Sanyo AVM-32F4, AVM32F9 User manual

1
Introduction 2
Safety Instructions 3
Location of Controls 4
Remote Control Use 5
Antenna Connection 6
Cable TV CATV) Connection 7
Video/Audio Connections 8
Basic Operation 10
Basic Menu Operation 11
Set-Up 13
Antenna Selection
Auto Channel Programming
Manual Memory Channel Add/Delete)
Fine Tuning
LNA Effects
Picture Adjustment 18
Sound Adjustment 20
Clock/Timer 28
Other Functions 31
Picture-in-Picture PIP) AVM-32F9 ONLY 34
V-Chip Operation 36
Reception Disturbance 48
Care and Maintenance 48
Troubleshooting Guide 49
Sanyo Comfort Warranty 50
TABLE OF CONTENTS
P.STD Button
Custom Manual) Adjustment
Using S.STD Button
Using On-Screen Menu
Equalizer
Headphones
Surround Sound
MTS
All manuals and user guides at all-guides.com
all-guides.com

3
2
SAFETY INSTRUCTIONS
Caution
To prevent electric shock do not use this (polarized) plug with an extension cord, receptacle or
other outlet unless the blades can be inserted fully to prevent blade exposure
GRAPHICAL SYMBOLS EXPLANATION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK)
NO PARTS INSIDE
REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
This lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (Servicing) instructions in
the literature accompanying the appliance
Caution
Any changes or modifications in construction of this device which are not expressly approved
by the party responsible for compliance could void the user’s authority to operate the
equipment
ANTENNA
Unless your TV is connected to a Cable TV system or to a centralized antenna system, a good
outdoor color TV antenna is recommended for the best performance However, if you are
located in a strong signal area that is free from interference and ghost conditions (multipath),
an indoor antenna may be sufficient
LOCATION
Select an area where sunlight or bright indoor illumination will not fall directly on the picture
screen
Also, be sure that the location selected allows a free flow of air to and from the perforated back
cover of the set
NOTES
Never remove the back cover of the set This can expose you to very high voltage and other
hazards
If the set does not operate properly, unplug it and call your dealer or service shop
VIEWING
This color TV may be viewed from any desired distance Most viewers prefer a distance of
three to six feet or more depending on screen size for maximum eye comfort
INTRODUCTION
It is especially important that you read and follow the instructions under the heading :
"SET-UP" on page 13
HOW TO GET THE MOST ENJOYMENT FROM YOUR NEW COLOR TV SET
Your new Color TV incorporates a host of features designed to give you excellent performance
In addition, this model utilizes a highly sophisticated Control Microprocessor for ultimate
convenience and control in the areas of Picture Adjustment, Channel Tuning, and On-Screen
display
We therefore strongly urge that you read all of these instructions before using your TV for the first time
Congratulations on your purchase of this Sanyo MTS stereo TruFlat
TM
screen television
Sanyo's TruFlat
TM
screen offers these important benefits
Distortion-Free Images - Sanyo TruFlat
TM
recreates the theater screen experience by
eliminating distortion that a curved conventional TV screen produces
Wider Viewing Angle - No curves mean that the full picture can be seen from a wider seating
range in your room
Less Reflection - Window and other reflections are reduced because of the curve-free design
The speakers are front-mounted at the left and right sides of the TV screen for better stereo
effect, delivering a high audio output of 30 watts (total) with surround sound modes
Othe Featu es
181-channel cable-compatible frequency synthesizer tuner with built-in MTS decoder
Parental guide using V-chip technology
600-line horizontal resolution
3-line digital comb filter
Velocity scan modulation for sharpest picture quality when brightness levels change from
one scene to another
Component video inputs (DVD)
S-Video input (Video 1/ Video 2)
3 sets of A/V inputs
Picture-in-Picture (1-tuner) (AVM-32F9 only)
Clock and Sleep/On-Off timer
Multi-color on-screen menu/display in English, French, Portuguese or Spanish
High-contrast dark picture tube
Closed-captioning decoder/Blocking
Audio out jacks
Auto channel programming
Automatic power shut-off
Remote control with Moon Glow
TM
keys for easy operation in a dark room (uses 2 x AAA
batteries, not incl )
Note: Some illustrations in this manual may differ from the actual unit for explanation purposes
Caution
Do not block or cover the ventilation holes on the cabinet top
Do not allow water or any liquids to enter the cabinet
All manuals and user guides at all-guides.com

5
4
REMOTE CONTROL USE
Point to remote control sensor of the TV set
The maximum operable distance is approximately 20 feet from the remote control sensor, and
not more than 30 to either side of center
The operation of the remote control is most effective when there is nothing between it and the
remote control sensor
The duration of the batteries is approximately 6 months to 1 year
Replace the batteries when the remote operation becomes unstable
BATTERY INSTALLATION
The battery compartment is located at the bottom of the remote control To access it, remove the
cover by sliding it down while lifting it
Correctly install 2 AAA batteries, observing polarities as shown in the compartment
Do not use a combination of old and new batteries or different type of batteries
If batteries become exhausted, remove and replace them soon
When battery leakage occurs, clean the battery compartment with a soft cloth and replace the
batteries
VIDEO Button Power Button
100 Button
Display Button
Channel Up ( ) Button
Sleep Button
Menu Button
Volume Up ( ) Button
Channel Down ( ) Button
Picture Button
Picture Standard Button
CCD Button
PIP Size Button
PIP Position Button
Surround Button
Strobe Button
Number Button
Quick View Button
Volume Down ( ) Button
Mute Button
MTS Button
Sound Standard Button
PIP On/Off Button
Add/Del Button
PIP TV/VIDEO Button
Swap Button
Wide Button
PIP Still Button
LOCATION OF CONTROLS
FRONT
S-VHS IN
12
1 Power Button
2 Remote Control Sensor with STAND BY Indicator
3 Channel Up ( ) Button
4 Channel Down ( ) Button
5 Volume Up ( ) Button
6 Volume Down ( ) Button
7 Menu Button
8 Video Button
9 Headphone Jack
10 Video/Audio 2 Input Jacks
11 S-VHS 2 Input Jack
12 S-VHS 1 Input Jack
13 Video / Audio 1 Input Jacks
14 Video / Audio 3 Input Jacks
15 Video / Audio Output Jacks
16 Component Video Input Jacks (DVD IN)
17
Coaxial cable Connector (75ohm)
21
3
4
5
6
7
8
9
10
11
13 14 15 16
These buttons included with AVM-32F9 only
REAR
17
All manuals and user guides at all-guides.com

7
6
CABLE TV (CATV) CONNECTION
A 75-ohm coaxial cable connector is built into the set for easy hookup
When connecting the 75 ohm coaxial cable to the set, screw the 75-ohm cable to the
COAXIAL CABLE CONNECTOR
Some cable TV companies offer "premium pay channels" Since the signals of these premium
pay channels are scrambled, a cable TV converter/descrambler is generally provided to the
subscriber by the cable TV company This converter/descrambler is necessary for normal
viewing of the scrambled channels (Set your TV to channel 3 or 4, as typically one of these
channels is used If this is unknown, consult your cable TV company One possible method of
utilizing the converter/descrambler provided by your cable TV company is explained below )
"A" position on the RF switch (not supplied)
You can view all unscrambled channels using the TV's channel keys
"B" position on the RF switch (not supplied)
You can view the scrambled channels via the converter/descrambler using the converter's
channel keys
NOTE : An RF switch equipped with position A/B (not provided) is required
Cable TV line
TV OUT IN
Cable TV converter/
descrambler
Two-set
signal
splitter
(not supplied)
RF switch (not supplied)
A
OUT IN
B
ANTENNA CONNECTION
ANTENNA
The antenna requirements for good color television reception are more important than those
for black & white television reception For this reason, a good quality outdoor antenna is
strongly recommended
The following is a brief explanation of the type of connections that are provided with the various
antenna systems:
OUTDOOR ANTENNA CONNECTION
Use one of the following two diagrams if you connect an outdoor antenna
A : Using a VHF/UHF combination outdoor antenna
B : Using separate VHF and/or UHF outdoor antenna
Connect an outdoor antenna cable lead-in to the COAXIAL CABLE CONNECTOR on the rear
of the TV set
1 A 75-ohm system is generally a round cable
with F-type connector that can easily be
attached to a terminal without tools
2 A 300-ohm system is a flat "twin-lead" cable
that can be attached to a 75 ohm terminal
through a 300-75 ohm ADAPTOR
300-ohm twin-lead cable (flat)
VHF/UHF ANTENNA
A. Combination VHF/UHF Antennas
B. Sepa ated VHF/UHF Antennas
VHF ANTENNA UHF ANTENNA
300/75-ohm
ADAPTOR
(not supplied) 300-ohm
twin-lead
300-ohm
twin-lead
300-ohm
twin-lead
75-ohm
coaxial cable
75-ohm coaxial cable
ANT/
CABLE
75Ω
ANT/
CABLE
75Ω
or
IN OUT
VHF/UHF ANTENNA
COMBINER
(not supplied)
REAR OF TV
REAR OF TV
75-ohm coaxial cable (round)
F-type connector
or
All manuals and user guides at all-guides.com

9
8
To view a connected video source, press the TV/VIDEO button on the side of the cabinet or
VIDEO button on the remote control
(2) Side Input Jacks
Please use the side jacks (VIDEO 2) for a GAME-PLAYER or CAMCORDER
To view a connected video source, press VIDEO button to set the TV to the VIDEO 2 mode
(3) Audio System Connecto s
You can hear the TV sound with a better stereo effect connecting the TV to your audio system
The audio signal available at these jacks is the same as the audio source of the program being
monitored on this TV screen
1 Adjust the volume of the TV to minimum
2 Connect the AUDIO OUT jacks on the rear of the set with the AUDIO LINE IN jacks through
an optional AUDIO/VIDEO cable
3 Set the INPUT SELECTION switch on the AMPLIFIER/AUDIO SYSTEM into the AUX
position and adjust the volume
NOTE If you have no "AUX IN" jack on your audio system, connect to CD or Video jacks
SPEAKERS
AMPLIFIER/AUDIO SYSTEM
AUDIO LINE INs
NOTES In the case that sound output of your VCR/VDP is MONO, connect it to "AUDIO IN L
(MONO)" Jack of your TV Then the sound can be heard from both R and L speakers
TO VIDEO OUT
TO AUDIO OUTS
GAME PLAYER
CAMCORDER
VCR or VDP
VIDEO/AUDIO CONNECTIONS
Prior to making any connections to your TV set, be sure to turn the POWER off
For a more detailed understanding of each connection, it is recommended that you read the
instruction manual for each connected component
If you use video or audio equipment placed near the TV, picture and/or sound may become
distorted due to interference between these components
In such case, separate each piece of equipment at a sufficient distance
The following shows examples for connecting external equipment
Do not connect another audio source to the same speaker to which the TV set is connected,
otherwise it may damage the amplifier of the TV set or that of the other audio source
(1) Rea Input Jacks
Please use the rear jacks (A/V IN ) for VCR , VDP or DVD
1 A/V 1 IN jacks
2 S-VHS jack
3 Component Video In jacks
VHF/UHF
OUTPUT
TO VIDEO OUT VCR, VDP or DVD
TO AUDIO OUT
TO VIDEO IN
TO AUDIO IN
VHF/UHF
OUTPUT
TO AUDIO OUT
TO AUDIO IN
VHF/UHF
OUTPUT
TO AUDIO OUT
TO AUDIO IN
VCR, VDP or DVD
VCR, VDP or DVD
NOTE There will be no color in the video signal from the VIDEO OUTPUT jack when the
selected video source is COMPONENT VIDEO IN/OUT (YUV)
TV S-VHS 1 VIDEO 2 VIDEO 3 YUV
All manuals and user guides at all-guides.com

11
10
BASIC MENU OPERATION
1 Press POWER button to turn the TV on
2 Press MENU button and move the cursor to "SETUP" option and press VOL + button
The "SET UP" menu is displayed
3 Press VOL
+ button to select ANTENNA option (TV or CATV)
4 Press CH /buttons to place cursor on the "AUTO PROGRAM " option and press VOL
+
button
5 When you have finished "AUTO PROGRAMMING", press MENU button repeatedly until the
menu disappears
6 Press CH /buttons to select the channel you want
7 Press VOL
+
or VOL - buttons to adjust volume to your desired listening level
AUTOPROGRAMMING
CATV 15
+STOP
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: ENTER :PREV
25%
BASIC OPERATION
FIRST PREPARATIONS
Connect either Antenna or Cable TV according to "ANTENNA CONNECTION"
instructions on page 6
Insert batteries into the remote control unit according to "REMOTE CONTROL USE"
instructions on page 5
Insert the AC Cord Plug into a standard 120V, 60Hz polarized AC outlet
TURN ON/OFF THE TV
1 Press the "POWER" button on the front panel
or on the remote control
2 Press the same button again to turn the
television off
CHANNEL SELECTION
Use CHANNEL ( ) buttons on the remote control (or on the front panel) Press the
button to advance for the higher channels, and the button to go down for the lower channels
Channels can be selected directly by using the number buttons on the remote control
For example, to select channel 5, press "0" first, then press "5"
For channel 120, press the 100 button first, then press "2", then "0"
VOLUME CONTROL
P ess VOLUME
+
/
-
buttons on either the remote control or
front panel to adjust volume to your desired listening level
Pressing the
+ button will increase sound volume, and the - button
will decrease sound volume The volume level is displayed on the
screen with reference number (0-100) and bar scale as shown
NOTE : Certain channels have been preset at the factory It may be necessary to add or
erase some channels in your areas See "AUTO PROGRAMMING" on page 14 for
presetting channels
or
(Front panel)
POWER
POWER
(Remote control)
VOLUME 25
NOTE : The volume level can be muted instantly by pressing MUTE button on the remote
control See "MUTE Button" on page 47
LANGUAGE
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER : EXIT
You can select language among
ENGLISH, SPANISH,
PORTUGUESE and FRENCH by
pressing VOL
+ button
All manuals and user guides at all-guides.com
all-guides.com

13
12
SET-UP
ANTENNA SELECTION
In this mode, you can change the antenna mode between "TV" (If you use a VHF/UHF
antenna) and " CATV " (If you have cable connection )
1 Press MENU button, move the cursor to "SETUP" option and press VOL + button The "SET
UP" menu is displayed
2 Press CH /buttons to place the cursor on the "ANTENNA" option and press VOL +
button
You can select "TV" (on-air) or "CATV" (cable TV) mode
3 When you have finished "ANTENNA" mode selecting, press MENU button repeatedly until the
menus disappear
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SETUP
ANTENNA : TV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
SETUP
ANTENNA : TV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
BASIC MENU OPERATION
You can execute every operation by pressing CH /buttons and VOL
+
/
-
buttons
alternately
If you learn one menu, you can easily operate other functions by viewing pictures
1 Pressing these buttons alternately makes
every operation easy
2 MOVE Press CH / buttons to move
cursor
3 SELECTION Press VOL
+
/
-
buttons to
change your selection
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
CONTRAST : 90
BRIGHT : 50
SHARPNESS : 50
COLOR : 50
TINT : 0
: SEL : ADJ :PREV
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
TIME
CLOCK : AM12:00
TIMER : OFF
ON TIME : AM12:00
OFF TIME : AM12:00
ON CHANNEL: TV 2
: SEL +: ENTER :PREV
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
FUNCTION
BLUEBACK : ON
CCD : CCD1
TILT : 0
BLOCKING
: SEL +: SET :PREV
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: ESPAÑOL
: PORTUGUÊS
: FRANÇAIS
: SEL +: SET :EXIT
All manuals and user guides at all-guides.com

15
14
SET-UP
MANUAL MEMORY (channel add/delete)
1. TO ADD A CHANNEL
If you want to add a channel not store during AUTO PROGRAM to the memorized channel
follow these steps
Select a channel you want to view by using the number buttons on the remote control
Press "ADD/DEL" button on the remote control
The channel is added to memory and the color of the channel number changes from
magenta to green
2. TO DELETE CHANNEL
You can exclude the channels of your choice from the memorized channels
Follow these steps to delete the channel in the TV's memory
Press CH /buttons or use the number buttons to select a channel you want to delete
Press "ADD / DEL" button on the remote control
The channel is removed from the memory and the color of the channel number changes
from green to magenta
2
CATV
2
CATV
CHANNEL ADDING CHANNEL DELETING
COLOR
: GREEN
COLOR
: MAGENTA
SET-UP
AUTO CHANNEL PROGRAMMING
This function allows the channels to be memorized automatically to match the TV broadcasts
and cable channels in your area
1 Press MENU button, move the cursor to "SETUP" option and press VOL + button The "SET
UP" menu is displayed
2 Press CH /buttons to place the cursor on the "AUTO PROGRAM" option and press
VOL + button
When tuned to an active channel in which TV programming is broadcast, this channel is
memorized and the color of the channel number changes from magenta to green
After all active channels are memorized, "SETUP" menu is displayed
3 When you have finished "AUTO PROGRAMMING", press MENU button repeatedly until the
menus disappear
NOTES If the broadcast signal is weak, the channel will not be memorized
If you wish to stop this procedure during the operation, press VOL + button
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SETUP
ANTENNA : CATV2
AUTOPROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: ENTER :PREV
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: ENTER :PREV
AUTOPROGRAMMING
CATV 15
+STOP
25%
All manuals and user guides at all-guides.com

17
16
SET-UP
LNA (Low Noise Amplifie ) EFFECTS
Set LNA ON to increase a weak incoming signal However, if you are located in a strong signal
area, such as nearby a broadcasting station, and if the picture is distorted, set LNA OFF
1 Press CH /buttons or use the number buttons to select a channel you want to adjust
2 Press MENU button, move the cursor to "SETUP" option and press VOL
+
button The "SET
UP" menu is displayed
3 Press CH / buttons to place the cursor on the "LNA" option
4 Press the VOL+ button
Whenever this button is pressed, the mode will change as follows
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : OFF
: SEL +: SET :PREV
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : OFF
: SEL +: SET :PREV
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
: SEL +: SET :PREV
SET-UP
FINE TUNING
If the reception is clear, you do not have to fine-tune the channel, because this is done
automatically during auto program and manual memory
If, however, the signal is weak or distorted, you may have to fine-tune the channel manually
1 Press CH /buttons or use the number buttons to select a channel you want to adjust
2 Press MENU button, move the cursor to "SETUP" option and press VOL
+
button The "SET
UP" menu is displayed
3 Press CH /buttons to place the cursor on the "FINE TUNE" option
4 Use VOL
+
/
-
buttons until you obtain a sharp and clear picture and good sound quality
5 If you wish to memorize the fine-tuned frequency for the channel, press ADD/DEL button The
[ ] symbol (red color) appears to the right of the channel number To delete the memory,
press the same button again The [ ] symbol disappears
NOTES The AFT (Automatic Fine Tuning) mode does not operate on the channels that are
fine-tuned
After the Auto Channel Programming has been performed, memorized channels
are automatically tuned to their optimum frequencies
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
A/D: MEMORY
: SEL : ADJ :PREV
MENU
SOUND
TIME
SET UP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : 0
LNA : ON
A/D: MEMORY
: SEL : ADJ :PREV
SETUP
ANTENNA : CATV2
AUTO PROGRAM
FINE TUNE : +2
LNA : ON
A/D: MEMORY
: SEL +: ADJ :PREV
All manuals and user guides at all-guides.com

19
18
PICTURE ADJUSTMENT
CUSTOM (MANUAL) ADJUSTMENT
You can sequentially select and adjust one of five picture properties
Contrast, Brightness, Sharpness , Color, or Tint
Press the MENU button Move the
cursor to PICTURE by pressing the CH
/buttons and press the VOL +
button
Move the cursor to CONTRAST by
pressing the CH /buttons and
press the VOL
+
/
-
buttons
Adjust "CONTRAST" with VOL
+
/
-
buttons
When you have finished contrast
adjustment, press MENU repeatedly until
the menus disappear
11
11
22
22
33
33
CONTRAST 90
44
44
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE
: SEL +: ENTER :EXIT
CONTRAST : 90
BRIGHT : 50
SHARPNESS : 50
COLOR : 50
TINT : 0
: SEL : ADJ :PREV
PICTURE ADJUSTMENT
P.STD (Pictu e Standa d) BUTTON
By pressing the P STD button on the remote control, you can sequentially select one of four
preset picture standards
(1) CUSTOM mode
(2) STANDARD mode
(3) DYNAMIC mode
(4) MILD mode
MODE PICTURE
CUSTOM Select this mode to use your customized picture setting
See next page
Select this mode to use the
factory-preset standard picture setting
Select this mode
-To emphasize more contrast
-To watch in brighter (daylight) environments
Select this mode
- For soft contrast
- When the room is dark
- To lessen eye fatigue
STANDARD
DYNAMIC
MILD
All manuals and user guides at all-guides.com

21
20
SOUND ADJUSTMENT
USING ON-SCREEN MENU
You can also select a sound setting by using the on-screen menu
Press the MENU button Move the
cursor to SOUND by pressing the CH /
buttons and press the VOL + button
Move the cursor to SOUND by pressing
the CH /buttons
Press the VOL
+ button
Whenever this button is pressed, the
mode will change as follows
11
11
22
22
33
33
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
CUSTOM STANDARD MUSIC MOVIE SPEECH
SOUND
SOUND : MUSIC
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
SOUND ADJUSTMENT
USING S.STD BUTTON
There is a choice of five audio settings By pressing the S STD button, the five settings can be
viewed in the sequence illustrated
1 Press S STD button
Whenever this button is pressed, the mode will change as follows
Select this mode to hear the adjusted sound you want See
EQUALIZER page 22
CUSTOM
Select this mode to use the factory presetting
STANDARD
Select this mode when listening to music
MUSIC
Select this mode when viewing a movie
MOVIE
Select this mode to hear voices clearly
SPEECH
CUSTOM STANDARD MUSIC MOVIE SPEECH
All manuals and user guides at all-guides.com
all-guides.com

23
22
SOUND ADJUSTMENT
HEADPHONES
Follow these instructions to select the audio source (main screen or PIP channel) that you want
to receive through the headphones
If you want to listen to sound from the PIP, make sure that sound from the PIP is being received
Press PIP button to display a PIP
Move the cursor to SOUND by pressing
the CH /buttons and press the
VOL+ button
Move the cusor to HEADPHONE by
pressing the CH /buttons and
press the VOL+ button
11
11
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
PIP
TV 2
AV1
22
22
33
33
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: ENTER :PREV
SOUND ADJUSTMENT
EQUALIZER
You can adjust five frequency ranges to your preference
Press the MENU button Move the
cursor to SOUND by pressing the CH /
buttons and press the VOL + button
Move the cursor to EQUALIZER by
pressing the CH /buttons and
press the VOL+ button
Adjust each frequency band, using
CH /buttons
11
11
22
22
33
33
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: ENTER :PREV
EQUALIZER
50 50 50 50 50
120 500 1 5K 5K 10K
: SEL : ADJ :PREV
All manuals and user guides at all-guides.com

25
24
SOUND ADJUSTMENT
SURROUND SOUND
SOUND MENU
Move the cursor to SOUND by pressing
the CH /buttons and press the
VOL
+ button
Move the cursor to SURROUND by
pressing the CH /buttons
Press the VOL
+ button
Whenever this button is pressed, the mode will change as follows
11
11
22
22
33
33
OFF ON
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
Move the cursor to SELECT by pressing
VOL+ button Each time you press, the
audio source changes between main
picture and PIP
Move the cursor to VOLUME and press
VOL+/- buttons, the headphone sound
level is adjusted
SOUND ADJUSTMENT
44
44
55
55
HEADPHONE
SELECT : MAIN
VOLUME : 30
: SEL +: SET :PREV
HEADPHONE
SELECT : MAIN
VOLUME : 30
: SEL : ADJ :PREV
All manuals and user guides at all-guides.com

27
26
SOUND ADJUSTMENT
MTS
USING SOUND MENU :
Press the MENU button Move the
cursor to SOUND by pressing the CH
/buttons and press the VOL +
button
Move the cursor to MTS by pressing the
CH /buttons
Press the VOL
+ button
Whenever this button is pressed, the mode will change as follows
11
11
22
22
33
33
STEREO SAP MONO
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : STEREO
: SEL +: SET :PREV
SOUND
SOUND : STANDARD
EQUALIZER
HEADPHONE
BALANCE : 0
SURROUND : OFF
MTS : SAP
: SEL +: SET :PREV
SOUND ADJUSTMENT
MTS
USING MTS BUTTON :
Your TV set incorporates an MTS (Multichannel Television Sound) decoder to receive stereo
broadcasts and any accompanying SAP (Second Audio Program) such as another language
sound track)
1 Press the MTS button
Depending on the audio signal type of the currently receiving broadcast, on-screen selection
appears as follows:
The " ", " " symbols indicate that MTS mode is being broadcast
STEREO symbol (RED color)
SAP symbol (RED color)
When the power is switched on or channel is changed, the " ", " " symbols are
automatically displayed, depending on the current
broadcast
NOTES
If the received signal is weak, noise may be heard
In such a case, press MTS button to set to the MONO mode for better sound reception
If the received SAP signal is weak, the SAP will not be heard
Even if both STEREO and SAP broadcasts are received, both broadcasts cannot be
heard at the same time
Transmission of CABLE TV signals may differ from off-air TV broadcasts
TV 2
STEREO SAP MONO
Stereo and SAP
Stereo or SAP
Mono
STEREO MONO/SAP MONO
Receiving signal On-sc een selections
MONO only
All manuals and user guides at all-guides.com

29
28
CLOCK/TIMER
ON/OFF TIMER
The ON/OFF timer lets you use alarm and automatic off functions
Press MENU button
The "MENU" is displayed on the
screen
Move the cursor to TIME by pressing the
CH /buttons and press the VOL +
button
"TIME" menu is displayed on the
screen
Move the cursor to TIMER by using CH
/buttons and press VOL + button
to set TIMER ON The time display
changes to green
NOTES If you have not yet set the television’s clock, the message "CLOCK STOPPED"
is displayed
If this happens, refer to "CLOCK" on previous page
11
11
22
22
33
33
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
TIME
CLOCK : AM 06:00
TIMER : ON
ON TIME : AM 12:00
OFF TIME : AM 12:00
ON CHANNEL : TV 2
: SEL +: SET :PREV
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
GREEN
CLOCK/TIMER
CLOCK
You can set the television’s clock so that the current time will be displayed when you press the
MENU button on the remote control
You must set the current time before you can set the automatic On/Off timer
Press MENU button and move to
"TIME"option by using CH /
buttons
Press VOL + button and press it again
Adjust "HOUR" with CH /buttons
Whenever these buttons are pressed,
the hour indication increases or
decreases by 1
Press VOL + button and adjust
"MINUTE" by using CH /buttons
Whenever these buttons are pressed,
the minute indication increases or
decreases by 1
Press the "MENU"button to return to the
main menu
11
11
22
22
33
33
44
44
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE : ENGLISH
: SEL +: ENTER :EXIT
TIME
CLOCK : AM 12:00
TIMER : OFF
ON TIME : AM 12:00
OFF TIME : AM 12:00
ON CHANNEL : TV 2
: MOVE : ADJ :PREV
WHITE
RED
TIME
CLOCK : AM 06:00
TIMER : OFF
ON TIME : AM 12:00
OFF TIME : AM 12:00
ON CHANNEL : TV 2
: SEL +: ENTER :PREV
GREEN
All manuals and user guides at all-guides.com

31
30
CLOCK/TIMER
ON TIME CHANNEL NUMBER
You can select the channel on which the TV turns on as programmed by ON-TIMER
This function will not work if the TIMER is set to OFF or the current time has not been set
1) Move cursor to ON CHANNEL and
press CH /key
2) Set channel number you want
TIME
CLOCK : AM 06:00
TIMER : ON
ON TIME : AM 07:30
OFF TIME : PM 10:15
ON CHANNEL : TV 2
: SEL +: ENTER :PREV
CLOCK/TIMER
Move the cursor to
ON TIME by using CH
/ buttons and press the VOL +/-
buttons to set the time (Refer to page 28)
Move the cursor to OFF TIME by using CH
/buttons and press the VOL + / -
buttons to set the time
Press "MENU" to return to the main
menu
AUTOMATIC POWER-OFF MODE
If the set is not switched off when the TV station stops broadcasting, it will automatically go to
power-off mode after 15 minutes
44
44
55
55
66
66
NOTES If you set "ON TIME" and "OFF TIME" with the same time, "NOT AVAILABLE"
message will be displayed
If the power is disconnected (in case of a power failure) and reapplied later, the
clock operation must be reset
TIME
CLOCK : AM 06:00
TIMER : ON
ON TIME : AM 07:30
OFF TIME : AM 12:00
ON CHANNEL : TV 2
: SEL +: ENTER :PREV
TIME
CLOCK : AM 12:00
TIMER : ON
ON TIME : AM 07:30
OFF TIME : PM 10:15
ON CHANNEL : TV 2
: SEL +: ENTER :PREV
OTHER FUNCTIONS
1 Press the MENU button Move the cursor to FUNCTION by pressing the CH /buttons
Make a selection by pressing the VOL + button
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE :ENGLISH
: SEL +: ENTER : EXIT
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE :ENGLISH
: SEL +: ENTER :EXIT
FUNCTION
BLUE BACK : OFF
CCD : CCD 1
TILT : 0
BLOCKING
: SEL +: SET :PREV
All manuals and user guides at all-guides.com
all-guides.com

33
32
OTHER FUNCTIONS
BLUE BACKGROUND
When there is no picture signal or the signal is weak, the screen reverts to a solid blue color
Disable this feature to watch very weak signals
CCD (Closed Caption Decode )
You can select closed caption mode
Press CCD button on the remote control to change selections as follows :
TILT COMPENSATION
If you notice a slight tilt of the picture (caused by a geomagnetic effect) you can
compensate for it:
TILT TO THE LEFT NORMAL TILT TO THE RIGHT
OFF CCD1 CCD2 TEXT1 TEXT2
* Refer to page 33 (CCD)
FUNCTION
BLUE BACK : OFF
CCD : OFF
TILT : 0
BLOCKING
: SEL +: SET :PREV
FUNCTION
BLUE BACK : ON
CCD : OFF
TILT : 0
BLOCKING
: SEL +: SET :PREV
FUNCTION
BLUE BACK : OFF
CCD : OFF
TILT :
0
BLOCKING
: SEL +: SET :PREV
FUNCTION
BLUE BACK : OFF
CCD : CCD 1
TILT : 0
BLOCKING
: SEL +: SET :PREV
OTHER FUNCTIONS
CCD :
This TV set incorporates a CCD (Closed Caption Decoder) to enable viewing closed captions
and TEXT broadcasts
Closed caption and TEXT each has 2 channels (CH1 & CH2)
Closed caption and TEXT information can only be viewed if they are being broadcast by a
television station, or contained in a videotape or videodisc
Press the CCD button to select CCD mode
CAPTION OPERATION AND CHARACTERISTICS :
After the set is turned on, caption signals will be displayed on screen (if broadcast) in about
10 seconds Once activated, the television will always remain in caption mode unless
deactivated by the CCD button
Captions appear on screen in various positions where they will least interfere with the picture
Generally captions will be displayed at the top or bottom of the screen
It is common to see unusual characters or misspelled words appearing in the caption This is
especially true during a live broadcast as captions are created while the program is in
progress
QUICK VIEW Button : Press Q VIEW button on the remote control The previously viewed
channel will appear on the screen Press Q VIEW again to switch back to the original channel
Repeatedly pressing Q VIEW switches between these two channels
DISPLAY BUTTON : Press DISPLAY button on the remote control The channel number of
the program you are viewing, the TIMER settings and the current time are displayed in sequence
The current time remains displayed on the screen, until DISPLAY button is pressed again
MUTE BUTTON : Press MUTE button on the remote control The sound of the TV program
being viewed will be reduced to zero and "MUTE" will appear on the screen
To restore normal sound, press MUTE again
WIDE BUTTON : This function lets you select between wide and normal screens
Wide 16 : 9
Normal 4 : 3
NOTES
When any function is displayed on screen, captions cannot be seen Captions will reappear
after display disappears
Errors will occur in captioning if the signal is weak or the videotape/videodisc is poorly recorded
A videotape that has been recorded over numerous times can also cause caption malfunction
NOTE : Changing the audio volume also restores the sound
OFF CCD1 CCD2 TEXT1 TEXT2
Press VOL+ to tilt to the left
Press VOL- to tilt to the right
All manuals and user guides at all-guides.com

35
34
In this mode, you can enjoy viewing two programs at the same time
PIP
PIP SIZE
PIP POSITION
PIP SWAP WITH MAIN SCREEN
MAIN
PIP
Press PIP on the remote control When it is ON, the PIP
screen appears in the lower right corner
Press PIP again
to clear the PIP screen from the main screen
1/9
PIP PIP
PIP PIP
Press SIZE to increase or decrease the PIP
screen size
Press POSITION Key on the remote control unit
and the position of PIP changes as shown
1/4
MAIN
PIP
Press SWAP to replace main screen with PIP
contents
PICTURE-IN-PICTURE (PIP) AVM-32F9 ONLY
PIP
STILL
MONITORING AV on PIP
STROBE
AV
STILL
Press STROBE for frame by frame movement
1) PIP is divided into 9 screens, and each displays
the movement one frame per second
(eg ) If you want to take a close look at the batting
form of a baseball player, press STROBE
Nine PIP screens will display the movement
frame by frame in one second intervals
2) Press STROBE or PIP to clear the function
Press STILL to freeze-frame the picture
Press STILL again to resume normal PIP screen
1) Press PIP
2) Press VIDEO to monitor AV source sequentially
TV AV 1 AV 2 AV 3
PICTURE-IN-PICTURE (PIP) AVM-32F9 ONLY
NOTE
PIP can not function when blocking is on
NOTE
Your TV set must be connected to a VCR for PIP to function
All manuals and user guides at all-guides.com

37
36
V-CHIP OPERATION
CALLING UP THE BLOCKING MENU WITH YOUR ACCESS CODE
1 Press the MENU button to display the MAIN MENU
2 Use the CHANNEL /buttons move the cursor to FUNCTION
3 Use the CHANNEL /buttons to move the cursor to BLOCKING
4 Press the VOLUME + button
5 The ACCESS CODE screen will appear
6 Enter the 4-button ACCESS CODE you have chosen As you
press each button, an asterisk (*) will appear on the screen
For initial set-up, use the factory preset ACCESS CODE:
VOL +, VOL +, VOL +, VOL +
7 As soon as you press the 4th button the BLOCKING menu
appears on the screen
MENU
SOUND
TIME
SETUP
FUNCTION
LANGUAGE :ENGLISH
: SEL +: ENTER :EXIT
ENTER ACCESS CODE
----
FUNCTION
BLUE BACK : OFF
CCD : OFF
TILT :
0
BLOCKING
: SEL +: SET :PREV
BLOCKING
MOTION PICTURE
TV PARENTAL GUIDE
CANADIAN ENGLISH
CANADIAN FRENCH
BLOCK : OFF
CHANGE CODE
: SEL +: SET :PREV
V-CHIP OPERATION
WHAT IS THE V-CHIP?
The V-CHIP is a microprocessor control circuit which recognizes TV and Motion Picture Ratings
These ratings are contained in a special electronic identification signal that is part of many television
programs and recorded videotapes
An on-screen menu allows the parent to set a secret 4-key combination ACCESS CODE and choose
which programs are suitable for viewing, and which programs should be blocked
(Please note that we have set an initial ACCESS CODE at the factory This initial code is VOL +, VOL
+, VOL + VOL +)
Once set, the television will only display those programs whose ratings fall within the standards the
parent has chosen Programs which do not fall within the standards the parent has chosen will not be
displayed unless the access code is entered
Some TV programs and movies may not be compatible with V-chip ratings
GENERAL PROCEDURE
As shipped from the factory, the V-CHIP is not operational until you perform these procedures :
Enter your 4-key ACCESS CODE to bring up the BLOCKING MENU
For initial setup, we strongly recommend that you use the factory preset ACCESS CODE of
VOL +, VOL +, VOL + VOL + Instructions on changing the ACCESS CODE are at the end of this
section
Enable Motion Picture rating and choose the Motion Picture Ratings which you wish to block
Enable TV Parental Guide Ratings and choose the TV Parental Guide Ratings which you wish to
block
IMPORTANT NOTICE - READ BEFORE PROCEEDING FURTHER
We urge you to read the entire V-CHIP section of this manual and make sure you understand it
throughly before proceeding further
Once chosen and enabled, programs whose ratings have been blocked CANNOT be viewed
unless you enter the 4 button key combination ACCESS CODE
If you forget the Access Code, the only way that you can clear the settings is by bringing the
television to an Authorized Service Center This is NOT covered under the warranty
PLEASE NOTE THAT THE INITIAL V-CHIP ACCESS CODE AS SHIPPED FROM OUR
FACTORY IS VOL +, VOL +, VOL +, VOL + (Press the VOL + button 4 times)
All manuals and user guides at all-guides.com

39
38
MOTION PICTURE RATING.
39
RATING REMARKS
N/A (No rating) Not rated or not applicable program movie
has not been rated or ratings do not apply
G (General audience) All ages admitted
PG (Parental guidance suggested) Some material may not be suitable for
children
PG-13 (Parents strongly cautioned) Some material may be inappropriate for
children under 13
R (Restricted) Under 17 requires accompanying
parent or adult guardian
NC-17 (No one 17 and under admitted)
X (Adults only)
NOTE
You do not need to block each MOTION PICTURE rating individually
For example, if you block movies with an R (restricted) rating, the V-chip will
automatically block NC-17 and X rated movies
In the same manner, passing (unblocking) the PG-13 rating would automatically
pass PG and G rated movies
V-CHIP OPERATION
MOTION PICTURE RATING
This procedure allows parents to block programs which contain MOTION PICTURE
ratings that they consider inappropriate see next page for Motion Picture ratings
1 Press VOL +, CH /button and select the rating which you wish to block
2 Press VOL + button
VIEW (yellow) changes to LOCK (red)
3 To change the rating, press CH /button and select N/A, and then press VOL+
button
V-CHIP OPERATION
38
MOTION PICTURE
N/A
GVIEW
PG VIEW
PG-13 VIEW
RVIEW
NC-17 VIEW
XVIEW
: SEL +: SET :PREV
All manuals and user guides at all-guides.com
