Sapling SBD 3000 Series Assembly instructions

SBD 3000 Series Wired Clock
The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
Installation and Programming Manual V8

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
2
Table of Contents
SBD 3000 Series Wired Clock
Table of Contents—2
Installation
Included in the Kit—3
Flush Mount Installation—4
ABS Surface (Wall) Mount Installation—5
ABS Surface (Wall) Mount Installation (continued)—6
ABS Double Mount Installation—7
ABS Double Mount Installation (continued)—8
ABS Double Mount Installation (continued)—9
Wiring and Jumper Settings (3100 Series)—10
Wiring and Jumper Settings (3200 Series)—11
Wiring and Jumper Settings (3300 Series)—12
Wiring Information
2-Wire Digital Communication - Slave Mode—13
RS485 Communication - Slave Mode—14
2-Wire Digital Communication - Master Mode—15
RS485 Communication - Master Mode—16
3-Wire Synchronous (Sync-Wire) Communication 24 Volt Wiring Information—17
3-Wire Synchronous (Sync-Wire) Communication 120 Volt Wiring Information—18
3-Wire Synchronous (Sync-Wire) Communication 240 Volt Wiring Information—19
Using the Output Sync Relay on the SBD 3300—20
Termperature Sensor Wiring (Optional)—21
Interfacing with Other Systems (Inputs) - 59 Minute Correction - 58 Minute Correction—22
Interfacing with Other Systems (Inputs) - National Time/Rauland - Dukane—23
Interfacing with Other Systems (Inputs) - Rauland Digital - Midnight Reset or Once a Day Pulse—24
Programming
Setting the Time on the SBD 3300 - Programming the SBD 3300—25
Programming the SBD 3300 (continued)—25-32
Software
Installing the SbdConfig.exe Software—33-36
Sbdconfig Software - Task Bar Functionality—37-38
Sbdconfig Software - Display Settings—39
Sbdconfig Software - Brightness Schedule—40
Sbdconfig Software - Clock Settings—41
Sbdconfig Software - Outputs—42
Sbdconfig Software - Elapsed Timer—43-45
Sbdconfig Software - Inputs—46-47
Sbdconfig Software - DST—48-49
Support
Reading the Display—50
Frequently Asked Questions—51
Troubleshooting—52
*Manuals may change without prior notice

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
3
Included in the Kit
Surface Mount – 24VAC Kit
Kit will be labeled: D-PK-3-24-S
• 24VAC Power Harness (18 AWG), Orange, Green, Yellow
Kit will be labeled: D-MK-WLL-PLTC-1
• 4 - 6-32 x 1” Machine Flat Screws
• 4 - 6-19 x 1/2” Flat Head Screws
• 4 - 8-32 x 7/19” Screws
• 2 - 8-32 x 7/16” Screws
Surface Mount - 120VAC or 240VAC Kit
Kit will be labeled: D-PK-3-110-S
• 120VAC or 240VAC Harness (18 AWG), Black, Green, White
Kit will be labeled: D-MK-WLL-PLTC-1
• 4 - 6-32 x 1” Machine Flat Screws
• 4 - 6-19 x 1/2” Flat Head Screws
• 4 - 8-32 x 7/19” Screws
• 2 - 8-32 x 7/16” Screws
Flush Mount – 24VAC Kit
Kit will be labeled: D-PK-3-24-F
• 1 - Grounding Wire, Loop End (18 AWG), Green
• 1 - 24VAC Power Harness (18 AWG), Black, Green, White
• 4 - Machine Flat Screws 6-32x1/2, Black
• 1 – 6-32 Hex Machine Screw Nut
• 1 – Internal Tooth Lockwasher #6
Flush Mount – 120VAC or 240VAC Kit
Kit will be labeled: D-PK-3-110-F
• 1 - Grounding Wire, Loop End (18 AWG), Green
• 1 - 120VAC or 240VAC Power Harness (18 AWG), Black, Green, White
• 4 - Machine Flat Screws 6-32x1/2, Black
• 1 – 6-32 Hex Machine Screw Nut
• 1 – Internal Tooth Lockwasher #6
Below is a list of all the items included in the SBD 3000 installation kit. The items in the kit will correspond to the type of mounting and voltage
option chosen.
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
4
1. Mount the flush mount box into the wall.
2. Connect the ground wire into the flush mount box using the tooth lockwasher and the machine screw nut
(included in the kit).
3. Disconnect the red filter from the display panel.
4. Connect the wiring as shown on the wiring diagram.
5. IMPORTANT: If using a low voltage system (24 volt) make sure that the transformer is an isolated transformer.
6. Mount the display panel into the flush mount box using the four (4) black machine screws (#6, included in the kit).
Make sure the switches are on the right side.
7. Snap the red filter into the display panel.
Flush Mount Installation
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
5
ABS Surface (Wall) Mount Installation
e
w
q
r
t
y
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
6
1. Mount Housing to Wall and/or Gang Box - To mount the housing to the wall, install two (2) wall anchors into the wall (not supplied
in kit) and take two pan head screws no larger than #8 (also not supplied in kit) and drive them into the anchors leaving an 1/8th inch
gap between the head of the screw and the wall. Mount the housing to the wall by lining up the two keyholes in the back of the housing
with the two screws with the 1/8 inch gap and slide the housing onto the heads of the screws. Next, mark the 2 mounting holes at the
bottom of the housing on the wall. Remove the housing and install wall anchors at this location. Hang the housing on the keyholes and
install the bottom screws. To mount the housing to the gang box, take the four (4) 6-32 x 1” screws (supplied in kit) and screw them
through the four holes in the center of the inside of the housing and the four holes in the gang box.
Note: If using a metal gang box, a ground must be provided to the gang box.
2. Feed Wiring Into the Housing - Take the wire coming from the inside of the gang box and feed it through the hole in the middle of
the housing.
3. Plug and Secure Wiring - Loosen the provided wire clamp (comes attached to the inside of the housing) and slip excess wiring
through and tighten the clamp. After securing excess wiring, connect the wiring into the appropriate connector on the back of the
display board. (See the Wiring and Jumper Settings on pages 10-12).
4. Mount Display Board to Housing - Using the four (4) self tapping, 6-19 x 1/2” flat head screws (supplied in the assembly kit), take
the display board and screw it to the front side of the clock housing (4 screws per clock).
5. Snap on Filter - Take the red filter bezel and snap it on to the front side of the housing.
6. Snap on Frame - Take the gray frame and snap it on to the front side of the housing.
ABS Surface (Wall) Mount Installation (continued)
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
7
ABS Double Mount Installation
qt
i
a
y
r
w
w
e
u
o
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
8
ABS Double Mount Installation (continued)
*For metal mounting bracket: Use a wall anchor that can support 50 lbs or more with a maximum
screw size of #8
1. Install metal mounting bracket - First, remove the metal mounting bracket from the inside of the double mount base by unscrewing
the two (2) 6-32 x 1/2” screws located on the underside of the base (save these screws for step #5). Next, screw the metal mounting
bracket to the wall or ceiling in which the clocks are being installed. To mount to the double gang switch box, screw the four (4) 6-32 x
1” screws (supplied in the assembly kit) through the inner four holes of the metal mounting bracket. Use the outer four holes to mount to
the anchors in the wall (both anchors and screws are not supplied in kit).
Note: If using a plastic switch box, a ground wire must be routed through the switch box and into one (1) of
the four (4) metal mounting bracket screws in order to provide ground to the metal mounting bracket. The metal
mounting bracket
MUST
be secured by both the screws going to the switch box
AND
the anchors going into the
wall.
2. Mount clock housings to pole - Align the hole in the center each housing with one of the three holes on the mounting pole where
the wiring will be routed (the installer will choose which hole at the end of the pole to use based on how far they want the clock to sit
from the wall). Screw from the inside of the housing into the four holes surrounding the hole in the center of the housing using the four
(4) 8-32 x 7/16” screws (supplied in the assembly kit - 4 screws per clock), securing both housings to the mounting pole.
Note: End caps from one side of each clock must be removed to mount both clocks to the mounting pole.
Remove one end cap from each clock from the side in which the mounting pole enters the clock.
*Instructions continued on next page
3. Screw both housings together - Using the two (2) self tapping, 6-19 x 7/16” screws (supplied in the assembly kit), screw both back
sides of the clock housings together (2 screws per clock).
Installation
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
9
ABS Double Mount Installation (continued)
4. Feed wiring through base and pole - Take the wiring coming from the switch box and begin to feed it through the center of the
base of the mounting assembly until it emerges from the hole in the center of the clock housing.Make sure there is roughly 1.5’ of
wiring coming from the switch box. Perform this task for both clocks.
5. Snap and screw base to metal mounting bracket - Snap the base to the metal mounting bracket by first making contact with
the lip in the upper side of the base and the metal mounting bracket. When the base has been snapped onto the bracket, take
the two (2) 6-32 x 1/2” pan head screws that originally came installed on the base and screw them back into the two holes on the
underside of the base to secure the base to the metal mounting bracket.
6. Connect switch box wires to clock harness - Take the wiring harness supplied with the clock and make all necessary
connections between the wiring harness and the switch box wires using wire nuts. Perform this task for both clocks.
7. Plug and secure wiring - Loosen and slip excess wiring through provided wire clamp (comes attached to each housing) and
tighten the clamp. After securing excess wiring, connect the wiring harness into the appropriate connector on the back of the
display board. Perform this task for both clocks. (See the Wiring and Jumper Settings on pages 10-12).
8. Mount display board to housing - Using the four (4) self tapping, 6-19 x 1/2" flat head screws supplied in the assembly kit,
take the display board and screw it to the front side of the clock housing (4 screws per clock).
9. Snap on filter - Take the red filter bezel and snap it on to the front side of each clock housing.
10. Snap on frame - Take the gray frame and snap it on to the front side of each clock housing.
Installation

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
10
Wiring Information
Wiring and Jumper Settings (3100 Series)
**Jumper Position
JP 1 JP 4 JP 5
JP 6
JP 2
JP 3
Power Settings
1
4 5
2
3
24VAC @ 0.35A (ORG)
120VAC or 240VAC @ 0.1A (BLK)
No Connection
120VAC or 240VAC @ 0.1A (WHT)
24VAC @ 0.35A (YEL)
4 3
2
1
Note: When setting up the jumpers, Pin 1 & Pin 2 must be jumpered together OR Pin 2 & Pin 3 must be jumpered together. Below are the Jumper Positions and their corresponding functions.
Pin
1 2 3
Jumper Position Pin 1 & Pin 2 Pin 2 & Pin 3
JP 1 12 Hour Time 24 Hour Time JP 2 Bright Low JP 3 Time Display Only Alternating Time/Date Display JP 4 Normal Configuration JP 5 Real Time Clock 60Hz JP 6 Sync RS485 Select
Wiring Information
Note: Pin 1 will always be the square pad.
Please note: With the 3100 Series, the Alternating Time/Date display is displayed in the U.S. date format (MM:DD:YY). International users are advised to purchase the 3200 Series with the RS485 to USB Programming Cable (D-USB485-INTF-1) in order to program the display to alternate to the International date format (DD:MM:YY).

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
11
Wiring Information
Wiring and Jumper Settings (3200 Series)
**Jumper Position
JP 1 JP 4 JP 5
JP 6
JP 2
JP 3
Power Settings
1
4 5
2
3
24VAC @ 0.35A (ORG)
120VAC or 240VAC @ 0.1A (BLK)
No Connection
120VAC or 240VAC @ 0.1A (WHT)
24VAC @ 0.35A (YEL)
Elapsed Timer
5
2 1
4
3
No Connection TXD (Blue&Blue/White)
Common (Green&Green/White) RXD (Orange&Orange/White) 3.3V@0.1A (Brown&Brown/White)
P1 - Sync Inputs P2 - User Inputs
1 2 3 4
P7 - RS485
Input A
Input B
Output A
Output B
P3 - Relay Output
4 3
2
1
*Relay 1 N.O.
*Relay 2 N.O.
Note: When setting up the jumpers, Pin 1 & Pin 2 must be jumpered together OR Pin 2 & Pin 3 must be jumpered together. Below are the Jumper Positions and their corresponding functions.
Pin
1 2 3
*Refer to pages 19-21 for further installation instructions.
Jumper Position Pin 1 & Pin 2 Pin 2 & Pin 3
JP 1 12 Hour Time 24 Hour Time JP 2 Bright Low JP 3 Time Display Only Alternating Date/Time Display JP 4 Normal Configuration JP 5 Real Time Clock 60Hz JP 6 Sync RS485 Select
Cat 5 Cable
Wiring Information
Note: Pin 1 will always be the square pad.
Please note: With the 3200 Series, the Alternating Time/Date display is in U.S. format (MM:DD:YY) when using the jumper switch. International date format (DD:MM:YY) settings is done via the RS485 to USB Programming Cable - Part number: D-USB485-INTF-1 (sold separately).

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
12
Wiring Information
Wiring and Jumper Settings (3300 Series)
**Jumper Position
JP 1 JP 4 JP 5
JP 6
JP 2
JP 3
Power Settings
1
4 5
2
3
24VAC @ 0.35A (ORG)
120VAC or 240VAC @ 0.1A (BLK)
No Connection
120VAC or 240VAC @ 0.1A (WHT)
24VAC @ 0.35A (YEL)
Elapsed Timer
5
2 1
4
3
No Connection TXD (Blue&Blue/White)
Common (Green&Green/White) RXD (Orange&Orange/White) 3.3V@0.1A (Brown&Brown/White)
P1 - Sync Inputs P2 - User Inputs
12 3 4 5 6 7 8 9 12 3 4 5 6 7 8 9
AC / DC Com
120VAC or 240VAC Sync
24VAC Sync Dukane Reset
Dukane Pulse
Dry Contact
3.3VDC@20ma
Common
Common
User Input 4 User Input 3 User Input 2 User Input 1 12VDC@40ma
Each User Input is a Contact Closure
1 2 3 4
P7 - RS485
Input A
Input B
Output A
Output B
P3 - Relay Output
4 3
2
1
*Relay 1 N.O.
*Relay 2 N.O.
*Contact Rating 0.3A @ 120VAC 0.5A @ 24 VAC
Note: When setting up the jumpers, Pin 1 & Pin 2 must be jumpered together OR Pin 2 & Pin 3 must be jumpered together. Below are the Jumper Positions and their corresponding functions.
Pin
1 2 3
*Refer to pages 22-24 for further installation instructions.
Jumper Position Pin 1 & Pin 2 Pin 2 & Pin 3
JP 1 12 Hour Time 24 Hour Time JP 2 Bright Low JP 3 Time Display Only Alternating Date/Time Display JP 4 Normal Configuration JP 5 Real Time Clock 60Hz JP 6 Sync RS485 Select
Cat 5 Cable
Wiring Information
Note: Pin 1 will always be the square pad.
Please note: With the 3300 Series, the Alternating Time/Date display is in U.S. format (MM:DD:YY) when using the jumper switch. International date format (DD:MM:YY) settings is done via the RS485 to USB Programming Cable - Part number: D-USB485-INTF-1 (sold separately).

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
13
Wiring Information
2-Wire Digital Communication - Slave Mode
SMA 2000 or 3000 Series Master Clock
24VAC SAM Series Wired Clock
24V SBD 3000 Series Wired Clock
24VAC SAM Series Wired Clock
19
White
Black
White
Black
Orange
Yellow
120VAC or 240VAC
120VAC or 240VAC
18
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
14
Wiring Information
RS485 Communication - Slave Mode
SMA 2000 or 3000 Series Master Clock
24VAC or 120VAC or 240VAC SRM Series RS485 Clock
SBD 3200/3300 Series Wired Clock
Yellow/Black
Orange/White
Black
White
Black
White
P7-1
P7-2
P7-3
P7-4
24VAC or 120VAC or
240VAC
24VAC or 120VAC or 240VAC SRM Series RS485 Clock
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
15
Wiring Information
2-Wire Digital Communication - Master Mode
SBD 3300 Series Wired Clock
Brown Purple
24VAC SAM Series Wired Clock
24V SBD 3000 Series Wired Clock
24VAC SAM Series Wired Clock
120VAC or 240VAC
120VAC or 240VAC
12
7
65
7
65
Gray
Black
Orange
Yellow
Gray
Black
White
White
P7-4 P7-3
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
16
Wiring Information
RS485 Communication - Master Mode
SBD 3200/3300 Series Wired Clock
SBD 3300 Series Wired Clock
Brown Purple
Yellow/Black
Orange/White
Black
White
Black
White
P7-3 P7-4
P7-1
P7-2
P7-3
P7-4
24VAC or 120VAC or
240VAC
24VAC or 120VAC or 240VAC SRM Series RS485 Clock
24VAC or 120VAC or 240VAC SRM Series RS485 Clock
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
17
Wiring Information
3-Wire Synchronous (Sync-Wire) Communication 24 Volt Wiring Information
SMA 2000 or 3000 Series Master Clock
24VAC
24VAC SBD 3300 Series Digital Clock
Wiring Information
P1-1
P1-3
24VAC SAM Series Analog Clock
24VAC SAM Series Analog Clock

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
18
Wiring Information
3-Wire Synchronous (Sync-Wire) Communication 120 Volt Wiring Information
SMA 2000 or 3000 Series Master Clock
120VAC
SBD 3300 Series Digital Clock
P1-1
P1-2
120VAC SAM Series Analog Clock
120VAC SAM Series Analog Clock
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
19
3-Wire Synchronous (Sync-Wire) Communication 240 Volt Wiring Information
SMA 2000 or 3000 Series Master Clock
240VAC
SBD 3300 Series Digital Clock
P1-1
P1-2
240VAC SAM Series Analog Clock
240VAC SAM Series Analog Clock
Wiring Information
Wiring Information

The Sapling Company, Inc.
1633 Republic Road
Huntingdon Valley, PA 19006
USA
+1 215.322.6063 P.
+1 215.322.8498 F.
www.sapling-inc.com
20
Using the Output Relays on the SBD 3300
Intercom, paging system, or other device
Wiring Information
Output Relay
Green
White
(Relay 1) P3 - 1 & 2
or
(Relay 2) P3 - 3 & 4
Relay Input
Wiring Information
