Sanyo PDG-DWL100 - WXGA DLP Projector Installation instructions

EXPAND SERIAL COMMAND
FUNCTIONAL SPECIFICATIONS
PDG-DWL100

Ver. 1.00
SANYO Electric Co., Ltd
DS Company
Projector Division

PDG
-
DWL1
0
0
Expand Serial Command Functional Specifications

2 / 47
−CONTENTS −
1．Overview .........................................................................................................................6
2．Serial Interface Specification........................................................................................6
2.1 Transfer Specification .................................................................................................6
2.2 Connection...................................................................................................................6
3．Notes for communication..............................................................................................7
4．Notation...........................................................................................................................8
5．Functional Execution Command Table........................................................................9
5.1. Image Command Table...........................................................................................9
5.2. PC Control Command Table ..................................................................................9
5.3. Input Control Command Table ..............................................................................9
5.4. Screen Command Table.........................................................................................9
5.5. Lamp Command Table............................................................................................9
5.6. Sound Command Table....................................................................................... 10
5.7. Setting Command Table...................................................................................... 10
6 Status Read Command Table......................................................................................11
6.1 Image Status Read Command Table...................................................................11
6.2 PC Status Read Command Table ........................................................................11
6.3 Video Status Read Command Table....................................................................11
6.4 Input Status Read Command Table.....................................................................11
6.5 Screen Status Read Command Table .................................................................11
6.6 Lamp Status Read Command Table................................................................... 12
6.7 Sound Status Read Command Table................................................................. 12
6.8 Setting Status Read Command Table................................................................ 12
6.9 Other Status Read Command Table................................................................... 12
7 Error Code Table ......................................................................................................... 13
8 Functional Execution Command ........................................................................... 14
8.1 Format................................................................................................................... 14
8.2 Transfer Example................................................................................................. 14
8.3 Operation Requirements..................................................................................... 14
8.4 Image Command.................................................................................................. 15
8.4.1 CF_ BRIGHT Command ............................................................................... 15
8.4.2 CF_CONT Command.................................................................................... 15
8.4.3 CF_COLOR Command ................................................................................. 15
8.4.4 CF_SHARP Command.................................................................................. 15
8.4.5 CF_GAMMA Command ................................................................................ 16
8.4.6 CF_COLTEMP Command............................................................................. 16
8.4.7 CF_IMAGE Command .................................................................................. 16
8.4.8 CF_BCOLOR Command............................................................................... 16
8.4.9 CF_TINT Command ...................................................................................... 17

PDG
-
DWL1
0
0
Expand Serial Command Functional Specifications

3 / 47
8.4.10 CF_WHITEPEAKING Command.................................................................. 17
8.5 PC Control Command.......................................................................................... 18
8.5.1 CF_FSYNC Command.................................................................................. 18
8.5.2 CF_TDOTS Command.................................................................................. 18
8.5.3 CF_H-POS Command................................................................................... 18
8.5.4 CF_V-POS Command ................................................................................... 18
8.6 Input Control Command...................................................................................... 19
8.6.1 CF_INPUT Command ................................................................................... 19
8.6.2 CF_SYSTEM Command ............................................................................... 19
8.6.3 CF_INPUT1 Command ................................................................................. 19
8.6.4 CF_INPUT2 Command ................................................................................. 20
8.6.5 CF_INPUT3 Command ................................................................................. 20
8.6.6 CF_INPUT4 Command ................................................................................. 20
8.6.7 CF_INPUT5 Command ................................................................................. 20
8.6.8 CF_INPUT6 Command ................................................................................. 20
8.6.9 CF_INPUT7 Command ................................................................................. 21
8.6.10 CF_INPUT8 Command ................................................................................. 21
8.7 Screen Control Command .................................................................................. 22
8.7.1 CF_SCREEN Command ............................................................................... 22
8.7.2 CF_KEYSTONE Command .......................................................................... 22
8.7.3 CF_MOUNTING Command........................................................................... 22
8.7.4 CF_DZCENT Command................................................................................ 22
8.8 Lamp Command................................................................................................... 23
8.8.1 CF_LAMPH Command ................................................................................. 23
8.8.2 CF_LAMPMODE Command ......................................................................... 23
8.9 Sound Command ................................................................................................. 24
8.9.1 CF_VOLUME Command............................................................................... 24
8.9.2 CF_MUTE Command.................................................................................... 24
8.10 Setting Command ................................................................................................ 25
8.10.1 CF_INPUTSEARCH Command.................................................................... 25
8.10.2 CF_LANG Command.................................................................................... 25
8.10.3 CF_P-MANETIME Command ....................................................................... 25
8.10.4 CF_FDEFAULT Command............................................................................ 26
8.10.5 CF_RS232MODE Command ........................................................................ 26
8.10.6 CF_STANDBYMODE Command.................................................................. 26
8.10.7 CF_CCAPTION Command ........................................................................... 26
8.10.8 CF_ FANCONTROL Command.................................................................... 27
8.10.9 CF_ LAMPLIFERE Command...................................................................... 27
8.10.10 CF_ RCODE Command ................................................................................ 27
8.10.11 CF_FREEZE Command................................................................................ 27

PDG
-
DWL1
0
0
Expand Serial Command Functional Specifications

4 / 47
9 Status Read Command............................................................................................... 28
9.1 Format................................................................................................................... 28
9.2 Transfer Example................................................................................................. 28
9.3 OSD........................................................................................................................ 28
9.4 Image Status Read Commands.......................................................................... 29
9.4.1 CR_BRIGHT Command................................................................................ 29
9.4.2 CR_CONT Command.................................................................................... 29
9.4.3 CR_COLOR Command................................................................................. 29
9.4.4 CR_SHARP Command ................................................................................. 29
9.4.5 CR_GAMMA Command................................................................................ 29
9.4.6 CR_COLTEMP Command............................................................................. 30
9.4.7 CR_IMAGE Command.................................................................................. 30
9.4.8 CR_BRTCOLOR Command ......................................................................... 30
9.4.9 CR_TINT Command...................................................................................... 30
9.4.10 CR_WHITEPEAKING Command.................................................................. 31
9.5 PC Status Read Commands................................................................................ 32
9.5.1 CR_FSYNC Command.................................................................................. 32
9.5.2 CR_TDOTS Command.................................................................................. 32
9.5.3 CR_H-POS Command .................................................................................. 32
9.5.4 CR_V-POS Command................................................................................... 32
9.5.5 CR_SETPCADJ Command........................................................................... 33
9.6 Video Status Read Command............................................................................. 34
9.6.1 CR_SERSYS Command............................................................................... 34
9.7 CR_INPUT Command .......................................................................................... 35
9.7.1 CR_INPUT Command................................................................................... 35
9.7.2 CR_SOURCE Command .............................................................................. 35
9.7.3 CR_SYSTEM Command............................................................................... 36
9.7.4 CR_SRCINP1 Command.............................................................................. 36
9.7.5 CR_SRCINP2 Command.............................................................................. 36
9.7.6 CR_SRCINP3 Command.............................................................................. 37
9.7.7 CR_SRCINP4 Command.............................................................................. 37
9.7.8 CR_SRCINP5 Command.............................................................................. 37
9.7.9 CR_SRCINP6 Command.............................................................................. 37
9.7.10 CR_SRCINP7 Command.............................................................................. 37
9.7.11 CR_SRCINP8 Command.............................................................................. 37
9.8 Screen Status Read Commands......................................................................... 38
9.8.1 CR_SCREEN Command............................................................................... 38
9.8.2 CR_KYSTNMODE Command....................................................................... 38
9.8.3 CR_MOUNTING Command.......................................................................... 38
9.9 Lamp Status Read Commands........................................................................... 39

PDG
-
DWL1
0
0
Expand Serial Command Functional Specifications

5 / 47
9.9.1 CR_LAMPREPL Command.......................................................................... 39
9.9.2 CR_LAMPH Command................................................................................. 39
9.9.3 CR_LAMPMODE Command......................................................................... 39
9.9.4 CR_LAMPSTS Command............................................................................. 39
9.9.5 CR_PROJH Command ................................................................................. 40
9.9.6 CR_HMLAMP Command.............................................................................. 40
9.10 SOUND status Read Commands........................................................................ 41
9.10.1 CR_VOLUME Command .............................................................................. 41
9.10.2 CR_MUTE Command.................................................................................... 41
9.11 Setting Status Read Commands ........................................................................ 42
9.11.1 CR_INPUTSEARCH Command.................................................................... 42
9.11.2 CR_LANG Command.................................................................................... 42
9.11.3 CR_P-MANETIME Command....................................................................... 42
9.11.4 CR_SECURITY Command............................................................................ 42
9.11.5 CR_PJLOCKNOW Command ...................................................................... 43
9.11.6 CR_PJLOCKMENU Command .................................................................... 43
9.11.7 CR_RS232MODE Command........................................................................ 43
9.11.8 CR_STANDBYMODE Command.................................................................. 43
9.11.9 CR_CCAPTION Command........................................................................... 43
9.11.10 CR_FANCONTROL Command..................................................................... 44
9.11.11 CR_LAMPLIFERE Command....................................................................... 44
9.11.12 CR_RCODE Command................................................................................. 44
9.12 Other Status Read Commands........................................................................... 45
9.12.1 CR_STATUS Command................................................................................ 45
9.12.2 CR_SIGNAL Command ................................................................................ 45
9.12.3 CR_VMUTE Command ................................................................................. 45
9.12.4 CR_FREEZE Command................................................................................ 45
9.12.5 CR_TEMPWARN Command......................................................................... 46
9.12.6 CR_TEMPFAIL Command............................................................................ 46
9.12.7 CR_TEMP Command.................................................................................... 47

PDG
-
DWL100
Expand Serial Command Functional Specifications

6 / 47 
1．Overview
・ This Functional Specification defines communication with Network board for PDG- DWL100.
・ Commands are designed to Network communication, but most commands are also available to
remote-control a projector through RS-232C from a computer. Therefore, commands are defined as
Expand Serial Commands.
・ The operation by some commands depends on Input or Source of the projector.
2．Serial Interface Specification
2.1 Transfer Specification
Items Specification
Synchronous System Asynchronous
Transmission Speed 9600/19200
Data Length 8 bit
Parity N/A
Stop Bit 1
Flow Control N/A
1) Transmission Speed: Initial setting value is 9600.
2) Transmission Speed can be changed in service mode.
2.2 Connection
Use the dedicated serial cables for the connection between a computer and the projector.
PC Projector
COM 1 Serial Port IN

（D‑Sub9Pin）（Mini8Pin）
Connect COM port of the computer to SERIAL PORT IN of the projector.
COM Port (COM1 or COM2) of a computer is specified by the control software of the computer.

PDG
-
DWL100
Expand Serial Command Functional Specifications

7 / 47 
3．Notes for communication
3.1 Expand Serial Command is defined as a single command per line that starts with “C” and ends with
carriage return (0x0D).
3.2 When a projector receives carriage return (0x0D), it starts decoding.
3.3 There are two types of commands; the Functional Execution Command and the Status Read
Command.
・Example of Functional Execution Command:”CF_BRIGHT_032” [CR]
・Example of Status Read Command: “CR_BRIGHT” [CR]
Note) “_” indicates a space
3.4 It clears the information of buffer in the conditions bellow:
・When the projector receives LF (0x0A) or EOF (0x1A).
・When it takes more than one second to receive a single command.
(Until receiving the carriage return after the reception of the first data.)
3.5 The projector processes commands and returns responses within a few ms to 8000 ms after the
reception of the command.
When several commands are issued in succession, do not send another command unless the
response to the previous command has been returned; need to confirm that the processing of the
current command has been completed and returned the response before sending another
command.
Command
PC →Projector “CF_BRIGHT_032” [CR]
Projector →PC “000” [CR]
Command processing Response
(A few ms – 8000 ms)
Note) When the computer sends another command before the previous response has been
returned, the projector may not operate properly.
Note) When the current command processing has not been completed, another command
process cannot be accepted by the projector.
3.5.1 Normally it is less than 1000ms for the completion of receiving a command and returning the
response, but it takes more than 1000ms for some Functional Execution Commands (CF
commands) as listed below:
Command Item
CF_IMAGE Select Image Mode
CF_INPUT Select Input
CF_SCREEN Select Screen Size
CF_SYSTEM Select System
CF_IMAGEADJ Reset/Store for Image Adjustment
It takes about 8 seconds for the internal initialization after plugging inAC power.
During this time commands cannot be processed. Do not issue any command.


PDG
-
DWL100
Expand Serial Command Functional Specifications

8 / 47 
4．Notation
4.1 Data from a controller to a projector is represented as COMMAND, and responded data from a
projector to a controller against the incoming command is represented as RESPONSE.
4.2 [CR]: Carriage Return Code
The command ends with carriage return code.
The response also ends with carriage return code.
4.3 _: Space Code
All space code is indicated by (_).
4.4 %1: Parameter included in command.
When there is more than one parameter, they are represented as %2, %3…
In this specifications,”Slot” notation is same as ”Input” notation. Etc.Slot1=Input1.

PDG
-
DWL100
Expand Serial Command Functional Specifications

9 / 47 
5．Functional Execution Command Table
5.1.Image Command Table
Execute command Item
CF_BRIGHT_%1[CR] Set value of Brightness
CF_CONT_%1[CR] Set value of Contrast
CF_COLOR_%1[CR] Set value of Color
CF_SHARP_%1[CR] Set value of Sharpness
CF_GAMMA_%1[CR] Set value of Gamma Correction
CF_COLTEMP_%1[CR] Set level of Color Temperature
CF_IMAGE_%1[CR] Set Image mode Preset
CF_BCOLOR_%1[CR] Set value of Brilliant Color
CF_TINT_%1[CR] Set value of Tint
CF_WHITEPEAKING_%1[CR]
Set value of White peaking
5.2. PC Control Command Table
Execute command Item
CF_FSYNC_%1[CR] Set value of Fine sync
CF_TDOTS_%1[CR] Set value of Total dots
CF_H-POS_%1[CR] Set value of Horizontal Position
CF_V-POS_%1[CR] Set value of Vertical Position
5.3. Input Control Command Table
Execute command Item
CF_INPUT_%1[CR] Select Input
CF_SYSTEM_%1[CR] Select System in Video or S-Video input mode
CF_INPUT1_%1[CR] Select Input1 and set input selected in %1
CF_INPUT2_%1[CR] Select Input2 and set input selected in %1
CF_INPUT3_%1[CR] Select Input3 and set input selected in %1
CF_INPUT4_%1[CR] Select Input4 and set input selected in %1
CF_INPUT5_%1[CR] Select Input5 and set input selected in %1
CF_INPUT6_%1[CR] Select Input6 and set input selected in %1
CF_INPUT7_%1[CR] Select Input7 and set input selected in %1
CF_INPUT8_%1[CR] Select Input8 and set input selected in %1
5.4. Screen Command Table
Execute command Item
CF_SCREEN_%1[CR] Select Aspect Ratio.
CF_KEYSTONE _%1[CR] Set Keystone Correction
CF_MOUNTING_%1[CR] Select Mounting mode
CF_DZCENT_%1[CR] Cancel Digital zoom
5.5. Lamp Command Table
Execute command Item
CF_LAMPH_%1[CR] Reset total lamp running time for each lamp
CF_LAMPMODE_%1[CR] Switch dimmer function levels of Normal/Eco

PDG
-
DWL100
Expand Serial Command Functional Specifications

10 / 47 
5.6. Sound Command Table
Execute command Item
CF_VOLUME_%1[CR] Set value of Volume.
CF_MUTE_%1[CR] Set ON/OFF of Sound Mute.
5.7. Setting Command Table
Execute command Item
CF_INPUTSEARCH_%1[CR] Set ON/OFF of Input search
CF_LANG_%1[CR] Select language for OSD
CF_P-MANETIME_%1[CR] Set timer for Power management
CF_FDEFAULT_%1[CR] Return the settings to Factory Default status
CF_RS232MODE_%1[CR] Set RS232/LAN of RS232 mode
CF_STANDBYMODE_%1[CR] Set Standby mode.
CF_CCAPTION_%1[CR] Set Closed caption.
CF_FANCONTROL_%1[CR] Set Fan control.
CF_LAMPLIFERE_%1[CR] Set Lamp life Reminder.
CF_RCODE_%1[CR] Select Remote Control Reception Code
CF_FREEZE_%1[CR] Set Freeze on.

PDG
-
DWL100
Expand Serial Command Functional Specifications

11 / 47 
6 Status Read Command Table
6.1 Image Status Read Command Table
Status read command Item
CR_BRIGHT [CR] Get value of Brightness
CR_CONT [CR] Get value of Contrast
CR_COLOR [CR] Get value of Color
CR_SHARP [CR] Get value of Sharpness
CR_GAMMA [CR] Get value of Gamma
CR_COLTEMP [CR] Get value of Color temperature
CR_IMAGE [CR] Get Selected Image Status
CR_BCOLOR [CR] Set value of Brilliant Color
CR_TINT [CR] Set value of Tint
CR_WHITEPEAKING [CR] Get value ofWhite peaking
6.2 PC Status Read Command Table
Status read command Item
CR_FSYNC [CR] Get setting value of Fine Sync.
CR_TDOTS [CR] Get setting value of Total Dots
CR_H-POS [CR] Get setting value of Horizontal Position
CR_V-POS [CR] Get setting value of Vertical Position
CR_SETPCADJ [CR] Get currently displayed signal
6.3 Video Status Read Command Table
Status read command Item
CR_SERSYS [CR] Get currently selected signal.
6.4 Input Status Read Command Table
Status read command Item
CR_INPUT [CR] Get selected Input
CR_SOURCE [CR] Get selected Source
CR_SYSTEM [CR] Get selected System in Video Input mode
CR_SRCINP1 [CR] Get selected source for Input 1
CR_SRCINP2 [CR] Get selected source for Input 2
CR_SRCINP3 [CR] Get selected source for Input 3
CR_SRCINP4 [CR] Get selected source for Input 4
CR_SRCINP5 [CR] Get selected source for Input 5
CR_SRCINP6 [CR] Get selected source for input 6
CR_SRCINP7 [CR] Get selected source for input 7
CR_SRCINP8 [CR] Get selected source for input 8
6.5 Screen Status Read Command Table
Status read command Item
CR_SCREEN [CR] Get selected screen size
CR_KYSTNMODE [CR] Get Keystone mode
CR_MOUNTING [CR] Get Mounting mode

PDG
-
DWL100
Expand Serial Command Functional Specifications

12 / 47 
6.6 Lamp Status Read Command Table
Status read command Item
CR_LAMPREPL[CR] Get information on Lamp replacement time
CR_LAMPH [CR] Get total Actuality used time of lamps
CR_LAMPMODE [CR] Get setting status of dimmer function level.
CR_LAMPSTS [CR] Get Lamp lighting status
CR_PROJH [CR] Get total running time of projector
CR_HMLAMP [CR] Get the total number of lamps
6.7 Sound Status Read Command Table
Status read command Item
CR_VOLUME [CR] Get value of Volume.
CR_MUTE [CR] Get setting status of Mute.
6.8 Setting Status Read Command Table
Status read command Item
CR_INPUTSEARCH [CR] Get setting status of Input search.
CR_LANG [CR] Get selected language
CR_P-MANETIME [CR] Get value of time when Power management
CR_SECURITY [CR] Get setting status of security
CR_PJLOCKKNOW [CR] Get actual setting status of security
CR_PJLOCKMENU [CR] Get setting status of security of menu
CR_RS232MODE [CR] Get setting status of RS232 mode
CR_STANDBYMODE[CR] Get setting status of Standby mode.
CR_CCAPTION [CR] Get setting status of Closed caption.
CR_FANCONTROL [CR] Get setting status of Fan control.
CR_LAMPLIFERE [CR] Get setting status of Lamp life Reminder.
CR_RCODE [CR] Get selected Remote Control Code
6.9 Other Status Read Command Table
Status read command Item
CR_STATUS [CR] Get status of projector.
CR_SIGNAL [CR] Get status of signal existence.
CR_VMUTE [CR] Get setting status of No Show.
CR_FREEZE [CR] Get setting status of Freeze
CR_TEMPWARN [CR]
Get temperature status whether it is close to abnormal
level or not.
CR_TEMPFAIL [CR] Get temperature in abnormal temperature status.
CR_TEMP [CR] Get temperature status of now.

PDG
-
DWL100
Expand Serial Command Functional Specifications

13 / 47 
7 Error Code Table
Error Code Contents
? -When the received data which cannot be decoded. -Parameter designation error (wrong digit number, including invalid
value, etc.)
000 Normal reception.
(This is “Not” error.)
101 Specified function is not available in the selected mode.
102 Specified value is out of range. (Not reflected)
103
Command mismatched to Hardware (The command is for the
Optional function which is not implemented)
201 Increased/decreased value is out of range in the item which is
specified with numerical parameter or changeable numerical value.

PDG
-
DWL100
Expand Serial Command Functional Specifications

14 / 47 
8 Functional Execution CommandFormat
①PC issues a command in the format below:
Pattern1: “CF_Command” [CR]
Pattern2: “CF_Command_” %1 [CR]
CF_: Header
Command: Text
%1: Parameter (Text)
_: Space (To separate Command and Parameter)
①The projector decodes the received command and when it gets ready to receive another
command, it returns the Correspondence.
“000” [CR]: (0x06, 0x0D) When the projector receives the Functional Execution
Command.
“nnn” [CR]: Except “000”, when it cannot execute commands for some specific reason.
Refer to [7. Error Code Table] for detail.
①When the projector cannot decode the command, it returns “?” [CR].
8.2 Transfer Example
When setting projector’s total dots to 1344 by Expand Command.
PC →PJ: “CF_TDOTS_1344” [CR]
PC ←PJ: “000” [CR] ---------------- Acceptable
8.3 Operation Requirements
Functional Execution Commands are limited in the status bellow/
(Status Read Commands are available in following status.)
Projector Status Available Functional Execution Command
In Standby Mode C00: POWER ON
Cooling Down in process NONE (No Execution)
Cooling Down in process due to
abnormal temperature NONE (No Execution)
In Abnormal Temperature NONE (No Execution)
Power Failure
(For 60 seconds after Power failed.) NONE (No Execution)
Note) The projector returns an appropriate error code when it receives other command in the
above status.

PDG
-
DWL100
Expand Serial Command Functional Specifications

15 / 47 
8.4 Image Command
8.4.1 CF_ BRIGHT Command
Command “CF_BRIGHT_%1” [CR]
%1
“
-
50
~
0
50
”
---------------
Directly specify setting
value of Brightness
“UP” ---------------------- Increment setting value of Brightness by 1
“DN” ---------------------- Decrement setting value of Brightness by 1
Details
Set user controlled value of Brightness.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.4.2 CF_CONT Command
Command
“CF_CONT_%1” [CR]
%1
“
-
50
~
0
50
”
---------------
Directly specify setting value of Contrast
“UP”--------------------- Increment setting value of Contrast by 1
“DN”--------------------- Decrement setting value of Contrast by1
Details
Set user controlled value of Contrast.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.4.3 CF_COLOR Command
Command
“CF_COLOR_%1” [CR]
%1
“
-
16
~
0
16
”
---------------
Directly specify setting value of Color
“UP”--------------------- Increment setting value of Color by 1
“DN”--------------------- Decrement setting value of Color by 1
Details
Set user controlled value of Color.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [
CR]
Unacceptable
“Error Code” [CR]
8.4.4 CF_SHARP Command
Command
“CF_
SHARP_
%1” [CR]
%1
“000
~
031”
--------------
Directly specify setting value of Sharpness.
“UP”--------------------- Increment setting value of Sharpness by 1
“DN”--------------------- Decrement setting value of Sharpness by 1
Details
Set user controlled value of Sharpness.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [C
R]

PDG
-
DWL100
Expand Serial Command Functional Specifications

16 / 47 
8.4.5 CF_GAMMA Command
Command
“CF_GAMMA_%1” [CR]
%1 “000~003” ---------------- Directly specify setting value of Gamma “UP”---------------------- Increment setting value of Gamma by 1
“DN”---------------------- Decrement setting value of Gamma by1
Details
Set user controlled value of Gamma.
(Available only in the normalPower ON status)
No display is shown when projector received command
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.4.6 CF_COLTEMP Command
Command
“CF_COLTEMP_%1”
[CR]
%1
“000”
–
“00
2
”
“UP” ------------------------------Change the Color Temp upward
“DN” ------------------------------Change the Color Temp downward
Details
Set Color Temperature
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.4.7 CF_IMAGE Command
Command
“CF_IMAGE__%1” [CR]
%1
“PRESEN”
------------
Presentation
(Fixed value to display graphic image with Presentation)
“BRIGHT” -------- Bright (Fixed value to focus on tone reproduction for Bright)
“MOVIE ------ Movie (Fixed value to focus on tone reproduction for Movie)
“SRGB” ------ sRGB (Fixed value to focus ontone reproduction for sRGB)
“USER” ------ USER (Fixed value to focus on tone reproduction for USER)
Details
Select Image mode.
(Available only in the normal Power ON status)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable “Error Code” [CR]
8.4.8 CF_BCOLOR Command
Co
mmand
“CF_
BCOLOR
_%1”[CR]
%1
“
O
N
~
O
FF
”
------
Directly specify setting value of
Brilliant Color
.
“UP”---- Change the Brilliant Color upward
“DN”---- Change the Brilliant Color downward
Details
Set user controlled value of
Brilliant Color
.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]

PDG
-
DWL100
Expand Serial Command Functional Specifications

17 / 47 
8.4.9 CF_TINT Command
Command
“CF_TINT_%1”[CR]
%1
“
-
50~0
50
”
------
Directly specify setting value of Tint
.
“UP”---- Set Tint to UP
“DN”---- Set Tint to DN
Details
Set user controlled value of Tint.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error C
ode” [CR]
8.4.10 CF_WHITEPEAKING Command
Command
“CF_WHITEPEAKING_%1”[CR]
%1
“000
~
010”
------
Directly specify setting value of White peaking.
“UP”------------ Increment setting value of White peaking by 1
“DN” ----------- Decrement setting value of White peaking by 1
Details
Set user controlled value of White peaking.
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]

PDG
-
DWL100
Expand Serial Command Functional Specifications

18 / 47 
8.5 PC Control Command
8.5.1 CF_FSYNC Command
Command
“CF_FSYNC
_
%1” [CR]
%1
“0000
~
0031
”
-----------------
Directly specify setting value of
Fine sync
“UP” --------------------------- Increment setting value of Fine sync by 1
“DN” --------------------------- Decrement setting value of Fine sync by 1
Details
Set value of
Fine sync
in
PC signal
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.5.2 CF_TDOTS Command
Comm
and
“CF_TDOTS
_
%1” [CR]
%1
“
-
005
~
0005
”
---------------
Directly specify setting value of
Total dots
“nnnn” indicates minimum value, which is current
(Display Dots + Position H) value
“UP” ------------------------- Increment setting value of Total dots by 1
“DN” ------------------------- Decrement setting value of Total dots by 1
Details
Set value of Total Dots in PC signal
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000”
[CR]
Unacceptable
“Error Code” [CR]
8.5.3 CF_H-POS Command
Command
“CF_H
-
POS_%1” [CR]
%1
“
-
005
~
0005
”
--------
Directly specify setting value of Horizontal Position
“nnnn” indicates maximum value, which is current value of
(Total Dots - Display Dots)
“UP” ------------------- Increment setting value of Horizontal Position by 1
“DN” ------------------ Decrement setting value of Horizontal Position by 1
Details
Set value of Horizontal Position in PC signal
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.5.4 CF_V-POS Command
Command
“CF_V
-
POS_%1” [CR]
%1
“
-
00
5
~
0005
”
------------
Directly specify setting value of Vertical Position
“nnnn” indicates maximum value, which is current (Total Line
– Display Line) value
“UP” --------------------- Increment setting value of Vertical Position by 1
“DN” --------------------- Decrement setting value of Vertical Position by 1
Details
Set Vertical Posit
ion value in PC signal
(Available only in the normal Power ON status)
No display is shown when projector received command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]

PDG
-
DWL100
Expand Serial Command Functional Specifications

19 / 47 
8.6 Input Control Command
8.6.1 CF_INPUT Command
Command
“CF_INPUT
_
%
1” [CR]
%1
“
HDMI
”
----------------------------
Select
HDMI
“COMPUTER1” ----------------- Select Computer 1
“YPBPR1” ------------------------ Select YPbPr 1
"COMPUTER2” ----------------- Select Computer 2
“YPBPR2” ------------------------ Select YPbPr 2
“SCART” -------------------------- Select Scart
“VIDEO” --------------------------- Select Video
“S-VIDEO” ------------------------ Select S-video
Details
Select
Input
(Valid only when it is in the normal PowerON status.)
This command works the same way as “SOURCE” button of the projector
and remote control.
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“
Error Code
” [CR]
8.6.2 CF_SYSTEM Command
Command
“CF_SYSTEM_%1” [CR]
%1
Input is
Video
“AUTO”
---------------------------
Select MODE
1
“NTSC” --------------------------- Select MODE 2
“PAL” --------------------------- Select MODE 3
“SECAM” --------------------------- Select MODE 4
Input is
S-Video
“AUTO” --------------------------- Select MODE 1
“NTSC” --------------------------- Select MODE 2
“PAL” --------------------------- Select MODE 3
“SECAM” --------------------------- Select MODE 4
Details
Select system of the currently selected Input.
(Valid only when in the normal Power ON status.)
When selected Input does not meet the requirement for the specified %1,
return “101” [CR] and the command is not executed.
No display is shown when projector received command..
Correspondence
Acceptable
“000” [CR]
Unacceptable
“Error Code” [CR]
8.6.3 CF_INPUT1 Command
Command
“CF_INPUT1
_
%1” [CR]
%1
“HDMI”
----------------------------
Select HDMI
Details
Select HDMI
(Valid only when it is in the normal Power ON status.)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“
000” [CR]
Unacceptable
“
Error Code
” [CR]

PDG
-
DWL100
Expand Serial Command Functional Specifications

20 / 47 
8.6.4 CF_INPUT2 Command
Command
“CF_INPUT2
_
%1” [CR]
%1 “COMPUTER１” ---------------------------- Select Computer1
Details
Select
Computer1
(
Valid only
when
it is i
n the normal Power ON status.
)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“
Error Code
” [CR]
8.6.5 CF_INPUT3 Command
Command
“CF_INPUT3
_
%1” [CR]
%1
“YPBPR1”
----------------------------
Select YPbPr1
Details
Select YPbPr1 (
Valid only
when
it is
i
n the normal Power ON status.
)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“
Error Code
” [CR]
8.6.6 CF_INPUT4 Command
Command
“CF_INPUT4
_
%1” [CR]
%1
“COMPUTER2”
----------------------------
Se
lect Computer2
Details
Select Computer2 (
Valid only
when
it is i
n the normal Power ON status.
)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“
Error Code
” [CR]
8.6.7 CF_INPUT5 Command
Command
“CF_
INPUT5
_
%1” [CR]
%1
“YPBPR 2”
----------------------------
Select YPbPr 2
Details
Select YPbPr 2 (
Valid only
when
it is i
n the normal Power ON status.
)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacce
ptable
“
Error Code
” [CR]
8.6.8 CF_INPUT6 Command
Command
“CF_INPUT6
_
%1” [CR]
%1
“SCART”
----------------------------
Select Scart
Details
Select Scart (
Valid only
when
it is i
n the normal Power ON status.
)
The projector shows Image OSD atreceiving the command.
Correspondence
Acceptable
“000” [CR]
Unacceptable
“
Error Code
” [CR]
