Sanyo DWM-4500 User manual

EXTERNAL SPEAKERS(4Ω)
SPEAKER EXTERNAL
INTERNAL
L
R
REAR IN
1
2
Quick-Guide
DWM-4500
DVD Home Theater System
Accessories
Wireless remote
control
Video cable
Hook up
FM indoor antenna
lead wire
Do not connect the power cord
to a 120V AC 60Hz outlet until all
connections have been made.
1AD6P1P2103-- DWM-4500, Issue Number 1, Printed in China
Set the FREQUENCY switch to
“1”, “2”, “3” or “4”.
Match the number on both
sub-woofer and rear speaker.
Sub-woofer
(Powered speaker)
2 "AA" batteries
(not supplied)
Attach the
ferrite core.
Pull out gently the antenna vertically.
•Try not to hold, bend, or twist the antenna.
CAUTION:
Keep it out of reach of young children who might damage it.
Sub-woofer
(Powered speaker)
Rear speaker
(Powered speaker)
Antenna and Switch
Main unit
(DVD receiver)
4
Need help? Call
1-800-813-3435
Weekdays: 7:30 AM - 4:00 PM
Central Time
System cable to Sub-woofer
(Powered speaker)
System cable
System cable
Assistance
speaker cable
for rear speaker
Ferrite core x 2
21
System cable
DWM-4500 Quick(Eng).p65 05.1.12, 1:15 PM1

Hook up
After all speaker
connections have been
made, attach the ferrite
core.
Ferrite core
Main unit
(Left side)
FM indoor antenna lead wire
Speaker Wire Color Use
Black and White Front left speaker
Black and Red Front right speaker
Black and Green Center speaker
The speaker cables are packed in the speaker
package.
Main unit (DVD Receiver)
RedWhite Green BlackBlack Black
Front right speakerFront left speaker Center speaker
Sub-woofer
(Powered speaker)
System cable
Ferrite core
3
Rear speaker (Powered speaker)
Sub-woofer
(Powered speaker)
Place it near the front speaker.
However, do not place it in front
of the TV.
Center speaker
Front left speaker
Front right speaker
DWM-4500 Quick(Eng).p65 05.1.12, 1:15 PM2

34
CHANNEL
TO TV ANT. IN
R-AUDIO-LVIDEO
A/V INPUT JACKS
VHF/UHF
ANTENNA
IN
AUX
S-VIDEO
OUT VIDEO OUT
34
CHANNEL
TO TV ANT. IN
R-AUDIO-LVIDEO
A/V INPUT JACKS
VHF/UHF
ANTENNA
IN
34
CHANNEL
VHF/UHF
FROM ANT.
IN
OUT
TO TV
IN OUT
LINE1(AUX1)
VIDEO
L
R
L
R
AUDIO
AUX
S-VIDEO
OUT SPEA
VIDEO
OUT
FRONT
CENTER
R L
Hook up (Using RF Modulator, not supplied)
Sub-woofer, TV and RF Modulator connections
Sub-woofer, VCR, TV and RF Modulator connections
Set the channel number CH3 (or CH4) on all TV, VCR
and RF Modulator, whichever is not used for regular
broadcasts in your area.
TV
Set the channel number CH3 (or CH4) on both TV and RF Modula-
tor, whichever is not used for regular broadcasts in your area.
TV
RF Modulator
RF Modulator
HiFi Stereo VCR
TV/CATV
Antenna Cable
TV/CATV
Antenna Cable
To AC 120V, 60Hz
To AC 120V, 60Hz
5A
Important Information:
Do not connect the unit to a VCR directly.
The playback picture will be distorted
because DVD video discs are copy
protected.
If your TV has a Video
input jack...
5
Yes
No
6A
After all connec-
tions have been
made, connect
the power cord
of sub-woofer
and rear speaker
to a 120V AC
60Hz outlet.
To AC 120V,
60Hz
Sub-woofer (Powered speaker)
Sub-woofer
(Powered
speaker)
DWM-4500 Quick(Eng).p65 05.1.12, 1:15 PM3

MENU
Play Movie
Languages & Audio Set-Up
Subtitles
Theatrical Trailers
Scene Selections
If a DVD disc menu appears
on the TV screen...
TV
TV setting
or VIDEO, VIDEO 1, VIDEO 2, A/V, etc.
6A
Turn on the power and load the disc.
7
6TV setting
Your TV remote
controller Press [0], then [3] (or [4]).
Turn on your television.
Select the video input
source from your televi-
sion.
(Refer to your TV’s owner
manual.)
Turn on your television.
Set the channel number
CH3 (or CH4) on your
television, whichever is
not used for regular
broadcasts in your area.
TV
TV
Press the ENTER
button.
Playback starts.
Select the “Play
Movie” by the ar-
row button.
Label facing
toward you
Playback starts
automatically.
Select “DVD/CD”.
OR
Note:
Some discs may not start playback automatically.
In such case, press [a] (Play) to start playback.
Rear speaker
(Powered speaker)
8
DWM-4500 Quick(Eng).p65 05.1.12, 1:15 PM4
