SERVICE MANUAL Colour Television
Product Code: 111337812
Original Version
Chassis Series: LA5-A
F5TP
FILE NO.
Model No. C20LB88B
Service Ref. No. C20LB88B-00
(Argentina)
Give complete “SERVICE REF. NO.” for parts
order or servicing. It is shown on the rating
plate at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television trans-
mission system and power source differ from
the design specifications.Refer to the specifi-
cation table.
Specifications
Power Source . . . . . . . . .AC220V, 50Hz / 60Hz
Receiving System . . . . . .PAL (M/M, N/N), NTSC (M/M)
Channel Coverage
Antenna mode VHF: CH02-CH13, UHF: CH14-CH69
CATV mode VHF band: CH01-CH13, Mid band: CH14-CH22
Super band: CH23-CH36, Hyper band: CH37-CH64
Ultra band: CH65-CH94 and CH100-CH125
Low mid band: CH95-CH99
Video IF . . . . . . . . . . . . . 45.75MHz
Aerial Input Impedance . . 75Ω
Ext.Terminals
Video inputs: Phono jack ✕2 (1Vp - p, 75Ω)
Audio inputs: Phono jack ✕2 (436mVrms, more than 40KΩ)
Sound Output (RMS) . . . . 2W
Speakers . . . . . . . . . . . 5 cm x 9 cm x 2 pcs.
Dimensions . . . . . . . . . 496 (W) ✕464 (H) ✕472 (D)mm
Weight . . . . . . . . . . . . . approx. 16.7 Kg
Specifications subject to change without notice.
VIDEO AUDIO MENU CH
- VOL +

Contents
-2-
Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chassis Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
IC Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Service Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Purity and Convergence Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cabinet Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chassis Electrical Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-23
Safety Notice
SAFETY PRECAUTIONS
1: An isolation transformer should be connected in the
power line between the receiver and the AC line
when a service is performed on the primary of the
converter transformer of the set.
2: Comply with all caution and safety-related notes pro-
vided on the cabinet back, inside the cabinet, on the
chassis or the picture tube.
3: When replacing a chassis in the cabinet, always be
certain that all the protective devices are installed
properly, such as, control knobs, adjustment covers
or shields, barriers, isolation resistor-capacitor net-
works etc.. Before returning any television to the
customer, the service technician must be sure that
it is completely safe to operate without danger of
electrical shock.
X-RADIATION PRECAUTION
The primary source of X-RADIATION in television receiver is the picture tube.The picture tube is specially con-
structed to limit X-RADIATION emissions.For continued X-RADIATION protection, the replacement tube must be
the same type as the original including suffix letter. Excessive high voltage may produce potentially hazardous X
- RADIATION.To avoid such hazards, the high voltage must be maintained within specified limit.Refer to this ser-
vice manual, high voltage adjustment for specific high voltage limit. If high voltage exceeds specified limits, take
necessary corrective action. Carefully follow the instructions for + B1 volt power supply adjustment, and high volt-
age check to maintain the high voltage within the specified limits.
PRODUCT SAFETY NOTICE
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by mark in the parts list and the schematic diagram designate components in which
safety can be of special significance. It is particularly recommended that only parts designated on the parts list
in this manual be used for component replacement designated by mark . No deviations from resistance
wattage or voltage ratings may be made for replacement items designated by mark .

Chassis Block Diagrams
-3-
T611B
Q432
IC501
LA78040
VERT-OUT
T471
HV
IC802
IC801
CPU
QXXAVC479P
56
34
TUNER SAW IC201
LA76818AM
AUDIO
IC001
SDA SCL
ON-TIME STANDBY
R G B
BLK
OSD
32
31
19 20
21 22
SDA SCL
1
2
X161
A101
ANT
IF IN
5/6
SCL
SDA
R
G
B
BLK
12 11 14 15 16 17 42
EXT VIDEO IN
K1001 K1002
REAR AVIN FRONT AVIN
VIDEO VIDEO
A-L A-L
19 20
21
R G
B
7
AC
POWER
CIRCUIT
CONVERTER
TRANS
130V(MAIN HIGH)
20V(AUDIO)
12V(MAIN LOW)
24V(VERT)
9V IC202
REG.IC
5V-2
REG.IC
IC681
5VRC
2723
HORIZ-OUT
FBT
VERT.OUT
HORIZ.OUT
EXT AUDIO IN
AMP
LA4266_2W
1
AUDIO OUTPUT
51
5
Q900 CRT
IF/VIDEO/CHROMA/DEFLECTION
(WITH PLL)
FILTER
MEMORY
IIC BUS CONTROL
15
C-CAPTION IN
40
SELECTED VIDEO OUT
MAIN SIGNAL PROCESSING CIRCUIT

Chassis Block Diagrams
-4-
SYSTEM CONTROL
QXXAVC479P
15
C-CAPTION IN
IC001
*Stereo Model
only

IC Block Diagrams
-5-
IC201 < IF/Video/Chroma/Def. > LA76818A
1
DC
VOL
SW
FM
DET
23456
IF
AGC
RF
AGC
VIF
7
8910
IF
VCC 5V 11 12 13
BUS
PEAKING
CORING BLACK
STRETCH
SYNC
SEP
14 15
ABL
DC
REST
CLAMP
OSD
CONTRAST
BRIGHT
16 17 18 19 20
CONTRAST
BRIGHT RGB
MATRIX
OSD
SW
DRIVE/OUT-OFF
VCC 21 22 23
FSC/
SYNC SW
24 25 26 27
VER
RAMP HOR
VCCH
VCC
VER
C/D
HOR
OUT
PHASE
SHIFTER
AFC2
AFC1
VER
SEP
HOR
C/D
1/256
COLOR
CLAMP
LPF
ALC
+
SW
CLAMP
DEMO
PAL
SW
ACC
BPF
ON/OFF
DELAY
LINE
SW
TRAP
AFT
VIDEO
DET
TRAP
LIM
AMP
BPF
SPLL
BPF
VIDEO
AMP IF
IDENT VIDEO
SW APC1 TINT
VXO DDS APC2 DC ADS.
CLAMP
VCO
1H DELAY
HOR
VCO
FBP
2829
30
31
32 1H
VCC
33
34
353637
38
39
40
41
42
CLMP
43
4445
CLMP
V/C VCC
5V
46
47
48
4950
A2C
PLL
51
525354
Audio Output
FM Output/Selected
Audio Output
PIF AGC
RF AGC Output
PIF Input1
PIF Input 2
IF Ground
IF Vcc
FM Filter
AFT Output
Bus Data
Bus Clock
ABL
Red Input
Green Input
Blue Input
Fast Blanking Input
RGB Vcc
Red Output
Green Output
Blue Output
fsc output or C
Sync output
Vertical Output
Ramp ALC Filter
Horizontal/BUS Vcc
Horizontal Output
Horizontal AFC Filter
Flyback Pulse Input
VCO IREF
Clock (4MHz) Outupt
CCD Vcc
CCD Filter
CCD/Horizontal Ground
SECAM B-Y Input
(Cb Input)
SECAM R-Y Input
(Cr Input)
Chroma APC2 Filter
Clamp Filter
4.43 MHz Crystal
Chroma APC1 Filter
Selected Video Output
Video/Vertical/BUS Ground
External Video Input(Y-IN)
Video/Vertical Vcc
Internal Video Input (S-C IN)
Black Level Detector
Video Output
VCO Filter
VCO Coil 2
VCO Coil 1
APC Filter
Ext. Audio Input
SIF Output
SIF APC Filter
SIF Input

IC Block Diagrams
-6-
IC201 <IF System Block Diagram> LA76818A
11 12
BUS
Interface
SAW 5
6
4
8 7
PIF
In1
PIF
In2
IF In
9V
30K
RF AGC
Out
120K
IF VCC
IF
GND
VIF AMP
VIF 1 VIF 2 VIF 3
IF AGC
Drive
RF
AGC 2ndIF
AGC
RF AGC
Delay
6bit
IF AGC
Def
1bit
+
-
(6 Vcc)/7
To
BUS
3
0.022u PIF
AGC
IF
AGC
Data Clock
APC
Det
+π/4
-π/4
Snd
Det Amp
52
SIF.Out
Sound
Trap
Video
Det
Buzz
Canceller
50 APC
Filter
330
0.47u +
PLL Pull-in SW
To
BUS
Lock
Det
Video.Level
3bit
Amp
54
10p SIF.In
Sound
BPF
VCO.Coil
VCO
COIL1 VCO
COIL2
48 49
VIF
VCO Chroma
Counter
B/N INV IF
Ident
OSC
C/D
Amp
SIF. Sys
2bit pre-
scaller
SIF
VCO
500K
BPF
SIF
APC
Filter
1K
0.01u 1000p
53 LIM
AMP FM
Det
FM.Level
5bit
Chroma
C/D
APC
Det
500K
Det
To
BUS
Chroma
VCO
VIF
Counter
Reset
Pulse
VCO
Ident
VIF.Sys
2bit Phase
Detector
A.MUTE
1bit VOLUME
D/A
VOLUME
Filter
A.SW
1bit
Input
Select VOLUME
(ATT)
-
+
-
+
2.5V
Amp
FM Gain
1bit Deem-TC
1bit
De-
emph
FM Mute
1 bit
2
9
46
51
1
A.Fil.Def
1bit
VOLUME
7bit
47
VCO
Alignment
AFT 10 AFT
Vcc
100K
100K
0.1u
VCO
Filter
+
0.47u
Audio.out
+
Audio in
10u
Video
Out
FM
Filter
+
1u
FM
Out
0.01u
+
to BUS Line
+

IC Block Diagrams
-7-
IC001 < Audio AMP. > LA42052-E
123
PRE
GND
46789
NC
10
AMP
5
POWER
GND
NC FILTER NC
VCC
INPUT OUT
PUT
NFL
30KΩ
300Ω
Thermal
Protection
-
+AMP
Pump
Up
1
INVERTING INPUT
2
Vcc
3
PUMP UP OUT
4
GND
5
Ver. OUTPUT
6
OUTPUT STAGE Vcc
7
NON INV. INPUT
IC501 < Vertical Output > LA78040N, TDA9302H

MENU CH
- VOL +
-8-
Service Adjustments
S1.00110000 S2.11111000
ADDRESS DATA
02 H-PHA 08
Item No. Item Data value
General
This set has an On-screen Service Menu system includ-
ed in the CPU thar allows remote operation for most of
the service adjustments.
Service Adjustment-1
1. Enter the Service Menu
While pressing the MENU button on the televi-
sion, press the Number Key 2on the remote control
unit.The Service Menu now appear.
2. Service Adjustments:
Press the CHANNEL UP or CHANNEL DOWN
button on the remote control handset to select the
desired service menu item you want to adjust.
Use the VOLUME + or - to adjust the data.The + or
- button will increase or decrease the data
sequentially.
3. Exit from the Service Menu
Press the MENU button to turn off the Service Menu
display.
The data which is set in the service mode is stored
into the memory IC automatically.
[ Service Mode Display ]
MENU
[ Entering the Service Menu ]
VOLUME +
VOLUME -
CHANNEL UP
CHANNEL DOWN
[ Service Adjustment ]
[ Exit from the Service Menu ]
MENU

-9-
Service Adjustments
No. Item Initial value Range Description
01 RFAGC 06 00~63 RF AGC adjustment
02 H-PHA 08 00~31 H-PHASE adjustment (50Hz)
03 V-POS 32 00~63 Vertical position adjustment (50Hz)
04 V-SIZ 54 00~127 Vertical size adjustment (50Hz)
05 V-SCO 17 00~31 Vertical-S compensation (50Hz)
06 VLIN 15 00~31 Vertical linearity adjustment (50Hz)
07 H-P60 +4 -16~+15 Difference value of H-PHASE adjustment (60Hz)
08 V-P60 0 -32~+31 Difference value of V-POSITION adjustment (60Hz)
09 V-S60 +1 -64~+63 Difference value of V-SIZE adjustment (60Hz)
10 VSC60 0 -16~+15 Difference value of Vertical-S compensation (60Hz)
11 VLI60 +1 -16~+15 Difference value of Vertical linearity adjustment (60Hz)
12 OSDHP 30 01~255 OSD horizontal remark position
13 OSDC 50 00~127 OSD contrast
14 V-SCP 07 00~07 V-SIZE COMP (50Hz)
15 SBIAS 70 00~127 Sub Bias adjustment
16 RBIAS 00 00~255 Red Bias adjustment
17 GBIAS 00 00~255 Green Bias adjustment
18 BBIAS 00 00~255 Blue Bias adjustment
19 RDRIV 63 00~127 Red Drive adjustment
20 GDRIV 07 00~15 Green Drive adjustment
21 BDRIV 63 00~127 Blue Drive adjustment
22
-- -- -- White balance (a lateral line)
23 DRV
-- -- Brightness and dark of White balance adjustment
24 B-YD 10 00~15 B-Y DC Level
25 R-YD 10 00~15 R-Y DC Level
26 B-YND 0 -16~+15 Difference value of NTSC B-Y DC Level
27 R-YND 0 -16~+15 Difference value of NTSC R-Y DC Level
28 G-YA 00 00,01 G-Y Angle
29 RBGB 08 00~15 R-Y/B-Y Gain Balance
30 RBAG 08 00~15 R-Y/B-Y Angle
31 G-YAN 00 00,01 Difference value of NTSC G-Y Angle
32 RBGBN 0 -8~+7 Difference value of NTSC R-Y/B-Y Gain Balance
33 RBABN 0 -8~+7 Difference value of NTSC R-Y/B-Y Angle
34 COGV 01 00~03 Coring gain
35 BLK 03 00~03 BLK. STR. Start (W/Defeat)
36 BLKG 03 00~03 BLK. STR. Gain
37 BRTA 00 00, 01 BRT. ABL Defeat
38 BRST 00 00, 01 Mid. Stp. Defeat
39 BRTH 00 00~07 Bright. ABL.Threshold
40 WPL 00 00~03 WPL Ope. Point (W/Defeat)
41 YGAM 00 00~03 Y Gamma Start
42 PORW 00 00, 01 AV Mode Pre/Over SW
43 PORS 02 00~03 AV Mode Pre/Over-shoot adjustment
44 RFCO 0 00~03 Difference Value of RF Corring Gain
45 PORWN 01 00, 01 RF Pre/Over SW
46 PORSN 03 00~03 RF Pre/Over-shoot adjustment
47 TINT 0 -16~+15 Tint
48 SHRF 0 -16~+15 Difference Value of RF Sharpness
49 TEXC 08 00~127 OSD Text Contrast
50 AUFL 00 00, 01 Auto. Fresh
On-screen Service Menu
Following table shows the initial values which have been stored in the CPU ROM, and items for the service
adjustments.
To be continued.

-10-
Service Adjustments
Important Notice:
Do not attempt to adjust service adjustments not listed on below otherwise it may cause loss of performance and for
correct operation.
No. Item Initial value Range Description
51 COOP 07 00~07 Colour Killer
52 Y-APF 01 00, 01 Y-APF Select
53 DEEM 00 00, 01 De-emphasis TC
54 V-LVL 04 00~07 Video Level
55 FMLVL 16 00~31 FM Level
56 TTEST 00 00~07 Trap Test
57 IFOM-S 00 00, 01 Over Mod. SW
58 IFMN-S 00 00, 01 Audio Monitor SW, Monitor/FM
59 IFTRPS 01 00, 01 IC Built-in SIF Trap ON/OFF
60 IFMLVL 136 00~255 Video Level Coarse Adjustment & Mod. Operating Dot Setting
61 VBSW 00 00, 01 VBLK SW
62 FBTS 00 00, 01 FBP Blanking SW
63 HBLKL 06 00~07 H-Blanking Control Left
64 HBLKR 04 00~07 H-Blanking Control Right
65 AFCRF 00 00, 01 Adjustment of AFC Gain & Gate (RF)
66 VSURF 00 00, 01 Adjustment of Vertical Sync. Separation Sensitivity (RF)
67 CDMRF 00 00~07 Vertical Count Down Loop Adjustment (RF)
68 AFCAV 00 00, 01 Adjustment of AFC Gain & Gate (AV)
69 VSUAV 00 00, 01 Adjustment of Vertical Sync. Separation Sensitivity (AV)
70 CDMAV 00 00~07 Vertical Count Down Loop Adjustment (AV)
71 HLK-T 00 00, 01 H-lock, V-Det. (RF)
72 HLK-V 00 00, 01 H-lock, V-Det. (AV)
73 VCO-SW 00 00, 01 C. VCO Adjustment SW
74 VCOADJ 03 00~03 C. VCO Adjustment
75 GRAY 00 00, 01 Gray Mode
76 CROSS 00 00~03 Cross Black/White
77 HL-SW 01 00, 01 Half Tone ON/OFF
78 HL-TON 00 00~03 Half Tone Level
79 AVNCON 64 00~127 Contrast (No Signal in AV)
80 AVNBRI 64 00~127 Brightness (No Signal in AV)
81 POMT 12 00~127 Power Mute Time
82 CHMT 12 00~31 Channel Mute Time
83 SYST 03 00~255 System-N
84 RELAY 80 00~255 Power Relay Time
85 CCD 31 00~31 Horizontal Remark Position Compensation Register
86 TVAVTM 00 00~255 AV/TV Mute Time

-11-
Service Adjustments
NOTE: Do not attempt this adjustment with weak signal.
(1)Tune the receiver to most clearest (or strongest) VHF
station in your area. Set the brightness and contrast
controls to maximum. Set the colour control to mini-
mum.
(2)Select Item No. 01 [RFAGC] in the service mode.
(3)Change value until the snow noise just disappears.
(4)Exit from the service mode.
(1)Receive a monochrome circular pattern.
(2)Set the brightness and contrast to normal.
(3) Select Item No. 02 [H-PHA] in the service mode.
(4)Change value to be optimum horizontal centre position.
(5)Exit from the service mode.
(1)Receive a monochrome circular pattern.
(2)Set the brightness and contrast to maximum.
(3) Select Item No. 03 [V-POS] in the service mode.
(4)Change value to be optimum vertical centre position.
(5)Exit from the service mode.
(1)Receive a monochrome circular pattern.
(2)Set the brightness and contrast to maximum.
(3) Select Item No. 04 [V-SIZ] in the service mode.
(4)Change value to be optimum vertical size.
(5)Exit from the service mode.
(1)Receive a monochrome circular pattern.
(2)Set the brightness and contrast to normal.
(3) Select Item No. 12 [OSDHP] in the service mode.
(4)Change value to be proper OSD position.
(5)Exit from the service mode.
(1) Switch on the TV.
(2) Select Item No. 65 [AFCRF] in service mode.
(3) Change data value to “01”.
(4) Exit from the service mode.
(1) Tune receiver to a caption channel.
(2) Check that CAPTION position is in the horizontal
center of the screen. If CAPTION center is too right or
left, perform steps 3-6. (See figure below.)
(3) Select Item No. 85 [CCD] in the service mode.
(4) Adjust data with + or - key for proper horizontal center.
(5) Exit from the service mode
±Item 85 [CCD] CAPTION H-POSITION ADJ.
±Item 65 [AFCRF] AFC GAIN
Item 12 [OSDHP] OSD POSITION
Item 04 [V-SIZ] VERTICAL SIZE
Item 03 [V-POS] VERTICAL CENTRE
Item 02 [H-PHA] HORIZONTAL CENTRE
Item 01 [RFAGC] AGC
Horizontal centre
Vertical centre
Vertical size
XXX XXXX XXXX XXX
AB
Caption H-position Adj.
A=B

-12-
(1)Receive a monochrome circular pattern.
(2)Set the brightness and colour to normal, contrast to maximum.
(3)Enter to the service mode.
(4)Set each value of Item-16 RBIAS, 17 GBIAS, 18 BBIAS mode to 00. Set each value of Item-19 RDRIV, 21 BDRIV
mode to 63, 20 GDRIV to 07.
(5)Select Item-22 mode to be one horizontal scanning line and turn the screen volume on the FBT to obtain just visible
one coloured line.
(6)Press the 1 (Red Bias +), 4 (Red Bias
- ), 2 (Green Bias +), 5 (Green Bias - ), 3 (Blue Bias +) or 6 (Blue Bias - )
button to adjust the brightness of each colour until a dim white line produced. Please see the control button alloca-
tions in this mode.
(7)Select Item-23 DRV mode to enter the white balance adjusting mode.
(8)Press the 7 (Red Drive +), RECALL (Red Drive - ), 8 (Blue Drive +) or 0 (Blue Drive - ) button alternately to
produce normal black and white picture.
(9)Exit from the service mode.
(10) Check for proper grey scale tracking at all brightness levels.
NOTE: If the grey scale adjustment is made after picture tube replacement, check the high voltage.
Items 16-23 GREY SCALE
Service Adjustments
Red Bias -
Red Bias + Green Bias
-
Blue Bias +
Red Drive +
Blue Drive -
Blue Drive +
Green Bias +
Blue Bias -
Press the MENU button to exit
from service mode
Red Drive
-
E
E
B
33 T471-H1
T471-H2
T471-H4
T471-H5
T471-H6
T471-H7 T471-H10
T471
R449
D485
R488
R423A
C465
R481
C423
C423-H1
C423-H2
C423-H3
D438
C420
C420-H1
C420-H2 C420-H3
C423A
C420B
C424A
C424
D439
C422
C422A
JP436
L432
L431
C425
C425A
KQ
C486
C471
R424
R435
C426
R355
C442A
L442
T431
R434
C433
Q431
R474
R485
R445
C424-H1 C425-H1
C424-H3
C424-H2 C425-H2 C425-H3
KDY-1
C442-
C442-H3
C442-H1
C
L462H2
C432
R433
C420A
C420A-H2
C434
R432
C431
C629
C628
T471-H9
1
4
Q613-H6
KDY
T471A
Q432-H5
Q432-H4
Q432-H7
Q432-H6
Q432-H2
Q432
T471-H8
Q432-H3
Q432-H1
J145
C487
R435H2
R435H1
T431A
R423
C465A
C355
JP488
JP487 JP486 C486A
JP476
R449A
T471-H11
T471-H3
D650
R487
C426A
C420A-H1
TP-B
(FBT)
H-OUT
C
T
MAIN BOARD
SCREEN VR
(Under side)
F.B.T.

Service Adjustments
-13-
FINE TUNING - +
To return to normal TV mode, press the MENU button on
the TV set or remote control handset. (Or will automatical-
ly return to normal TV mode after 5 seconds.)
Fine tuning service mode
Fine tuning data value will be automatically stored in
memory.
Service Adjustment-2
This adjustment is used to do a fine tuning of the channels with poor reception after they have been stored by the
automatic tuning.
This function is available for one channel only and the fine-tuned channel is memorized into IC802 (EEPROM).
FINE TUNING
1. Enter the Service Menu
While pressing the MENU button on the television,
press the “4”or MENU button on the remote control
unit.The Service Menu now appear.
2. Service Adjustments:
Press and hold the VOLUME + or VOLUME
-
button
on the remote control handset or TV set to make fine
tuning adjustment. Press and hold the VOLUME +
button for higher frequency tuning, and press and hold
the VOLUME - for lower frequency tuning.
[ Entering the Service Menu ]
[ Exit from the Service Menu ]
MENU
MENU
VOLUME +
VOLUME -
[ Service Adjustment ]
MENU CH
- VOL +
MENU

VOL + VOL - CH + MENU VOL + VOL - CH + CH -
21
T4AL250V
VOL + VOL - CH + CH - MENU
W601
E
E
E
E
E
12
43
E
E
R/G
1610
71
17
814
PS601A
JP601
RL601
KE-2KE-1
KE
D641
R620
F601A F601B
R602-H1
SW190
SW1902
SW1905 SW1904 SW1903
KH
R602-H4
R602B
R602-H2
R602
R601
L601
C601A
C601
C606
C605
C608
D606
D605
D608
SW601-H4
SW601-H2
KG-1 KG-2
VA601
D607
D1902
J032
C610
R103
435
D
C468
R445
R652
C651
C609
Q612
R643
R642
R641
R624
R623
R622
R619
R616
R614
R613
R611
Q642
Q641
Q625
Q611
D616
C611
R633
C614
D615
D614
R615
D610
L612
D643
D611
L613
R627
D619
R631
D617
L616
R4
R628
R629
C629
C628
D652
C654
R653
C657
R665
R664
C693
Q693
C658
C613
R621 R625
R626
Q613-H6
Q613
C615
L615
R632
L614
R644
C644
C639
C656 L651
L653
C655
D651
D654
R661
C617
J010
J012
D469A
J
C6
J060
J061
J062 J063
J064
C66
J065
D661
R663
R695
L654
Q691
J069
J079
JP652
R662
L601-H2
L601-H1
L601-H4 L601-H3
C609-H1
J142
J009
J144
J14
R435H1
C618
D653
R1907
D1901
C652
R602A
PS601
R602-H3
R602-H5
R602-H6
R602-H7
R602-H8
JP488
R650
D650
D639
R639
C609-H2
A1901
C1902
VR651
J135
T611A
T611B
J165
TP-B
CONVERTER
TRANS.
+B ADJ.
TP +B +130V
E
B
33 T471-H1
T471-H2
T471-H4
T471-H5
T471-H6
T471-H7 T471-H10
T471
D485
R488
R481
C423
C423-H1
C423-H2
C423-H3
D438
C420
C420-H1
C420-H2 C420-H3
C423A
C420B
C424A
C424
D439
C422
C422A
JP436
L431
C425
C425A
KQ
C486
C471
C442A
L442
431
R485
C424-H1 C425-H1
C424-H3 C425-H3
KDY-1
C442-
C442-H3
C442-H1
C
L462H2
C420A
C420A-H2
T471-H9
1
4
KDY
T471A
Q432-H5
Q432-H4
Q432-H2
Q432
T471-H8
Q432-H3
Q432-H1
C487
1A
JP487 JP486 C486A
T471-H11
T471-H3
R487
C420A-H1
(FBT)
H-OUT
C
Service Adjustments
-14-
Service Adjustment-3
Note: +B (+130V) Voltage Check and Grayscale Adjustment
must be completed before attempting HighVoltage Check.
(1)Connect high voltage voltmeter negative lead to
ground, and connect + lead to anode of picture tube.
(2)Tune receiver to an active channel and confirm TV is
operating properly.
(3)The high voltage must be 14”=21KV ± 1KV,
20”/21”=25KV ± 1KV, 29”=26.5KV ± 1KV and less than
14”=25KV, 20”/21”=27.5KV, 29”=29.5KV at 0 beam
current (Brightness and contrast minimum setting).
Note: If the picture tube is replaced, check the high
voltage.The horiz. width adjustment affects the high
voltage.Therefore, re-check the high voltage.
HIGH VOLTAGE CHECK
(1)Receive the monochrome circular pattern.
(2)Set the brightness to normal and contrast to maximum.
(3)Adjust the focus control on the F.B.T. for the best focus
on the screen centre.
FOCUS ADJUSTMENT
FOCUS VR (Upper side)
This TV set has a built-in power supply protection circuit.
It is provided to protect the TV set in case of a power
supply circuit malfunctions.When something abnormality
occurs during TV reception, the TV set goes to the stand-
by mode.
When an abnormality occurs during TV reception, it
causes pin 27 of the CPU to go continually Low volt-
age for about one second.The CPU detects that this
has occurred and outputs the signal from pin 31 to
switch off the power supply lines.
Releasing the protective circuit and restor-
ing power supply
To release the protective circuit and restore power supply,
turn the power to the TV set OFF and then ON again via
either the main power switch or the ON-OFF button on the
remote control.This will work only if the power supply trou-
ble was temporary. If there is permanent trouble such as a
damaged circuit, power cannot be restored and the circuit
will have to be repaired.
Protection Circuit
F.B.T.
1. Connect a DC voltmetre to TP-”+B +130V” and the
ground. Set the +B adjustment control (VR651) to
middle range.
2. Set the brightness to normal and contrast to maximum.
3.Tune the receiver to anactive channel and synchronized
picture.
4. Adjust +B voltage to 130± 1.0 volt DC by using VR651.
+B POWER SUPPLY ADJUSTMENT
VR651
TP +B +130V

-15-
Purity and Convergence Adjustment
RED
BLUE
Adjust tabs together to
superimpose red and
blue horizontal line.
Figure- 2 BLUE AND RED LINE MOVEMENT Figure- 3 BLUE/RED AND GREEN MOVEMENT
Adjust tabs together to
superimpose red/blue
and green horizontal
line.
Adjust tabs angle to superimpose
blue and red vertical line. Adjust tabs angle to superimpose red/blue and green vertical line.
GREEN
BLUE / RED
CAUTION:The Convergence and Purity adjustments have been made at the factory. Readjustment
should be made only after picture tube or deflection yoke replacement, following the steps below:
PURITY ADJUSTMENT
1. Demagnetize the picture tube and receiver using an external
degaussing coil. When replacing picture tube or deflection
yoke, mount deflection yoke and purity-convergence magnets
assembly properly, see figures 1 and 4.
2. Turn Red and Blue guns off and provide only Green raster.
Rotate Screen control to fully counterclockwise. Rotate Red
and Blue Bias controls fully counterclockwise. Slowly rotate
Green Bias control clockwise to produce Green raster.
3. Loosen the screw holding the DeflectionYoke and remove the
3 Rubber Wedges, and slide the DeflectionYoke fully forward.
4. Rotate and spread the Tabs of the two Purity Magnets to cen-
tre the vertical green belt in the picture screen. The Purity
Magnets are also adjusted to obtain vertical centring of the
raster.
5. Slowly slide the Deflection Yoke backward until a uniform
green screen is obtained.
6. Check the purity of the red and blue screens for uniformity,
turn off other colours to check this (use bias controls).
Readjust the yoke position if necessary until all screens are
pure.
7. Adjust each Bias control and screen control to obtain white
raster. Refer to Gray Scale Adjustment. If part of the picture
screen is coloured, adjust the DeflectionYoke position forward
or backward slightly.
8. Tighten the mounting screw of the Deflection Yoke. Adjust
Convergence next.
CENTRE CONVERGENCE ADJUSTMENT
1. Use a dot crosshatch pattern signal.
2. Turn Red and Blue guns on and turn off Green gun. Adjust the
angle between the Tabs of the Four Pole Magnet 1 and 2, and
superimpose the Red and Blue vertical lines in the centre area
of the picture screen. Refer to figure 2.
3. Keeping the mutual angle of theTabs of the Four Pole Magnet
turn them together to superimpose the Blue and Red horizon-
tal lines in the centre area of the picture screen. Refer to fig-
ure 2.
4. Turn Green gun on and adjust Six Pole Magnet 3 and 4 that
the Green line superimposed on the Red/Blue lines.
This is the same procedure used in steps 2 and 3.
Refer to figure 3.
OUTER AREA CONVERGENCE ADJUSTMENT
Slightly loosen the screw holding the Deflection Yoke. Adjust the
Deflection Yoke to converge the detail in the outer area (left side
and right side) of the picture screen by orbital movement of the
front of the Yoke, then secure the Deflection Yoke in appropriate
position by putting the wedges as illustrated.Tighten screw hold-
ing the Deflection Yoke.
RUBBER
WEDGE
DEFLECTION YOKE
DEFLECTION YOKE
MOUNTING SCREW
Figure 4. Deflection Yoke Movement
SIX-POLE
MAGNET TABS FOUR-POLE
MAGNET TABS
ANGLE
OF TABS
PURITY
MAGNET
TABS
4
3
2
1
FOCUS GAP
(G3-G4)
Figure 1. Purity and Convergence Magnets
MAGNET TABS
ANGLE OF MAGNET TABS
Figure 5. Adjusting Magnet

VIDEO AUDIO MENU CH
- VOL +
-16-
1 610 269 8923 BUTTON POWER-F5TB
610 252 8725 SPRING-S-S6KL
or 610 270 5591 SPRING-HKG-S6KL
2 610 269 9166 DEC IND-F5TB
3 610 269 8930 BUTTON UNITED-F5TB
4 610 270 7229 CABINET FRONT-F5TC
5 645 040 1107 BADGE,SANYO*53.5X12L53.5
6 610 269 6585 CABINET BACK-F5TB
7 610 315 5197 LABEL RATING-F5TP
8 645 051 8904 ASSY,REMOCON JXMRA
9 610 297 3723 RC-BATTERY LID-JXMRA
10 645 004 3925 ANTENNA CONVERTER
645 005 0251 ANTENNA CONVERTER
610 316 0900 INSTRUCTION MANUAL-F5SM
Key No. Part No. Description Key No. Part No. Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
AUDIO
IN
ANT.75Ω
R
L
VIDEO IN
1
2
6
7
8
9
10
Cabinet Parts List
43
5

-17-
F5TP
OUT OF CIRCUIT BOARD
PICTURE TUBE
Q901 414 010 4604 CRT A48EJN05X101
COIL
L901 652 001 4435 COIL,DEGAUSSING
MISCELLANEOUS
SP901 652 000 0612 SPEAKER,16
652 001 4176 SPEAKER,16
SP902 652 000 0612 SPEAKER,16
652 001 4176 SPEAKER,16
W901 645 037 2490 CORD,POWER-2.4MK-A5102
W902 652 001 4510 ASSY,WIRE GND CONNECTOR F
610 314 1701 ASSY,PWB,MAIN F5TP
1AA0B10E694AA
TRANSISTOR
Q111 405 015 9701 TR 2SC2814-F4-TB
Q171 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q261 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q431 405 018 0507 TR 2SC3332-R
405 018 0606 TR 2SC3332-S
Q432 406 017 1908 TR TT2140LS-YB11
Q527 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q611 405 013 6801 TR 2SC2274-E
405 013 7006 TR 2SC2274-F
Q612 405 006 6504 TR 2SA984-E
405 006 6702 TR 2SA984-F
!
!
!
Chassis Electrical Parts List
Ref. No. Part No. Description Ref. No. Part No. Description
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
!
Note: Parts order must contain Service Ref. No., Part No., and descriptions. The main PCB unit will be supplied without tuner and
flyback transformer. They should be ordered separately.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF F : ±1PF G : ±2pF
R : ±0.25-0pF S : ±0-0.25pF E : +0-1pF
More than 10pF
A : Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H : ±3% J : ±5% K : ±10%
L : ±15% M : ±20% N : ±30%
P : +100-0% Q : +30-10% T : +50-10%
U : +75-10% V : +20-10% W : +100-10%
X : +40-20% Y : +150-10% Z : +80-20%
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC...........Ceramic
MT-PAPER.........Metallized Paper
POLYESTER......Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO..........Polypropylene
MT-POLYPRO....Metallized Polypropylene
COMPO FILM.....Composite film
MT-COMPO........Metallized Composite
STYRENE...........Styrene
TA-SOLID...........Tantalum Solid
AL-SOLID...........Aluminium Solid
ELECT................Electrolytic
NP-ELECT..........Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT..........Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M: ±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE.........Metal Glaze
WIRE WOUND...Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES....Fusible
NOTES:

-18-
F5TP
Q613 405 171 4107 TR 2SK2647
Q625 405 013 6801 TR 2SC2274-E
405 013 7006 TR 2SC2274-F
Q641 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
405 006 1806 TR 2SA933S-R
Q642 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
Q651 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q652 405 089 0000 TR 2SA1707-S
405 089 0109 TR 2SA1707-T
405 009 6907 TR 2SB985-S
405 009 7003 TR 2SB985-T
Q654 405 059 9804 TR 2SD1913-Q-RA
405 059 9903 TR 2SD1913-R-RA
Q661 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q662 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q663 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q681 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
Q693 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2309 TR 2SC1815-Y
405 157 0505 TR 2SC536NF-NPA
405 151 8705 TR 2SC536NG-NPA
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
Q818 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q861 405 134 5905 TR 2SA1037AK-T146-R
405 147 2205 TR 2SA1037AK-S-T146
405 002 0308 TR 2SA1037K T146 R
405 002 0407 TR 2SA1037K T146 S
405 002 6706 TR 2SA1179-M6-TB
405 002 6904 TR 2SA1179-M7-TB
405 163 1503 TR 2SA1179N-M6-TB
405 163 2708 TR 2SA1179N-M7-TB
405 173 9605 TR 2SA1235A1E
405 173 9704 TR 2SA1235A1F
Q871 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q881 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q886 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC001 409 472 4408 IC LA4266
IC201 409 517 5902 IC LA76818A
IC202 409 241 5407 IC BA178M05T
409 265 4806 IC L78M05CV
409 172 1509 IC MC78M05CT
409 320 5700 IC UPC78M05AHF
IC501 409 507 0900 IC LA78040N
409 510 1109 IC TDA9302H
IC681 409 241 5407 IC BA178M05T
409 265 4806 IC L78M05CV
Ref. No. Part No. Description Ref. No. Part No. Description

409 172 1509 IC MC78M05CT
409 320 5700 IC UPC78M05AHF
IC801 410 527 1907 IC LC863440W-53Z0-TLM
IC802 409 495 7004 IC CAT24WC04P
409 470 3403 IC KS24C041C
409 427 4705 IC M24C04-BN6
410 499 0908 IC AT24C04-10PI-2.7
CAPACITOR
C004 404 084 4204 ELECT 4.7U M 50V
C005 404 089 2700 ELECT 100U M 25V
C007 403 342 3300 CERAMIC 0.1U K 25V
C008 403 342 3300 CERAMIC 0.1U K 25V
C031 404 089 2700 ELECT 100U M 25V
C035 403 045 1504 ELECT 1000U M 25V
C041 403 047 5005 ELECT 470U M 25V
C101 403 044 1703 ELECT 470U M 16V
C106 403 051 3103 ELECT 47U M 50V
C107 404 084 4303 ELECT 47U M 50V
403 051 3103 ELECT 47U M 50V
C111 403 215 2201 CERAMIC 0.01U K 50V
C112 403 215 2201 CERAMIC 0.01U K 50V
C113 403 215 2201 CERAMIC 0.01U K 50V
C120 403 224 6603 CERAMIC 0.022U Z 50V
C121 403 215 2201 CERAMIC 0.01U K 50V
C122 403 042 2405 ELECT 100U M 16V
C132 403 048 6308 ELECT 0.47U M 50V
C134 404 084 3900 ELECT 10U M 50V
C135 403 048 6308 ELECT 0.47U M 50V
C138 403 284 4304 CERAMIC 0.022U K 50V
C171 403 155 2101 CERAMIC 1500P K 50V
C172 403 215 2201 CERAMIC 0.01U K 50V
C178 404 084 3801 ELECT 1U M 50V
C1902 403 050 2800 ELECT 22U M 50V
C201 403 086 2300 NP-ELECT 1U M 50V
C202 403 058 2604 POLYESTER 0.015U J 50V
403 179 3207 POLYESTER 0.015U J 50V
C203 403 215 2201 CERAMIC 0.01U K 50V
C204 403 049 4204 ELECT 10U M 50V
C205 403 049 4204 ELECT 10U M 50V
C209 403 048 6308 ELECT 0.47U M 50V
C210 403 047 5005 ELECT 470U M 25V
C212 403 155 4204 CERAMIC 15P J 50V
C221 403 342 3300 CERAMIC 0.1U K 25V
C222 403 342 3300 CERAMIC 0.1U K 25V
C223 403 342 3300 CERAMIC 0.1U K 25V
C224 403 342 3300 CERAMIC 0.1U K 25V
C225 403 049 0008 ELECT 1U M 50V
C226 403 086 2300 NP-ELECT 1U M 50V
C227 403 049 4204 ELECT 10U M 50V
C230 403 215 2201 CERAMIC 0.01U K 50V
C231 403 260 2904 MT-COMPO 0.33U J 50V
C232 403 260 2904 MT-COMPO 0.33U J 50V
C233 403 045 1504 ELECT 1000U M 25V
C240 403 215 2201 CERAMIC 0.01U K 50V
C243 403 215 2201 CERAMIC 0.01U K 50V
C244 403 051 3103 ELECT 47U M 50V
C245 403 086 2300 NP-ELECT 1U M 50V
C246 403 049 0008 ELECT 1U M 50V
C247 403 049 9803 ELECT 2.2U M 50V
C273 403 342 3300 CERAMIC 0.1U K 25V
C352 403 075 6906 CERAMIC 100P K 500V
C358 403 049 0008 ELECT 1U M 50V
C423 404 077 4709 MT-POLYPRO 8000P H 1.5K
403 343 8304 MT-POLYPRO 8000P H 1.5K
C426 403 066 6106 MT-POLYEST 0.47U J 250V
C432 403 075 7101 CERAMIC 1000P K 500V
C433 403 076 3102 CERAMIC 3900P K 500V
C434 403 051 3103 ELECT 47U M 50V
C441 403 346 6901 MT-POLYPRO 0.22U J 250V
C442 403 346 6901 MT-POLYPRO 0.22U J 250V
C469 403 049 4204 ELECT 10U M 50V
C471 404 056 5208 NP-ELECT 2.2U M 100V
404 056 5307 NP-ELECT 2.2U M 100V
404 045 6605 NP-ELECT 2.2U M 50V
C486 403 055 8401 ELECT 22U M 250V
C487 403 076 5304 CERAMIC 680P K 500V
C510 404 084 4204 ELECT 4.7U M 50V
403 051 0607 ELECT 4.7U M 50V
C514 403 049 4204 ELECT 10U M 50V
C515 403 045 9807 ELECT 2200U M 25V
C517 403 053 2104 ELECT 220U M 35V
C518 403 073 3907 CERAMIC 3900P K 50V
C520 403 064 1202 POLYESTER 0.1U K 100V
403 276 9706 POLYESTER 0.1U K 100V
C521 403 054 1502 ELECT 470U M 35V
C524 403 260 2508 MT-COMPO 0.18U J 50V
C527 403 049 4204 ELECT 10U M 50V
C601 404 072 7705 MT-POLYEST 0.068U M 250V
404 079 6503 MT-POLYEST 0.068U M 250V
404 073 7506 MT-POLYEST 0.068U M 275V
404 092 0700 MT-POLYEST 0.068U M 275
C608 403 076 6707 CERAMIC 1000P K 1K
403 312 8205 CERAMIC 1000P K 1K
C609 404 038 1600 ELECT 100U M 400V
404 069 5707 ELECT 100U M 400V
C610 404 073 3904 CERAMIC 1000P K 250V
404 073 2105 CERAMIC 1000P M 250V
404 071 3302 CERAMIC 1000P M 400V
404 086 0907 CERAMIC 1000P M 400V
C611 403 056 9704 POLYESTER 0.01U J 50V
403 178 9309 POLYESTER 0.01U J 50V
C613 403 181 8207 POLYESTER 0.1U K 50V
C614 403 237 7901 MT-COMPO 0.22U J 50V
C615 403 325 5109 CERAMIC 220P K 1K
C617 403 325 5109 CERAMIC 220P K 1K
C618 403 083 8107 POLYPRO 0.01U J 630V
C628 404 073 5106 CERAMIC 470P K 250V
404 073 3300 CERAMIC 470P M 250V
404 071 4507 CERAMIC 470P K 400V
404 087 0302 CERAMIC 470P M 400V
C629 404 073 4505 CERAMIC 2200P K 250V
404 073 2907 CERAMIC 2200P M 250V
404 071 4101 CERAMIC 2200P M 400V
404 084 5904 CERAMIC 2200P M 400V
C639 403 049 0008 ELECT 1U M 50V
C643 403 043 7409 ELECT 3300U M 16V
C644 404 084 4105 ELECT 3.3U M 50V
403 046 1602 ELECT 3.3U M 25V
C651 404 073 9005 ELECT 220U M 160V
C652 404 087 3402 ELECT 1000U M 35V
403 052 8503 ELECT 1000U M 35V
C654 403 045 9807 ELECT 2200U M 25V
C655 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
C656 403 222 1303 CERAMIC 1000P K 1K
403 271 9602 CERAMIC 1000P K 1K
C657 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
C658 403 247 5003 CERAMIC 470P K 1K
403 269 1809 CERAMIC 470P K 1K
C663 404 084 3801 ELECT 1U M 50V
403 049 0008 ELECT 1U M 50V
C664 404 084 2705 ELECT 10U M 16V
!
!
!
-19-
F5TP
Ref. No. Part No. Description Ref. No. Part No. Description

-20-
F5TP
403 041 8804 ELECT 10U M 16V
C665 403 043 0202 ELECT 220U M 16V
C681 403 040 5408 ELECT 2200U M 10V
C691 403 039 6508 ELECT 100U M 10V
C693 403 043 9106 ELECT 47U M 16V
C801 403 155 4204 CERAMIC 15P J 50V
C802 403 157 2505 CERAMIC 27P J 50V
C803 403 215 2201 CERAMIC 0.01U K 50V
C805 403 049 4204 ELECT 10U M 50V
C824 403 342 3300 CERAMIC 0.1U K 25V
C835 403 049 0008 ELECT 1U M 50V
C837 403 145 9905 CERAMIC 22P J 50V
C838 403 145 9905 CERAMIC 22P J 50V
C841 403 145 9905 CERAMIC 22P J 50V
C842 403 145 9905 CERAMIC 22P J 50V
C851 403 157 3106 CERAMIC 56P J 50V
C852 403 157 3106 CERAMIC 56P J 50V
C853 403 157 3106 CERAMIC 56P J 50V
C861 403 049 0008 ELECT 1U M 50V
C862 403 342 3300 CERAMIC 0.1U K 25V
C880 403 155 2200 CERAMIC 3300P K 50V
C891 403 049 0008 ELECT 1U M 50V
C893 403 049 9803 ELECT 2.2U M 50V
C894 403 281 5007 CERAMIC 0.033U K 25V
C896 403 113 3805 CERAMIC 1000P K 50V
RESISTOR
R003 401 027 6905 CARBON 750 JA 1/6W
R005 401 025 1308 CARBON 150 JA 1/6W
R006 401 026 8108 CARBON 4.7 JA 1/6W
R011 401 105 3406 MT-GLAZE 27K JA 1/16W
R041 401 012 5708 CARBON 1K JA 1/4W
R1004 401 027 6608 CARBON 75 JA 1/6W
R1011 401 105 0504 MT-GLAZE 1K JA 1/16W
R1013 401 105 0504 MT-GLAZE 1K JA 1/16W
R1014 401 105 0702 MT-GLAZE 100K JA 1/16W
R103 401 061 8101 OXIDE-MT 39K JA 1W
R106 401 024 6700 CARBON 100 JA 1/6W
R107 401 105 0405 MT-GLAZE 100 JA 1/16W
R108 401 105 2102 MT-GLAZE 18K JA 1/16W
R109 401 105 8203 MT-GLAZE 68K JA 1/16W
R111 401 105 0504 MT-GLAZE 1K JA 1/16W
R112 401 105 6001 MT-GLAZE 5.6K JA 1/16W
R114 401 105 4007 MT-GLAZE 330 JA 1/16W
R115 401 027 2105 CARBON 56 JA 1/6W
R116 401 105 4403 MT-GLAZE 39 JA 1/16W
R130 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R132 401 105 5202 MT-GLAZE 470 JA 1/16W
R140 401 105 5905 MT-GLAZE 560 JA 1/16W
R141 401 105 5905 MT-GLAZE 560 JA 1/16W
R171 401 105 1402 MT-GLAZE 150 JA 1/16W
R172 401 105 4601 MT-GLAZE 3.9K JA 1/16W
R173 401 024 7004 CARBON 1K JA 1/6W
R176 401 105 0603 MT-GLAZE 10K JA 1/16W
R1902 401 105 2102 MT-GLAZE 18K JA 1/16W
R1903 401 105 6605 MT-GLAZE 6.8K JA 1/16W
R1904 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R1905 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R1906 401 105 2805 MT-GLAZE 2.2K JA 1/16W
R1907 401 026 0607 CARBON 270 JA 1/6W
R1908 401 105 0405 MT-GLAZE 100 JA 1/16W
R1910 401 105 0405 MT-GLAZE 100 JA 1/16W
R1911 401 105 5202 MT-GLAZE 470 JA 1/16W
R1912 401 026 9600 CARBON 470 JA 1/6W
R211 401 025 1308 CARBON 150 JA 1/6W
R212 401 105 1402 MT-GLAZE 150 JA 1/16W
R221 401 105 0504 MT-GLAZE 1K JA 1/16W
R222 401 105 0504 MT-GLAZE 1K JA 1/16W
R223 401 105 0504 MT-GLAZE 1K JA 1/16W
R224 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R225 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R226 401 105 3406 MT-GLAZE 27K JA 1/16W
R227 401 105 4205 MT-GLAZE 33K JA 1/16W
R228 401 024 7707 CARBON 100K JA 1/6W
R229 401 105 6704 MT-GLAZE 680K JA 1/16W
R230 401 026 9303 CARBON 47 JA 1/6W
R234 401 105 0900 MT-GLAZE 120 JA 1/16W
R235 401 105 0900 MT-GLAZE 120 JA 1/16W
R236 401 105 0900 MT-GLAZE 120 JA 1/16W
R243 401 068 3703 OXIDE-MT 470 JA 2W
R244 401 105 5400 MT-GLAZE 47K JA 1/16W
R245 401 105 5400 MT-GLAZE 47K JA 1/16W
R263 401 105 0603 MT-GLAZE 10K JA 1/16W
R264 401 024 9008 CARBON 120 JA 1/6W
R265 401 105 3901 MT-GLAZE 33 JA 1/16W
R267 401 026 9600 CARBON 470 JA 1/6W
R271 401 105 0405 MT-GLAZE 100 JA 1/16W
R272 401 105 0405 MT-GLAZE 100 JA 1/16W
R280 401 105 0405 MT-GLAZE 100 JA 1/16W
R286 401 203 9904 MT-GLAZE 4.7K FA 1/16W
R289 401 105 0405 MT-GLAZE 100 JA 1/16W
R291 401 068 1600 OXIDE-MT 4.7 JA 2W
R351 401 105 7404 MT-GLAZE 8.2K JA 1/16W
R352 401 012 7009 CARBON 10K JA 1/4W
R354 401 025 8208 CARBON 22K JA 1/6W
R355 401 013 6407 CARBON 12K JA 1/4W
R356 401 105 0603 MT-GLAZE 10K JA 1/16W
R357 401 025 7805 CARBON 2.2K JA 1/6W
R358 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R423 401 020 2904 CARBON 47K JA 1/4W
R423A 401 022 4104 CARBON 68K JA 1/4W
R424 401 024 7004 CARBON 1K JA 1/6W
R426 401 024 7400 CARBON 10K JA 1/6W
R430 401 105 0504 MT-GLAZE 1K JA 1/16W
R432 401 024 7004 CARBON 1K JA 1/6W
R433 401 058 3706 OXIDE-MT 1K JA 1W
R434 401 059 6706 OXIDE-MT 180 JA 1W
R435 402 069 8704 WIRE WOUND 8.2 KA 7W
402 074 5309 WIRE WOUND 8.2 KA 7W
402 098 0700 WIRE WOUND 8.2 KA 7W
R441 401 064 8702 OXIDE-MT 1K JA 2W
R442 401 062 2306 OXIDE-MT 4.7K JA 1W
R475 401 009 5803 CARBON 330 JA 1/2W
R479 401 105 7404 MT-GLAZE 8.2K JA 1/16W
R481 401 067 2509 OXIDE-MT 3.3 JA 2W
R488 402 079 5106 FUSIBLE RES 2.2 J- 1W
R510 401 024 7400 CARBON 10K JA 1/6W
R511 401 024 7400 CARBON 10K JA 1/6W
R514 401 024 7400 CARBON 10K JA 1/6W
R515 401 024 7400 CARBON 10K JA 1/6W
R516 401 026 1307 CARBON 27K JA 1/6W
R518 401 058 0606 OXIDE-MT 1.8 JA 1W
R519 401 024 5604 CARBON 1 JA 1/6W
R522 401 027 5205 CARBON 680 JA 1/6W
R524 401 066 0308 OXIDE-MT 180 JA 2W
R527 401 027 3003 CARBON 56K JA 1/6W
R529 401 058 9005 OXIDE-MT 1.2K JA 1W
R601 401 008 8607 CARBON 220K JA 1/2W
R602 402 071 1205 WIRE WOUND 3.9 KA 7W
402 072 4304 WIRE WOUND 3.9 KA 7W
402 098 0601 WIRE WOUND 3.9 KA 7W
R611 401 020 0801 CARBON 470 JA 1/4W
R613 402 001 8106 FUSIBLE RES 680 J- 1/4W
R614 401 025 8208 CARBON 22K JA 1/6W
!
!
!
Ref. No. Part No. Description Ref. No. Part No. Description
