Savant IDC-T00L User manual

The Savant™ In-Wall Wireless Charging Dock for Apple® iPod touch® Quick Reference Guide
includes information to install the IDC-T00L, IDC-TMPL and the IBB-T00L. The IDC-T00L is
comprised of one IDC-TMPL (Mounting Plate) and one IBB-T00L (Back Box).
IDC-T00L with Bezel and TrueControl®App II
Specifications
Environmental
Environmental
Temperature
32° to 104° F (0° to 40° C)
Humidity
10% to 90% Relative Humidity (non-condensing)
Dimensions and Weight (without bezel)
Dimensions and Weight (without bezel)
Height
7.29 in/18.51 cm
Width
3.63 in/9.23 cm
Depth
2.50 in/6.35 cm
Weight
4.0 lb/1.81 kg (shipping weight)
Dimensions and Weight of Bezel (sold separately)
Dimensions and Weight of Bezel (sold separately)
Height
7.40 in/18.80 cm
Width
3.75 in/9.53 cm
Depth
0.17 in/0.44 cm
Weight
1.5 lb/0.680 kg (shipping weight)
Power
Power
Supply
24V DC, 120-240V AC, 50/60 Hz
Maximum Power
8 Watts
Power Cable Length
300 ft/100 meters maximum (AWG 22 minimum)
Compliance
Compliance
Safety and Emissions
FCC Part 15 | CE Mark | C-Tick
RoHS
Compliant
NOTE: Overall dimensions for dock, not cut out dimensions.
SURGE PROTECTION: Use a surge-protected circuit for all components requiring 120-240V
AC, 50/60 Hz source power.
ELECTRIC SHOCK: The 100-240V AC, 50-60 Hz source power poses an electric shock hazard
that has the potential to cause serious injury to installers and end users.
ELECTRICAL DISCONNECT: Remove power before working on the dock.
IDC-T00L with Bezel and Back Box
LQ PP
LQ PP
12%(=(/
LQ PP
LQ PP
LQ PP
LQ PP
LQ PP
LQ PP
LQ PP
,1,7,$/'5$:,1*
72''5 
5(9 &5($725 (&2
'$7( '(6&5,37,21

:,7+%(=(/

6$9$176<67(06//&
35235,(7$5<
&21),'(17,$/
0$7(5,$/
),1,6+
7,7/(
6,=( 81,76 ':*12 5(9
6&$/( 6+((7
7+,6'2&80(17
&217$,16&203$1<
35235,(7$5<
,1)250$7,21$1',6
12772%(
5(352'8&('25
',675,%87('
:,7+28735,25
$87+25,=$7,21
3(56(9(5$1&(:$<
+<$11,60$
),1,6+
0$7(5,$/
287/,1('5$:,1*)25,'&7/
 
2) 
,1&+
%
72/(5$1&('$7$7$%/(
81/(6627+(5:,6(63(&,),('
00
,1
;
;;
;;;
;;;;
$6127('





$6127('

$1*/(
72548(
'(*

6&5(:72548('$7$
6,=(,7(0 72548(9$/8(
Back Box - IBB-T00L
Important: Always locate the studs and utilities (electrical wires, ducts, water and gas
pipes) before cutting an opening in the wall. Ensure all required power and control cables have
been routed to the site of back box.
Savant requires that the Back Box be installed in the wall before installing the iOS device in the
Mounting Plate.
NOTE: The In-Wall Dock Assembly is not a weather resistant unit. Do not locate in a damp or
humid area.
View of IBB-T00L
Box Contents
(1) Back Box for In-Wall-Dock (093-0812-xx)
(1) Cut out template (009-0928-xx)
(1) Quick Reference Guide (this document)
Installation of the Back Box
1. Align the box to the stud, if available. Back box can be either horizontal or vertical.
2. Attach the box to the stud using nails/screws provided by the installer or use the flags that
are attached to the Back Box. Do not use a powered screwdriver to tighten the tabs; the tabs
can be easily over tightened.
3. Feed power cable through selected knockout and tie off rough wires, as required.
Mounting Plate - IDC-TMPL
View of IDC-TMPL
Box Contents
(1) Mounting Plate for In-Wall Wireless Charging Dock (168-0042-xx)
(1) Installation Kit (075-0150-xx)
•(1) 24V DC 60 Watt Power Supply (025-0046-xx)
•(1) Power Cable (2 ft) (064-0048-xx) or appropriate International cord
•(1) 2-position Phoenix Connector (028-9160-xx)
•(4) 6-32 x ½” Phillips Flat Screws (039-0262-xx)
(1) Quick Reference Guide (this document)
Accessories
In-Wall Dock Bezel (BXX-T00LX-xx)
See Tech Specs for style, color options, and quantity for bezels.
Installation of the IDC-TMPL
1. Loosen the locking screw (1) on the Mounting Plate.
2. Place the iOS device in the Mounting Plate onto the Lightning Connector.
3. Tilt the iOS device to close and secure to the Mounting Plate with the locking screw.
4. Verify the polarity with the connector label on the back of the Mounting Plate.
5. At the wall opening, insert and secure the 24V DC connector into the Dock.
6. Insert the Mounting Plate into the Back Box using the (4) screws provided and level the iOS
device, if necessary.
7. Attach bezel with magnets.
8. Configure using RacePoint Blueprint™.
In-Wall Wireless Charging Dock
for iPod touch®
Quick Reference Guide
009-0905-01
IDC-T00L-00
IDC-TMPL-00
IBB-T00L-00
042913
Document based upon target specifications. Specifications subject to change prior to final product release.
All manuals and user guides at all-guides.com
all-guides.com

Rear View of Mounting Plate with Cable
Charging Dock Pinouts
Charging Dock Pinouts
+
24V DC In
-
24V DC Return
Additional Documentation
Additional Documentation is available at: dealers.SavantSystems.com
Knowledge Base > Savant Hardware > iOS Docks > Control Docks > iPod touch and
iPhone
In-Wall Wireless Charging Dock
for iPod touch®
Quick Reference Guide
009-0905-01
IDC-T00L-00
IDC-TMPL-00
IBB-T00L-00
042913
Document based upon target specifications. Specifications subject to change prior to final product release.
'(6&5,37,21
&5($725 (&2 
127(681/(6627+(5:,6(63(&,),('
5(9 &5($725 (&2
'$7( '(6&5,37,21
86('6285&()253$57)$%5,&$7,217+,6'5$:,1*,672%(86(')253$57
,163(&7,21$1'&5,7,&$/',0(16,2167+$7$))(&7),7)250$1')81&7,21
0$5.3$57180%(55(9'$7(0$18)$&785(521
$%8/.3$&.$*,1*
%21352'8&7$66+2:1

6$9$176<67(06//&
35235,(7$5<
&21),'(17,$/
0$7(5,$/
),1,6+
7,7/(
6,=( 81,76 ':*12 5(9
6&$/( 6+((7
7+,6'2&80(17
&217$,16&203$1<
35235,(7$5<
,1)250$7,21$1',6
12772%(
5(352'8&('25
',675,%87('
:,7+28735,25
$87+25,=$7,21
3(56(9(5$1&(:$<
+<$11,60$
),1,6+
0$7(5,$/
,32',1:$//&$%/(9,(:
'5$:,1*B180%(5 
2) 
,1&+
%
72/(5$1&('$7$7$%/(
81/(6627+(5:,6(63(&,),('
00
,1
;
;;
;;;
;;;;
$6127('





$6127('

$1*/(
72548(
'(*

6&5(:72548('$7$
6,=(,7(0 72548(9$/8(
Copyright © 2013 Savant Systems, LLC. SAVANT and RacePoint Blueprint are trademarks of Savant Systems, LLC.
All brand names, product names and trademarks are the property of their respective owners.
Savant Systems, LLC reserves the right to change product specifications without notice.
