SATO M-5900RV User manual

Page 1-1
M-5900RV Printer
Parts List
Industrial Bar Code Printers
P/N 9001084
Rev. A
®

Rev. APage 2
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Table of Contents
M-5900RV Page
Parts List
Frame Assembly........................................................................................................3
Base Cover Assembly...............................................................................................6
Thermal Head Assembly...........................................................................................9
Cover Assembly ......................................................................................................12
Main PCB Assembly................................................................................................14
Centronics PCB Assembly .....................................................................................15
Cutter Unit Option ...................................................................................................16
Dispenser Unit Options ..........................................................................................17

Page 3
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Frame Assembly
*
*
*
THESE ITEMS INCLUDED IN THIS
PART NUMBER
*

Rev. APage 4
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Frame Assembly

Page 5
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Frame Assembly
NO. CODE DESCRIPTION QTY
1 PA2520600 Side frame 1
2 PB2520200 Collar (A) 1
3 MA0401021 Pan head screw 1
4 PV9720200 Bush 1
5 PA2520700 Side frame (B) 1
6 PB2520200 Collar (A) 1
7 MA0401021 Pan head screw 1
8 PA3522500 Frame bracket 1
9 MH4300821 S-tight screw 4
11 PA3522600 Paper guide 1
12 MH4300821 S-tight screw 4
13 PE1570801 Sensor cover 2
14 PA3523700 Bracket 1
15 MH4300621 S-tight screw 3
16 PE3520400 Roller (A) 2
17 PE3520500 Roller (B) 2
18 MA0301022 Pan head screw 2
21 PE2520300 Collar (A) 1
22 PC1520200 Roller spring 1
23 PE3520101 Roller (A) 1
24 PM6401200 Metal (B) 1
25 PT9520400 Spacer 1
26 MH0300821 P-tight screw 1
27 PE1520300 Label guide shaft 1
28 MH0300821 P-tight screw 1
31 PR7520100 Stepping motor 1
32 PR7520200 Motor pulley 1
33 PT8122064 Timing belt 1
34 PA3522700 Sensor bracket (bottom) 1
35 MD4300621 Pan head screw 2
40 RJ3520000 Sensor PCB 1
41 RH1523300 Head open switch 1
42 MD3201221 Pan head screw 2
43 PR1520300 Platen roller 1
45 PA1680200 Supporter clamp 1
46 MD4300621 Pan head screw 1
47 MD4300821 Pan head screw 5

Rev. APage 6
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Base Cover Assembly

Page 7
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer SParts List
Base Cover Assembly

Rev. APage 8
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Base Cover Assembly
1 PR3521500 Base frame 1
2 PT6680100 Rubber foot 4
3 PH1523200 Center frame 1
4 MH4300621 S-tight screw 3
5 PH1523300 Front plate 1
6 MH4300621 S-tight screw 5
7 PV9520300 Bush 1
8 PZ0521600 Rear cover 1
9 MH4300621 S-tight screw 3
10 MD4300821 Pan head screw 3
11 PA1729000 Cover (memory card) 1
12 MD4300821 Pan head screw 1
13 NB2040022 Toothed lock washer 1
14 MT1400722 Hex nut 1
15 PE1720300 Label stopper 1
16 PA3524000 Label unwind bracket 1
17 PA4520300 Stopper spring 1
18 NA1003022 Plain washer 1
19 MH0300821 P-tight screw 1
20 MD4300821 Pan head scrw 4
23 PE1520600 Rewind shaft bracket 1
24 MH4300821 S-tight screw 3
25 PE2520101 Spacer 1
26 MA0401621 Pan head screw 1
27 PA3526000 PCB bracket 1
28 MD4300821 Pan head screw 3
31 KA500801A Power supply unit EX1 1
33 MD4300821 Pan head screw 2
34 GA200301A Switch 1
35 HJ300081A Inlet 1
36 MD4300821 Pan head screw 2
37 RH1523000 POW cable set 1
39 RH1525100 AC cord set (2) 1
40 RH1525200 AC cord set (3) 1
41 QC6523700 Sticker 1
43 PH2520801 Cover 1
45 RH1525500 AC cord set (4) 1
46 RH1525600 AC cord set (5) 1
NO. CODE DESCRIPTION QTY

Page 9
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Thermal Head Assembly

Rev. APage 10
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Thermal Head Assembly

Page 11
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Thermal Head Assembly
1 PA3522800 Head bracket 1
2 PC1520100 Head spring 2
3 PA2520300 Head adjustment plate 1
4 MP7300522 Hex bolt 2
5 PA3525200 Tear off Bar 1
9 GH000421A Thermal head 1
14 MD4300821 Pan head screw 1
16 MH0250621 Screw 1
19 RH1520900 Head cable set 1
20 PA3523300 Sensor bracket (up) 1
21 PE1631200 Sensor bracket 1
22 MD4300621 Pan head screw 2
25 RH1522200 Sensor Assy 1
26 PA4520200 Paper pressure 1
27 MD4300621 Pan head screw 2
31 PA3523000 Head bracket 1
32 PB0520800 Head shaft 1
33 MA1300422 Flat head screw 1
34 MH4300821 S-tight screw 1
35 NA1003022 Plain washer 1
36 ND0070030 E-snap ring 1
37 PA3523400 Latch lever 1
38 PC2520100 Torque spring 1
39 PC2520201 Torque spring 1
41 PB2520200 Collar (A) 1
42 PB2520300 Collar (B) 1
43 MJ9401021 Shin head screw 2
44 PA2521000 Adjust plate 1
45 PB5550100 Adjust nut 1
46 MD4300621 Pan head screw 2
47 MD4300821 Pan head screw 1
48 PE1520100 Lever guard 2
NO. CODE DESCRIPTION QTY

Rev. APage 12
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Cover Assembly

Page 13
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Cover Assembly
1 PH0520700 Front cover (A) 1
2 MH0300821 P-tight screw 5
3 PH0520800 Dip switch cover 1
4 PH2520700 Panel 1
5 PE1520800 Button 1
7 PZ0521700 Front cover (B) 1
8 MH0300821 P-tight screw 4
9 PH1523500 Cover (RH) 1
10 MD4300621 Pan head screw 2
11 PH1523601 Cover (LH) 1
12 MD4300621 Pan head screw 4
15 RJ5520001 LCD display 1
16 RJ2522020 KB PCB set 1
17 RH1770500 KB cable set 1
18 MH0300821 P-tight screw 1
21 PG0520100 Shield 1
NO. CODE DESCRIPTION QTY

Rev. APage 14
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Main PCB Assembly
1 RJ1522300 Main PCBsub assy(W/O ROM) 1
5 JG900411A Cap 1
6 MD4300821 Pan head screw 6
NO. CODE DESCRIPTION QTY

Page 15
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
2
Centronics PCB Assembly
1 RJ1772001 Parallel Interface 1
2 RJ1771200 Serial Interface 1
NO. CODE DESCRIPTION QTY

Rev. APage 16
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
1 PR7522100 Cutter set 1
2 MD4300621 Pan head screw 2
3 MH4300621 S-tight screw 2
4 RJ4520100 Cutter PCB 1
5 MD4300621 Pan head screw 2
6 RH1683400 FG liner 1
7 RH1522600 Cutter cable 1
NO. CODE DESCRIPTION QTY
Cutter Unit Option

Page 17
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Dispenser Unit Option

Rev. APage 18
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Dispenser Unit Option

Page 19
SATO Industrial Bar Code Printers
Rev. A SATO M-5900RV Printer Parts List
Dispenser Unit Option

Rev. APage 20
SATO M-5900RV Printer Parts List
SATO Industrial Bar Code Printers
Dispenser Unit Option
1 PA3523100 Dispense bracket 1
2 PT9690500 Cap 1
3 PB0521300 Pressure guide (A) 2
4 PB0521500 Dispense br shaft 1
5 ND0060030 E-snap ring 2
6 PB5550100 Adjust nut 1
7 MD4300821 Pan head screw 2
8 PB0521600 Dispense roller shaft 1
9 PE3520600 Dispense roller 5
10 ND0020030 E-snap ring 1
11 PR1520200 Pressure roller 1
12 PB0521800 Pressure roller shaft 1
13 ND0040030 E-snap ring 2
15 PA3523200 Dispense sensor bracket 1
16 PE1570300 Dispense sensor bracket 2
17 MH0250621 P-tight screw 2
18 RH1522900 Dispense sensor 1
19 MH4300621 S-tight screw 2
22 PA2520800 Dispense bar 1
23 MD4300621 Pan head screw 1
24 PB0521400 Pressure guide (B) 2
25 MD4300621 Pan head screw 2
26 PC2520300 Pressure spring 2
29 PB0522401 Shaft (rewind) 1
30 PA0520300 Rewind plate 1
31 PA1520500 Tension plate 1
32 PE2520500 Guide collar 1
33 PC1520400 Spring (Rewind) 1
34 PA0770100 Frange 1
35 PJ4770100 Facing 2
36 PE8770400 Pulley (50) 1
37 PE7770100 Frange 1
39 PA3525300 Rewind frame 1
40 PT1112080 Ball supporter 2
41 PT8134064 Timing belt 1
42 ND0060030 E-snap ring 2
43 MD4300621 Pan head screw 2
44 MA0300621 Pan head screw 2
NO. CODE DESCRIPTION QTY
