Sanyo NET@ DP47460 User manual

Specifications
POWER RATING . . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
221 W (AVG.)
ANTENNA INPUT IMPEDANCE. . . . . . . . . . . . . . . . . 75Ω
UHF/VHF/CATV
DIGITAL
RECEIVING CHANNEL . . . . . . . . . . . . . . . . . 2 - 13 (VHF),
14 - 69 (UHF),
01, 14-94, 95-135 (CATV)
1-135 (DIGITAL)
REMOTE READY. . . . . . . . . 48 KEY REMOTE CONTROL
SOUND OUTPUT. . . . . . . . . . . . . . . . . . . . . . . 10.0 W/CH
INTERMEDIATE FREQUENCY
PICTURE IF CARRIER . . . . . . . . . . . . . . . . . . 45.75MHz
SOUND IF CARRIER . . . . . . . . . . . . . . . . . . . 41.25MHz
COLOR SUB CARRIER . . . . . . . . . . . . . . . . . 42.17MHz
CABINET DIMENSIONS
WIDTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1130mm
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 746mm
DEPTH INCLUDING BASE . . . . . . . . . . . . . . . . 324mm
REFERENCE No. SM780177
DP47460, N8VG, PRODUCT CODE 113024106
FILE NO.
SERVICE MANUAL
Remote Control Digital
Color Television DP47460 (U.S.A.)
(CANADA)
ORIGINAL VERSION
Chassis No. P47460-00
NOTE: Match the Chassis No. on
the unit’s back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit’s, additional Service
Literature is required. You
must refer to “Notices” to the
Original Service Manual
prior to servicing the unit.
Servicing should be performed by only trained and qualified service personnel.
Contents
SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . 2
SERVICE ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . 3
ON-SCREEN SERVICE MENU . . . . . . . . . . . . . . . . . . . . . 4
POWER FAILURE CIRCUIT . . . . . . . . . . . . . . . . . . . . . . . 5
MECHANICAL DISASSEMBLY . . . . . . . . . . . . . . . . . . . . 6
CHASSIS ELECTRICAL PARTS LIST . . . . . . . . . . . . . . . . 8
COMPONENT AND TESTPOINT LOCATIONS . . . . . . 22
BLOCK DIAGRAM POWER LINES. . . . . . . . . . . . . . . . . 26
BLOCK DIAGRAM SIGNAL LINES . . . . . . . . . . . . . . . . 27
120 HZ POWER LINES . . . . . . . . . . . . . . . . . . . . . . . . . . 28
IC BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . 31
TROUBLESHOOTING FLOW CHARTS . . . . . . . . . . . . . 35
CONTROL PORT FUNCTIONS. . . . . . . . . . . . . . . . . . . . 38
MAIN SHEET BLOCK DIAGRAM & PERIPHERICALS. . 40
SCHEMATIC NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
IC, DIODE, AND TRANSISTOR PIN LAYOUTS. . . . . . . 42
PC BOARD CONNECTIONS AND LOCATIONS . . . . . . 43
CAPACITOR AND RESISTOR CODE CHART . . . . . . . . 44
SCHEMATIC DIAGRAMS. . . . . . . . . . . . . . . . . . . . . . . . 45
© Sanyo Manufacturing Corporation 2010

– 2 –
SAFETY PRECAUTIONS
WARNING: The chassis of this receiver has a floating
ground with the potential of one half the AC line voltage in
respect to earth ground. Service should not be attempted by
anyone not familiar with the precautions necessary when
working on this type of equipment.
The following precautions must be observed:
1. An isolation transformer must be connected in the power
line between the receiver and the AC line before any ser-
vice is performed on the receiver.
2. Comply with all caution and safety-related notes provid-
ed inside the cabinet, on the chassis, and on the back.
3. When replacing a chassis in the cabinet, always be certain
that all the protective devices are installed properly, such
as control knobs, adjustment covers, shields and barriers.
4. Before replacing the back cover of the set, thoroughly
inspect the inside of the cabinet to see that no stray parts
or tools have been left inside.
Before returning any television to the customer, the
service technician must perform the following safety
checks to be sure that the unit is completely safe to
operate without danger of electrical shock.
ANTENNA COLD CHECK
Remove AC plug from the 120 VAC outlet and place a
jumper across the two blades. Connect one lead of an ohm-
meter to the jumpered AC plug, and touch the other lead to
each exposed antenna terminal (UHF and VHF antenna ter-
minals). The resistance must measure between 1M ohm and
5.2M ohm. Any resistance value below or above this range
indicates an abnormality which requires corrective action.
LEAKAGE CURRENT CHECK
Plug the AC line cord directly into a 120 VAC outlet. (Do not
use an isolation transformer for this check.) Use an AC volt-
meter, that has 5000 ohms per volt or more sensitivity.
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 μF
150 VAC capacitor, between a known good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of the
cabinet (antennas, handle bracket, metal cabinet, screw
heads, metal overlays, control shafts, etc.). Measure the AC
voltage across the 1500 ohm resistor. The AC voltage
should not exceed 750 mV. A reading exceeding 750 mV
indicates that a dangerous potential exists. The fault must
be located and corrected. Repeat the above test with the
receiver power plug reversed.
NEVER RETURN A RECEIVER TO THE CUSTOMER
WITHOUT TAKING THE NECESSARY CORRECTIVE ACTION.
PRODUCT SAFETY NOTICE
When replacing components in a receiver, always keep in
mind the necessary product safety precautions. Pay special
attention to the replacement of components marked with a
in the parts list and in the schematic diagrams. To ensure
safe product operation, it is necessary to replace those com-
ponents with the exact same PARTS.
SERVICING ELECTROSTATICALLY SENSITIVE DEVICES
Semiconductors (solid-state devices) that can be damaged
by static electricity are referred to as Electrostatically
Sensitive (ES) devices. Examples of typical ES devices are:
Integrated Circuits (IC), Field-Effect Transistors (FET), and
“chip” components. The following techniques should be
observed strictly, to reduce the occurrence of semiconduc-
tor damage due to electrostatic discharge.
1. Immediately prior to handling any semiconductor com-
ponent or an assembly containing a semiconductor
device or devices, discharge the electrostatic buildup on
your body by touching a known earth ground. You may
also obtain and wear a commercially available discharg-
ing wrist strap device.
CAUTION: Be sure to remove the wrist strap before
applying power to any unit being serviced.
2. After removing an ES equipped assembly, place it on a
conductive surface, such as, aluminum foil, to prevent
buildup or exposure to static electricity.
3. Use only grounded-tip soldering irons to solder or unsol-
der ES devices.
4. Use only anti-static solder removal devices. Some suc-
tion-type devices can generate static electricity adequate
to damage ES devices.
5. A replacement ES device will come packaged in protective
material (conductive foam, aluminum foil, or some compa-
rable conductive material). Do Not remove an ES device
from its protective packaging unless you are prepared to
install it immediately.
6. Precisely prior to removing an ES device from its protective
packaging, touch the protective packaging to the chassis or
assembly in which the device will be installed.
CAUTION: Be sure that no power is applied to the chassis
or circuit assembly.
7. Incidental body movements, such as, lifting a foot from
a carpeted floor or the rubbing of fabric together can
generate static electricity sufficient to damage ES devices.
Therefore, minimize all body movements while handling
exposed (unpackaged) ES devices.
SAFETY INSTRUCTIONS

– 3 –
SERVICE ADJUSTMENTS
GENERAL
This set has an On-screen Service Menu system included in
the CPU that allows remote operation for most of the
service adjustments.
ON-SCREEN SERVICE MENU SYSTEM
1. Enter the Service Menu:
•Turn off the receiver and disconnect the AC power
supply.
•While pressing the Volume (––) button on the televi-
sion, reconnect the AC power supply. The Service
Menu will now appear. The remote can now be used
to make adjustments. See Figure 1 below.
2. Service Adjustments:
•Press the Cursor  and key to select the desired
service menu item you want to adjust. See page 4 for
the On-screen Service Menu.
•Use the Cursor or key to adjust the data.
The or key will increase or decrease the data
sequentially.
3. Exit from the Service Menu:
•Press the MENU key to turn off the Service Menu
display.
Figure 1. Service Menu Display
HEX DATA
ITEM NO. TITLE
POWER
INPUT
ENTER
MENU
VOL
CH
POWER
INPUT
ENTER
MENU
VOL
CH
Volume – :Enter Service Menu
Menu:
Exit Service Menu Cursor :
Select Item
Cursor :
Adjust the data

– 4 –
ON-SCREEN SERVICE MENU
Table 1. ON-SCREEN SERVICE MENU
When IC801 (EEPROM) is replaced, check the bus data to confirm they are the same as below. See page 3 for
On-Screen Service Menu access and adjustments.
PROGRAM CODES
The microprocessor used in this model is a multi-purpose type and is used in several different models. To ensure
proper operation and the correct features for your particular model, the program codes must be correct.
Note 1. Option Data 1 (NO. 087 OP1) should be hexadecimal
00. See 087 above. If this program code is wrong the TV will
not operate properly.
Note 2. Option Data 2 (NO. 088 OP2) should be hexadecimal
28. See 088 above. If this program code is wrong the TV will
not operate properly.
No. Title Initial Data Note
1A0 MUTE A0h Audio mute at Power ON
086 VOL 30h Volume setup inspection
087 OP1 00h Option 1 Data (HDMI)
088 OP2 28h Option 2 Data (Display Panel)
101 1R00 00h ROM Correction Data
102 1R01 00h ROM Correction Data
↓↓ ↓ ↓
197 2R47 00h ROM Correction Data
198 2R48 00h ROM Correction Data
• All data except in gray box area is fixed. Do not change for correct operating.
• Data in gray box is initial and can be set according to adjusment information.

– 5 –
POWER FAILURE CIRCUIT
Check the following if the unit is turned off by the power
failure detector.
1. Disconnect the AC power cord (120V AC line) for a short
time.
2. Connect a DC Voltmeter to the circuits shown below.
3. Press the Power key and check for the proper voltage
supplies.
4. If any of these voltages is low, the power failure detec-
tor should turn the unit off within three seconds.
5. Check all circuits shown below.
Note: If power failure is detected 3 times in 15 minutes,
the set will enter the standby mode and cannot be
switched On.To reset the operating programs of the
CPU it is necessary to disconnect the AC cord for a
short time.
CPU (IC800) is programmed so the set will go to standby
mode when there is circuit failure as described below.
(Refer to“Block Diagram Power Lines”.)
This unit is equipped with a Power Failure Detector function
included in the CPU which checks for an abnormal condi-
tion in the chassis power supplies.
If, while the power is on, a failure is caused by any of the
following that results in a low voltage supply, the CPU will
turn the unit off in 1.5 seconds to prevent further damage:
•Failure within the power supply circuits.
•A short circuit in the load side from the supply.
Power Failure: Detected voltage failure for circuit.
(Connected to IC800 pin 48 and pin 23.)
(Normal: High; Failure: Low)
If, while the power is off, the power is switched on and any
of these failures remains uncorrected, the CPU will shut off
the power within three seconds.
48
18
IC800 (SUB-CPU)
23
Power Fail 1
Power On
Power Fail 2
1
Power Board
Main
D1674
K8B
D1660
D1651
D1683
Audio_Pow
13V
120Hz
9V
D1632
D1633
3.3V
D6722
D6721
3.3V
LVDS_Pow
12V 5V
D6791
5V

– 6 –
STAND REMOVAL
Note: Position TV face down on a padded or cushioned
surface to protect the screen and finish.
Remove 4 screws (B: 6x12) to take the stand off.
MECHANICAL DISASSEMBLY
Back Lid
DD
DD
A
CAUTION:
This LCD TV uses several different kinds of screws. Using
the correct screw is necessary to prevent damage. Lead
wires must be redressed to their previous locations after
servicing. The Earth sheet and gasket are provided to pre-
vent interference to other radio and television receivers.
The Earth sheet and gasket should be returned to its previ-
ous position after servicing.
MAIN BOARD REMOVAL
Remove 5 screws (A: 3X6) to take the Main Board off.
120HZ BOARD REMOVAL
Remove 4 screws (C: 3X14) to take the 120Hz board off.
POWER UNIT REMOVAL
Remove 6 screws (C: 3X14) to take the Power Unit off.
BACK LID REMOVAL
1. Remove 4 screws (D: 4x8).
2. Remove 2 screws (A: 3x6) to take the Back Lid off.
BB
Main BoardPower Unit
CA
A
A
A
C
CC
C
C
C
CC
C
A
120Hz Board

– 7 –
BACK CABINET REMOVAL
Remove 12 screws to take the back cabinet off.
(C: 3x14)
ELECTROSTATICALLY SENSITIVE DEVICES
Many solid-state devices (especially Integrated
Circuits) are Electrostatically Sensitive, and, therefore,
require special handling techniques as described
under “Servicing Electrostatically Sensitive Devices,”
on page two in this service literature.
LCD PANEL REMOVAL
Lift up the LCD panel from front cabinet.
SPEAKER REMOVAL
Take off each speaker from front cabinet.
RC LED BOARD REMOVAL
Remove 1 screw (C: 3x14) to take the RC LED board off.
KEY SW BOARD REMOVAL
Remove 1 screw (C:3x14) to take the KEY SW board off.
C
C
C
C
CC CC
CC
CC
C
RC LED Board
Speaker Speaker
C
KEY SW Board

– 8 –
CHASSIS ELECTRICAL PARTS LIST
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS
and PRODUCT SAFETY NOTICE on Page 2.
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACE-
MENT DESIGNATED BY A . NO DEVIATIONS FROM RESISTANCE, WATTAGE, AND VOLTAGE RATINGS MAY
BE MADE FOR REPLACEMENT ITEMS DESIGNATED BY A .
Schematic
Location Part No. Description Schematic
Location Part No. Description
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
CAPACITORS RESISTORS

– 9 –
Schematic
Location Part No. Description
CAPACITORS
C001 CK1H102KLZBNG CERAMIC 1000P K 50V
C002 CK1H102KLZBNG CERAMIC 1000P K 50V
C003 CK1E105KGMBNG CERAMIC 1U K 25V
C004 CK1E105KGMBNG CERAMIC 1U K 25V
C005 CK1H102KLZBNG CERAMIC 1000P K 50V
C006 CK1H102KLZBNG CERAMIC 1000P K 50V
C007 CK1H102KLZBNG CERAMIC 1000P K 50V
C008 CK1H102KLZBNG CERAMIC 1000P K 50V
C009 CK1H104KLZBNG CERAMIC 0.1U K 50V
C010 CK1H104KLZBNG CERAMIC 0.1U K 50V
C011 CK1H104KLZBNG CERAMIC 0.1U K 50V
C012 CK1H104KLZBNG CERAMIC 0.1U K 50V
C013 CK1H104KLZBNG CERAMIC 0.1U K 50V
C014 CK1H104KLZBNG CERAMIC 0.1U K 50V
C015 CK1H104KLZBNG CERAMIC 0.1U K 50V
C016 CK1H104KLZBNG CERAMIC 0.1U K 50V
C017 CEXLB1E102VEN ELECT 1000U M 25V
C018 CC1H331JLZCNG CERAMIC 330P J 50V
C019 CC1H331JLZCNG CERAMIC 330P J 50V
C020 CK1E105KGMBNG CERAMIC 1U K 25V
C021 CK1H104KLZBNG CERAMIC 0.1U K 50V
C022 CK1H104KLZBNG CERAMIC 0.1U K 50V
C023 CK1E105KGMBNG CERAMIC 1U K 25V
C024 CK1H104KLZBNG CERAMIC 0.1U K 50V
C025 CK1H104KLZBNG CERAMIC 0.1U K 50V
C026 CK1H104KLZBNG CERAMIC 0.1U K 50V
C027 CK1H104KLZBNG CERAMIC 0.1U K 50V
C028 CC1H150JLZCNG CERAMIC 15P J 50V
C029 CC1H150JLZCNG CERAMIC 15P J 50V
C031 CC1H681JLZCNG CERAMIC 680P J 50V
C032 CC1H101JLZCNG CERAMIC 100P J 50V
C033 CK1H472KLZBNG CERAMIC 4700P K 50V
C034 CK1H104KLZBNG CERAMIC 0.1U K 50V
C035 CK1H104KLZBNG CERAMIC 0.1U K 50V
C036 CK1E105KGMBNG CERAMIC 1U K 25V
C037 CK1E105KGMBNG CERAMIC 1U K 25V
C039 CK1H104KLZBNG CERAMIC 0.1U K 50V
C040 CK1H104KLZBNG CERAMIC 0.1U K 50V
C041 CK1H104KLZBNG CERAMIC 0.1U K 50V
C042 CK1H104KLZBNG CERAMIC 0.1U K 50V
C600 CE1C101M1WANG ELECT 100U M 16V
C601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C602 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C603 CE1C101M1WANG ELECT 100U M 16V
C604 CK1E105KGMBNG CERAMIC 1U K 25V
C800 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C801 CK1H104KLZBNG CERAMIC 0.1U K 50V
C802 CK1A105KLZBNG CERAMIC 1U K 10V
C803 CK1H104KLZBNG CERAMIC 0.1U K 50V
C806 CE1C221M1WANG ELECT 220U M 16V
C808 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C809 CK1A105KLZBNG CERAMIC 1U K 10V
C813 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C820 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C821 CC1H180JLZCNG CERAMIC 18P J 50V
C822 CC1H220JLZCNG CERAMIC 22P J 50V
C1000 CEXLB1H4R7VDN ELECT 4.7U M 50V
C1002 CK1A105KLZBNG CERAMIC 1U K 10V
C1004 CK1A105KLZBNG CERAMIC 1U K 10V
C1006 CK1A105KLZBNG CERAMIC 1U K 10V
C1009 CK1A105KLZBNG CERAMIC 1U K 10V
C1010 CK1A105KLZBNG CERAMIC 1U K 10V
C1012 CK1A105KLZBNG CERAMIC 1U K 10V
C1014 CK1A105KLZBNG CERAMIC 1U K 10V
C1016 CK1A105KLZBNG CERAMIC 1U K 10V
C1025 CC1H471JLZCNG CERAMIC 470P J 50V
C1034 CC1H101JLZCNG CERAMIC 100P J 50V
C1035 CC1H101JLZCNG CERAMIC 100P J 50V
C1610 CC1H391JLZCNG CERAMIC 390P J 50V
C1611 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1612 CK1E105KGMBNG CERAMIC 1U K 25V
C1613 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1614 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1615 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1616 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1617 CK1H563KLZBNG CERAMIC 0.056U K 50V
C1618 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1619 CK1E105KGMBNG CERAMIC 1U K 25V
C1620 CEXLB1E102VEN ELECT 1000U M 25V
C1621 CK1E105KGMBNG CERAMIC 1U K 25V
C1623 CK1H222KLZBNG CERAMIC 2200P K 50V
C1624 CK1A105KLZBNG CERAMIC 1U K 10V
C1625 CEXLB0J222VEN ELECT 2200U M 6.3V
C1627 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1628 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1629 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1631 CE1C221M1WANG ELECT 220U M 16V
C1632 CK1A105KLZBNG CERAMIC 1U K 10V
C1633 CK1A105KLZBNG CERAMIC 1U K 10V
C1634 CE1C101M1WANG ELECT 100U M 16V
C1636 CE1C221M1WANG ELECT 220U M 16V
C1640 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1642 CK1A105KLZBNG CERAMIC 1U K 10V
C1644 CEXLB0J102VDN ELECT 1000U M 6.3V
C1646 CK1H333KLZBNG CERAMIC 0.033U K 50V
C1648 CK1H472KLZBNG CERAMIC 4700P K 50V
C1649 CK1H472KLZBNG CERAMIC 4700P K 50V
C1650 CK1E105KGMBNG CERAMIC 1U K 25V
C1651 CK1E105KGMBNG CERAMIC 1U K 25V
C1652 CEXLB1C102VDN ELECT 1000U M 16V
C1654 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1655 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1656 CC1H221JLZCNG CERAMIC 220P J 50V
C1658 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C1659 CK1E105KGMBNG CERAMIC 1U K 25V
C1660 CE1C101M1WANG ELECT 100U M 16V
C1661 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1662 CEXLB1E102VEN ELECT 1000U M 25V
C1663 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1664 CE1C101M1WANG ELECT 100U M 16V
C1665 CK1E105KGMBNG CERAMIC 1U K 25V
Schematic
Location Part No. Description

– 10 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C1666 CEXLB0J102VEN ELECT 1000U M 6.3V
C1667 CK1E105KGMBNG CERAMIC 1U K 25V
C1668 CC1H221JLZCNG CERAMIC 220P J 50V
C1669 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1671 CK1E105KGMBNG CERAMIC 1U K 25V
C1672 CEXLB1E102VEN ELECT 1000U M 25V
C1673 CEXLB1V471VEN ELECT 470U M 35V
C1674 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1675 CK1E105KGMBNG CERAMIC 1U K 25V
C1676 CK1H105KGNBNG CERAMIC 1U K 50V
C1679 CC1H221JLZCNG CERAMIC 220P J 50V
C1680 CK1E105KGMBNG CERAMIC 1U K 25V
C1681 CC1H221JLZCNG CERAMIC 220P J 50V
C1693 CK1H102KLZBNG CERAMIC 1000P K 50V
C1700 CEXLB1V471VDN ELECT 470U M 35V
C1701 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1702 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1703 CK1E105KGMBNG CERAMIC 1U K 25V
C1705 CK1H472KLZBNG CERAMIC 4700P K 50V
C1706 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C1707 CEXLB0J102VDN ELECT 1000U M 6.3V
C1709 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1800 CK1H102KLZBNG CERAMIC 1000P K 50V
C1801 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1805 CK1A105KLZBNG CERAMIC 1U K 10V
C1816 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1823 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1824 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2000 CC1H150JLZCNG CERAMIC 15P J 50V
C2001 CC1H150JLZCNG CERAMIC 15P J 50V
C2002 CC1H150JLZCNG CERAMIC 15P J 50V
C2003 CC1H150JLZCNG CERAMIC 15P J 50V
C2004 CC1H150JLZCNG CERAMIC 15P J 50V
C2005 CC1H150JLZCNG CERAMIC 15P J 50V
C2009 CC1H150JLZCNG CERAMIC 15P J 50V
C2010 CC1H150JLZCNG CERAMIC 15P J 50V
C2011 CC1H150JLZCNG CERAMIC 15P J 50V
C2012 CC1H150JLZCNG CERAMIC 15P J 50V
C2013 CC1H150JLZCNG CERAMIC 15P J 50V
C2014 CC1H150JLZCNG CERAMIC 15P J 50V
C2018 CC1H150JLZCNG CERAMIC 15P J 50V
C2019 CC1H150JLZCNG CERAMIC 15P J 50V
C2020 CC1H150JLZCNG CERAMIC 15P J 50V
C2021 CC1H150JLZCNG CERAMIC 15P J 50V
C2022 CC1H150JLZCNG CERAMIC 15P J 50V
C2023 CC1H150JLZCNG CERAMIC 15P J 50V
C2403 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2404 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2405 CK1A105KLZBNG CERAMIC 1U K 10V
C2407 CK1A105KLZBNG CERAMIC 1U K 10V
C2409 CC1H101JLZCNG CERAMIC 100P J 50V
C2410 CC1H101JLZCNG CERAMIC 100P J 50V
C2416 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2417 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2418 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3000 CE1C101M1WANG ELECT 100U M 16V
C3050 CK1A105KLZBNG CERAMIC 1U K 10V
C3051 CK1A105KLZBNG CERAMIC 1U K 10V
C3053 CC1H680JLZCNG CERAMIC 68P J 50V
C3054 CC1H470JLZCNG CERAMIC 47P J 50V
C3055 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3056 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3057 CK0J106KGMBNG CERAMIC 10U K 6.3V
C3058 CC1H470JLZCNG CERAMIC 47P J 50V
C3059 CC1H680JLZCNG CERAMIC 68P J 50V
C3061 CK1A105KLZBNG CERAMIC 1U K 10V
C3062 CK1A105KLZBNG CERAMIC 1U K 10V
C3063 CK1A105KLZBNG CERAMIC 1U K 10V
C3064 CK1A105KLZBNG CERAMIC 1U K 10V
C3065 CK1A105KLZBNG CERAMIC 1U K 10V
C3066 CK1A105KLZBNG CERAMIC 1U K 10V
C5500 CK1H102KMNBNG CERAMIC 1000P K 50V
C5501 CK1A105KLZBNG CERAMIC 1U K 10V
C5503 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5505 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5506 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5507 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5508 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5510 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5511 CK1H102KMNBNG CERAMIC 1000P K 50V
C5512 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5513 CK1H102KMNBNG CERAMIC 1000P K 50V
C5514 CK1A105KLZBNG CERAMIC 1U K 10V
C5515 CK1H102KMNBNG CERAMIC 1000P K 50V
C5516 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5517 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5518 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5519 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5520 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5521 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5522 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5523 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5524 CK1H102KMNBNG CERAMIC 1000P K 50V
C5525 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5526 CK1H102KMNBNG CERAMIC 1000P K 50V
C5527 CK1H102KMNBNG CERAMIC 1000P K 50V
C5528 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5529 CK1H102KMNBNG CERAMIC 1000P K 50V
C5530 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5531 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5532 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5533 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5534 CK1H102KMNBNG CERAMIC 1000P K 50V
C5535 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5536 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5537 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5538 CK1H102KMNBNG CERAMIC 1000P K 50V
C5539 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5540 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5542 CE1C221M1WANG ELECT 220U M 16V
C5543 CK1C104KMNBNG CERAMIC 0.1U K 16V

– 11 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C5544 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5545 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5546 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5547 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5553 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5554 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5555 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5556 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5557 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5558 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5559 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5560 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5561 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5562 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5566 CC1H101JLZCNG CERAMIC 100P J 50V
C5567 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5568 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5569 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5570 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5571 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5572 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5573 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5574 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5575 CK1H102KMNBNG CERAMIC 1000P K 50V
C5576 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5577 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5578 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5579 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5580 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5582 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5583 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5584 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5585 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5586 CK1H102KMNBNG CERAMIC 1000P K 50V
C5587 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5592 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5593 CK1H102KMNBNG CERAMIC 1000P K 50V
C5594 CC1H120JLZCNG CERAMIC 12P J 50V
C5595 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5596 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5597 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C5598 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5599 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5602 CC1H120JLZCNG CERAMIC 12P J 50V
C5603 CK1H102KMNBNG CERAMIC 1000P K 50V
C5604 CE1C101M1WANG ELECT 100U M 16V
C5606 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5607 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5609 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5610 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5611 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5612 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5613 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5614 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5615 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5617 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5618 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5619 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5621 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C5622 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C5623 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5624 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5625 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5626 CC1H120JLZCNG CERAMIC 12P J 50V
C5627 CC1H120JLZCNG CERAMIC 12P J 50V
C5628 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C5629 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
C5630 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5631 CC1H120JLZCNG CERAMIC 12P J 50V
C5632 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5633 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5634 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5635 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5636 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5637 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5638 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5639 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5640 CK1H102KMNBNG CERAMIC 1000P K 50V
C5641 CK1H102KMNBNG CERAMIC 1000P K 50V
C5642 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5643 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5644 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5645 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5646 CK1H102KMNBNG CERAMIC 1000P K 50V
C5647 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5650 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5651 CK1H102KMNBNG CERAMIC 1000P K 50V
C5652 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5653 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5654 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5655 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5656 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5657 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5658 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5659 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5660 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5661 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5662 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5663 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5664 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5665 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5666 CK1E474KLZBNG CERAMIC 0.47U K 25V
C5667 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5668 CK1E474KLZBNG CERAMIC 0.47U K 25V
C5669 CK1E474KLZBNG CERAMIC 0.47U K 25V
C5670 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5671 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5672 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5673 CK1E474KLZBNG CERAMIC 0.47U K 25V
C5674 CK1H153KLZBNG CERAMIC 0.015U K 50V
C5675 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5676 CK0J475KLZBNG CERAMIC 4.7U K 6.3V

– 12 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C5677 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5678 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5679 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5680 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5681 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5682 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5683 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C5684 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5685 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5686 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5687 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5688 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5689 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5690 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5691 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5692 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5693 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5694 CK1H473KLZBNG CERAMIC 0.047U K 50V
C5695 CC1H220JLZCNG CERAMIC 22P J 50V
C5697 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5698 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5699 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5701 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5704 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5705 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5706 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5707 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5708 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5709 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5710 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5711 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5712 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5713 CK1H102KMNBNG CERAMIC 1000P K 50V
C5714 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5715 CK1H102KMNBNG CERAMIC 1000P K 50V
C5716 CK1H102KMNBNG CERAMIC 1000P K 50V
C5717 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5722 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5725 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5726 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5727 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5728 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5729 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5730 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5731 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5732 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5733 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5734 CK1H102KMNBNG CERAMIC 1000P K 50V
C5735 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5736 CK1H102KMNBNG CERAMIC 1000P K 50V
C5737 CK1H102KMNBNG CERAMIC 1000P K 50V
C5738 CK1C104KMNBNG CERAMIC 0.1U K 16V
C5750 CE1C221M1WANG ELECT 220U M 16V
C5752 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5753 CEXLB0J102VDN ELECT 1000U M 6.3V
C5754 CK1H333KLZBNG CERAMIC 0.033U K 50V
C5755 CK1H333KLZBNG CERAMIC 0.033U K 50V
C5770 CE1C221M1WANG ELECT 220U M 16V
C5772 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5773 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5774 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5775 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5776 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5777 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5779 CK1A105KLZBNG CERAMIC 1U K 10V
C5780 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5781 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5782 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5783 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5784 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5785 CK1E103KMNBNG CERAMIC 0.01U K 25V
C5800 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5801 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5900 CK0J106KGMBNG CERAMIC 10U K 6.3V
C5901 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5902 CK1E224KLZBNG CERAMIC 0.22U K 25V
C5962 CK1A105KLZBNG CERAMIC 1U K 10V
C6000 CK1C104KMNBNG CERAMIC 0.1U K 16V
C6001 CK1C104KMNBNG CERAMIC 0.1U K 16V
C6002 CK1C104KMNBNG CERAMIC 0.1U K 16V
C6003 CK1C104KMNBNG CERAMIC 0.1U K 16V
C6004 CK1C104KMNBNG CERAMIC 0.1U K 16V
C6105 CC1H470JLZCNG CERAMIC 47P J 50V
C6106 CC1H470JLZCNG CERAMIC 47P J 50V
C6110 CEXLB0J102VDN ELECT 1000U M 6.3V
C6111 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6112 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6113 CC1H100JLZCNG CERAMIC 10P J 50V
C6114 CC1H100JLZCNG CERAMIC 10P J 50V
C6314 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6316 CE1C101M1WANG ELECT 100U M 16V
C6408 CK0J106KGMBNG CERAMIC 10U K 6.3V
C6409 CK1H102KLZBNG CERAMIC 1000P K 50V
C6410 CK1H102KLZBNG CERAMIC 1000P K 50V
C6411 CK1H102KLZBNG CERAMIC 1000P K 50V
C6500 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6550 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6580 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6600 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6602 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6603 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6604 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6605 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6606 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6607 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6609 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6610 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6611 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6612 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6613 CK1H104ZLZFNG CERAMIC 0.1U Z 50V

– 13 –
Schematic
Location Part No. Description Schematic Location Part No. Description
C6614 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6615 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6616 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6617 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6618 CK1H104KLZBNG CERAMIC 0.1U K 50V
C6620 CK0J106KGMBNG CERAMIC 10U K 6.3V
C6621 CE1C101M1WANG ELECT 100U M 16V
C6624 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6625 CK1A105KLZBNG CERAMIC 1U K 10V
C6627 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8500 CK1H103KLZBNG CERAMIC 0.01U K 50V
C8501 CK1A105KLZBNG CERAMIC 1U K 10V
C8503 CE1C221M1WANG ELECT 220U M 16V
C8504 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8505 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C8550 CK1H103KLZBNG CERAMIC 0.01U K 50V
C8551 CK1A105KLZBNG CERAMIC 1U K 10V
C8553 CE1C221M1WANG ELECT 220U M 16V
DIODES
D007 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D008 DZ02DZ6.2Y—G ZENER DIODE 02DZ6.2Y(TPH3
DZUDZS6.2B—G ZD UDZS-TE-176.2B
DZXLBXB6.2B-G ZENER DIODE MM3Z6V2B
D800 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D801 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1001 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1002 DZ02DZ3.9Y—G ZENER DIODE 02DZ3.9Y(TPH3
DZUDZS3.9B—G ZD UDZS-TE-173.9B
DZXLBXB3.9B-G ZENER DIODE MM3Z3V9B
D1602 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1603 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1604 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1605 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1632 DZ02DZ3.0Y—G ZENER DIODE 02DZ3.0Y(TPH3
DZUDZS3.0B—G ZENER DIODE UDZS3.0B-TE-1
DZXLBXB3.0B-G ZENER DIODE MM3Z3V0B
D1633 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1634 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D1651 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1660 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1674 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1683 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
DDXLBB053—-G DIODE 1SS35
D1700 DDSS3P3-E3—G DIODE SS3P3-E3/84A
DDSS3P3-M3—G DIODE SS3P3-M3/84A
D2402 DDRB551V-30-G DIODE RB551V-30-TE-17
D2403 DDRB551V-30-G DIODE RB551V-30-TE-17
SC8508 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8509 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8510 DDDF2S6.8UFSG DIODE DF2S6.8UFS
SC8511 DDDF2S6.8UFSG DIODE DF2S6.8UFS
INTEGRATED CIRCUITS
IC001 QSTA333W13TRP IC STA333W13TR
IC600 QLM1117S-ADJP IC LM1117S-ADJ
IC800 QXXAAJQ1240— IC LC87F2932AVU-Y10US1T
IC800A QXXGA0500125M IC LC87F2932AVU-QIP-E
IC800C 1AA6P4P2085— LABEL-LC87F2932AVU-
Y10US1T
IC801 QLE24C023M-EP IC LE24C023M-TLM-E
QXXAVC837—-P IC AT24C02BN-10SU-1.8
QXXAVC986—-P IC CAT24C02WI-GT3
IC804 QTC7SET14FU-P “IC TC7SET14FU-(TE85L,F”
QXXAVD177—-P “IC 74AHCT1G14GW,125”
IC1610 QBD9845FV—-P IC BD9845FV-E2
IC1611 QBD9845FV—-P IC BD9845FV-E2
IC1630 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC1640 QPQ070XNA1ZPP IC PQ070XNA1ZPH
IC1650 QLM1117S-ADJP IC LM1117S-ADJ
IC1670 QXXGA0500165P IC LV5806MX-TLM-H
IC1700 QLV5803M-E—P IC LV5803M-TE-L-E
IC2401 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2402 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2403 QLE24C023M-EP IC LE24C023M-TLM-E
QXXAVC837—-P IC AT24C02BN-10SU-1.8
QXXAVC986—-P IC CAT24C02WI-GT3
IC2404 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC2405 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC3050 QBA4558RF-E2P IC BA4558RF-E2
QNJM4558M—-P IC NJM4558M-TE2
IC5501A 1AA2HER0052— HEAT SINK SHEET-N7BE
IC5501 QXXAVD156—-M IC BCM3549VSKFSB5G
IC5600 Q74AHC1G08GWP IC 74AHC1G08GW

– 14 –
Schematic
Location Part No. Description Schematic Location Part No. Description
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC5601 Q74AHC1G08GWP IC 74AHC1G08GW
QTC7SH08FU—P IC TC7SH08FU(TE85L)
IC5700 QXXAVD191—-M IC K4T1G164QE-HCF8
IC5701 QXXAVD191—-M IC K4T1G164QE-HCF8
IC5750 QXXAVD076—-G IC PQ018EHS2ZPH
IC5770 QRT9026GSP—P IC RT9026GSP
IC5800 QXXAAJQ1245— IC TC58NVG0S3ETA00
IC5800A QXXAVD168—-M IC TC58NVG0S3ETA00
IC5800C 1AA6P4P2109— LABEL-TC58NVG0S3ETA00
IC5900 QXXAVD046—-P IC XC6108N28AMR
IC6600 QTDA9996——M IC TDA9996
IC6601 QLM1117S-ADJP IC LM1117S-ADJ
IC8500 QRT9711CGB—P IC RT9711CGB
IC8550 QRT9711CGB—P IC RT9711CGB
COILS
L001 1LB4L26B1630G “INDUCTOR ,22UH”
L002 1LB4L26B1630G “INDUCTOR ,22UH”
L003 1LB4L26B1630G “INDUCTOR ,22UH”
L009 1LB4L26B0700G “INDUCTOR , 120 OHM”
L011 1LB4L26B0700G “INDUCTOR , 120 OHM”
L012 1LB4L26B0700G “INDUCTOR , 120 OHM”
L013 1LB4L26B1630G “INDUCTOR ,22UH”
L017 1LB4L26B0700G “INDUCTOR , 120 OHM”
L018 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L019 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L020 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L800 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L801 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1602 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1605 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1606 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1608 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1609 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1610 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1613 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1614 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1620 1LB4L2XA100MG “INDUCTOR,10.0U M”
L1621 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1622 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1623 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1624 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1625 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1632 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1641 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1646 1LB4L2XA100MG “INDUCTOR,10.0U M”
L1647 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1648 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1653 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1664 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1665 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1672 1LB4L2XA100MG “INDUCTOR,10.0U M”
L1673 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1674 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1695 1LB4L26B0740G “INDUCTOR , 220 OHM”
L1716 1LB4L26B1180G INDUCTOR 10U M
L1750 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1800 1LB4L26B0740G “INDUCTOR , 220 OHM”
L2000 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L2001 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L2002 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L2003 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L2004 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L2005 1AV4L2GAR22JG “INDUCTOR,0.22U J”
L3000 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L5500 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5501 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5502 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5503 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5504 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5505 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5506 1LB4L26B0740G “INDUCTOR , 220 OHM”
L5507 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5508 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5509 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5510 1AV4L2GAR33JG “INDUCTOR,0.33U J”
L5511 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L5513 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5514 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5515 1AV4L2GA2R2JG “INDUCTOR,2.2U J”
L5516 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5517 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5518 1AV4L2GAR47JG “INDUCTOR,0.47U J”
L5519 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5520 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5521 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5522 1LB4L26B0740G “INDUCTOR , 220 OHM”
L5523 1LB4L26B1300G “INDUCTOR 1000OHM, P”
L5753 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L5754 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L5770 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L5771 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L5772 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L5800 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6103 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L6105 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L6107 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6108 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6112 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6113 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6117 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6124 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L6302 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6303 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6304 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6305 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6306 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6307 1AV4L3CY201MG “IMPEDANCE,200 OHM M”
L6323 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L6325 1LB4L26B0740G “INDUCTOR , 220 OHM”

– 15 –
Schematic
Location Part No. Description Schematic Location Part No. Description
L6326 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6403 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6600 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L6601 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6602 1LB4L26B0740G “INDUCTOR , 220 OHM”
L6605 1LB4L26B0740G “INDUCTOR , 220 OHM”
L8501 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L8551 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
TRANSISTORS
Q800 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q801 TISA1235AC1EP TR ISA1235AC1E
TISA1235AC1FP TR ISA1235AC1F
TXXLBB005—-P TR MMBTSA1235F
Q806 TISA1235AC1EP TR ISA1235AC1E
TISA1235AC1FP TR ISA1235AC1F
TXXLBB005—-P TR MMBTSA1235F
Q808 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1001 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1002 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1005 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1006 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1007 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1008 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1009 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1010 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1011 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1012 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1600 TAO4449——-P TR AO4449
Q1602 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1603 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1630 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1634 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1640 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1641 TAO4449——-P TR AO4449
Q1700 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1801 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1802 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1805 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q1806 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q2400 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q2450 TUM6K1N——-P TR UM6K1N-TN
Q5500 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q5750 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q8500 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
Q8550 T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
TXXLBB006—-P TR MMBTSC3928R
RESISTORS
R001 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R002 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R003 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R004 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R005 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R006 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R007 1LB4L26B0700G “INDUCTOR, 120 OHM”
R008 1LB4L26B0700G “INDUCTOR, 120 OHM”

– 16 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R009 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R010 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R011 RGF1201JTCANL MT-GLAZE 1.2K JA 1/10W
R012 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R013 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R015 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R019 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R022 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R023 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R601 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R602 RGF12R0JTCANL MT-GLAZE 12 JA 1/10W
R603 RGF2200FTCANL MT-GLAZE 220 FA 1/10W
R800 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R803 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R804 RGF2702JTCANL MT-GLAZE 27K JA 1/10W
R805 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R806 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R807 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R810 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R811 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R813 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R818 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R819 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R820 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R821 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R826 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R827 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R828 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R829 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R830 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R831 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R833 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R836 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R839 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R840 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R841 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R845 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R847 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R848 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R851 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R852 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R854 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R856 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R857 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R858 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R859 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R860 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R861 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R862 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R865 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R868 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R870 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R871 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R875 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R876 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R877 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R879 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R881 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R883 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R884 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R885 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R886 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R887 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R888 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R890 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R891 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R892 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R893 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R894 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R897 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R899 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1001 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1005 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1006 RGF82R0JTCANL MT-GLAZE 82 JA 1/10W
R1010 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R1012 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1014 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1015 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1016 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1018 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1019 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1020 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1021 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1022 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1030 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1036 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R1037 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1038 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1040 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R1041 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1042 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1043 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1044 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1045 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1046 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1047 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1048 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1049 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1050 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1051 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1052 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1053 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1054 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1055 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R1056 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1057 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1058 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R1065 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R1066 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R1085 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1089 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1097 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W

– 17 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R1099 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1101 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1103 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1105 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1107 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1109 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1111 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1600 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1607 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1611 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1612 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R1613 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1614 RGF2401JTCANL MT-GLAZE 2.4K JA 1/10W
R1615 RGF1002FTCANL MT-GLAZE 10K FA 1/10W
R1616 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1617 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1618 RGF1002FTCANL MT-GLAZE 10K FA 1/10W
R1619 RGF2000JTCANL MT-GLAZE 200 JA 1/10W
R1620 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R1621 RGF2201FTCANL MT-GLAZE 2.2K FA 1/10W
R1622 RGF1002FTCANL MT-GLAZE 10K FA 1/10W
R1623 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1624 RGF18R0JTCANL MT-GLAZE 18 JA 1/10W
R1625 RN1R005JTFANL MT-FILM 0.005 JA 1W
R1626 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1627 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1628 RGF1502FTCANL MT-GLAZE 15K FA 1/10W
R1630 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1631 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1632 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1633 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1635 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1636 RGF2200FTCANL MT-GLAZE 220 FA 1/10W
R1638 RGF1501FTCANL MT-GLAZE 1.5K FA 1/10W
R1640 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1641 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1642 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1643 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1644 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1646 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1647 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1648 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1649 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1650 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1651 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1656 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1662 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R1663 RGF12R0JTCANL MT-GLAZE 12 JA 1/10W
R1664 RGF8200FTCANL MT-GLAZE 820 FA 1/10W
R1668 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1669 RGF1003FTCANL MT-GLAZE 100K FA 1/10W
R1670 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1671 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1675 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R1676 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1677 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R1678 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1680 RN1R005JTFANL MT-FILM 0.005 JA 1W
R1681 RGF18R0JTCANL MT-GLAZE 18 JA 1/10W
R1684 RG14700JTEANL MT-GLAZE 470 JA 1W
R1696 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R1698 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1701 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1702 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R1703 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1704 RGF1001FTCANL MT-GLAZE 1K FA 1/10W
R1705 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R1707 RGF4701FTCANL MT-GLAZE 4.7K FA 1/10W
R1709 RGF6800JTCANL MT-GLAZE 680 JA 1/10W
R1800 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1801 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1802 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1805 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1806 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1807 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1808 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1810 RGF3300JTCANL MT-GLAZE 330 JA 1/10W
R1811 RGF3300JTCANL MT-GLAZE 330 JA 1/10W
R1812 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1826 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1827 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1829 1LB4L26B1300G “INDUCTOR 1000OHM, P”
R1830 1LB4L26B1300G “INDUCTOR 1000OHM, P”
R1833 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1835 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1837 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1842 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1844 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1847 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1848 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1852 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1856 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R1863 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1869 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1870 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R2406 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R2407 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R2408 RGF1503JTCANL MT-GLAZE 150K JA 1/10W
R2409 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R2410 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2411 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2412 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R2414 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R2415 RGF3303JTCANL MT-GLAZE 330K JA 1/10W
R2419 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2420 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2432 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2434 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2435 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R2436 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W

– 18 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R2437 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R2445 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2446 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2447 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R2450 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2451 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R2455 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2456 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2459 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2460 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R2461 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R3050 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R3051 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R3052 RGF1502FTCANL MT-GLAZE 15K FA 1/10W
R3053 RGF1502FTCANL MT-GLAZE 15K FA 1/10W
R3054 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R3055 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R3056 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R3057 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R3058 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R3059 RGF3302FTCANL MT-GLAZE 33K FA 1/10W
R3060 RGF1502FTCANL MT-GLAZE 15K FA 1/10W
R3061 RGF1502FTCANL MT-GLAZE 15K FA 1/10W
R3062 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R3063 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5499 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5507 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5508 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5512 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5514 RGF2400JTCANL MT-GLAZE 240 JA 1/10W
R5515 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5516 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5517 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5518 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5522 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5523 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5525 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5526 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R5527 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R5529 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5532 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5535 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5539 RGF22R0JTCANL MT-GLAZE 22 JA 1/10W
R5540 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5541 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5542 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5543 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5544 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5550 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5551 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5554 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5555 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5560 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5561 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5562 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5563 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5566 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5570 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5574 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5575 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5576 RGF39R0JTCANL MT-GLAZE 39 JA 1/10W
R5577 RGF1201JTCANL MT-GLAZE 1.2K JA 1/10W
R5578 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5581 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5582 RGF3901FTCANL MT-GLAZE 3.9K FA 1/10W
R5583 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R5584 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5585 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5587 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R5588 RGF27R0JTCANL MT-GLAZE 27 JA 1/10W
R5589 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5590 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5593 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5595 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5596 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5597 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R5598 RGF27R0JTCANL MT-GLAZE 27 JA 1/10W
R5599 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5600 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5603 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5604 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5605 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5606 RGF82R0JTCANL MT-GLAZE 82 JA 1/10W
R5607 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5608 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5609 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5610 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5611 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5613 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5614 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5615 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5616 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5617 RGF22R0JTCANL MT-GLAZE 22 JA 1/10W
R5619 RGF3300FTCANL MT-GLAZE 330 FA 1/10W
R5621 RGF22R0JTCANL MT-GLAZE 22 JA 1/10W
R5622 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5623 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5625 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5626 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5627 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5628 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5629 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R5630 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5632 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5634 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5636 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5637 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5638 RGF2R20JTCANL MT-GLAZE 2.2 JA 1/10W
R5640 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5641 RGF5600FTCANL MT-GLAZE 560 FA 1/10W
R5642 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5643 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W

– 19 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R5644 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5645 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5646 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5647 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5648 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5650 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5651 RGF2R20JTCANL MT-GLAZE 2.2 JA 1/10W
R5652 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5654 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5655 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5659 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5660 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5661 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5662 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5663 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5664 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5665 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5666 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5667 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5668 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5669 RGG1000JTHANL MT-GLAZE 100 JA 1/16W
R5675 RGF2R20JTCANL MT-GLAZE 2.2 JA 1/10W
R5676 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5678 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5680 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5682 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5684 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R5685 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5686 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5687 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5688 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5689 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5690 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5691 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5692 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5693 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5694 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5695 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R5700 RGG1000JTHANL MT-GLAZE 100 JA 1/16W
R5701 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5707 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5709 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5710 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5711 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5720 RGG1000JTHANL MT-GLAZE 100 JA 1/16W
R5721 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5750 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5751 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5752 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R5756 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5780 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R5800 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R5801 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5802 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5811 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R5813 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5815 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5816 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5819 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5821 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5822 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5825 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5827 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5828 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R5901 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5902 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5950 RGF22R0JTCANL MT-GLAZE 22 JA 1/10W
R5954 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5955 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5957 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5959 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R5962 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R5963 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R5964 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6000 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R6001 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R6002 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R6003 RGF27R0JTCANL MT-GLAZE 27 JA 1/10W
R6004 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R6007 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R6008 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6009 RGF4R70JTCANL MT-GLAZE 4.7 JA 1/10W
R6010 RGF10R0JTCANL MT-GLAZE 10 JA 1/10W
R6011 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R6012 RGF27R0JTCANL MT-GLAZE 27 JA 1/10W
R6013 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R6101 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6104 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6105 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6107 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6109 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6319 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R6321 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6322 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6329 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6332 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6341 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R6342 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6347 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6364 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R6365 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6366 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6381 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R6382 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6397 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6398 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6413 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6414 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R6419 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R6420 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R6502 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6503 RGF4702JTCANL MT-GLAZE 47K JA 1/10W

– 20 –
Schematic
Location Part No. Description Schematic Location Part No. Description
R6505 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6506 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6507 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6508 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6509 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6510 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6511 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6512 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6513 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6514 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6552 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6553 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6555 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6556 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6557 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6563 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6564 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6565 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6566 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6567 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6568 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6569 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6582 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6583 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R6585 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6586 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6587 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6588 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6589 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6590 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6591 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6592 RGF5R60JTCANL MT-GLAZE 5.6 JA 1/10W
R6593 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6594 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6603 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6604 RGF1202FTCANL MT-GLAZE 12K FA 1/10W
R6612 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6613 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R6616 RGF2200FTCANL MT-GLAZE 220 FA 1/10W
R6617 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R6618 RGF1200FTCANL MT-GLAZE 120 FA 1/10W
R6619 RGF3300JTCANL MT-GLAZE 330 JA 1/10W
R8500 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8502 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R8504 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R8505 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8506 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R8513 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R8514 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R8550 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8552 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R8554 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R8555 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R8556 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
RB5780 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
RB5781 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
RB5782 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
RB5783 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
RB5784 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
RB5785 1LB4R1YB750JG R-NETWORK 75X4 0.0 63W
CRYSTAL/OSCILLATOR
X800 1AV4V11B1771G “OSC,CERAMIC 8.00MHZ”
X801 1AV4V10B0560N “OSC,CRYSTAL 32.768KHZ”
X5500 1AV4V10B9440N “OSC,CRYSTAL 54MHZ”
