SATION SS3006.0101 User manual

KNX Biological Presence Detector User Manual
----------------------------------------------------------------------------------------------------------------------------------------------
Zhuhai Sation Technology Co., Ltd | www.sation.com.cn
3F-2,Building B1, No.1 Software Road, Zhuhai Hi-tech Zone, Zhuhai, Guangdong, China 519000
Copyright Clarify
Copyright ownership belongs to Zhuhai Sation Technology
Co., Ltd. shall not be reproduced, copied, or used in other
ways without permission. Otherwise Zhuhai Sation
Technology Co., Ltd. will have the right to pursue legal
responsibilities.
Version
Notice
1. Please read this user manual carefully before using the product.
2. This product is used in indoor environment and installed in
electrical control box.
3. Please install this product in a dry and ventilated place.
4. Before power on, please confirm the input voltage according to
the manual; after power on, please confirm the normal output
Voltage before connecting to the control bus.
5. Please make sure the secure shell is in good condition, if the
shell is damaged, please stop using to avoid accident.
6. This product is NOT a toy, please make sure it is out of children
touch.
7. Only be suitable for EIB/KNX system bus.
8. Others:
The below sign indicates this product can’t be dealt as ordinary
family rubbish, in order to avoid the possible environment and
human health harm caused by the electrical waste, this product
must follow recovery processing. Please contact the local
recycling department after this product is scrapped, to make
sure it can go as the right waste processing procedure.
The user manual refer to the
following devices：
SATION-SS3006.0101
Version Release Date Remark
V1.0 Dec 11st ,2020 1st Release
V1.1 Mar 20, 2022 Add 24GHz Detection

KNX Biological Presence Detector User Manual
----------------------------------------------------------------------------------------------------------------------------------------------
Zhuhai Sation Technology Co., Ltd | www.sation.com.cn
3F-2,Building B1, No.1 Software Road, Zhuhai Hi-tech Zone, Zhuhai, Guangdong, China 519000
1. Technical Parameters
Bus Power supply DC21~31V
Aux Power supply DC12~30 V
Current < 15mA
Power consumption <450mW
Prog Button Press inner cover of sensor
LED indicator Red Light
Motion Detection 8-10Meters in Diameter(Height 3M)
Micro-movement 8-10Meters in Diameter(Height 3M)
Breath Detection 6-8Meters in Diameter(Height 3M)
Sensitivity Adjustable Level 10
Installation Height 2.5-3Meters
Installation Recess Mount
Lux Range 1 lux~60k lux
Working Temperature -5℃~+45℃
Storage Temperature -25℃~+55℃
Temp. During Transport -30℃~+70℃
2. Function Overview
KNX biological presence detector adopts living detection
technology, which can accurately detect movement,fretting and
breathing signal, to achieve real presence detection.
The KNX biological presence detector has a built-in Lux sensor,
which can automatically control the load according to the
environmental illuminance value.
The detection sensitivity is divided into 10 levels (level 1 ~ level
10). Control options include one light group and one HCV channel,
separate control objects for day and night, master-slave function,
support for backup light or indicator control, etc. The HCV channel
can signal the heating equipment, air conditioning, ventilation
equipment and shutter control of the room, etc., to achieve
comprehensive control in a small area.
Main Functions:
* Lux range: 1 lux ~ 60k lux
* Day/night control mode can
be configured independently
and can be switched externally
* Monitor 3 types output data,
such as switch value, dimming
value and scene value.
* Working mode: manual,
automatic/semi-automatic
* Support to set the threshold
value of load brightness
* Supports motion detection
with 1~10 levels of sensitivity
* Support to set load working
cycle and idle cycle.
* Support master and slave
detectors
* Support Lux value output
function, its value can be sent
periodically
* Support brightness change
output switch function
* Lux values can be calibrated
externally and internally.
Notice
* Movement Signal: Large-scale
movement of the body, used for
induction triggering.
* Micro-motion signal: The
sensor detects tiny movements
of the body in real time.
* Breathing signal: In the
absence of micro-motion signal,
the sensor detects the
breathing signal
* LED feedback can be
configured (default activated),
and the normal cycle is 30
seconds to flash once in a
human environment.

KNX Biological Presence Detector User Manual
----------------------------------------------------------------------------------------------------------------------------------------------
Zhuhai Sation Technology Co., Ltd | www.sation.com.cn
3F-2,Building B1, No.1 Software Road, Zhuhai Hi-tech Zone, Zhuhai, Guangdong, China 519000
3. Detection schematic
4. Wiring
1. Programming button 2. Lux sensor and Led indicator
3. Mounting ring 4. Screw fixing holes
5. KNX terminal 6. Aux Power supply
5. Dimension
6. Precautions
1) The sensor enters self-test
mode when first power on,
which take around 20S, In this
mode, sensor do not detect
movement.
2) The sensor should be kept
away from substances with
high medium density such as
large-area metal plates and
glass as far as possible
3) Avoid using objects that
vibrate for a long time around
the sensor, such as shaking
head fans, etc.
4) Avoid invalid light sources
irradiating the detector's Lux
sensor.
5) The microwave sensor has
a certain ability to penetrate
building wall, Microwaves may
cause false alarms when there
are moving objects outside the
fortified area. In order to avoid
false triggering, pay attention
to the select installation
location and the appropriate
detection scope.
