BASIC SERIAL COMMAND
FUNCTIONAL SPECIFICATIONS
PLC-XTC50AL
SANYO Electric Co., Ltd
DS Company
Projector Business Division

PLC-XTC50ALBasic Serial Command Functional Specifications                 
2/26
Contents
1. Overview.............................................................................................................................5
2. Serial Interface Specification ...........................................................................................5
2.1. Transfer Specification ................................................................................................5
2.2. Connection..................................................................................................................5
3. Notes for Communication ................................................................................................6
4. Functional Execution Command Table...........................................................................7
5. Status Read Command Table...........................................................................................8
6. Functional Execution Command .....................................................................................9
6.1 Format......................................................................................................................9
6.2 When the command pipelining is needed............................................................9
6.3 Transfer Example....................................................................................................9
6.4 Operation Requirements..................................................................................... 10
6.5 POWER ON Command .........................................................................................11
6.6 POWER OFF Command (Quick POWER OFF)....................................................11
6.7 POWER OFF Command........................................................................................11
6.8 INPUT 1 Command................................................................................................11
6.9 INPUT 2 Command................................................................................................11
6.10 INPUT 3 Command............................................................................................... 12
6.11 NETWORK Command.......................................................................................... 12
6.12 VOLUME + Command.......................................................................................... 12
6.13 VOLUME – Command.......................................................................................... 12
6.14 SOUND MUTE ON Command.............................................................................. 12
6.15 SOUND MUTE OFF Command............................................................................ 12
6.16 VIDEO MUTE ON Command ............................................................................... 13
6.17 VIDEO MUTE OFF Command.............................................................................. 13
6.18 SCREEN NORMAL SIZE Command ................................................................... 13
6.19 SCREEN WIDE SIZE Command.......................................................................... 13
6.20 MENU ON Command ........................................................................................... 13
6.21 MENU OFF Command.......................................................................................... 13
6.22 DISPLAY CLEAR Command................................................................................ 14
6.23 BRIGHTNESS + Command.................................................................................. 14
6.24 BRIGHTNESS - Command .................................................................................. 14
6.25 INPUT 2 VIDEO Command .................................................................................. 14
6.26 INPUT 2 Y,Pb/Cb,Pr/Cr Command...................................................................... 14
6.27 INPUT 2 RGB Command...................................................................................... 14
6.28 IMAGE Command................................................................................................. 14
6.29 ON START SET Command .................................................................................. 15
6.30 ON START CANCEL Command.......................................................................... 15
6.31 POWER MANAGEMENT READY Command...................................................... 15

PLC-XTC50ALBasic Serial Command Functional Specifications                 
3/26
6.32 POWER MANAGEMENT CANCEL Command................................................... 15
6.33 POWER MANAGEMENT SHUTDOWN Command............................................. 15
6.34 D.ZOOM + Command........................................................................................... 15
6.35 D.ZOOM - Command............................................................................................ 16
6.36 INPUT 3 VIDEO Command .................................................................................. 16
6.37 INPUT 3 S-VIDEO Command............................................................................... 16
6.38 POINTER RIGHT Command................................................................................ 16
6.39 POINTER LEFT Command .................................................................................. 16
6.40 POINTER UP Command ...................................................................................... 16
6.41 POINTER DOWN Command................................................................................ 17
6.42 ENTER Command ................................................................................................ 17
6.43 FREEZE ON Command........................................................................................ 17
6.44 FREEZE OFF Command...................................................................................... 17
6.45 ZOOM + Command............................................................................................... 17
6.46 ZOOM - Command ............................................................................................... 17
6.47 FOCUS + Command............................................................................................. 18
6.48 FOCUS - Command.............................................................................................. 18
6.49 INPUT 1 ANALOG RGB Command..................................................................... 18
6.50 INPUT 1 SCART Command................................................................................. 18
6.51 INPUT 1 DVI (PC DIGITAL) Command................................................................ 18
6.52 INPUT 1 DVI (AV HDCP) Command.................................................................... 18
6.53 LENS SHIFT UP Command ................................................................................. 18
6.54 LENS SHIFT DOWN Command........................................................................... 19
6.55 LENS SHIFT LEFT Command ............................................................................. 19
6.56 LENS SHIFT RIGHT Command........................................................................... 19
6.57 AUTO PC ADJ. Command................................................................................... 19
6.58 PRESENTATION TIMER Command .................................................................... 19
6.59 KEYSTONE ↑Command .................................................................................. 19
6.60 KEYSTONE ↓Command .................................................................................. 20
6.61 KEYSTONE →Command.................................................................................... 20
6.62 KEYSTONE ←Command.................................................................................... 20
7Status Read Command............................................................................................... 21
7.1 Format................................................................................................................... 21
7.2 Transfer Example................................................................................................. 21
7.3 Operation Requirements..................................................................................... 21
7.4 Status Read Command........................................................................................ 22
7.5 Input Mode Read Command ............................................................................... 25
7.6 Lamp Time Read Command................................................................................ 25
7.7 Setting Read Command ...................................................................................... 25
7.8 Temp Read Command ......................................................................................... 26

PLC-XTC50ALBasic Serial Command Functional Specifications                 
4/26
7.9 Lamp Mode Read Command .............................................................................. 26

PLC-XTC50ALBasic Serial Command Functional Specifications                 
5/26
1. Overview
・ These specifications define projector control commands for PLC-XTC50AL.
・ The projector control commands are used to control a projector through RS-232C from a computer.
2. Serial Interface Specification
2.1. Transfer Specification
Item Spec if icat io n
Synchronous system Asynchronous
Transmission Speed 9600 / 19200
Data Length 8 bits
Parity None
Stop Bit 1
Flow Control None
1) Transmission speed: initial setting value is 19200.
2) Transmission speed can be changed in service mode.
2.2. Connection
Dedicated serial cable must be used for the connection between computer and projector.
PC      Projector
COM 1    Control Port

（D-Sub 9 Pin）（D-Sub 9 Pin）

PLC-XTC50ALBasic Serial Command Functional Specifications                 
6/26
3. Notes for Communication
・ The projector command is defined as one command per line that starts with “C” and ends with
carriage return (0x0D).
・ When carriage return (0x0D) is received, decoding starts.
・ There are two types of commands; Functional Execution Commands which function in a way
comparable to remote and console keys and Status Read Commands which get basic statuses
of projector.
Example of Functional Execution Command: “C05” [CR]
Example of Status Read Command: “CR0” [CR]
・ In the cases below, it clears information of receive buffer.
1) When LF (0x0A) and EOF (0x1A) are received
2) When it takes more than a second to receive one command (until the projector receives
carriage return since it has received the first data)
・ or the pipelining of Functional Execution Command, allow the following interval time after
receiving return value.
1) Commands “VOLUME +/-“, “ZOOM UP/DOWN”, “FOCUS UP/DOWN” and “LENS-SHIFT
UP/DOWN/RIGHT” -->100ms
2) Other commands --> 500ms
・ For the pipelining of Status Read Command, allow more than 500 ms of interval time after
reception of return value.
・ Do not send any subsequent command before reception of return value; however this is not the
case when no response is returned after more than 5 seconds.
・ It takes about 7 seconds for internal initialization after plugging in AC power. During this time, it
cannot process commands. Do not issue any command.
・ During 7 seconds after powering on in Standby mode, when the command for internal
initialization or lamp lighting is received, ACK value is returned but the function is not executed.
However, for Status Read Command, the function is executed in 500 ms after receiving ACK
value for POWER ON command.
・ During countdown and cooling operations:
During countdown operation after execution of power-on, as well as during cooling operation after
execution of power-off, ACK value is returned but the function is not executed when command is
received.
・ On switching INPUT:
During 5 seconds after switching action has started in response to reception of INPUT switching
command, ACK value is returned but the function is not executed when command is received.
However, for Status Read Command, the function is executed in 500 ms after receiving ACK
value for INPUT switching command.
・ The number of characters indicating successful reception of command varies according to the
command. Please see [7. Status Read Command].
・ Characters used for commands must be Capital (A - Z).

PLC-XTC50ALBasic Serial Command Functional Specifications                 
7/26
4. Functional Execution Command Table
Command
Item Command
Item
C00 POWER ON C20 BRIGHTNESS +
C01
POWER OFF
(
QUICK POWER
OFF) C21 BRIGHTNESS -
C02 POWER OFF C22 ---
C03 --- C23 INPUT 2 VIDEO
C04 --- C24 INPUT 2 Y,Pb/Cb,Pr/Cr
C05 INPUT 1 C25 INPUT 2 RGB
C06 INPUT 2 C26 ---
C07 INPUT 3 C27 IMAGE
C08 NETWORK C28 ON START Enable
C09 VOLUME + C29 ON START Disable
C0A VOLUME - C2A POWER MANAGEMENT READY
C0B SOUND MUTE ON C2B POWER MANAGEMENT OFF
C0C SOUND MUTE OFF C2C ---
C0D VIDEO MUTE ON C2D ---
C0E VIDEO MUTE OFF C2E POWER MANAGEMENT SHUT DOWN
C0F SCREEN NORMAL SIZE (4：3） C2F ---
C10 SCREEN WIDE SIZE （16：9）C30 D.ZOOM +
C11 --- C31 D.ZOOM -
C12 --- C32 ---
C13 --- C33 INPUT 3 VIDEO
C14 --- C34 INPUT 3 S-VIDEO
C15 --- C35 ---
C16
---
C36 ---
C17
---
C37 ---
C18
---
C38 ---
C19
---
C39 ---
C1A --- C3A POINTER RIGHT
C1B --- C3B POINTER LEFT
C1C MENU ON C3C POINTER UP
C1D MENU OFF C3D POINTER DOWN
C1E DISPLAY CLEAR C3E ---
C1F --- C3F ENTER
“---“means “No Function”.

PLC-XTC50ALBasic Serial Command Functional Specifications                 
8/26
Command Item Command Item
C40 --- C80 ---
C41 --- C81 ---
C42 --- C82 ---
C43 FREEZE ON C83 ---
C44 FREEZE OFF C84 ---
C45 --- C85 ---
C46 ZOOM - C86 ---
C47 ZOOM + C87 ---
C48 --- C88 ---
C49 --- C89 AUTO PCADJ
C4A FOCUS - C8A PRESENTATION TIMER
C4B FOCUS + C8B ---
C4C --- C8C ---
C4D --- C8D ---
C4E --- C8E KEYSTONE ↑
C4F --- C8F KEYSTONE ↓
C50 INPUT 1 ANALOG RGB C90 KEYSTONE →
C51 INPUT 1 SCART C91 KEYSTONE ←
C52 INPUT 1 DVI (PC DIGITAL) C92 ---
C53 INPUT 1 DVI (AV HDCP) C93 ---
C54 --- C94 ---
C55 --- C95 ---
C56 --- C96 ---
C57 --- C97 ---
C58 --- C98 ---
C59 --- C99 ---
C5A --- C9A ---
C5B --- C9B ---
C5C --- C9C ---
C5D Lens Shift Up C9D ---
C5E Lens Shift Down C9E ---
C5F Lens Shift Left C9F ---
C60 Lens Shift Right
“———“means “No Function”
5. Status Read Command Table
Command Item Note
CR0 STATUS READ
CR1 INPUT MODE READ
CR2 ---
CR3 LAMP TIME READ
CR4 SETTING READ
CR5 ---
CR6 TEMP READ
CR7 LAMP MODE READ
CRC ---

“———“means “No Function”.

PLC-XTC50ALBasic Serial Command Functional Specifications                 
9/26
6. Functional Execution Command
6.1 Format
・ PC issues a command in the following format:
“C” Command [CR]
Command: two characters (See Functional Execution Command Table)
・ Projector decodes the received data and returns the result when getting ready to receive the
next command.
[ACK] [CR]：(0x06, 0x0D) When received Functional Execution Commands.
・ When received data cannot be decoded, “?” [CR] is returned.
6.2 When the command pipelining is needed
In the case of the function requiring command pipelining, such as “Volume +/-“ and “Zoom +/-“,
operation should follow the same way as in remote control:
1) Sending-side system issues commands every 100 ms after receiving the return value.
2) When receiving an applicable command, the function is executed for 120 ms from the
moment.
3) When receiving the same command in sequence within 120 ms, the function is executed for
another 120 ms from the moment of the second command reception.
4) When any other command is not received after 120 ms, the execution of pipelining is stopped.
5) When Projector receives another command within 120 ms, the execution of pipelining is
stopped.
6.3 Transfer Example
Change Projector mode to Video with Basic Command.
Command
PC →Projector “C” “0” “7” CR
Projector →PC ACK CR
Processing
(A few ms 〜5 s）

PLC-XTC50ALBasic Serial Command Functional Specifications                 
10/26
6.4 Operation Requirements
In the following status of projector, Available Functional Execution Commands are limited.
Projector Status Available Functional Execution Commands
Standby Mode C00: POWER ON
Countdown in process
C00: POWER ON →Countdown is terminated
C01: POWER OFF
C02: POWER OFF →Countdown is terminated
C46: ZOOM -
C47: ZOOM +
C4A: FOCUS -
C4B: FOCUS +
C5D: LENS SHIFT UP
C5E: LENS SHIFT DOWN
C5F:LENS SHIFT LEFT
C60:LENS SHIFT RIGHT
When ZOOM+/-, FOCUS +/-, LENS SHIFTUP/
DOWN/LEFT/RIGHT are executed during Countdown
is in process, POINTER Command become effective,
and ZOOM/FOCUS/LENS SHIFT become enable to
control by POINTER Command.
(*POINTER Command:C3A/CA3B/C3C/C3D)
Cooling Down in process NONE (No Execution)
Cooling Down due to
Abnormal Temperature NONE (No Execution)
Abnormal Temperature Status NONE (No Execution)
Abnormal Power Status NONE (No Execution)
Abnormal Filter Status NONE (No Execution)
Power
-
Save
Cooling Down
in process
NONE (No Execution)
Power Save Status
C00
:
POWER ON
C01: POWER OFF
Cooling Down
in process
after OFF
operation due to Lamp Failure NONE (No Execution)
Note) in above status, the projector returns [ACK] [CR] even if it receives the other command.

PLC-XTC50ALBasic Serial Command Functional Specifications                 
11/26
6.5 POWER ON Command
Command
“
C00
”
[CR]
Detail
Power ON
When already Power is ON, no operation is started.
When sending this command during Countdown in process,
Countdown is terminated.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.6 POWER OFF Command (Quick POWER OFF)
Command
“
C01
”
[CR]
Detail
Power OFF (Standby)
This command executes Quick Power OFF operation without displaying “Power
OFF?” message, which is displayed when Power is turned OFF with button of the
projector or remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.7 POWER OFF Command
Command
“
C02
”
[CR]
Detail
Power OFF (Standby)
This command works the same way as when Power is OFF with STAND-BY
button of the remote control.
(When the command is sent once, “Power OFF?” message is displayed. If this
command is sent again while “Power OFF?” message is displayed, Power OFF
operation is executed.)
When sending this command during Countdown in process, Countdown is
terminated.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.8 INPUT 1 Command
Command
“
C05
”
[CR]
Detail
Select Input 1
. This command works differently from the command by
“
Input 1
”
key of the remote control. When Input 1 has been already selected, this
command does not execute the source switching; just for switching to Input 1.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.9 INPUT 2 Command
Command
“
C06
”
[CR]
Detail
Select Input 2
.
This command works differently fro
m the command by
“
Input
2
”
key of the remote control. When Input 2 has been selected, this command does
not execute the source switching; just for switching to Input 2.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
12/26
6.10INPUT 3 Command
Command
“
C07
”
[CR]
Detail
Select Input
3. This command works differently from the command by
“
Input 3
”
key of the remote control. When Input 3 has been selected, this command does
not execute the source switching; just for switching to Input 3.
Response
Accepta
ble
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.11NETWORK Command
Command
“
C08
”
[CR]
Detail
Select
Network
Input
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.12VOLUME + Command
Command
“
C09
”
[CR]
Detail
Volume Up.
This command operates the same way as VOLUME + button of the projector and
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.13VOLUME – Command
Command
“
C0A
”
[CR]
Detail
Volume Down
This command operates the same way as VOLUME – button of the projector and
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]
6.14SOUND MUTE ON Command
Command
“
C0B
”
[CR]
Detail
Sound Mute ON.
This command works the same way as “MUTE” button of the remote control for
Mute ON, but does not work for Mute OFF.
Response
Acceptab
le
[ACK] [CR]
Unacceptable ？[CR]
6.15SOUND MUTE OFF Command
Command
“C0C” [CR]
Detail
Sound Mute OFF.
This command works the same way as “MUTE” button of the remote control for
Mute OFF, but does not work for Mute ON.
Response
Acceptable
[ACK] [CR]
Unacceptable ？[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
13/26
6.16VIDEO MUTE ON Command
Command
“
C0D
”
[CR]
Detail
Video Mute ON
This command works the same way as “SHUTTER” button of the remote control
for SHUTTER CLOSE, but does not work for SHUTTER OPEN
Response
Acceptable
[ACK] [CR]
Unaccepta
ble
“
?
”
[CR]
6.17VIDEO MUTE OFF Command
Command
“
C0E
”
[CR]
Detail
V
ideo
M
ute OFF
This command works the same way as “SHUTTER” button of remote control for
SHUTTER OPEN, but does not work for SHUTTER CLOSE
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[
CR]
6.18SCREEN NORMAL SIZE Command
Command
“
C0F
”
[CR]
Detail
Set screen size to Normal (4:3)
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.19SCREEN WIDE SIZE Command
Command
“
C10
”
[CR]
Detail
Set screen size to Wide (16:9)
Response
Acceptable
[A
CK] [CR]
Unacceptable
“
?
”
[CR]
6.20MENU ON Command
Command
“
C1C
”
[CR]
Detail
Display On
-
Screen Display Menu
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.21MENU OFF Command
Command
“
C1D
”
[CR]
Detail
Clear On
-
Screen Display Menu
Response
Accept
able
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
14/26
6.22DISPLAY CLEAR Command
Command
“
C1E
”
[CR]
Detail
Clear On
-
screen
Display
under all conditions
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.23BRIGHTNESS + Command
Command
“
C20
”
[CR]
Detail
Increment
Bri
ghtness
by 1 according to user control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.24BRIGHTNESS - Command
Command
“
C21
”
[CR]
Detail
Decrement Brightness by 1 according to user control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.25INPUT 2 VIDEO Command
Command
“
C23
”
[CR]
Detail
Select Video input
in
Input 2
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.26INPUT 2 Y,Pb/Cb,Pr/Cr Command
Command
“
C24
”
[CR]
Detail
Select Y,
Pb/Cb,
Pr/Cr input
in
Input 2
Response
Acceptabl
e
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.27INPUT 2 RGB Command
Command
“
C25
”
[CR]
Detail
Select RGB input
in
Input 2
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.28IMAGE Command
Command
“
C27
”
[CR]
Detail
Switch Image Setting status
.
Previous Image
mode is displayed for 4 seconds by
receiving first command. Image Mode gets switched by receiving another
command while the display is on the screen.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
15/26
6.29ON START SET Command
Command
“
C28
”
[CR]
Detail
Enable
Power ON Start
This status is stored in EEPROM and retained regardless of Power OFF/ON
operation.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.30ON START CANCEL Command
Command
“
C29
”
[CR]
Detail
Disable
Power ON Start
This status is stored in EEPROM and retained regardless of Power OFF/ON
operation.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.31POWER MANAGEMENT READY Command
Command
“
C2A
”
[CR]
Detail
Set Power
Management
function to ready status
This status is stored in EEPROM and retained regardless of Power OFF/ON
operation.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.32POWER MANAGEMENT CANCEL Command
Command
“
C2B
”
[CR]
Detail
Set
Power
Management
function to off status
This status is stored in EEPROM and retained regardless of Power OFF/ON
operation.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.33POWER MANAGEMENT SHUTDOWN Command
Command
“
C2
E
”
[CR]
Detail
Set Power
Management
function to
Shutdown mode.
This status is stored in EEPROM and retained regardless of Power OFF/ON
operation.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.34D.ZOOM + Command
Command
“
C30
”
[CR]
Detail
Enter Digital Zoom mode and expand image size
This command works the same way as “D.ZOOM ▲” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
16/26
6.35D.ZOOM - Command
Command
“
C31
”
[CR]
Detail
Enter Digital Zoom mode and
reduce
image size
This command works the same as “D.ZOOM ▼” button of the remote control.
Response
Acceptable
[AC
K] [CR]
Unacceptable
“
?
”
[CR]
6.36INPUT 3 VIDEO Command
Command
“
C33
”
[CR]
Detail
Select Video input
in
Input 3
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.37INPUT 3 S-VIDEO Command
Command
“
C34
”
[CR]
Detail
Select S
-
Video input
in
Input 3
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.38POINTER RIGHT Command
Command
“
C3A
”
[CR]
Detail
Move the Pointer of On
-
Screen Display Menu to the right
.
This command works differently from the command by Point button “>” of the
projector and has no “Volume +” function.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.39POINTER LEFT Command
Command
“
C3B
”
[CR]
Detail
Move the Pointer of On
-
Screen Display Menu to the left
This command works differently from the command by Point button “<” of the
projector and has no “Volume -” function.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.40POINTER UP Command
Command
“
C3C
”
[CR]
Detail
Move up the Pointer of On
-
Screen Display Menu
This command works the same way as “▲” button of the projector.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
17/26
6.41POINTER DOWN Command
Command
“
C3D
”
[CR]
Detail
Move down the Pointer of On
-
Screen Display Menu
This command works the same way as “▼” button of the projector.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.42ENTER Command
Command
“
C3F
”
[CR]
Detail
This command works the same
way
as
“
SELECT
”
button of
the
projector and
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.43FREEZE ON Command
C
ommand
“
C43
”
[CR]
Detail
Freeze on
-
screen
This command works the same way as “FREEZE” button of the remote control for
Freeze ON, but does not work for Freeze OFF.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.44FREEZE OFF Command
Command
“
C44
”
[CR]
Detail
Cancel Freeze mode
This command works the same way as “FREEZE” button of the remote control for
Freeze Off, but does not work for Freeze ON.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.45ZOOM + Command
Command
“
C47
”
[CR]
Detail
Expand image size
This command works the same way as “ZOOM ▲” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.46ZOOM - Command
Command
“
C46
”
[CR]
Detail
Reduce
image size
This command works the same way as “ZOOM ▼” button of the remote control.
Response
Acceptable
[ACK] [CR
]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
18/26
6.47FOCUS + Command
Command
“
C4B
”
[CR]
Detail Adjust on-screen focus by making focal length longer. (The lens moves backward)
This command works the same way as “FOCUS ▲” button of the remote control.
Response
Acceptable
[ACK] [C
R]
Unacceptable
“
?
”
[CR]
6.48FOCUS - Command
Command
“
C4A
”
[CR]
Detail Adjust on-screen focus by making focal length shorter. (The lens moves forward
)
This command works the same way as “FOCUS ▼” button of the remote control.
Response
Acceptable
[ACK] [C
R]
Unacceptable
“
?
”
[CR]
6.49INPUT 1 ANALOG RGB Command
Command
“
C50
”
[CR]
Detail
Select Analog RGB input
in
Input 1
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.50INPUT 1 SCART Command
Command
“
C51
”
[CR]
Detail
Select SCART input in
Input 1
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.51INPUT 1 DVI (PC DIGITAL) Command
Command
“
C52
”
[CR]
Detail
Select DVI (PC Digital) input
in
Input 1
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.52INPUT 1 DVI (AV HDCP) Command
Command
“
C
53
”
[CR]
Detail
Select DVI (AV HDCP) input of Input 1
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.53LENS SHIFT UP Command
Command
“
C5D
”
[CR]
Detail
Move
projection area u
p
w
a
rd.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
19/26
6.54LENS SHIFT DOWN Command
Command
“
C5E
”
[CR]
Detail
Move projection area downw
a
rd.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.55LENS SHIFT LEFT Command
Command
“
C5F
”
[CR]
Detail
Move projection area
left
ward.
Response
Acceptable
[ACK] [CR]
Unacc
eptable
“
?
”
[CR]
6.56LENS SHIFT RIGHT Command
Command
“
C60
”
[CR]
Detail
Move
projection area right
ward.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.57AUTO PC ADJ. Command
Command
“
C89
”
[CR]
Detail
Execute AUTO PC ADJ. function
This command works the same way as “AUTO PC” button ofthe remote control.
Sending this command during Auto PC Adj. process terminates the operation.
This is the same by “AUTO PC” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.58PRESENTATION TIMER Command
Command
“
C8A
”
[CR]
Detail
Start Timer for presentation
This command works the same way as “P-TIMER” button of the
remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.59KEYSTONE ↑Command
Command
“
C8E
”
[CR]
Detail
Correct keystone distortion by reducing upper part of
. This command
invokes both operations of keystone distortion correction and OSD display,
regardless of whether the “KEYSTONE” OSD has been already displayed or not.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]

PLC-XTC50ALBasic Serial Command Functional Specifications                 
20/26
6.60KEYSTONE ↓Command
Command
“
C8F
”
[CR]
Detail
Correct keystone distortion by reducing lower part of image. This command
invokes both operations of keystone distortion correction and OSD display,
regardless of whether the “KEYSTONE” OSD has been already displayed or not.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.61KEYSTONE →Command
Command
“
C90
”
[CR]
Detail
Correct keystone distortion by reducing right part of image. This command
invokes both operations of keystone distortion correction and OSD display,
regardless of whether the “KEYSTONE” OSD has been already displayed or not.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
6.62KEYSTONE ←Command
Command
“
C91
”
[CR]
Detail
Correct keystone distortion by reducing
left
part of image
.
This command
invokes both operations of keystone distortion correction and OSD display,
regardless of whether the “KEYSTONE” OSD has been already displayed or not.
Response
Acceptable
[ACK] [CR]
Unacceptable
“
?
”
[CR]
