Sanyo PLC-WK2500 - 2500 Lumens User manual

PLC
PLC- -WK2500 WK2500
©2010 SANYO
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a
general estimate. The brightness of a lamp usually decreases over time and use.
2500 LUMENS zWXGA zULTRAPORTABLE PROJECTOR
WXGA ULTRAPORTABLE PROJECTOR
Back Panel
Resolution WXGA (1280 x 800)
Brightness (typical) 2500 Lm
Contrast Ratio 3000:1
Image Size 40"-300“
Aspect Ratio 16:10
Projection Lamp 215W
Scanning Frequency H:15-100kHz, V:50-100Hz
Fan Noise 29 dBA (Eco)
Voltage 100-240V AC (auto voltage) ; 50/60 Hz
Power Consumption 195W (Eco), 286W(High)
Input signal compatibility WUXGA/UXGA/ WXGA/ SXGA+/ SXGA/ XGA/ SVGA/
VGA/ MAC/ 1080i/50,60 / 1035i/ 720p/ 480p,i / 575p,i
Color System NTSC / PAL / SECAM / NTSC4.43 / PAL-M / PAL-N
Projection Lens (inch) F 2.00– 2.15 f=0.72" – 0.87"
Throw Ratio 1.44 - 1.72 : 1
Throw Distance (feet) 3.9’ – 36.4’
Zoom / Focus Manual
Up / Down Ratio 13 :1
Digital Keystone Correction V +/- 30°(Auto keystone +/- 20°)
Digital Zoom 16x – 1/4x
Speaker Output 10W
Weight (lbs) 6.4 lbs
Dimensions (inch) W,H,D 13.1” x 4.1” x 9.7”
Replacement Lamp # 610 349 7518
Replacement Remote # 645 099 3213
Lamp Life * (hours) 6000h (Eco)
Input PC/Video D-sub 15 x1 (RGB, Component, S-Video)
D-sub 15 x1 (RGB, Monitor out)
RCA x1 (Composite)
Audio Stereo mini jack x 1
RCA x2 (R/L, mono)
Output PC/Video D-sub 15 x1 (in common)
Audio Stereo mini jack x 1
Other Feature RJ-45 (LAN)
Dsub 9pin (RS232C)
Included Accessories
Power cord
VGA cable
Remote control
AAA Battery x2
Quick reference guide
Owner’s Manual(CD-Rom)
PIN code Label
Optional Accessories POA-CA-COMPVGA
POA-CA-VGAS
POA-CACVCL2
(Component -VGA cable)
(S-Video –VGA cable)
(Soft carry case)
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
3LCD Built-in Network Closed Caption
ULTRA-PORTABLE, FULLY COMPACT AND HIGH BRIGHTNESS
The PLC-WK2500 weighs less than 7 pounds and delivers true WXGA
picture quality in a versatile package.
This projector achieves 2500Lm and provides a crisp clear image.
HIGH CONTRAST RATIO OF 3000:1
Sanyo improves contrast ratio with a new built-in iris which detects
the picture image and then controls light output.
Image quality is increased thanks to this newly developed iris system.
ULTRA-LONG LASTING LAMP AND FILTER
The PLC-WK2500 allows saving your total cost of ownership with an ultra
long life lamp and filter. The lamp enables 6000H, the filter enables
5500H with eco mode in ideal conditions, thanks to a re-designed cooling
system and filter size and layout.
COMPLETE EASY AUTO SET UP FUNCTION, SMART AUTO INPUT
SEARCH AND AUTO VERTICAL KEYSTONE CORRECTION
PLC-WK2500 provides "Auto Set Up Function" that corrects keystone
shaped distortion by searching for an input signal and detecting projector
incline, automatically compensating for keystone picture distortion,
therefore reducing set up time. These features... Auto Keystone
Correction, Auto Input Search and Auto PC Adjustment make it an easy
to use smart projector.
WIRED LAN (RJ-45) FOR NETWORK PROJECTOR CONTROL
This model is equipped with Wired LAN (RJ-45) that allows you to
manage and control the projector via the Network. Providing access to
check the projectors operating time of the lamp, control the projector and
receive any warning notifications by email. Power ON/OFF and switching
of the input signal can also be controlled.
MICROPHONE TERMINAL WITH 10W SPEAKER
The PLC-WK2500 offers an additional feature of a microphone input
terminal. Simply connecting the microphone to the terminal, the presenter
can use this feature immediately. The projector is equipped with a 10W
speaker and therefore there is no need to set-up any amplifier and
cables.
CLOSED CAPTION
PLC-WK2500 is Closed Caption compatible.
