Sanyo PLC-XT25 User manual

4500 & 3800 ANSI LUMENS TRUE XGA MULTIMEDIA PROJECTORS
Issued 01/07 © 2007 SANYO
PLC-XT25/XT20
XGA Portable Multimedia Projectors
EASY INSTALLATION
The symmetric Lens Center Design offers unlimited setup
options to meet specific staging requirements. To further
increase installation convenience, the significantly improved
Up/Down/Left/Right lens shift ensures flawless image
projection even at the most challenging positions.
REMARKABLE BRIGHTNESS
The high-tech optical system and the 300W UHP lamp deliver
an impressive 4500 and 3800 ANSI lumens brightness levels,
respectively.
MINDBLOWING CONTRAST RATIO
With a high-contrast optical system employing the Micro Lens
technology, the PLC-XT25/20 achieves a remarkable contrast
ratio of 1000:1.
HIGH RELIABILITY
Newly design cabinet has improved air flow system with
sophisticated design One-Way Flow System, which is an
efficient temperature control system that cools the projector with
single intake and exhaust vents. A Filter Warning function can
alert the user to clean clogged filters, hence increases picture
quality and suitable for the professional use.
EASY MAINTENANCE
PLC-XT25 embodies both beauty and practicality with its
detachable top cover. The user can effortlessly flip open its top
plate to clean and replace the Prism Block system. Well-
maintained LCD Panels will significantly reduce artifact from
projected images.
NETWORK CONNECTIVITY
An optional PJ-Net Camera (POA-PN03C) and PJ Master
Software (POA-PJNM01) allows for control and administration
of projectors via a network. The user can monitor the actual
picture and check projector status and control projector
functions via any web browsers. A warning notification will be
automatically sent to the registered users’emails, whenever
the projector encounters problems.
WHISPER QUIET FAN
The Whisper Quiet fan system produces an amazingly low
noise level of only 31 dBA (Eco mode).
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 888-337-1215 (toll-free)
Fax [phone]
www.sanyolcd.com
S p e c i f i c a t i o n s
Resolution XGA (1024 x 768)
Brightness (typical) 4500/3800 ANSI Lumens –PLC-XT25/XT20
Uniformity 90%
LCD Panel System 1.0”TFT Poly w/Micro Lens x 3 (XT20 w/o Micro Lens)
Number of Pixels 2,359,296 (786,432 x 3)
Contrast Ratio 1000:1
Projection Image (diagonal) 30”-300”
Aspect Ratio 4:3
Throw Distance 3.9’-32.8’
Zoom/Focus Powered (1:1.3 zoom)
Up/Down Ratio
Right/Left Ratio 10:0 –1:1 13:7 –7:13
Digital Keystone Correction Vert. + 40/-40
Projection System Polarized Beam Splitter optical system
Projection Lens F1.7-2.1 / f1.34”-1.73”
Lens Throw Ratio 1.6 –2.1: 1
Projection Lamp 300W UHP
Scanning Frequency H 15-100kHz; V 50-100Hz (auto sense/select)
Dot Clock 140MHz(Analog), 100MHz(Digital)
Color System PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
Computer Compatibility UXGA(Only AnalogRGB), WXGA, SXGA/+, XGA, SVGA, VGA
Sound Output 1W
Voltage 100-240V AC; 50/60/Hz (auto sense/select)
BTU Rating 1467
dB Rating 31 dBA (Eco mode)
Power Consumption 430W
Dimensions (WxHxD) 13.7”x 6.2”x 17.5”(w/o surface projection)
Net Weight 19.2 lbs.
User Maintenance Clean air filters, replace lamp assembly
Computer Input Terminal 1 RGB (D-Sub15 x1, DVI-D x1) Audio (stereo mini jack x 1)
Computer Input Terminal 2 RGB/Component/Composite (BNC x 5)
Audio (stereo mini jack x 1)
Video Input Terminal Composite (RCA) S-Video (mini DIN4) Stereo Audio
(RCA x 2)
Additional Input Terminals USB (Type B), Control (Mini Din 8-pin)
Output Terminals Monitor Out (D-Sub 15 x 1) Audio (stereo mini-jack)
Included Accessories Wireless/Wired I/R Remote Control w/Mouse Pad and
Laser Pointer AC power cord VGA Cable USB Cable
Lens cover Owner’s manual (Quick manual & CD-
ROM) 2 “AAA”Batteries PIN Code labelSerial Cable
Optional Accessories POA-PN03C –Optional PJ-Net Camera (ship from Dec/06)
POA-PJNM01 –PJ Master Software
6103307329 –Replacement Lamp
Optional Lenses (see below)
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
Optional Lens Specifications
On Axis Short
Fixed Short Zoom Long Zoom Ultra Long Zoom
Part No. LNS-W11 LNS-W10 LNS-T10 LNS-T11
Zoom Fixed Power Power Power
Throw Ratio 0.8:1 1.23-1.62:1 2.12-3.39:1 3.4-5.4:1
F Stop 2.3 2.3-2.6 2.0-2.6 2.1-2.52
Lens Shift
(U/D, L/R) Fixed 10:0-1:1 13:7-7:13 10:0-1:1 13:7- 7:13 10:1-1:1 13:7-7:13
*W11/T11 will ship from Feb. 2007
* 20L/25L: Lens sold separately
Back
panel of PLC
-
XT25/20
PJ
-
Net Camera POA
-
PN03C
