OVS-01CC Quick Reference Guide
[1] Make holes to mount the sensor. [2] Run a cable thru the post or pole.
[4] Fix the base using 4 screws. [5] Connect wires.
3.
Set the Microwave maximum range.
Recommended to set the range 1m(3.28ft.) shorter than the
actual width of the road.
4. Perform calibration in order to memorize the
background of the detection area. Ensure no
pedestrians or vehicles are present.
Calibration Area Check
Standby
Area Check
Detection
Calibration
1. Press the Calibration button.
2. Operation indicator blinks in blue.
5. System operation check.
Check the entire coverage area by using actual vehicle.
[6] Attach the sensor body to the base
and adjust the sensor angle.
6. Put the front cover on the top of the base first, and attach it
while spreading it open and pushing down the front cover.
7. Tighten the front cover retaining screw.
[3] Loosen the retaining screws on the bottom
of the front cover and remove the front
cover, detach the sensor unit.
Hold here and
pull forward
2. Install the sensor, wire it and apply power.
GL+588(23.15)
Mounting
Pitch 32±1
(1.26±0.04)
Mounting Pitch
70±1(2.76±0.04)
5(0.20)
M4 Tap
Depending on the
cable diameter
[Unit : mm(inch)]
1. Install the pole for the sensor in the following layout configuration.
Installation height: 500mm(19.69in.) from the ground to the bottom of the sensor
Installation angle: 90 degrees to the vehicle direction of travel.
Sensor
Vehicle Path
90°
Calibration
Maximum Range (m)
Output1
5 6 7 8
1 2 3 4
N.O.
N.C.
Output2
N.O.
N.C.
Maximum Range Botton
Left side of the lane
Center of the lane
Right side of the lane
Sensor
Power Supply 12-24VDC
Power Output1 Output2
Applicable Wire
Single conductor: 0.5-1.2mm (equivalent to CPEV)
Stranded wire: 0.3-2.0sq
Non-Voltage Relay Output N.O./N.C. Switchable
30VDC 0.3A or less (resistance load)
Non-Voltage Relay Output N.O./N.C. Switchable
30VDC 0.3A or less (resistance load)
Two way traffic lane : Install the sensor on the the lane of traffic you wish to monitor.
The sensor cannot detect a vehicle in the opposite lane.
Road to
be detected
Road not to
be detected
Road to
be detected
Road not to
be detected
500mm(19.69in.)
