Sanyo VCC-4312P User manual

INSTRUCTION MANUAL
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
VCC-4312P
COLOUR CCD camera
CCD-Farbkamera
Caméra CCD COULEUR
CCD
About this manual
Before installing and using the camera, please read this
manual carefully. Be sure to keep it handy for later reference.
Über diese Bedienungsanleitung
Lesen Sie bitte vor der Montage und dem Inbetriebnehmen der
Kamera zuerst diese Bedienungsanleitung sorgfältig durch und
bewahren Sie sie zum späteren Nachschlagen auf.
A propos de ce manuel
Avant d’installer et d’utiliser la caméra, veuillez lire ce
manuel attentivement. Gardez-le à portée de main
pour toute référence ultérieure.
L53S2/XE GB 1998, 12, 25

Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If
you need help with installation and/or settings, please consult your
dealer.
CONTENTS
PRECAUTIONS........................................................................................ 2
PARTS NAMES ....................................................................................... 3
MOUNTING THE LENS........................................................................... 7
CONNECTIONS....................................................................................... 9
SETTINGS................................................................................................10
TROUBLESHOOTING ............................................................................. 13
SPECIFICATIONS....................................................................................14
ACCESSORIES
1C mount adaptor ( mm)....................1 pc.
The C mount adaptor must be used to be able to install a C mount
lens on the camera.
2Lens iris plug (4-pin) ............................1 pc.
3AC adaptor .........................................1 pc.
123
FEATURES
•The optical filter is switched automatically to colour image or black
and white image according to the subject brightness.
•Built-in interline transfer method 1/3" CCD, approx. 320,000
picture elements
•Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
•100% solid state components giving excellent immunity to shock
and vibration
•Not subject to interference from magnetic or electrostatic fields
•High sensitivity, minimum required illumination is 0.0 lux (F1.2)
•Horizontal resolution, more than 330 TV lines
•Power supply: 12 – 1 V DC operation
L 3S2/XE GB 1998, 12, 2
English 1

RECAUTIONS
In case of problem
Do not use the camera if smoke or a strange odour comes from the
unit, or if it seems not to function correctly. Disconnect the power
cord immediately, and consult your dealer (or a Sanyo Authorized
Service Centre).
Do not open or modify
Do not open the cabinet, as it may be dangerous and cause damage
to the unit. For internal settings and repairs, consult your dealer (or a
Sanyo Authorized Service Centre).
Do not put objects inside the unit
Make sure that no metal objects or flammable substance get inside
the camera. If used with a foreign object inside, it could cause a fire,
short-circuits or damages.
If water or a liquid gets inside the camera, disconnect the power cord
immediately, and consult your dealer (or a Sanyo Authorized Service
Centre). Be careful to protect the camera from rain, sea water, etc.
Be careful when handling the unit
To prevent damages, do not drop the camera or subject it to strong
shock or vibration.
Install away from electric or magnetic fields
If installed close to a TV, radio transmitter, magnet, electric motor,
transformer, audio speakers the magnetic field they generate will
distort the image.
rotect from humidity and dust
To prevent damages to the camera, do not install it where there is
greasy smoke or steam, where the dampness may get too high, or
where there is a lot of dust.
rotect from high temperatures
Do not install close to stoves, or other heat generating devices, such
as spotlights, etc., or where it could be subject to direct sunlight, as
that could cause deformation, discoloration or other damages.
Be careful when installing close to the ceiling, in a kitchen or boiler
room, as the temperature may raise to high levels.
Install where the temperature range will stay between –10˚C and
0˚C.
(no condensation)
Cleaning
•Dirt can be removed from the cabinet by wiping it with a soft
cloth. To remove stains, wipe with a soft cloth moistened with a
soft detergent solution and wrung dry, then wipe dry with dry soft
cloth.
•Do not use benzine, thinner or other chemical product on the
cabinet, as that may cause deformation and paint peeling. Before
using a chemical cloth, make sure to read all accompanying
instructions. Make sure that no plastic or rubber material comes in
contact with the cabinet for a long period of time, as that may
cause damage or paint peeling.
ENGLISH
L 3S2/XE GB 1998, 12, 2
2 English

ARTS NAMES
1Lens iris output connector (4 pin)
This 4-pin connector is used to send the DC control signal and power supply to an auto-iris type lens.
2Flange-back adjustment lever (See page 6)
3Flange-back lock screw
4Lens mount cap
The cap is installed to protect the lens mount section.
Remove the lens mount cap before installing a lens (sold separately).
5Camera installation bracket
The bracket can be fixed at the top or bottom of the camera. When fixing the bracket, be sure to use the
longer screws and install the shorter screws on the opposite side to seal the openings.
CAUTION:
When installing the camera support, select a location that can support the total weight of the
camera and accessories.
1232
1
5
1
4
1
2
3
4
3
2
1Shorter screws: M3 x 4
2Longer screws: M3 x 6
3Camera mounting
screw hole:
1/4"-20 UNC
L 3S2/XE GB 1998, 12, 2
English 3

ARTS NAMES
6Camera setup section (under the cover)
This unit factory settings are as indicated below. These settings are for when using a 1/3 inch CS mount DC
(without EE internal amplifier) type lens. However, if due to installation conditions or environment the settings
may need to be modified for best results (see "SETTINGS"). To access the controls, remove the cover fixing
screw, then remove the cover.
Control name osition
aColour and Black/White level switch (C-BW) L
bHigh speed electronic shutter switches (ES) All OFF: 1/50 sec
cRed and Blue colour adjustment volume (R, B) about centre
dWhite balance switch (WB) A
eElectronic iris (EI)/Backlight compensation (BLC) switch OFF
fAuto-iris lens switch (A.I. LENS) DC
gLens iris level volume (LEVEL) about centre
Notes:
•The EI/BLC switch cannot be used simultaneously.
•When using a 1/2 or 2/3 inch C mount VIDEO (with EE internal amplifier) auto-iris type lens, set the
A.I. LENS switch to the VIDEO position.
•If not using an auto-iris lens, make sure the EI/BLC switch is set to OFF.
b
c
d e f g
6
a
LEVEL
DC
VIDEO
A. I.
LENS
LH
VR301
ON
OFF
ON
WB
A
M
BLC
EI
VR302
BR
VR303
C-BW
L
H
ON
1324
L 3S2/XE GB 1998, 12, 2
4 English

ARTS NAMES
7ower indicator ( OWER)
Comes on when the power to the camera is on.
8Video output connector (VIDEO OUT: BNC type)
Connect this connector to a device such as a VCR or monitor with a VIDEO IN connector.
9External sync composite video signal input connector (VBS IN: BNC type)
Connect to this connector the synchronizing signal output from a synchronizing signal device or the composite
signal of a video distributor.
F12 V DC input terminal (12 V DC, NC)
OWER SOURCE
Connect DC connecting cord from the AC adaptor to the 12 V DC IN terminal on the camera.
Then, plug the AC adaptor into an AC outlet.
WARNING:
•This AC adaptor is specially conceived for this camera.
Never use another type of AC adaptor with this camera, and do not use this AC adaptor to power other
types of cameras.
•Not for use with toys.
•Never try to disassemble or modify the AC adaptor.
•AC adaptor output: 1 V DC
7
9
F
8
NC + –
L 3S2/XE GB 1998, 12, 2
English 5

ARTS NAMES
Flange-back adjustment
If the pick-up surface is not correctly positioned with relation to the lens focal point, the picture will be out of
focus (in particular when using auto-iris power zoom lenses, sold separately). If that is the case, adjust the
flange-back position as described below.
1Using a + screwdriver, loosen the flange-back lock screw (M2:+).
2Set the zoom lens to the maximum telephoto position, set the focus using the focus ring on the lens.
3Set the zoom lens to the maximum wide angle position, set the focus using the flange-back adjustment
lever.
4Repeat steps 2 and 3, until the image stays in focus when changing from a telephoto shot to a wide angle
shot.
When the setting is complete, tighten the flange-back lock screw.
Note:
When flange-back lock screw is completely tighten it will protrude slightly as shown in the illustration (Fig. 1).
Do not tighten the screw further.
Fig. 1
Flange-back lock screw
2
3
1, 4
L 3S2/XE GB 1998, 12, 2
6 English

MOUNTING THE LENS
Check the lens mount
Do not use a lens if the length “L” is more than 5 mm. That may damage the
camera and prevent proper installation.
Installation of a DC type auto-iris lens (sold separately)
A 1/3 inch CS mount type lens without EE amplifier circuit that only uses a DC power source. This camera can
receive (the A.I. LENS switch to the DC type) a CS mount type lens without the need of an adaptor.
If the lens plug shape or wiring does not correspond, please install the supplied plug as indicated in the pin
layout table.
Installation of a VIDEO type auto-iris lens (sold separately)
A 1/2 or 2/3 inch C mount type lens with EE amplifier circuit that uses the video signal and a DC power source.
1Remove the lens mount cap.
2Attach the supplied C mount adaptor (A) to the auto-iris lens (B), then install the assembly on the camera.
3Connect the lens plug to the LENS connector on the side of the camera.
If the lens plug shape or wiring does not correspond to the specifications below, connect the supplied plug
as indicated.
•When using lenses from other makers, make sure that the pins connections in the plug correspond to
the ones of the camera.
Refer to the lens specifications to check the pins connections in the plug.
•If they are different than indicated, remove the original plug and connect the supplied plug according to
the diagram.
L
2 (A) (B)
3
3
1
24
L 3S2/XE GB 1998, 12, 2
English 7

MOUNTING THE LENS
4Set the A.I. LENS switch in the camera setup section to the VIDEO position.
in layout
DC type lenses VIDEO type lenses
1Brake coil (–) +12 V DC ( 0 mA max.)
2Brake coil (+) Not used
3Drive coil (+) Video output (1.0 Vp-p, high impedance)
4Drive coil (–) Ground (for video signal and DC power)
Compatible auto-iris lenses
1/3 inch Sanyo DC type lens 1/2 or 2/3 inch VIDEO type lens
VCL-CS8LY: Standard angle, f= 8 mm Standard angle, f= 9 mm
VCL-CS4LY: Wide angle, f= 4 mm Telephoto angle, f= 12 mm
VCL-CS2LY: Ultra-wide angle, f= 2.8 mm More telephoto angle, f= 16 mm
If using a VIDEO type auto-iris lens
•Set the ALC and LEVEL controls on the lens to adjust the iris. Normally the ALC volume should be turned
all the way to Av (Average).
•Depending on the type of lens used, the lens may not perform properly. In such a case, adjust the LEVEL
volume on the lens casing to correct.
DC
VIDEO
4
4
1
2
3
L 3S2/XE GB 1998, 12, 2
8 English

CONNECTIONS
Basic co ectio for mo itori g or recordi g
The peripheral devices (VCR, monitor, lens, etc.) and cables are sold separately.
1Make the video signal connection between the camera and the monitor or time lapse VCR.
2Insert the plug of this power cord into a wall outlet.
The OWER indicator (A) will light. Adjust the picture on the monitor using the Brightness and Contrast
controls.
Note:
When installing the camera, use metal brackets to fix the AC adaptor. Then attach it firmly using a metal strap.
Coaxial cable type and maximum length
•Cable type RG- 9U (3C-2V), 2 0 m maximum.
•Cable type RG-6U ( C-2V), 00 m maximum.
•Cable type RG-11U (7C-2V), 600 m maximum.
CAUTION:
•The RG- 9U type cable should not be run through electrical conduits or through the air.
•Using CCTV/Video-grade coaxial cable.
(Video signal connections)
: VIDEO IN
: VIDEO OUT
(A)
1
L 3S2/XE GB 1998, 12, 2
English 9

SETTINGS
High speed electronic shutter setting
Normally, the speed setting switches for
the high speed electronic shutter are all
set to the OFF position. This sets the
electronic shutter speed to 1/ 0 sec. The
switches can be set as indicated in table
A to select one of the 8 speeds available.
CAUTION:
•When using the high speed electronic
shutter, the EI/BLC switch must be
set to the OFF position.
•Using the high speed electronic
shutter indoors with low lighting, will
give darker pictures. In such a case,
add some lights to make sure the
lighting is sufficient. If the lighting is
very bright, pay attention to the light
angle in order to avoid or minimize
the smear phenomenon effect.
LEVEL
DC
VIDEO
A. I.
LENS
LH
VR301
ON
OFF
ON
WB
A
M
BLC
EI
VR302
BR
VR303
C-BW
L
HON
1324
Table A
1 1/ 0 sec.
2 1/120 sec.
3 1/2 0 sec.
4 1/ 00 sec.
5 1/1000 sec.
6 1/2000 sec.
7 1/4000 sec.
8 1/10000 sec.
1234
2314
234
1
234
1
234
1
234
1
234
1
23
1 4
White balance adjustment
Normally the WB (white balance) switch is set
to the A (automatic) position and the white
balance is adjusted automatically. If a manual
white balance adjustment is necessary, follow
the steps below.
Set the WB switch to the M (manual) position,
then adjust the colour.
•Turn R (VR303) to set the red ratio and/or
B (VR302) to set the blue ratio.
WB
A
M
VR302
BR
VR303
L 3S2/XE GB 1998, 12, 2
10 English

SETTINGS
Lens iris adjustment
If using a DC type auto-iris lens, you will need to set the LEVEL
(VR301) volume when shooting in the conditions described below.
L (counterclockwise): To decrease the contrast
H (clockwise): To increase the contrast
•If shooting simultaneously in a dark room and through a bright
window.
•If the subject background is extremely bright or dark.
•If the brightness of the picture on the monitor is not correct.
Backlight compensation setting
Use an auto-iris lens and set the EI/BLC switch to the BLC-ON
position, to engage the backlight compensation function.
If using a VIDEO type auto-iris lens
•The ALC volume on the lens should be turned all the way to Av
(Average).
•If the backlight compensation function does not compensate
properly for the conditions, set using the LEVEL volume on the
lens.
CAUTION:
The electronic iris function and the backlight compensation function
cannot operate simultaneously.
LEVEL
LH
VR301
ON
OFF
ON
BLC
EI
L 3S2/XE GB 1998, 12, 2
English 11

SETTINGS
Electronic iris function setting
Use a manual or fixed iris lens and set the lens aperture to the
shortest F stop. Set the EI/BLC switch to the EI-ON position.
Note:
Please refer to the specifications for dynamic range of the electronic
iris.
CAUTION:
•The electronic iris is suitable for normal indoor use. When the
EI/BLC switch is set to the EI-ON position, do not use an auto-iris
lens.
•If used under fluorescent light, the image may flicker. In such a
case, change to incandescent lighting or set the EI/BLC switch to
the OFF position and use an auto-iris lens.
•When shooting bright subjects, pay attention to the light angle in
order to avoid or minimize the smear phenomenon effect.
When using an auto-iris lens (for indoor/outdoor
use)
Set the EI/BLC switch to the OFF position.
CAUTION:
If conditions are outside the electronic iris operation range or more
than the maximum illumination, it will cause saturation of the CCD. In
that case, use a manual iris lens.
ON
OFF
ON
BLC
EI
L 3S2/XE GB 1998, 12, 2
12 English

SETTINGS
C • B/W (colour/black and white) switch setting
This switch lets you select the timing of the automatic switching of
the optical filter to colour image or black and white image, according
to the subject brightness. The default setting is “L”. Set the switch
according to the brightness.
(Fig. 1)
H: for a brighter setting than L
L: Standard setting
Notes:
•After the power has been turned off, switching will restart from
colour, when the power is restored.
•A sound may be heard when the colour image or black and white
image is switched. Also, the image will be distorted as shown in
Fig. 1, this is normal and does not indicate a problem.
•When using infrared lighting, if there is a strong reflection on the
subject, the optical filter may switch from black and white to
colour mode, Use only enough infrared lighting so that the mode
is not switched.
•The focus setting may be different in black and white mode and
colour mode. Please check the focus setting in both modes.
TROUBLESHOOTING
Before taking the camera for repairs, please check below to make sure
that the camera is used correctly. If it still does not perform correctly,
please consult your dealer or a Sanyo Authorized Service Centre.
No picture on the monitor screen
•Is the power turned on to all connected devices? Is the voltage correct?
•Are all the signal connecting cables correctly connected?
•Is the lighting sufficient?
•Has the lens cap been removed?
•Is the lens type (DC or VIDEO) correctly selected?
Depending on the type of lens, the A. I. LENS switch must be set
accordingly.
•Is the iris control correctly set?
The picture is not clear
•Is the monitor correctly adjusted?
•Is the flange-back position correctly set?
•Is the lens focus correctly adjusted?
•Are the lens surfaces clean?
If there is dust or finger prints on the lens, the image quality will
deteriorate. To clean the lens use a soft cloth or a commercially
available lens cleaning set.
SERVICE
This camera is a precision instruments and if treated with care, will
provide years of satisfactory performance. However, in the event of a
problem, the owner is advised not to attempt to make repairs or open
the cabinet. Servicing should always be referred to your dealer or
Sanyo Authorized Service Centre.
C-BW
L
H
L 3S2/XE GB 1998, 12, 2
English 13

S ECIFICATIONS
Camera:
Scanning system : PAL standard
(62 TV lines, 2 frames/sec.)
Interlace : PLL 2:1 interlace
Image device : 1/3 inch solid state image device
CCD
icture elements : 37 (H) x 97 (V)
Effective picture elements : 00 (H) x 82 (V)
Synchronizing system : Internal sync, External sync
(Automatic switching)
Resolution : 330 TV lines horizontally, 400 TV
lines vertically
Video output level : 1.0 Vp-p/7 ohms, composite
Video S/N ratio : More than 48 dB
Minimum required
illumination
(incandescent lighting)
:Approx. 0.0 lux with a F 1.2 lens
(B/W mode),
Approx. 1.0 lux with a F 1.2 lens
(colour mode)
Electronic shutter : 8 speeds, selectable by switches:
(1/ 0, 1/120, 1/2 0, 1/ 00, 1/1000,
1/2000, 1/4000, 1/10000 sec.)
Backlight compensation : Manual ON/OFF switching,
Multi-zone light measuring system
(Active when using an auto-iris lens)
Iris function : Manual ON/OFF switching
Electronic iris range : 1 lux to 0,000 lux (F 1.2, lens:
colour mode)
1.4 lux to 70,000 lux (F 1.4, lens:
colour mode)
Flange-back : 12. mm ± 0. mm
White balance : ATW/Manual switching
Lens mount : CS mount (or C mount with the
supplied adaptor)
Environmental conditions : Temperature: –10˚C ~ + 0˚C
Humidity: less than 90%
(no condensation)
ower supply : 12 V DC (Supplied from AC adaptor)
ower requirement : 12 – 1 V DC/210 – 170 mA
(without Auto iris lens)
Weight : Approx. 4 0 g (without lens)
AC Adaptor:
Environmental conditions : Temperature: –10˚C ~ + 0˚C
Humidity: less than 90%
(no condensation)
ower requirement : 220 – 230 V AC 0Hz
ower consumption : Approx. .3 W
Weight : Approx. 680 g
L 3S2/XE GB 1998, 12, 2
14 English

S ECIFICATIONS
Dimensions: mm
Features and specifications are subject to change without prior
notice or obligations.
136
126.5
1
15.4
25.2
11
1/4”–20 UNC
67
54
28
3
100
1,830 1,830
68
62
L 3S2/XE GB 1998, 12, 2
English 15
