Sanyo Avm-1309s, avm-1901s, avm-2509 User manual

AVM-1309S

AVM-1901S

AVM-2509S

CONTENTS

Important Safety Tips . . . . . . . . . . . . . . . . . . . . 2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basic Hookup Methods . . . . . . . . . . . . . . . . . . . 4

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 5

TV Adjustment and Setup . . . . . . . . . . . . . 6 ~ 7

V-Guide Information . . . . . . . . . . . . . . . . . . . . . 7

V-Guide Operation (Parental Control) . . . . 8 ~ 9

Setting the Sleep Timer . . . . . . . . . . . . . . . . . . 9

Resetting the TV . . . . . . . . . . . . . . . . . . . . . . . . 9

Closed-Captioning . . . . . . . . . . . . . . . . . . . . . .10

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . 10

Helpful Hints–Problems/Solutions . . . . . 11 ~ 12

Warranty (U.S.A.) . . . . . . . . . . . . . . . . . . . . . . 13

Warranty (CANADA) . . . . . . . . . . . . . . . . . . . . 14

Child Safety Matters . . . . . . . . . . . . . Back Cover

FRANÇAIS . . . . . . . . . . . . . . . . . . . . . . .15 ~ 28

Table des matières . . . . . . . . . . . . . . . . . . . . .15

ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . 29 ~ 43

Contenido . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Color TV Owner’s Manual

Manuel d’instructions

du télécouleur

Color TV Manual Del Propietario

Printed in U.S.A. SMC, October 2001 /Imprimé aux É.-U. SMC, octobre 2001/

Impreso en U.S.A. SMC, Octubre 2001

Part No. / Node pièce / No. de Parte : 1AA6P1P2585A–

Service Code / Code de service / Código de Servicio : 610 289 2901

MENUMENU POWERPOWER

CHANNELCHANNEL

MENUMENU MENUMENU

VOLUMEVOLUME

AVM-1309S (Pictured / Illustré / Ilustró)

Welcome to the World of Sanyo

Thank you for purchasing a Sanyo Color Television. You made an excellent choice for Performance, Reliability, and Value. The TV

is designed with easy on-screen set-up instructions and operating features. To meet the growing needs of our customers, this tele-

vision has a “V-Chip” for parental controlled viewing. “Read this manual before assembling (or using) this product.” Need

assistance? Visit our web site at www.sanyoctv.com.

AVM-1309S

AVM-1901S

AVM-2509S

CONTENTS

Important Safety Tips . . . . . . . . . . . . . . . . . . . . 2

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Basic Hookup Methods . . . . . . . . . . . . . . . . . . . 4

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . 5

TV Adjustment and Setup . . . . . . . . . . . . . 6 ~ 7

V-Guide Information .....................7

Color TV Owner’s Manual

Manuel d’instructions

du télécouleur

Color TV Manual Del Propietario

MENU POWER

CHANNEL

MENU MENU

VOLUME

Welcome to the World of Sanyo

Thank you for purchasing a Sanyo Color Television. You made an excellent choice for Performance, Reliability, and Value. The TV

is designed with easy on-screen set-up instructions and operating features. To meet the growing needs of our customers, this tele-

vision has a “V-Chip” for parental controlled viewing. “Read this manual before assembling (or using) this product.” Need

assistance? Visit our web site at www.sanyoctv.com.

Positioning the appliance

1. Do not place your appliance on an unstable cart, stand, shelf or table.

Serious injury to an individual, and damage to the appliance, may result

if it should fall. Your salesperson can recommend approved carts and

stands or shelf and wall mounting instructions. An appli-

ance and cart combination should be moved with care.

Quick stops, excessive force, and uneven surfaces may

cause the appliance and cart combination to overturn.

2. Slots and openings in the cabinet and in the back or bottom are

provided for ventilation. To ensure reliable operation of the appliance and

to protect it from overheating, these openings must not be blocked or

covered. The openings should never be covered with a cloth or other

material, and the bottom openings should not be blocked by placing the

unit on a bed, sofa, rug, or other similar surface. This appliance should

never be placed near or over a radiator or heat register. This appliance

should not be placed in a built-in installation such as a bookcase unless

proper ventilation is provided.

3. Do not expose the appliance to rain or use near water . . . for example,

near a bathtub, swimming pool, kitchen sink, in a wet basement, etc.

Hooking Up Outdoor Antenna

LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER

NATIONAL ELECTRICAL CODE INSTRUCTIONS.

4. If an outside antenna is connected to the receiver, be sure the antenna

system is grounded so as to provide some protection against voltage

surges and built up static charges. Article 810 of the National Electrical

Code, ANSI/NFPA 70, provides information with respect to proper

grounding of the mast and supporting structure, grounding of the lead in

wire to an antenna discharge unit, size of grounding conductors,

location of antenna discharge unit, connection to grounding electrodes,

and requirements for the grounding electrode.

An outside antenna system should not be located in the vicinity of over-

head power lines or other electric light or power circuits, or where it can

fall into such power lines or circuits. When installing an outside antenna

system extreme care should be taken to keep from touching such power

lines or circuits as contact with them might be fatal.

Plug in the power cord

5. This product should be operated only from the type of power source indi-

cated on the marking label. If you are not sure of the type of power

supply to your home, consult your product dealer or local power

company. This product is equipped with a polarized alternating current

line plug (a plug having one blade wider than the other). This plug will fit

into the power outlet only one way. This is a safety feature. If you are

unable to insert the plug fully into the outlet, try reversing the plug. If the

plug should still fail to fit, contact your electrician to replace your obso-

lete outlet. Do not defeat the safety purpose of this polarized plug. Do not

overload wall outlets, extension cords, or integral convenience recepta-

cles as this can result in a risk of fire or electric shock.

6. Power-supply cords should be routed so that they are not likely to be

walked on or pinched by items placed upon or against them, paying par-

ticular attention to cords at plugs, convenience receptacles, and the point

where they exit from the product.

Cleaning

7. Before cleaning,unplugtheunitfromthewalloutlet.Donotapplyliquidclean-

ers or aerosol cleaners directly to the unit. Use a damp cloth for cleaning.

Service & Repair

8. Unplug the appliance from the wall outlet and refer servicing to

qualified service personnel under the following conditions:

A. If the power cord or plug is damaged or frayed.

B. If liquid has been spilled into the appliance.

C. If the appliance has been exposed to rain or water.

D. If the appliance has been dropped or the cabinet has been damaged.

E. If the appliance exhibits a distinct change in performance.

F. If the appliance does not operate normally by following the operating

instructions, adjust only those controls that are covered in the oper-

ating instructions. Improper adjustment of other controls may result

in damage and will often require extensive work by a qualified tech-

nician to restore the appliance to normal operation.

9. Upon completion of any service or repair, request the service techni-

cian’s assurance that only Factory Authorized Replacement Parts that

have the same characteristics as the original parts were used, and that

routine safety checks have been performed to determine that the appli-

ance is in safe operating condition. Unauthorized substitutions may

result in fire, electrical shock, or other hazards.

10. Never add accessories that have not been specifically designed for use

with this appliance as they may cause hazards.

11. For added protection during a lightning storm, or when the set is left

unattended and unused for long periods of time, unplug it from the wall

outlet and disconnect the antenna. This will prevent damage to the set

due to lightning or power line surges.

12. Never push objects of any kind into this product through openings as

they may touch dangerous voltage points or short-out parts that could

result in a fire or electric shock. Never spill liquid of any kind on the

product.

EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATIONAL

ELECTRICAL CODE, ANSI/NFPA 70

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING

A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING

AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANY-

ING THIS UNIT.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS. BEFORE

OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS. RETAIN THIS

LITERATURE FOR REFERENCE. Follow all instructions...

“Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40

of the NEC that provides guidelines for proper grounding and, in particular, specifies that

the cable ground shall be connected to the grounding system of the building, as close to

the point of cable entry as practical.”

NEC

- NATIONAL ELECTRICAL CODE

ANTENNA

LEAD IN

WIRE

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUND

CLAMP

ELECTRIC

SERVICE

EQUIPMENT

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)
