Savant OWC-200B User manual

On-Wall Charging Dock
(OWC-200B/OWC-200W)
Quick Reference Guide
009-0422-03
OWC-200B-10
OWC-200W-10
Copyright © 2012 Savant Systems LLC, SAVANT and RacePoint Blueprint are trademarks of Savant Systems, LLC.
Apple®, iTunes®, iPod touch®, iPod® Classic and iPod nano® are registered trademarks or trade names of Apple Inc.
All brand names, product names and trademarks are the property of their respective owners.
Savant Systems, LLC reserves the right to change product specifications without notice.
Savant Confidential and Proprietary
091012
45 Perseverance Way, Hyannis, MA 02601 Phone [phone] Fax [phone] SavantSystems.com
The Savant®On-Wall Charging Dock is available in two colors: OWC-2000B (Black) or
OWC-200W (White). This Quick Reference Guide provides the information necessary to
install the On-Wall Charging Dock for Apple iOS devices.
Box Contents
(1) On-Wall Charging Dock (OWC-200B/W)
(1) Cut out template (009-0247-xx)
(1) On-Wall Dock Bezel (074-0191-xxB/W)
(1) Installation Kit – (Black - 075-0108-xx/ White –075-0109-xx)
•(1) Power cord, detachable 10A Plug, 1.83 M, 1250W (014-0035-xx) or appropriate
international cord.
•(1) 24V DC 60 watt Power Supply (025-0046-xx)
•(2) 2-pin Screw Down Connector (028-9160-xx)
•(4) #6 x 1.5 Screw (039-0068-xx)
•(2) #8-32 x 1.75 Screw (039-0147-xx)
•(1) Media Dock Filler Plate (074-0225-xxB/W)
(1) Quick Reference Guide (this document)
Specifications
Environmental
Operating Temperature
32º to 104º F (0º to 40º C)
Operating Humidity
10% to 90% Non-condensing
Maximum BTU
9 BTU/hour
On-Wall Dock - Dimensions and Weight (with bezel)
Dimensions (H x W x D) *
6.53in x 5.0 in x 2.7 in (16.6 cm x 12.8 cm x 6.9 cm)
Weight
0.5 lb/0.23 kg
Power
Supply
24V DC, 120-230V AC, 50/60 Hz
Maximum Power Draw
7Watts
Power cable length
Up to 100 meters (AWG 18)
Compliance
Safety and Emissions
FCC Part 15 | CE Mark | C-Tick
RoHS
Compliant
* Overall dimensions for charging dock, not cut out dimensions.
ELECTRICAL DISCONNECT: The 24V DC power adapter connected to the On-Wall
Charging Dock should be easily accessible in the event of an electrical malfunction.
SURGE PROTECTION: Use a surge-protected circuit for all components requiring 120-
230V AC, 50/60 Hz source power.
ELECTRICAL DISCONNECT: Remove power before working on the dock.
Wiring to Dock
Wiring and Pinouts
Wired Dock 24V DC
+ (Positive)
White
24V DC In
- (Negative)
Black
24V DC Return
Installation without RIB-OWMD Configuration Box
1. Connect the 24V DC power supply to the On-Wall Charging Dock and route through
the wall opening.
2. After making the connections to On-Wall Dock, position the unit in the opening and
secure with the two rotating mounting tabs.
3. Turn the tab screws clockwise; the tabs will grab the interior wall. Tighten until snug.
Do not over tighten.
Caution: Do not use a powered screwdriver to tighten the tabs; the tabs can be easily over
tightened.
4. Position the bezel over the On-Wall Dock and press, ensuring that the wall plate seats
properly.
Note: The On-Wall Dock also has screw-mounting holes for optional stud mounting.

On-Wall Charging Dock
(OWC-200B/OWC-200W)
Quick Reference Guide
009-0422-03
OWC-200B-10
OWC-200W-10
Copyright © 2012 Savant Systems LLC, SAVANT and RacePoint Blueprint are trademarks of Savant Systems, LLC.
Apple®, iTunes®, iPod touch®, iPod® Classic and iPod nano® are registered trademarks or trade names of Apple Inc.
All brand names, product names and trademarks are the property of their respective owners.
Savant Systems, LLC reserves the right to change product specifications without notice.
Savant Confidential and Proprietary
091012
45 Perseverance Way, Hyannis, MA 02601 Phone [phone] Fax [phone] SavantSystems.com
Optional Pre-/Post-Construction Box
The OWC-200B/OWC-200W can be installed with or without an On-Wall construction box.
The On-Wall construction box (RIB-OWMD) is optional and can be used pre-or post-
construction to save the space required for the OWC-200X and to terminate the roughed in
wires.
Note: The On-Wall Dock Assembly is not a weather resistant unit. Do not locate in a damp or
humid area.
Installing the On-Wall Dock into the RIB-IWMD
Place the OWC-200B/OWC-200W into the RIB-OWMD and use the #8-32 screws (2) to
attach
Additional Documentation
For more documentation, go to savantsystems.com and navigate as follows:
>Dealer Login > Knowledge Base > Products
•Refer to the Construction Box for On-Wall Dock (RIB-OWMD) Quick Reference
Guide
•Click link: RacePoint Blueprint™
