SATO M-8485Se Series User manual

M8485S e - High Speed OEM Printer
www.satoamerica.com
Throughput
The M8485S e continues to set the benchmark for OEM printer performance in automatic
label applicator systems. Utilizing the latest in 32-bit microprocessor technology, along
with 16 MB of standard RAM, the M8485S e provides virtually instantaneous “time to
first label out”. When printing at its maximum speed of 12 ips, the M8485S e is capable
of handling your most demanding automatic print apply application, especially those
where data changes on every label.
Interchangeable
The height, width and location of mounting holes are identical to earlier SATO OEM print
engines, making it easy to upgrade to the M8485S e . Plus, the M8485S e is compatible
with the programming commands for the M8400S and the M8485S, making it a simple
drop-in replacement.
Host Interface Flexibility
Designed with a modular interface slot, the M8485S e allows for a wide variety of interface
options to be easily installed and field upgraded. These bi-directional interfaces include
a high-speed IEEE1284 Parallel (ECP), RS232C Serial, 10BaseT/100BaseTX Ethernet
and 802.11g Wireless Ethernet.
Legendary Reliability
Your labeling application is demanding and uptime is paramount. The M8485S e was
designed to provide reliable performance over extended periods of time. It was
specifically developed as a high-duty cycle applicator print engine...it is not a repackaged
desktop printer. Even the heavy gauge steel enclosure was designed for production
environments. Yet, internal access for maintenance is simple.
OEM SOLUTIONS
The “Standard” for all automatic print & apply Labeling
The industrial OEM high-speed
printers are ideal for a range of
applications, including:
Compliance Labeling
Warehouse Logistics
Pallet Tracking
Retail Labeling
Product Authentication
Cross-Docking
Shipping Labels
Weigh-Scale Labeling
RFID Labeling (optional)
The M8485S e is the “standard” print engine used in print apply applications around the world. With its 5" print width and maximum
print speed of 12 inches per second, the M8485S e is your first choice for high-speed labeling applications.

SATO America, Inc.
10350-A Nations Ford Road, Charlotte, NC 28273
Phone: [phone] Fax: [phone]
E-mail: [email protected]
www.satoamerica.com
© 2006 SATO America, Inc. All rights reserved. Specifications subject to change without notice. Rev. 07/06
Brand or product names are trademarks and registered of their respective companies.
SPECIFICATIONS
Printing Method
Print Resolution
Print Speed
Max. Print Area
Media Size
Ribbon Size
Dimensions
Weight
M8485S e
Thermal Transfer/Direct Thermal
203 dpi (8 dots/mm)
Up to 12"/s (300mm/s)
5" (128mm) W x 49.2" (1249mm) L
Max. 5.27" (134mm) W
Min. 1" (25mm) W x 0.24" (6mm) L(1)
5.25" (133mm) W x 1968' (600m) L
Min. 1.6" (39.5mm) W, Face-In Wind
9.7" W x 16.1" D x 11.7" H
(245mm W x 408mm D x 298mm H)
25 lbs. (11.34 kg)
(1)Minimum label length at print speeds greater than 6 ips is 1 inch.
Memory:
16 MB Standard RAM
2 MB Standard Flash
1 MB PCMCIA - Optional
6 MB Optional Flash - Total
Processor:
32-BIT RISC
Media:
Die cut labels, plain paper facestock & synthetics.
Maximum unwind torque: 8 ft./lbs.
Back feed:
Adjustable, ± 10" (255mm)
Sensing:
Transmissive sensor for die cut labels & tags.
Reflective sensor for use with preprinted sensing
marks. Automatic, programmable setting to top of
form.
External Connector:
Ext. (Applicator I/F): 14-pin Amp
Plug-In Interface Modules:
• Serial - RS232C (up to 57.6k bps)
• Parallel - IEEE1284 (ECP)
• Ethernet - 10BaseT/100BaseTX
• Wireless 802.11g
• RS422/485
Barcode Symbologies:
LLiinneeaarr::
UPC-A, UPC-E, EAN-8, EAN-13, Code 39,
Code 93, Code 128, Codabar, MSI, Bookland,
Industrial 2/5, Interleaved 2/5, Matrix 2/5, Postnet,
UCC/EAN 128, RSS, Composite
22--DDiimmeennssiioonnaall::
PDF417, Micro PDF417, Truncated
PDF417, Maxicode, Data Matrix, QR Code
Fonts:
Bitmap - 12 proportional, mono-spaced and outline
fonts (Code table 858). Internal CG Triumvirate &
CG Times fonts scalable from 2 to 99 points.
Optional downloaded TrueType fonts.
Barcode & Font Formatting:
360° rotation of barcodes and text, character
expansion horizontally and vertically, sequential
numbering, form overlay for high-speed editing of
complex formats.
Graphic Support:
Printing & storage of .PCX, .BMP format, SATO
Hex/binary
Software:
Windows®Drivers (Windows®95, 98, ME, NT4.0,
2000, XP)
“Label Gallery Free” - Label Software
Printer Utilities
Electrical Requirements:
115V/220V (± 10%), 50/60 Hz (± 1%)
Auto-switching
Agency Certifications: CE, UL, CSA, TÜV,
FCC Class A
Environmental Requirements:
Operating: 41° to 104°F (5° to 40°C)
15-85% RH, non-condensing
Storage: 23° to 140°F (-5° to 60°C)
Max. 90% RH, non-condensing
Other Features:
• Standard Real Time Clock
• Optional Opposite Hand Models
• Optional 4 MB Flash Memory
• Optional RFID Capability
