Tynetec ZXT475 User manual

DocNo.FM0599issueCPage1
169MHzTelecareDevices
PIRMovementDetector

__________________________________________________________________________________________________________
 

Passiveinfrareddetector
WalktestLED(disabledduringnormaloperation)
Alarminterval:1or3minutes
UserreplaceableAALithiumbatteries
Lowbatterywarning
Dimensions:121mmx71mmx55mm(HxWxD)
Weight:135grams
TynetecPartNo.ZXT475





WhatcanthePIRMovementDetectorbeusedfor?

ThePIRdetectorcanbeusedfor2differentapplications;
IntruderMonitoring–ifmovementisdetectedanalarmisreported
InactivityMonitoring–ifnomovementisdetectedwithinapresetperiodanalarmisreported


RecommendedLocation

ThePIRshouldbewallmountedathighlevel(2.1m)inthehallwaytomonitormovementbetweenrooms.
IftherearepetsinthehomethePIRshouldbeinvertedandfittedatlowlevel(1m)–seePETALLEYmode.
Toavoidfalsealarmsthereshouldbenomovingobjectsorrapidtemperaturechanges(heatingducts)inthedetectionarea.


TypicalToolsRequired

Becarefulwhenusingstepladders–alwaysfacethedirectionyouareworking.
Adrillisnotrequirediftheselfadhesivefixingpadisused.
Alwaysmakesurethecorrectdrillbitsandscrewdriversareused.


Installation–UsingScrewFixings

1. UndoSCREW“A”fromthebottomofthedetectorandremovethe  UP
completelidassembly.

2. Drill‐outthe2mostsuitableFIXINGHOLES“B”insidetherearsection.
Usethisasatemplatetomarkthewall.

3. Beforedrillingthewallbesuretherearenoelectricalcables  NORMAL
orplumbingunderthesurface.ORIENTATION

4. Usethescrews&plugsprovidedtofixtherearsectiontothewallSCREW“A”
notingthecorrectorientation(seenextpageforPETALLEY).

5. Removetheinsulatingtabtoconnectthebatteries,
refitthelidandtightenthescrew.    FIXINGHOLES“B”  B


Installation–UsingSelfAdhesivePadsB B

UndoSCREW“A”andremovethelidassembly.
Removetheinsulatingtabtoconnectthebatteries.B  B
Refitthelidandtightenthescrew.
Selectthebestlocationwherethewallsurfaceisclean,dryandeven.
Sticktheadhesivepadtotherearofthedetector.
Pressthedetectorfirmlyagainstthewallensuringitisstucksecurely.



Tynetec,abusinessunitofLegrandElectricLtd
Unit10CowleyRoad,BlythRiversideBusinessPark,Blyth
Northumberland,NE245TF.Tel:01670352371Fax:01670362807
Email:[email protected]Web:www.tynetec.co.uk

DocNo.FM0599issueCPage2
PetAlleyModeUP

TopreventpetscausingfalseactivationsthePIRdetector
mustbeinvertedandfittedatlowlevel(1m).    PETALLEYORIENTATION

Whenfittedinthismodeanymovementbelow    FITATLOWLEVELWITHLEDATTHETOP
the1mlevelwillgoun‐detected.

Resultsbasedontestsina4mx4mroom.


WalkTestMode

Toenterthewalktestmode;

1. UndothescrewandremovethePIRlid
2. Waitforabout5secondsDETECTION
3. RefitthelidPATTERN
4. ThefrontredLEDwillflashrapidly8timesTOPVIEW

Younowhave3minutestoperformawalktest.

TheredLEDwillflashoncewhenmovementisdetected.

NOTE:therearenoradiotransmissionsduringawalktest.

AttheendofthewalktestperiodtheredLEDwill
flashrapidly8times.

ThePIRisnowinnormaloperatingmodeand 
theLEDwillNOTflashwhenmovementisdetected.






TamperSwitch

WhenthePIRlidisremovedthetamperswitchwilloperateandtransmitanalarmsignal.Thiswillalsocheckthebatterycondition
(andreportanalarmiflow)toassistServiceEngineers.

ThetamperswitchshouldbeactivatedwhenlearningthePIRontotheSayPhone,Reach,AdventxtorAltecResponse.
Seepage4forhowtoputeachoftheseproductsinto“LearnMode”.

Therangeofallradiodevicescanbeaffectedbytheworkingenvironment‐alwaystakecareduringinstallation
andperformseveraltestcalls.


DILSwitchSettings

The2wayDILswitchinsidethePIRdetectorisusedtosetthesensitivityandalarminterval;

DILSwitchNo.&FunctionOFF(Default)ON

SW1=PulseCount(Sensitivity)2pulsestotrigger3pulsestotrigger
SW2=AlarmIntervalTime3minutes1minute

IffalsealarmsareaproblemtrysettingDILswitch1ONtoreducethesensitivity.
AfteranactivationthePIRturnsitselfoffforthealarmintervaltimetoconservebatterypower.
Duringthealarmintervalperiodmovementisnotdetected.















NORMALDETECTION
PATTERN‐SIDEVIEW
PETALLEYDETECTION
PATTERN‐SIDEVIEW

DocNo.FM0599issueCPage3
Maintenance

Noroutinemaintenanceisrequired;howeverawalktestshouldbeperformedonceayeartoverifyoperation.
PIR’sarenotassusceptibletodustandcontaminationassomedetectorsbutitisstillrecommendedtocleanthemperiodically.
PIR’scanbedustedorwipedcleanwithadampcloth,neverusedetergentsorpolish.


Decorating

NeverpaintthePIRdetectoritself.
Unlikesomedetectors,PIR’sarenotsusceptibletocontaminationfrompaintfumesthereforenospecial
precautionsneedtobetaken.


BatteryLife

Undernormaloperatingconditions(40activations/day)the
PIRbatteriesshouldlastforupto2years.

Thebatteriesarecheckedeveryday,ifthevoltagefallsandstaysbelowapresetlevel
a“lowbattery”callisautomaticallysenttotheControlCentreorLocalManager.

Anotherlowbatterycallwillnotbetransmittedfor7days.

Thebatteriesshouldbereplacedwithin2weeksofthefirstlowbatterywarning.

Replacementbatteries:2xAAsizeEnergizerLithium–alwaysreplaceinpairs.

Takecaretorefitthebatteriesinthecorrectpolarity.

DetailedinformationonbatterymanagementforallTynetecproductsisavailableinaseparatedocument.
ContactTynetec’scustomersupportdeptandrequestacopyofDocNo.FM0630.


ProductReturns

Intheunlikelyeventthattheproductisfoundtobefaultyordevelopsafaultitmustbereturnedtothepointofsalewithproofof
purchase,adescriptionofthefaultandbothbatteries(disconnected).


OperatingEnvironment

Thisproductisintendedforuseinsidedomesticenvironments,itisnotforoutdooruse.Forapplicationsinenvironmentswhere
conditionssuchashumidity,temperature,vibrationandnoisedeviatefromthoseofahomepleasecontactthemanufacturer
withthedetails.

Thisunitisdesignedtodetectmovementandactivateanalarm,beingonlyapartofacompletesystem,noresponsibilitycanbe
acceptedforanydamagesorotherconsequencesresultingfromanintrusion.


ConditionstoAvoid

Rapidvariationintemperature
Highvibrationorshocks
Exposuretodirectsunlightorpowerfullights
Exposuretowind,airconditioningorheating
ItemsblockingthePIRdetectorfieldofview


ElectricalApprovalSummary

RFImmunity/EMC: EN61000‐4‐2
  EN61000‐4‐3
  EN61000‐4‐4

RadiatedEmissions:EN55022(B)

Radio: EN300‐220
+
+

DocNo.FM0599issueCPage4
LearningthePIRDetectorontoaSayPhoneV2…

1. TurntheSayPhoneV2off,re‐applypowerandthefrontlightwillflashRED/AMBER/GREEN.
2. WhenthelightisflashingpresstheREDbuttononce–theSayPhoneV2willannounce
“TriggerRadioDevice”andthefrontlightwillgosteadyAMBER.
3. ActivatethePIRtamperswitch–theSayPhoneV2willannounce“MovementSensor”.
4. PresstheGREENbuttonontheSayPhoneV2andwaitforabout12secondsuntilthefront
lightgoessteadyGREEN.
5. CheckwiththeControlCentrethatitisconvenienttoperformatestcall,activatethePIRandconfirmthey
receivethecorrectcalltype.
6. SeetheSayPhoneV2installation&programmingguide(TynetecDocNo.FM0546)formoreinformation.

LearningthePIRDetectorontoaSayPhone21…

1. TurntheSayPhone21off,re‐applypowerandthefrontlightwillflashRED/AMBER/GREEN.
2. WhenthelightisflashingpresstheGREENandGREYbuttonstogether,thedisplay
willshowLearnTrigger–RadioLearn.PresstheREDbuttontoconfirm.
3. ActivatethePIRtamperswitch–theSayPhone21willannounce“MovementSensor”andthedisplaywill
promptyouforaDeviceLocation.
4. UsetheGREYbuttonstoselecttheappropriate2digitlocationcode(listedintheSayPhone21
installationmanual)thenpresstheREDbuttontoconfirm.
5. ThedisplaywillchangetoshowTriggerMessage–presstheREDbuttonseveraltimestoexitthismode.
6. PresstheGREENbuttonontheSayPhone21andwaitforabout12secondsuntilthefrontlightgoes
steadyGREEN.
7. CheckwiththeControlCentrethatitisconvenienttoperformatestcall,activatethePIRandconfirmthey
receivethecorrectcalltype.
8. SeetheSayPhone21installation&programmingguide(TynetecDocNo.FM0450)formoreinformation.

LearningthePIRDetectorontoaReachorReachPlus…

1. PressandholdtheGREENbuttonuntiltheReachannounces“TriggerRadioDevice”andthefrontlight
startsflashingGREEN.
2. ActivatethePIRtamperswitch–theReachwillannounce“MovementSensor”.
3. PresstheGREENbuttontoexitthelearnmode.
4. CheckwiththeControlCentrethatitisconvenienttoperformatestcall,activatethePIRandconfirmthey
receivethecorrectcalltype.
5. SeetheReachinstallation&programmingguide(TynetecDocNo.FM0621)ortheReachPlusinstallation&
programmingguide(TynetecDocNo.FM0662)formoreinformation.

LearningthePIRDetectorontoanAdventxt…

1. PresstheLINEkeyontheManagersDECTtelephoneandwaitforthe“Ready”prompt.
2. Enter5000followedbythekey.
3. EntertheflatnumberthePIRisbeinginstalledinfollowedbythekey.
4. ActivatethePIRtamperswitchandwaitforthe“EnterLocationCode”prompt.
5. Entertheappropriate2digitlocationcode(listedinAdventxtuserguide)orpress#andwaitforthe
“PendantEnabled–EnterFlat”prompt.
6. Pressthe#keytoexitthemodefollowedbytheLINEkeytocleartheconnection.
7. ActivatethePIRandcheckthecorrectcalltypeisreported.
8. SeetheAdventxtuserguide(TynetecDocNo.FM0420)formoreinformation.

LearningthePIRDetectorontoanAltecResponse…

1. FromthemainmenudisplayselectRadioDevicesandpresstheENTERkey.
2. PressENTERagainandthedisplaywillpromptyouto“TriggertheSensor”.
3. ActivatethePIRtamperswitch–thedisplaywillshowthedevicetypeandits8digitIDnumber.
4. PressthekeytoselectAcceptthenpressENTER.
5. ThedisplaywillshowFlat,usethe&keystochoosethedwellingtypefromthelist.
6. PressthekeytoselectNo:000000thenpresstheENTERkey.Usethe&keystoselecteach
digitoftheflatnumberandthe&keystomovebetweendigitsthenpresstheENTERkey.
7. PressthekeyandthedisplaywillshowNoLocation,usethe&keystochoosetheappropriate
devicelocationfromthelist.
8. PressthekeyseveraltimestoselectExitthenpresstheENTERkey.
9. ActivatethePIRandcheckthecorrectcalltypeisreported.
10. SeetheAltecResponseuserguide(TynetecDocNo.FM0548)formoreinformation.






Tynetecoperatesapolicyofcontinuousimprovementandreservestherighttochangeproductspecificationswithoutnotice.
IfanyvariationtothedetailscontainedinthisdocumentaresuspectedpleasecontactTynetec’scustomersupportdepton01670352371.
