Features and Design
This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use.
This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display
(LCD) technology.
♦ Compact Design
This projector is designed compact in size and weight.
It is easy to carry and installed anywhere you wish to
use.
♦Simple Computer System Setting
The projector has the Multi-scan system to conform to
almost all computer output signals quickly (p.31). Up to
UXGA resolution can be accepted.
♦Useful Functions for Presentations
- The digital zoom function allows you to focus on the
crucial information during a presentation (p.38).
-Blackboards* can be used as a projection screen.
*The board color is limited to Green (pp.35, 42).
♦ Power Management
The Power management function reduces power
consumption and maintains the lamp life (p.53).
♦Lamp Control
Brightness of the projection lamp can be selected
(pp.27, 55).
♦Quick Termination
The AC power cord can be unplugged immediately
after turning off the projector without waiting for the
termination of the cooling fan rotation (p.21).
♦ Logo Function
The Logo function allows you to customize the screen
logo (pp.49-51). You can capture an image for the
screen logo and use it for the starting-up display or
between presentations.
♦ Multilanguage Menu Display
Operation menu is available in 17 languages; English,
German, French, Italian, Spanish, Portuguese, Dutch,
Swedish, Finnish, Polish, Hungarian, Romanian,
Russian, Chinese, Korean, Japanese and Thai (p.46).
Note:
• The On-Screen Menu and figures in this manual may differ slightly from the product.
• The contents of this manual are subject to change without notice.
♦ Security Function
The Security function helps you to ensure security
of the projector. With the Key lock function, you can
lock the operation on the top control or remote control
(p.55). PIN code lock function prevents unauthorized
use of the projector (pp.21, 56–57).
♦ Helpful Maintenance Functions
Lamp and filter maintenance functions provide for
better and proper maintenance of the projector.
♦LAN Network Function
This projector is loaded with the Wired and Wireless
LAN network function. You can project an image on a
computer as well as operate and manage the projector
via network. For details, refer to the owner’s manual
“Network Set-up and Operation.”
♦Memory Viewer Function
Insert the dedicated USB memory into the projector to
project images or presentation data stored within. You
do not have to carry computers or other equipment for
a presentation.
*USB memory is not supplied with the projector. For
details, refer to the owner’s manual of "Memory
viewer".
♦Auto setup Function
This function enables Input search, Auto Keystone
correction and Auto PC adjustment by simple pressing
the AUTO SETUP/CANCEL button on the top control
(p.47).
♦Colorboard Function
At the time of simple projection on the colored wall,
you can get the close color image to the color image
projected on a white screen by selecting the similar
color to the wall color from the preset four colors.
♦Closed Caption
This is a printed version of the program sound or other
information displayed on the screen. You can turn on
the feature and switch the channels (p.54).

3
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .2
TableofContents......................3
TotheOwner..........................4
Safety Instructions. . . . . . . . . . . . . . . . . . . . .5
AirCirculation 6
InstallingtheProjectorinProperPosition6
MovingtheProjector 6
Compliance...........................7
Part Names and Functions . . . . . . . . . . . . . .8
Front 8
Back 8
Bottom 8
RearTerminal 9
TopControl 10
RemoteControl 11
LaserPointerFunction 12
PointerFunction 12
WirelessMouseOperation 13
RemoteControlCode 13
RemoteControlBatteryInstallation 14
RemoteControlOperatingRange 14
AdjustableFeet 14
Installation...........................15
PositioningtheProjector 15
ConnectingtoaComputer 16
ConnectingtoVideoEquipment17
ConnectingtoComponentVideoEquipment 18
ConnectingtheACPowerCord 19
BasicOperation......................20
TurningOntheProjector 20
TurningOfftheProjector 22
HowtoOperatetheOn-ScreenMenu 23
MenuBar 24
ZoomandFocusAdjustment 25
AutoSetupFunction 25
KeystoneCorrection 25
SoundAdjustment 26
RemoteControlOperation 27
ComputerInput ......................29
InputSourceSelection
(RGB:Computer1/Computer2(Analog))29
InputSourceSelection
(RGB(PCdigital),RGB(AVHDCP)) 30
ComputerSystemSelection 31
AutoPCAdjustment 32
ManualPCAdjustment 33
ImageModeSelection 35
ImageAdjustment 36
ScreenSizeAdjustment 37
VideoInput..........................39
InputSourceSelection(Video,S-video) 39
InputSourceSelection
(Component,RGBScart21-pin) 40
VideoSystemSelection 41
ImageModeSelection 42
ImageAdjustment 43
ScreenSizeAdjustment 45
Setting..............................46
Setting 46
Information......................... 60
InputSourceInformationDisplay 60
Maintenance and Cleaning . . . . . . . . . . . . .61
WARNINGindicator 61
CleaningtheFilters 62
ResettingtheFilterCounter 62
AttachingtheLensCap63
CleaningtheProjectionLens 63
CleaningtheProjectorCabinet 63
LampReplacement 64
Appendix............................66
Troubleshooting 66
MenuTree 70
IndicatorsandProjectorCondition 72
CompatibleComputerSpecifications 73
TechnicalSpecifications 75
OptionalParts 76
PJLinkNotice 77
ConfigurationsofTerminals 78
PINCodeNumberMemo 79
USBThumbDriveCase79
Dimensions80

4
To the Owner
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE EXCEPT LAMP REPLACEMENT.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGECONSTITUTINGARISKOFELECTRIC
SHOCKISPRESENTWITHINTHISUNIT.
THIS SYMBOL INDICATES THAT THEREARE
IMPORTANT OPERATINGAND MAINTENANCE
INSTRUCTIONS IN THE OWNER'S MANUAL
WITHTHISUNIT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Before installing and operating this projector, read this
manualthoroughly.
This projector provides many convenient features and
functions. Operating the projector properly enables
youtomanage those featuresandmaintains it ingood
conditionformanyyearstocome.
Improperoperationmayresultinnotonlyshorteningthe
product-life, but also malfunctions, fire hazard, or other
accidents.
Ifyourprojectorseemstooperateimproperly,readthis
manualagain, checkoperations andcable connections
and try the solutions in the “Troubleshooting” section
in the back of this booklet. If the problem still persists,
contactthedealerwhereyoupurchasedtheprojectoror
theservicecenter.
Safety Precaution
CAUTION
DO NOT SET THE PROJECTOR IN GREASY, WET, OR
SMOKY CONDITIONS SUCH AS IN A KITCHEN TO PREVENT
A BREAKDOWN OR A DISASTER. IF THE PROJECTOR
COMES IN CONTACT WITH OIL OR CHEMICALS, IT MAY
BECOME DETERIORATED.
READ AND KEEP THIS OWNER'S MANUAL FOR
LATER USE.
WARNING: ●THISAPPARATUSMUSTBEEARTHED.
●TOREDUCETHERISKOFFIREOR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
–Thisprojectorproducesintenselightfromtheprojection
lens. Do not stare directly into the lens, otherwise eye
damagecouldresult.Beespeciallycarefulthatchildren
donotstaredirectlyintothebeam.
–Installtheprojectorinaproperposition.Otherwiseitmay
resultinfirehazard.
–Allowing the proper amount of space on the top, sides,
and rear of the projector cabinet is critical for proper
air circulation and cooling of the unit. The dimension
shown here indicate the minimum space required.
If the projector is to be built into a compartment or
similarly enclosed, these minimum distances must be
maintained.
–Do not cover the ventilation slot on the projector. Heat
build-up can reduce the service life of your projector,
andcanalsobedangerous.
–Iftheprojectorisunusedforanextendedtime,unplug
theprojectorfromthepoweroutlet.
–Donotprojectthesameimageforalongtime.The
afterimagemayremainontheLCDpanelsbythe
characteristicofpanel.
SIDEandTOP REAR
CAUTION
NotforuseinacomputerroomasdefinedintheStandard
fortheProtectionofElectronicComputer/DataProcessing
Equipment,ANSI/NFPA75.
Nepeut êtreutilisédansunesalled’ordinateurstelle
que définie dans la normeANSI/NFPA 75 Standard
forProtectionofElectronicComputer/DataProcessing
Equipment.
Thesymbolmarkandrecyclingsystemsdescribedbelow
apply to EU countries and do not apply to countries in other
areasoftheworld.
Your product is designed and manufactured with high quality
materialsandcomponentswhichcanberecycledand/or
reused.
Thesymbolmarkmeansthatelectricalandelectronic
equipment,batteriesandaccumulators,attheirend-oflife,
shouldbedisposedofseparatelyfromyourhouseholdwaste.
Note:
Ifachemicalsymbolisprintedbeneaththesymbolmark,
this chemical symbol means that the battery or accumulator
containsaheavymetalatacertainconcentration.Thiswillbe
indicatedasfollows:Hg:mercury,Cd:cadmium,Pb:lead
IntheEuropeanUnion there are separate collectionsystems
forusedelectricalandelectronicequipment,
batteriesandaccumulators.
Please,disposeofthemcorrectlyatyourlocal
communitywastecollection/recyclingcentre.
Please,helpustoconservetheenvironment
welivein!
0.7’(20cm)
1.5’(50cm) 3’(1m) 3’(1m)
20cm
50cm 1m 1m

5
Safety Instructions
All the safety and operating instructions should be read
beforetheproductisoperated.
Read all of the instructions given here and retain them
forlateruse.UnplugthisprojectorfromACpowersupply
beforecleaning.Donotuseliquidoraerosolcleaners.
Useadampclothforcleaning.
Followallwarningsand instructionsmarkedon the
projector.
For added protection to the projector during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will
preventdamageduetolightningandpowerlinesurges.
Do not expose this unit to rain or use near water... for
example,inawetbasement,nearaswimmingpool,etc...
Donotuse attachmentsnot recommendedbythe
manufacturerastheymaycausehazards.
Donotplacethisprojectoronanunstablecart,stand,
or table. The projector may fall, causing serious injury
to a child or adult, and serious damage to the projector.
Useonlywithacartorstandrecommendedbythe
manufacturer,orsoldwiththeprojector.Wallorshelf
mounting should follow the manufacturer’s instructions,
andshoulduseamountingkitapprovedbythe
manufacturers.
Anappliance andcartcombination
shouldbemovedwith care.Quick
stops,excessiveforce,anduneven
surfacesmaycausethe appliance
andcartcombinationtooverturn.
Slotsandopeningsinthebackandbottomofthecabinet
areprovidedforventilation,toensurereliableoperationof
theequipmentandtoprotectitfromoverheating.
Theopeningsshouldneverbecoveredwithclothorother
materials,andthebottomopeningshouldnotbeblocked
byplacingthe projectoronabed,sofa,rug,or other
similarsurface.Thisprojectorshouldneverbeplaced
nearoroveraradiatororheatregister.
Thisprojectorshouldnotbeplacedinabuilt-ininstallation
suchasabookcaseunlessproperventilationisprovided.
Neverpushobjectsofanykindintothisprojectorthrough
cabinetslotsastheymaytouchdangerousvoltagepoints
orshort outparts thatcouldresultin afireor electric
shock.Neverspillliquidofanykindontheprojector.
Donotinstalltheprojectorneartheventilationductof
air-conditioningequipment.
Thisprojectorshouldbeoperatedonlyfromthetype
of power source indicated on the marking label. If you
arenotsureofthetypeofpowersupplied,consultyour
authorizeddealerorlocalpowercompany.
Donotoverloadwalloutletsandextensioncordsasthis
canresultinfireorelectricshock.Donotallowanything
to rest on the power cord. Do not locate this projector
wherethecordmaybedamagedbypersonswalkingon
it.
Donotattempttoservicethisprojectoryourselfas
openingorremovingCoversmay exposeyouto
dangerousvoltageorotherhazards.Referallservicing
toqualifiedservicepersonnel.
Unplugthisprojectorfromwalloutletandreferservicing
toqualifiedservicepersonnel underthefollowing
conditions:
a.Whenthepowercordorplugisdamagedorfrayed.
b.Ifliquidhasbeenspilledintotheprojector.
c.Iftheprojectorhasbeenexposedtorainorwater.
d.Iftheprojectordoesnotoperatenormallybyfollowing
the operating instructions.Adjust only those controls
that are covered by the operating instructions as
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualifiedtechniciantorestoretheprojectortonormal
operation.
e.If the projector has beendroppedorthecabinethas
beendamaged.
f.Whentheprojectorexhibitsadistinctchangein
performance-thisindicatesaneedforservice.
Whenreplacementpartsarerequired,besurethe
servicetechnicianhasusedreplacementpartsspecified
bythemanufacturerthathavethesamecharacteristics
asthe originalpart. Unauthorizedsubstitutionsmay
resultinfire,electricshock,orinjurytopersons.
Uponcompletionof anyserviceorrepairsto this
projector, ask the service technician to perform routine
safety checks to determine that the projector is in safe
operatingcondition.
NOTE FOR CUSTOMERS IN THE US
HgLAMP(S)INSIDETHISPRODUCTCONTAIN
MERCURYANDMUSTBERECYCLEDORDISPOSED
OFACCORDINGTOLOCAL,STATEORFEDERAL
LAWS.

6
Safety Instructions
Openingsinthe cabinetareprovided forventilation.To
ensurereliableoperationoftheproductandtoprotectit
from overheating, these openings must not be blocked
orcovered.
CAUTION
Hotairisexhaustedfromtheexhaustvent.Whenusing
or installing the projector, the following precautions
shouldbetaken.
–Donotputanyflammableobjectorspraycannearthe
projector,hotairisexhaustedfromtheairvents.
–Keeptheexhaustventatleast3’(1m)awayfromany
objects.
–Do not touch a peripheral part of the exhaust vent,
especiallyscrewsandmetallicparts.Theseareaswill
becomehotwhiletheprojectorisbeingused.
–Donotputanythingonthecabinet.Objectsputonthe
cabinetwillnotonlygetdamagedbutalsomaycause
firehazardbyheat.
Cooling fans are provided to cool down the projector.
The fans’ running speed is changed according to the
temperatureinsidetheprojector.

CAUTION IN CARRYING OR TRANSPORTING
THE PROJECTOR
–Donotdroporbumptheprojector,otherwisedamages
ormalfunctionsmayresult.
–Whencarryingtheprojector,useasuitablecarryingcase.
– Do not transport the projector by courier or any other
transport service in an unsuitable transport case. This
may cause damage to the projector. For information
abouttransportingtheprojectorbycourieroranyother
transportservice,consultyourdealer.
–Donotputtheprojectorinacasebeforetheprojectoris
cooledenough.
Moving the Projector
Whenmovingtheprojector,replacethelenscapand
retractadjustablefeettopreventdamagetothelensand
cabinet.
Whentheprojectorisnotinuseforanextendedperiod,
putitintoasuitablecasewiththelenssideup.
Air Circulation
AirIntakeVent
AirintakeVent
ExhaustVent
(Hotairexhaust)
AirIntakeVent
Donottilttheprojectormorethan20
degreesfromsidetoside.
Donotpointtheprojectoruptoprojectan
image.
Donotpointtheprojectordowntoproject
animage.
Donotputtheprojectoroneithersideto
projectanimage.
Install the projector properly. Improper Installation may
reducethelamplifeandcauseafirehazard.
Installing the Projector in Proper Position
ExhaustVent
(Hotairexhaust)
Do not pitch the projector more than 30
degreesaboveandbelow.
30°
30°

7
Compliance
Federal Communications Commission Notice
Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful
interference in a residential installation.This equipmentgenerates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determinedbyturningtheequipment offandon,theuseris encouragedtotrytocorrecttheinterferenceby
oneormoreofthefollowingmeasures:
 –Reorientorrelocatethereceivingantenna.
 –Increasetheseparationbetweentheequipmentandreceiver.
 –Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
 –Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
UseofshieldedcableisrequiredtocomplywithclassBlimitsinSubpartBofPart15ofFCCRules.
Donotmakeanychangesormodificationstotheequipmentunlessotherwisespecifiedintheinstructions.If
suchchangesormodificationsshouldbemade,youcouldberequiredtostopoperationoftheequipment.
ModelNumber:PLC-XU305,PLC-XU355
TradeName:Sanyo
Responsibleparty:SANYOFISHERCOMPANY
Address :21605PlummerStreet,Chatsworth,California91311
TelephoneNo.:[phone]
TheACPowerCordsuppliedwiththisprojectormeetstherequirementforuseinthecountryyoupurchasedit.
AC Power Cord for the United States and Canada:
ACPowerCordusedinthe UnitedStatesandCanadaislistedbythe Underwriters
Laboratories(UL)andcertifiedbytheCanadianStandardAssociation(CSA).
ACPowerCordhasagrounding-typeAClineplug.Thisisasafetyfeaturetobesurethatthe
plugwillfitintothepoweroutlet.Donottrytodefeatthissafetyfeature.Shouldyoubeunable
toinserttheplugintotheoutlet,contactyourelectrician.
GROUND
AC Power Cord Requirement
AC Power Cord for the United Kingdom:
Thiscordisalreadyfittedwithamouldedplugincorporatingafuse,thevalueofwhichisindicatedonthepin
faceoftheplug.Shouldthefuseneedtobereplaced,anASTAapprovedBS1362fusemustbeusedofthe
samerating,markedthus
ASA
.Ifthefusecoverisdetachable,neverusetheplugwiththecoveromitted.Ifa
replacementfusecoverisrequired,ensureitisofthesamecolourasthatvisibleonthepinfaceoftheplug
(i.e.redororange).FusecoversareavailablefromthePartsDepartmentindicatedinyourUserInstructions.
Iftheplugsuppliedisnotsuitableforyoursocketoutlet,itshouldbecutoffanddestroyed.
Theendoftheflexiblecordshouldbesuitablypreparedandthecorrectplugfitted.
WARNING : A PLUG WITH BARED FLEXIBLE CORD IS HAZARDOUS IF ENGAGED IN A LIVE SOCKET
OUTLET.
TheWiresinthismainsleadarecolouredinaccordancewiththefollowingcode:
 Green-and-yellowEarth
 Blue . . . . . . . . . . . Neutral
 Brown . . . . . . . . . Live
Asthecoloursofthewiresinthemainsleadofthisapparatusmaynotcorrespondwiththecolouredmarkings
identifyingtheterminalsinyourplugproceedasfollows:
Thewirewhichiscolouredgreen-and-yellowmustbeconnectedtotheterminalintheplugwhichismarkedby
theletterEorbythesafetyearthsymbol orcolouredgreenorgreen-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or
colouredblack.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or
colouredred.
WARNING: THIS APPARATUS MUST BE EARTHED.
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.

8
Part Names and Functions
①⑤ ⑨③②
Front
Back
④
①Infrared Remote Receiver
②Zoom Ring
③Focus Ring
④Projection Lens
⑤Lens Cap
 (Seepage63forattaching.)

⑥Speaker
⑦Exhaust Vent
CAUTION
Hotairisexhaustedfromtheexhaustyivent.Donotput
heat-sensitiveobjectsnearthisside.
⑧Lamp Cover
⑨Air Intake Vent
⑩USB Connector (Series B)
⑪Terminals and Connectors
⑫ Top Controls and Indicators
⑬ LAN Connection Terminal
⑭ USB Connector (Series A)
⑮Power Cord Connector
⑯Filters
⑰Adjustable Feet
Note:
⑬LANConnectionTerminaland⑭USBConnector(Se-
riesA)arefortheNetworkfunction.Refertotheowner’s
manual“NetworkSet-upandOperation”.
Kensington Security Slot
ThisslotisforaKensingtonlockusedtodetertheftofthe
projector.
*KensingtonisaregisteredtrademarkofACCOBrands
Corporation.
CAUTION
Donotturnonaprojectorwithlenscapattached.High
temperaturefromlightbeammaydamagelenscapand
resultinfirehazard.
Bottom
⑭
⑦⑩
⑨
⑥

⑪ ⑬⑫
⑧
⑰
⑯
⑮

9
Part Names and Functions
Rear Terminal
⑦S-VIDEO IN
 ConnecttheS-VIDEOoutputsignalfromvideo
equipmenttothisjack(p.17).
⑩AUDIO IN
 Connecttheaudiooutputsignalfromvideo
equipmentconnectedto⑦or⑪tothisjack.
Foramonoaudiosignal(asingleaudiojack),
connectittotheL(MONO)jack(p.17).
⑨COMPUTER 1 / COMPUTER 2 AUDIO IN
 Connecttheaudiooutput(stereo)froma
computerorvideoequipmentconnectedto②
or④tothisjack.(pp16,18)
⑪VIDEO IN
 Connectthecompositevideooutputsignalto
thisjack(p.17).
②COMPUTER IN 1 / COMPONENT IN
 Connectoutputsignalfromacomputer,RGBscart
21-pinvideooutputorcomponentvideooutputto
thisterminal(pp.16,18).
⑧AUDIO OUT (VARIABLE)
 Connectanexternalaudioamplifiertothisjack
(pp.16-18).
 ThisterminaloutputssoundfromAUDIOIN
terminal(⑨or⑩).
③MONITOR OUT
 Thisterminalcanbeusedtooutputtheincoming
analogRGBsignalfromCOMPUTERIN2/DVI-I
terminalorCOMPUTERIN1/COMPONENTIN
terminaltotheothermonitor(p.16).
⑤LAN Connection Terminal
 ConnecttheLANcable(refertotheowner’smanual
“NetworkSet-upandOperation”). ⑫USB Connector (Series B)
 Inordertooperatethecomputerwiththeremote
controlandusethePAGE▲▼buttonsonthe
remotecontrolduringapresentation,connectthe
USBportofthecomputertotheUSBterminalwith
aUSBcable(notsupplied)(p.16).
⑥USB Connector (Series A)
 ConnecttheUSBcable(refertotheowner’smanual
“NetworkSet-upandOperation”).
② ③① ④ ⑤
⑥⑩ ⑦⑨
①CONTROL PORT
 Whentheprojectoriscontrolledbyacomputer,
connecttothisjackwithserialcontrolcable.
④COMPUTER IN 2 / DVI-I
 Connectcomputeroutput(Digital/AnalogDVI-Itype)
tothisterminal(p.16).
⑧⑪⑫

10
Part Names and Functions
Top Control
⑨LAMP REPLACE indicator
 Lightsyellowwhentheprojectionlampreachesits
endoflife(pp.64,72).
⑧WARNING indicator
 –Lightsredwhentheprojectordetectsanabnormal
condition.
 –Blinksredwhentheinternaltemperatureofthe
projectorexceedstheoperatingrange(pp.61,72).
④ON/STAND–BY button
Turntheprojectoronoroff(pp.20-22).
⑤POWER indicator
 –Lightsredwhentheprojectorisinstand-bymode.
 –Lightsgreenduringoperations.
 –BlinksgreeninthePowermanagementmode
(p.53).
③INPUT button
Selectaninputsource(pp.29-30,39-40).
⑥MENU button
 OpenorclosetheOn-ScreenMenu(p.23).
②POINT ▲▼◄► (VOLUME +/–) buttons
 –SelectanitemoradjustthevalueintheOn-Screen
Menu(p.23).
 –PantheimageintheDigitalzoom+mode(p.38).
 –Adjustthevolumelevel(Point◄►buttons)(p.26).
⑦AUTO SETUP/CANCEL button
 –Correctverticalkeystonedistortionandadjust
computerdisplayparameterssuchasFinesync.,
Totaldots,andPictureposition(pp.25,47).
 –DisplaytheimageinUSBthumbdriveorreturnto
themenubarinMemoryViewermenu.
 Refertotheowner'smanualof"Memory
Viewerfunction".
①SELECT button
 –Executetheselecteditem(p.23).
 –ExpandorcompresstheimageintheDigitalzoom
mode(p.38).
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩WIRELESS indicator
 Turngreenwhenthewirelesscommunicationis
establishedinthenetwork.
⑩

11
Part Names and Functions
㉖NETWORK button
SelecttheNetworkinput.Seeowner'smanual“NetworkSet-upandOperation”and
owner'smanualof"Memoryviewer".
Note:
Toensuresafeoperation,pleaseobserve
thefollowingprecautions:
–Donotbend,drop,orexposetheremote
controltomoistureorheat.
–Forcleaning,useasoftdrycloth.Donot
applybenzene,thinner,spray,orany
chemicalmaterial.
Remote Control
①
⑦
⑭
⑩
⑳
④
㉑
⑱
②
⑧
⑨
⑬
㉓
⑯
⑤
⑥
⑪
⑫
⑲
㉒
⑮
③
㉔
㉕
㉖
②ON/STAND-BY button
 Turntheprojectoronoroff.(pp.20-22)
⑤VIDEO button
 SelecttheVIDEOinputsource.(p.39)
⑥COMPUTER button
 SelecttheCOMPUTERinputsource.(pp.29-30,40)
⑬PAGE ▲▼buttons
Scrollbackandforththepagesonthescreenwhengivingapresentation.Touse
thesebuttons,connecttheprojectorandyourcomputerwithaUSBcable.(pp.9,16)
⑦INFO. button
 Operatetheinformationfunction.(p.60)
⑮D.ZOOM ▲▼buttons
 Zoominandouttheimages.(pp.27,38)
⑩MENU button
 OpenorclosetheOn-ScreenMenu.(p.23)
⑯RESET/ON/ALL-OFF switch
 When using the remote control, set this switch to “ON.” Set it to “ALL OFF” for
power saving when it is not used. Slide this switch to "RESET" to initialize the
remotecontrolcodeorswitchSpotlightandPointertotheLaserpointerfunction.
(pp.12-13)
⑱IMAGE button
 Selecttheimagemode.(pp.28,35,42)
⑲MUTE button
 Mutethesound.(p.26)
⑧
KEYSTONE button
 Correctkeystonedistortion.(pp.25,48)
⑨Point ▲▼◄►(VOLUME
+/–)
buttons
 –SelectanitemoradjustthevalueintheOn-ScreenMenu.(p.23)
 –PantheimageintheDigitalzoom+mode.(p.38)
 –Adjustthevolumelevel.(Point◄►buttons)(p.26)
㉑NO SHOW button
 Temporarilyturnofftheimageonthescreen.(p.28)
⑫ LASER button
 –OperatetheLaserpointerfunction.Laserbeamisemittedwhilepressingthis
buttonwithin1minute.Whenusingthislaserpointerformorethan1minute,
releasetheLASERbuttonandpressitagain.(p.12)
 –DisplaythePointeronthescreen.(p.12)
①L-CLICK button
Actastheleftmousebuttonforwirelessmouseoperation.(p.13)
③SIGNAL EMISSION indicator
Lightsredwhilethelaserbeamisbeingemittedfromthelaserlightwindowora
signalisbeingsentfromtheremotecontroltotheprojector.
⑪FREEZE button
 Freezethepictureonthescreen.(p.27)
⑭LAMP button
 Selectalampmode.(pp.27,55)
⑳P-TIMER button
 OperatetheP-timerfunction.(p.28)
㉒R-CLICK button
 Actastherightmousebuttonforwirelessmouseoperation.(p.13)
㉓SELECT button
 –Executetheselecteditem.(p.23)
 – ExpandorcompresstheimageinDigitalzoommode.(p.38)
㉔PRESENTATION POINTER button
Moveapointeroftheprojectororapointerforwirelessmouseoperation.(pp.12-13)
㉕AUTO SET/CANCEL button
–CorrectverticalkeystonedistortionandadjustthePCdisplayparameters.(pp.25,47)
–DisplaytheimageinUSBthumbdriveorreturntothemenubarinMemoryViewer
menu.
Refertotheowner'smanualof"Memoryviewer".
④LASER LIGHT window
Alaserbeamisemittedfromhere(p.12).
⑰
⑰SCREEN button
 Selectascreenmode.(pp.28,37,45)

12
Part Names and Functions
Spotlight
Pointer Function
Pointer
Laser Pointer Function
LASERbutton
PRESENTATIONPOINTER
button
This remote control emits a laser beam from the laser light window. Press the LASER button to activate the
laserpointer.Thesignalemissionindicatorlightsredandtheredlaserbeamisemitted.IftheLASERbuttonis
pressedformorethanoneminuteorifitisreleased,thelaserlightgoesoff.
ThelaseremittedisaClassIIlaser.Donotlookintothelaserlightwindoworpointthelaserbeamatyourselfor
otherpeople.Thefollowingisthecautionlabelforthelaserbeam.
CAUTION: Useofcontrols,adjustmentsorperformanceofproceduresotherthanthosespecifiedhereinmay
resultinhazardousradiationexposure.Neverlookdirectlyintothelaserlightwindowwhilealaser
isemitted,otherwiseeyedamagemayresult.
Thecautionlabelisputontheremotecontrol.
YoucanmovetheSpotlightorPointeroftheprojectorwiththeremotecontroltoemphasizeapartofthe
projectedimage.
Press and hold the MENU and NO SHOW buttons for
more than 5 seconds to activate the Pointer function.
(TheLaserpointerhasswitchedtothePointerfunction.)
1
PresstheLASERbuttonontheremotecontrolpointing
toward the projector. The Spotlight or Pointer is
displayedonthescreenwiththeLASERbuttonlighting
green. Then move the Spotlight or Pointer with the
PRESENTATIONPOINTERbutton.IftheLASERbutton
doesnotlightgreenandcontinuestoemitalaserbeam,
try the abovementioned procedure until the LASER
buttonlightsgreen.
2
To clear the Spotlight or Pointer out the screen, press
theLASERbuttonpointingtowardtheprojectorandsee
iftheLASERbuttonlightingisturnedoff.
ToswitchtotheLaserpointeragain,pressandholdthe
NOSHOWandMENUbuttonsformorethan5seconds
orslidetheRESET/ON/ALL-OFFswitchtoRESETand
thentoON.
WhenyouresetthePointerfunction,theremotecontrol
codewillbereset,aswell.
3
Note:
 You can choose the size of Spotlight (Large/Middle/
Small) and the pattern of Pointer (Arrow/Finger/Dot) in
theSettingMenu.See“Pointer”onpage52.
After the Laser pointer has
switchedto the Pointer,use
the LASER button as the
Pointer function ON-OFF
switch. Press the LASER
button pointing toward the
projector and see if it lights
green.
LaserLightWindow
SignalEmissionIndicator
MENUbutton
NOSHOWbutton
Press and hold the MENU
and NO SHOW buttons for
morethan5seconds.
PRESENTATIONPOINTER
button

13
PRESENTATION POINTER
button
R-CLICK button
L-CLICK button
While pressing the MENU
button, press the IMAGE
button number of times
correspondingtotheremote
controlcode.
MENU button
IMAGE button
RESET/ON/ALL-
OFF switch
Remote Control Code
Remote Control Code Number of Times Pressing IMAGE
Button
Code 1 1
Code 2 2
Code 3 3
Code 4 4
Code 5 5
Code 6 6
Code 7 7
Code 8 8
Wireless Mouse Operation
Theremotecontrolcanbeusedasawirelessmouseforyourcomputer.
Actasleft(click)mouse
buttonwhiletheprojector
andacomputerare
connectedwithaUSB
cable.
Movethepointeronthescreen
withthisbutton.
Actasright(click)mouse
buttonwhiletheprojectoranda
computerareconnectedwitha
USBcable.
Theeightdifferentremotecontrolcodes(Code1–Code8)areassignedtothisprojector.Switchingtheremote
control codes prevents interference from other remote controls when several projectors or video equipment
nexttoeachotherareoperatedatthesametime.Changetheremotecontrolcodefortheprojectorfirstbefore
changingthatfortheremotecontrol.See"Remotecontrol"intheSettingMenuonpage55.
Press and hold the MENU and IMAGE buttons for
more than five seconds to switch between the codes.
The code switches sequentially for one pressing the
IMAGEbutton.Seethelistbelow.
1
Toinitializetheremotecontrolcode,slidetheRESET/
ON/ALL-OFF switch to RESET, and then to ON. The
initialcodeissettoCode1.
2
Part Names and Functions
Beforeoperatingthewirelessmouse,connect
your computer and the projector with a USB
cable (not supplied). See “Connecting to a
Computer” on page 16. When the Pointer
function is used, the wireless mouse is not
available.
1
When a USB cable is connected to the
computer and the projector, turn on the
projector first, then the computer. If you turn
on the computer first, the wireless mouse
functionmaynotoperatecorrectly.
2

14
Part Names and Functions
Adjustable Feet
Toensuresafeoperation,pleaseobservethefollowingprecautions:
 ● Usetwo(2)AAAorLR03typealkalinebatteries.
 ● Alwaysreplacebatteriesinsets.
 ● Donotuseanewbatterywithausedbattery.
 ● Avoidcontactwithwaterorliquid.
 ● Donotexposetheremotecontroltomoistureorheat.
 ● Donotdroptheremotecontrol.
 ● Ifthebatteryhasleakedontheremotecontrol,carefullywipethecasecleanandinstallnewbatteries.
 ● Riskofanexplosionifbatteryisreplacedbyanincorrecttype.
 ● Disposeofusedbatteriesaccordingtotheinstructionsoryourlocaldisposalruleorguidelines.
Pressthelid
downwardandslideit.
Openthebattery
compartmentlid.
Installnewbatteries
intothecompartment.
Replacethe
compartmentlid.
Two AAA size batteries
Forcorrectpolarity
(+and–),besure
batteryterminalsare
incontactwithpinsin
compartment.
1 2 3
Point the remote control toward the projector (Infrared
Remote Receiver) when pressing the buttons. Maximum
operating range for the remote control is about 16.4'(5 m)
and60degreesinfrontoftheprojector.
Remote Control Operating Range
Remote Control Battery Installation
16.4'
(5m)
30° Remotecontrol
30°
AdjustableFeet
FeetLockLatches
Projectionanglecanbeadjustedupto12.0degreeswith
theadjustablefeet.
Liftthefrontoftheprojectorandpressthefeetlocklatches
onbothsideoftheprojector.
Releasethefeetlocklatchestolocktheadjustablefeetand
rotatetheadjustablefeettoaproperheight,andtilt.
Keystone distortion can be adjusted automatically with the
Autosetupfunctionormanuallybyusingtheremotecontrol
orthemenuoperation(seepages25,47-48).

15
Positioning the Projector
Forprojectorpositioning,seethefiguresbelow.Theprojectorshouldbesetperpendicularlytotheplaneofthe
screen.
Installation
Note:
 •Thebrightnessintheroomhasagreatinfluenceonpicturequality.Itisrecommendedtolimitambient
lightinginordertoobtainthebestimage.
 •Allmeasurementsareapproximateandmayvaryfromtheactualsizes.
7.8’(2.39m)
12.7’(3.88m)
11.8’(3.6m)
19.1’(5.83m)
15.8’(4.81m)
---
23.7’(7.23m)
---
2.3’(0.69m)
7.8’(2.39m)
11.8’(3.6m)
15.8’(4.81m)
23.7’(7.23m)
A
B
30" 62" 93"
124"
186"
2.3’(0.69m)
3.7’(1.14m)
30"

16
Installation
Connecting to a Computer
Cables used for connection
•VGACable(MiniD-sub15pin)*
•DVI-VGACable
•DVICable
•USBCable
•AudioCables
(*Onecableissupplied;othercablesarenotsuppliedwiththeprojector.)
Note:
 •InputsoundtotheCOMPUTER1/COMPUTER2AUDIOIN
terminalwhenusingtheCOMPUTERIN2/DVI-Iandthe
COMPUTERIN1/COMPONENTINterminalasinput.
 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-in
speakerisnotavailable.
• USBcableconnectionisneededwhenoperatingthecomputer
withtheremotecontrolorusingthePAGE▲▼buttonsonthe
remotecontrol.
Unplug the power cords of both the
projector and external equipment
fromtheAC outlet before connecting
cables.
ExternalAudioEquipment
Audiocable
(stereo)
Audiocable
(stereo)
MonitorInput
AudioOutput
COMPUTER2
AUDIOIN
AUDIOOUT
(stereo)
AudioInput
MonitorOutput
COMPUTER
IN2/DVI-I
DVI
cable
MONITOR
OUT
DVI
-VGA
cable
USBcable VGA
cable
COMPUTER
IN1
VGA
cable
Monitor
Output

17
Installation
Connecting to Video Equipment
Cables used for connection
•VideoandAudioCable(RCAx3)
•S-VIDEOCable
•AudioCable
(Cablesarenotsuppliedwiththeprojector.)
Unplug the power cords of
boththeprojectorandexternal
equipment from theAC outlet
beforeconnectingcables.
Note:
 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-
inspeakerisnotavailable.
 •TheS-VIDEOjackconnectionoverridestheVIDEOjack
connectionwhenselectingAutointheInputMenu(p.41).
ExternalAudioEquipment
Audiocable
(stereo)
VIDEO
S-VIDEO
S-Videocable
Videoandaudiocable
VideoandAudioOutput
S-VideoOutput
AUDIOIN
AudioInput
AUDIOOUT(stereo)
(R) (L) (Video)

18
Installation
Connecting to Component Video Equipment
Note:
 •When theAUDIO OUT is plugged-in, the projector's
built-inspeakerisnotavailable.
 •Seepage76fororderingoptionalcables.
Unplug the power cords of
both the projector and external
equipment from theAC outlet
beforeconnectingcables.
ExternalAudioEquipment
COMPUTER1/AUDIOIN
Audiocable
(stereo)
Audiocable
(stereo)
AudioInput
ComponentVideoOutput
(Y,Pb/Cb,Pr/Cr)
RGBScart21-
pinOutput AudioOutput
Scart-VGA
cable
Component-
VGAcable
AUDIO OUT
(stereo)
Component
cable
COMPUTERIN1/COMPONENTIN
Cables used for connection
•AudioCables
•Scart-VGACable
•VGACable   
•ComponentCable
•Component-VGACable
(Cablesarenotsuppliedwiththisprojector.)
MonitorInput
MONITOROUTPUT
VGAcable

19
Installation
Connecting the AC Power Cord
This projector uses nominal input voltages of 100-120 V or
200–240VACanditautomaticallyselectsthecorrectinput
voltage. It is designed to work with single-phase power
systems having a grounded neutral conductor. To reduce
theriskofelectricalshock,donotplugintoanyothertypeof
powersystem.
If you are not sure of the type of power being supplied,
consultyourauthorizeddealerorservicestation.
Connect the projector with all peripheral equipment before
turningtheprojectoron.
Note:
UnplugtheACpowercordwhentheprojectorisnot
inuse.Whenthisprojectorisconnectedtoanoutlet
withtheACpowercord,itisinStand-bymodeand
consumesalittleelectricpower.
Connect theAC power cord (supplied) to the
projector.
TotheACoutlet.
(200 - 240 V AC)
NOTE ON THE POWER CORD
ACpowercordmustmeetrequirementofthecountrywhereyouusetheprojector.
ConfirmtheACplugtypewiththechartbelowandproperACpowercordmustbeused.
IfsuppliedACpowercorddoesnotmatchyourACoutlet,contactyoursalesdealer.
Topowercord
connectoronyour
projector.
Projector side AC outlet side
Ground
TotheACoutlet.
(120 V AC)
For the U.S.A. and Canada
TotheACoutlet.
(200 - 240 V AC)
For the U.K.For Continental Europe
CAUTION
TheAC outlet must be near this equipment and must be
easilyaccessible.

20
Thepreparationdisplaywilldisappear
after30seconds.
(Seepage55forLampcontrolstatus.)
Turning On the Projector
Connect the projector’sAC power cord into anAC
outlet.ThePOWERindicatorlightsred. Openthelens
cap(seepages8,63).
Press the ON/SYAND-BY button on the top control
or  on the remote control. The POWER indicator
lightsgreenandthecoolingfansstarttooperate.The
preparation display appears on the screen and the
countdownstarts.
2
3
1
4Afterthecountdown,theinputsourcethatwasselected
thelasttimeandthelampcontrolstatusicon(seepage
55)appearonthescreen.
Complete peripheral connections (with a computer,
VCR,etc.)beforeturningontheprojector.
Selected Input Source and Lamp Control
Note:
 TheFilterwarningandLampreplacementicons
mayappearonthescreendependingonthe
usagestateoftheprojector.
Basic Operation
16
Lampcontrolstatus
Video
Note:
 •WhentheLogoselectfunctionissettoOff,thelogowill
notbeshownonthescreen(p.49).
 •WhenCountdown offorOffisselected in the Display
function,thecountdownwillnotbeshownonthescreen
(p.48).
 •Duringthecountdownperiod,alloperationsareinvalid.
 •WhentheInputSearchfunctionissettoOn2,theinput
signalwillbesearchedautomatically(p.47).
• WhenOffisselectedintheDisplayfunction,theVideo/
PC selection window and the input signal guidance
windowarenotshownonthescreen.(p.48)
5Ifthereisnosignalinputwhenstartontheprojector,
orthecurrentsignalismissedwhileoperatingthe
projector,theVideo/PCselectionwindowwillbe
displayedonthescreen,pleasemovethepointerto
inputsourcedesiredbypressingthePoint▲▼buttons
andpresstheSELECTbutton.Andthenfollowthe
inputsignalguidancewindowtocorrectthesignaland
connection.
IftheprojectorislockedwithaPINcode,PINcodeinput
dialogboxwillappear.EnterthePINcodeasinstructed
onthenextpage.
Video / PC selection window
Input signal guidance window
Video / PC selection window
Input signal guidance window
Nosignal
CurrentInputsetting:Video
Issignalprocessedcorrectly?
Iscableconnectedproperly?
Nosignal
CurrentInputsetting:RGB
Issignalprocessedcorrectly?
Iscableconnectedproperly?
Cancel
Cancel
