8009 DIODE MPG06G
D4019 !
!! 407 107 6001 DIODE RL203-BD80
D4020 !
!! 407 097 8009 DIODE MPG06G
D4022 !
!! 407 097 8009 DIODE MPG06G
D4023 !
!! 407 097 8009 DIODE MPG06G
D4024 !
!! 407 097 8009 DIODE MPG06G
D4025 !
!! 407 097 8009 DIODE MPG06G
D4600 407 012 4406 DIODE 1SS133
D4601 407 012 4406 DIODE 1SS133
D4602 !
!! 407 097 8009 DIODE MPG06G
FPC01 645 006 4760 HOLDER,FUSE
or 645 031 7903 HOLDER,FUSE
FPC02 645 006 4760 HOLDER,FUSE
or 645 031 7903 HOLDER,FUSE
HS460 614 331 8750 HEAT SINK
HS461 614 331 8750 HEAT SINK
HS462 614 331 8750 HEAT SINK
IC401 !
!! 409 463 6701 IC KIA7805API
IC402 !
!! 409 463 6701 IC KIA7805API

- 19 -
PARTS LIST
IC460 409 426 1903 IC KIA4558F
or 409 039 7804 IC NJM4558M
IC461 !
!! 409 463 6701 IC KIA7805API
L4000 !
!! 645 076 7203 LINE FILTER
L4203 645 006 3886 INDUCTOR,1U K
L4205 645 006 3886 INDUCTOR,1U K
L4206 645 006 3886 INDUCTOR,1U K
L4500 645 001 5441 INDUCTOR,2.2U K
L4501 645 001 5441 INDUCTOR,2.2U K
L4502 645 001 5441 INDUCTOR,2.2U K
L4503 645 063 5137 INDUCTOR,100U K
L4504 645 006 3602 INDUCTOR,1.1UH
L4505 645 006 3602 INDUCTOR,1.1UH
PR400 !
!! 423 031 8607 FUSE 125V 10A
or !
!! 645 066 9774 PROTECTOR,10A 125V
PR401 !
!! 423 031 8607 FUSE 125V 10A
or !
!! 645 066 9774 PROTECTOR,10A 125V
PR402 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR403 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR404 !
!! 645 066 9644 PROTECTOR,0.2A 125V
or !
!! 645 042 2515 PROTECTOR,0.2A 125V
PR405 !
!! 645 066 9781 PROTECTOR,2A 125V
or !
!! 645 042 2669 PROTECTOR,2A 125V
PR406 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR407 !
!! 423 031 8706 FUSE 125V 7A
or !
!! 645 066 9859 PROTECTOR,7A 125V
PR408 !
!! 645 066 9781 PROTECTOR,2A 125V
or !
!! 645 042 2669 PROTECTOR,2A 125V
PR409 !
!! 645 066 9736 PROTECTOR,1A 125V
or !
!! 645 042 2614 PROTECTOR,1A 125V
Q4001 !
!! 405 141 3604 TR KTA1273-Y
Q4002 !
!! 405 158 2102 TR KTC2026-Y
or !
!! 405 138 6403 TR KTD2058Y
Q4003 !
!! 405 141 3604 TR KTA1273-Y
Q4005 405 146 1704 TR KTA1504-Y
or 405 146 9700 TR KTA1504-GR
or 405 134 5905 TR 2SA1037AK-R
or 405 002 0308 TR 2SA1037K-R
or 405 005 5508 TR 2SA812-M6
Q4006 405 146 1704 TR KTA1504-Y
or 405 146 9700 TR KTA1504-GR
or 405 134 5905 TR 2SA1037AK-R
or 405 002 0308 TR 2SA1037K-R
or 405 005 5508 TR 2SA812-M6
Q4600 405 166 7007 TR KTD1304
Q4601 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4602 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4603 405 146 1704 TR KTA1504-Y
or 405 146 9700 TR KTA1504-GR
or 405 134 5905 TR 2SA1037AK-R
or 405 002 0308 TR 2SA1037K-R
or 405 005 5508 TR 2SA812-M6
Q4604 405 146 1704 TR KTA1504-Y
or 405 146 9700 TR KTA1504-GR
or 405 134 5905 TR 2SA1037AK-R
or 405 002 0308 TR 2SA1037K-R
or 405 005 5508 TR 2SA812-M6
Q4605 !
!! 405 141 3604 TR KTA1273-Y
Q4606 405 146 2107 TR KTC3875-Y
REF.NO. PART NO. DESCRIPTION
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4607 !
!! 405 159 1500 TR KTA1046-Y
or !
!! 405 138 6502 TR KTB1366Y
Q4630 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q4631 405 159 0503 TR KRC107S
or 405 141 5608 TR DTC114YKA
Q4632 !
!! 405 159 1500 TR KTA1046-Y
or !
!! 405 138 6502 TR KTB1366Y
R4005 !
!! 402 087 3408 RESISTOR 3.3M J- 1/2W
or !
!! 402 078 9501 CARBON 3.3M J- 1/2W
or !
!! 402 078 8108 CARBON 3.3M J- 1/2W
or !
!! 402 099 6206 RESISTOR 3.3M J- 1/2W
SCR60 411 098 1006 SCR S-TPG BIN 3X6
SCR61 411 098 1006 SCR S-TPG BIN 3X6
SCR63 411 098 1006 SCR S-TPG BIN 3X6
SG423 645 055 3202 SURGE-ABSORBER
SG424 645 055 3202 SURGE-ABSORBER
SG425 645 055 3202 SURGE-ABSORBER
SG452 645 055 3202 SURGE-ABSORBER
SG453 645 055 3202 SURGE-ABSORBER
SG455 645 055 3202 SURGE-ABSORBER
SG456 645 055 3202 SURGE-ABSORBER
SG457 645 055 3202 SURGE-ABSORBER
SG458 645 055 3202 SURGE-ABSORBER
SG459 645 055 3202 SURGE-ABSORBER
WR401 !
!! 614 123 2379 TERMINAL
WR402 !
!! 614 123 2379 TERMINAL
REF.NO. PART NO. DESCRIPTION
SUBWOOFER SPEAKER SOCKET P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
74 614 332 2375 ASSY,PWB,SOCKET(Only initial)
CN430 645 040 1190 PLUG,13P
CN431 645 040 1190 PLUG,13P
CN432 645 005 8455 SOCKET,6P
CN433 645 005 8455 SOCKET,6P
L4300 645 020 1813 INDUCTOR,1000 OHM
L4301 645 020 1813 INDUCTOR,1000 OHM
L4302 645 020 1813 INDUCTOR,1000 OHM
L4303 645 048 4469 INDUCTOR,22U
L4305 645 020 1813 INDUCTOR,1000 OHM
L4306 645 020 1813 INDUCTOR,1000 OHM
L4307 645 020 1813 INDUCTOR,1000 OHM
L4308 645 048 4469 INDUCTOR,22U
L4309 645 006 3602 INDUCTOR,1.1UH
L4310 645 006 3602 INDUCTOR,1.1UH
L4311 645 006 3602 INDUCTOR,1.1UH
L4312 645 020 1813 INDUCTOR,1000 OHM
L4313 645 020 1813 INDUCTOR,1000 OHM
L4314 645 020 1813 INDUCTOR,1000 OHM
L4315 645 020 1813 INDUCTOR,1000 OHM
SUBWOOFER SPEAKER TX-INTERFACE P.W.BOARD
ASSY
REF.NO. PART NO. DESCRIPTION
75 614 333 2534 ASSY,PWB,TX-INTERFACE
CN300 614 310 2472 PLUG,6P
or 645 005 8127 PLUG,6P
CN301 614 310 2496 PLUG,8P
or 645 005 8134 PLUG,8P
CN302 614 310 2472 PLUG,6P
or 645 005 8127 PLUG,6P
IC300 410 563 9905 IC LC651102F-4N01-E
IC301 409 039 8603 IC NJM4560M
IC302 409 575 1908 IC PST3645U
