Sanyo AWM-2600 User manual

Service Manual
FILE NO.
REFERENCE No. SM5810219
Mini Shelf System AWM-2600 (US)
DC-C300 (CA)
DC-S300 (AU)
SPECIFICATIONS
(AMPLIFIER SECTION)
Continuous minimum sine wave RMS power output per channel at
1 kHz 8 ohms with no more than 10 % total harmonic distortion
....................................................2.5 watts
Sound preset...............................4 electronic presets
Bass expander ............................+8 dB (at low volume level)
PHONE .......................................8 - 32 ohms
VIDEO .........................................400 mV/50 kohms
(AWM-2600SP MAIN SPEAKER SYSTEM)
Type ............................................Full range bass reflex
Drivers.........................................4.8" Dia
Maximum power-handing capacity
....................................................5 Watts (peak)
Nominal impedance ....................8 ohms
Dimensions (W x H X D) .............Approx. 7.6" x 11.6" x 7.5"
Weight .........................................approx. 3.7 lbs.
(SX-SR2600 SURROUND SPEAKER SYSTEM)(US only)
Type ............................................Full range
Drivers.........................................3.2" Dia
Maximum power-handling capacity
....................................................5 Watts (peak)
Nominal impedance ....................6 ohms
Dimensions (W x H x D)..............Approx. 6.7" x 4.9" x 3.6"
Weight .........................................approx. 3.7 lbs.
(CASSETTE DECK SECTION)
Track system...............................4 - track, 2 - channel stereo
Frequency response ...................125 Hz - 8 kHz (Normal tape)
Signal to noise ratio ....................45 dB
Wow and Flutter ..........................0.3%(WRMS)
Tape speed .................................1 - 7/8 i.p.s (4.75 cm/sec)
Fast forward and Rewind time
....................................................Approx. 120 sec (C - 60)
(CD CHANGER SECTION)
Type ............................................Changer, 3-disc
Channels .....................................2-channel stereo
Sampling frequency ....................44.1 kHz
Pick-up ........................................Optical 3-beam semiconductor laser
Frequency response ...................20 Hz - 10 kHz
Signal to noise ratio ....................60 dB
Wow and Flutter ..........................Below measurable limits
(TUNER SECTION)
Frequency range .........................FM : 87.9 - 107.9 MHz(200 kHz steps)
AM : 520 - 1,710 kHz(1- kHz steps))
Usable sensitivity ........................FM : 26 dBf(mono)
AM : 2000 micro V/m(AM Loop antenna)
(GENERAL SECTION)
Power requirements ....................120 V AC, 60 Hz
Power consumption ....................25 Watts
Dimensions .................................Approx. 11.3" x 11.6" x 14.1"
Weight (approx.) .........................2.1 oz. (Without batteries)
Specifications subject to change without notice.
PRODUCT CODE No.
129 604 00 AWM-2600/US
129 604 01 DC-C350/CA
129 604 04 DC-S300/AU

SANYO Technosound Co., Ltd.
Osaka, Japan
Jun./ '01 / 1100 BB Printed in Japan
