Sawgrass Technologies Stylus D88 User manual

Getting Started Guide
For EPSON StylusD88
SubliJetIQ™
Revision 2/2006

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
1
SubliJet IQ
Getting Started Guide
for the
EPSON StylusD88
© Copyright 2005, Sawgrass Technologies, Inc., Revision February
2006. All rights reserved. Printed in the United States of America.
SubliJet®is a registered trademark of Sawgrass Technologies, Inc.
SubliJet IQis a registered trademark of Sawgrass Technologies,
Inc. Epson®and Stylus®are registered trademarks of Seiko Epson
Corporation.
Other trademarks and registered trademarks are the property of their
respective owners.
No part of this manual may be reproduced or transmitted in any form
by any means without the prior written consent of Sawgrass
Technologies, Inc. Information in this manual is subject to change
without notice and does not represent a commitment on the part of
Sawgrass Technologies, Inc.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
2
IMPORTANT – READ CAREFULLY:
This Process License Agreement (“PLA”) is a legal agreement between you and Sawgrass
Technologies, Inc. (“Sawgrass”). By installing the SubliJet IQink in your printer, or otherwise
using the Sawgrass SubliJet IQink, you agree to be bound by the terms of this PLA. Ifyou do
not agree to the terms of this PLA, Sawgrass is unwilling to license the process of using the
SubliJet IQink to you. In such event, you may not use the SubliJet IQink, and you should
promptly contact your supplier for instructions on return of the unopened package.
The process of using the SubliJet IQink is protected by U.S. and foreign patents. Sawgrass will provide
a complete list of the relevant patents upon request. The use of the SubliJet IQink to practice the
patented process is permitted by this license.
GRANT OF LICENSE This PLA grants you the following rights: You may install and use the SubliJet IQ
ink packaged herewith in your EPSON printer to practice the printing process described in U.S. Patent
No. 5,488,907. The use of any ink, dye, or pigment to practice the Sawgrass Process, other than a
SubliJet IQink purchased from Sawgrass or its authorized distributor accompanied by a PLA,is not a
licensed use of the Sawgrass Process. No rights to use the Sawgrass Process, except those specified
herein, are granted, and no rights to use any other process, product, software, or hardware developed or
sold by Sawgrass are granted or implied hereby.
LIMITATIONS ON REVERSE ENGINEERING You agree that you will not attempt to reverse engineer,
reproduce, or deformulate the SubliJet IQink.
PATENTS AND COPYRIGHTS Sawgrass owns multiple U.S. and foreign patents which apply to the
Sawgrass Process and/or the SubliJet IQink or its use. All patents in and to the SubliJetink and the
method of using the SubliJet IQink are owned by Sawgrass Technologies, Inc. You may not copy the
printed materials accompanying the SubliJet IQink. All rights not specifically granted under this PLA are
reserved by Sawgrass Technologies, Inc.
Made In U.S.A.
CAUTION:
For best printing results, use the ink within six months of purchase. Please refer to the
individual ink bag/cartridge for the specific ink expiration date.
Keep out of reach of children.
Do not expose ink to temperatures above 100ºF or below 40ºF.
Keep ink out of direct sunshine.
Sawgrass Technologies, Inc.agrees to replace any defective ink within a reasonable time, which shall be
Sawgrass’ sole responsibility for errors or defects in these goods.
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. SAWGRASS SHALL NOT BE LIABLE FOR LOSS OF PROFIT OR OTHER
ECONOMIC LOSS, OR FOR INDIRECT, SPECIAL, CONSEQUENTIAL OR OTHER SIMILAR DAMAGES.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
3
Sawgrass Technologies, Inc. Limited Warranty
– QuickConnect IITM System
What Is Covered:
Defects in materials or workmanship.
Length of Warranty Coverage:
The warranty coverage for the QuickConnect is one year from date of
purchase. Any QuickConnect not purchased from Authorized Sawgrass
Resellers is not covered.
How to get service:
Please contact Sawgrass Technologies Technical Support at 843-884-
1575 or an Authorized Sawgrass Reseller. A technical support
representative will troubleshoot the issue and provide instructions on
how to get a replacement if necessary.
What we will do:
Provide you with a new, or at our option, a refurbished QuickConnect
unit. Alternatively, at our option, we may refund the purchase price. The
exchange is under warranty for the remainder of the original products’
warranty period or 90 days, whichever is longer. The replacement will be
shipped to you via Ground shipment. Any rush shipments will be freight
prepaid.
What your warranty does not cover:
Damage from misuse or neglect.
Damage caused by use outside of Sawgrass Technologies
recommendations.
Limitations of Warranty
THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FOR
A PARTICULAR PURPOSE. SAWGRASS SHALL NOT BE LIABLE FOR
LOSS OF PROFIT OR OTHER ECONOMIC LOSS, OR FOR INDIRECT,
SPECIAL, CONSEQUENTIAL, OR OTHER SIMILAR DAMAGES.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
4
END-USER LICENSE AGREEMENT FOR
SAWGRASS SOFTWARE- PowerDriver IQ®
IMPORTANT-READ CAREFULLY: This Sawgrass Technologies Inc. End-User License Agreement ("EULA") is a legal
agreement between you (either an individual or a single entity) and Sawgrass Technologies, Inc for the Sawgrass
software product identified above, which includes computer software and may include associated media, printed
materials, and "online" or electronic documentation ("SOFTWARE PRODUCT"). By installing, copying, or otherwise
using the SOFTWARE PRODUCT, you agree to bebound by theterms of this EULA. Ifyou do not agree tothe terms
of this EULA, do not install or use the SOFTWARE PRODUCT.
Software PRODUCT LICENSE
Copyright laws and international copyrighttreaties, aswell as other intellectual property laws and treaties protect the
SOFTWARE PRODUCT. The SOFTWARE PRODUCT is licensed, not sold. The title to, and ownership of, this
SOFTWARE PRODUCT remains with Sawgrass Technologies,Inc. (Sawgrass).
GRANT OF LICENSE. This EULA grants you the following rights:
This license is provided to you for your use according to the terms hereof. You may install and use the
SOFTWARE PRODUCT packaged herewith to practice the printing process described in U.S. Patent No.
5,488,907 (the "Sawgrass Process"). The use of any ink, dye or pigment to practice the Sawgrass Process,
other than a SubliJet ink which is purchased from Sawgrass or its authorized distributor, is not a licensed use of
the SOFTWARE PRODUCT. You agree not to use the SOFTWARE PRODUCT for any other purpose or in any
process except as expressly permitted hereby.
Not for Resale. You may not sell, or otherwise transfer for value,the SOFTWAREPRODUCT.
No Reverse Engineering, Decompilation, Copying or Disassembly. You may not reverse engineer,
decompile, copy or disassemble the SOFTWARE PRODUCT.
No Rental. You may not rent, lease, orlend the SOFTWARE PRODUCT.
Support Services. Sawgrass Technologies, Inc. may provide you with support services relatedto the
SOFTWARE PRODUCT ("Support Services"). Use of Support Services is governed by the Sawgrass
policies and programs described in the user manual, in "online" documentation, and/orin other Sawgrass-
provided materials. Any supplemental software code provided to you as part of the Support Services shall
be considered part of the SOFTWARE PRODUCT and subject to the terms and conditions of this EULA.
With respect to technical information you provide to Sawgrass as part of the Support Services, Sawgrass
may use such information for its business purposes, including for product support and development.
Sawgrass will not utilize such technical information in a form that personally identifies you.
No Assignment or Sublicense. You may not assign or sublicensethe rights granted hereby.
Termination. Without prejudice toany otherrights, Sawgrass may terminate this EULA if you fail to
comply with the terms and conditions ofthis EULA. In the event of termination, you must destroy all
copies of the SOFTWARE PRODUCT andall of its component parts.
COPYRIGHT. All title and copyrights in and tothe SOFTWARE PRODUCT (including but not limited to any images,
photographs, animations, video, audio, music, text, and "applets" incorporated into the SOFTWARE PRODUCT),the
accompanying printed materials, and any copies of the SOFTWARE PRODUCT are owned by Sawgrass Technologies
Inc. or its suppliers. Copyright laws and international treaty provisions protect the SOFTWARE PRODUCT. Therefore,
you must treat the SOFTWARE PRODUCT like any other copyrighted material, except that you may install the

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
5
SOFTWARE PRODUCT on a computer forthe uses permitted hereby. You may not copy the printed materials
accompanying the SOFTWARE PRODUCT. You may not loan, rent, lease, or otherwise transferthe other medium to
another user, except as part of the permanent transfer (as provided above) of theSOFTWARE PRODUCT.
U.S. GOVERNMENT RESTRICTED RIGHTS. The SOFTWARE PRODUCT and documentation are providedwith
RESTRICTED RIGHTS. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or
subparagraphs (c)(1) and (2) of the Commercial Computer Software-Restricted Rights at 48 CFR52.227-19, as
applicable.
MISCELLANEOUS
a. If you acquired this product inthe UnitedStates, this EULA is governed by the laws of the State of South Carolina.
In the event of any dispute arising under this license or from the use ofthe SOFTWARE PRODUCT, eachparty
irrevocably agrees to the jurisdiction of theUnited States District Court for the District of South Carolina, Charleston
Division.
b. If you acquired thisproduct in Canada,this EULA is governed bythe lawsof the Province of Ontario, Canada. In
the event of any dispute arising under this license or from the use of theSOFTWARE PRODUCT, each party
irrevocably agrees to the jurisdiction of the courts of the Province of Ontario and further agrees to commence any
litigation which may arise hereunder inthe courts located in the Judicial District of York, Province of Ontario.
c. If this product was acquired outsidethe United States, then local law may apply.
LIMITED WARRANTY. Sawgrass warrants that (a) the SOFTWARE PRODUCT will perform substantially in
accordance with the accompanying written materials fora period of thirty (30) days from the date of receipt, and (b)
any Support Services provided by Sawgrass shall be substantially as described in applicable written materials provided
to you by Sawgrass, and Sawgrass support engineers will makecommercially reasonable efforts to solve anyproblem
issues. Some states and jurisdictions donot allow limitations on duration of an implied warranty, so the above limitation
may not apply to you. To the extent allowed by applicable law, implied warrantieson the SOFTWARE PRODUCT, if
any, are limited to thirty (30) days.
CUSTOMER REMEDIES. Sawgrass' and its suppliers' entire liability and your exclusive remedy shall be, at Sawgrass'
option, either (a) return ofthe price paid, if any, or (b) repair or replacement of the SOFTWARE PRODUCT that does
not meet Sawgrass' Limited Warranty and which is returnedtoSawgrass with a copy ofyour receipt. This Limited
Warranty is void if failure ofthe SOFTWARE PRODUCT hasresulted from accident, abuse, or misapplication. Any
replacement SOFTWARE PRODUCT will be warrantedfor the remainder of the original warranty period or thirty (30)
days, whichever is longer. Outside the United States, neither these remedies nor any product support services offered
by Sawgrass are available without proof of purchase from an authorized international source.
NO OTHER WARRANTIES. To the maximum extent permitted by applicable law, Sawgrass and its suppliers disclaim
all other warranties and conditions, either express or implied, including, but not limited to, impliedwarranties of
merchantability, fitness for aparticular purpose, title, and non-infringement, with regard to the SOFTWARE PRODUCT,
and the provision of or failure to provide Support Services. This limited warranty gives you specific legal rights. You
may have others, which vary from state/jurisdiction to state/jurisdiction.
LIMITATION OF LIABILITY. To the maximum extent permitted byapplicable law, in no event shall Sawgrass or its
suppliers be liable forany special, incidental, indirect, or consequential damages whatsoever (including, without
limitation, damages for loss of business profits, business interruption, loss of business information, or any other
pecuniary loss) arising out of the use ofor inability to usethe SOFTWARE PRODUCT or the provision of or failure to
provide Support Services, even if Sawgrass has been advised of the possibilityof such damages. In anycase,
Sawgrass' entire liability under any provision of this EULA shall be limitedto U.S. $5.00.Because some states and
jurisdictions do not allow theexclusion or limitationof liability, the above limitation may not apply to you.
SubliJet IQ
®
and PowerDriver IQ
®
are registered trademarks of Sawgrass Technologies,
Inc. ColorSure™ is a trademark of Sawgrass Technologies, Inc.
General Notice: Other product names used herein are for identification purposes only and
may be trademarks of their respective owners. Sawgrass Technologies, Inc. disclaims any
and all rights in those marks.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
6
Table of Contents
Table of Contents.................................................................................................................6
Introduction ..........................................................................................................................7
About this Document...........................................................................................................8
Quick Connect II™ Set-up for the D88 ...............................................................................9
Printer Set-up for the D88..................................................................................................11
Installing SubliJet IQ™ Cartridges...................................................................................15
Replacing an Empty Cartridge..........................................................................................19
Selecting Paper ..................................................................................................................21
Heat Transfer Instructions ................................................................................................22
PowerDriver Introduction..................................................................................................24
System Requirements .......................................................................................................24
Setup Instructions – Windows 2000 and XP....................................................................24
Using PowerDriver IQ™ in Windows 2000 / XP...............................................................30
Appendix A: Network Printing in Windows 2000, XP .....................................................36
Host Machine (Server) .......................................................................................................36
Appendix B: Defeating Application Color Management.................................................37
Appendix C: Using ColorSure™ and Custom Palette ....................................................42
Appendix D: Custom Paper Sizes ....................................................................................50
Tips for Successful Sublimation ......................................................................................51
Supplies & Equipment.......................................................................................................53
Operating Conditions ........................................................................................................53
Storage................................................................................................................................53
Troubleshooting.................................................................................................................54
Technical Support..............................................................................................................57
Project Sublimation .................................................................Error! Bookmark not defined.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
7
Introduction
Congratulations on your purchase of SubliJet IQ™ digital transfer inks. The SubliJet IQ™
sublimation ink cartridges are the latest advancement for the EPSON Stylus D88 from
Sawgrass Technologies, Inc., a leader in the development of digitally driven color transfer
technologies and related products.
With this system, your printed images can be transferred onto any product designed to
accept sublimation dyes including: ceramic, metal, tiles, mylar, polyester fabric,
performance wear, TEC Film™, TEC Tile™, UniSub, and Hanes Soft L’Ink®T-shirts,
resulting in an attractive, durable product. Your imagination is the limit for producing
brilliant, near photo-quality images on caps, clipboards, clocks, mugs, mousepads,
plaques, puzzles, synthetic T-shirts, and more. SubliJet IQ™ is ideal for markets that
personalize, customize or create short-run output.
In addition, your system is bundled with PowerDriver IQ™, a user-friendly color
management software package that allows the user to create flawless transfers in less
time. The “Fast Copies” option reduces print time by automatically spooling the file to the
printer only once regardless of the number of copies. Design time is also condensed by
utilizing the ColorSure Palette. The color palette contains 160 more spot colors and the
custom palette gives users the ability to add, edit, import or export colors, thus streamlining
the color matching process. Instructions for installation and use of this systemcan be found
in this User’s Guide.
This document contains information for using SubliJet IQ™ inks and helpful tips are also
provided for getting the best results from your transfers. The information provided pertains
only to the use of SubliJet IQ™ in your EPSON Stylus D88 printer. If you have questions
about the operation of your EPSON printer, refer to the EPSON Stylus D88 Printer User’s
Guide.
Technical support is available from your Authorized SubliJet reseller or directly from
Sawgrass Technologies, Inc. See the section entitled Technical Support for additional
information.
We at Sawgrass strive to provide you with the tools to make the sublimation process easy
to learn and simple to master. We hope you will find that the tools we have developed will
make your years in the sublimation business fun and profitable. Please feel free to contact
us with your feedback about our products. For additional information on our other products,
visit our web site at www.sublimation.com.
Thank you and enjoy your SubliJet IQ™ printing system.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
8
About this Document
This document contains descriptions and procedures for using SubliJet
IQ inks, along with additional information for getting the best results from
your transfers.
The documentation provided pertains only to the use of SubliJet IQ™
inks in your EPSON Stylus D88 ink jet printer. To assist you in the
overall setup process, references are made back to the EPSON Stylus
D88 Printer Basics Guide for instructions.
To help point out important information, specific instructions, and
helpful tips look for the following symbols:
Indicates Must-Do items, including
warnings and important guidelines. These
must be followed to prevent damage to
y
our
p
rinter.
Indicates useful tips for printing
and sublimation.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
9
Before you Begin
Quick Connect II™ Set-up for the D88
1. Check to ensure that you have all of the components necessary to
setup your Quick Connect II™ system.
2. Place the Quick Connect II box on a level surface next to where your
printer is going to be placed. It should be on the left hand side of your
printer with the clamps facing towards the front.
Components
1. Ink Cartridge + tubes
2. 1 x Long Tube Grip
3. 1 x Short Tube Grip
4. 4 x Ink Bags
5. Small primer bottle
6. Ink Box
7. Chips
8. Foam Block
9. Power Driver CD
(Not Shown)
10. Printer
It is crucial that the OEM ink supplied with
your printer is installed before you attempt
to install your SubliJet IQ™ inks. This allows
for two things: First, it primes the ink
delivery system, ensuring that the SubliJet
IQ™ ink will load more easily. Second, it
familiarizes you with the basic operation of
your printer. Please see the EPSON Stylus
D88 Printer User’s Guide for instructions on
installation.
For more detailed instructions please refer to the Video Installa
t
ion Guide on your PowerDrive
r
™C
D
Your ink bags should never be elevated above
the print head. Keeping the bags beside the
printer at the same level assures the ink delivery
system will operate properly.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
10
3. Remove the lid from the box and place it to the side.
4. Clamp the tubes at the end of each line before you clip on each bag to
prevent ink from entering them. Insert the ink bags into the ink box by
clipping them into the connectors inside each chamber. All chambers
are labeled with the corresponding color for each ink bag.
5. Once all ink bags are connected inside your Quick Connect II™ ink
box, you will need to obtain the small primer bottle to prime each line.
6. Take the cartridge in one
hand and the priming bottle
in the other. Squeeze the
priming bottle to release all
of the air and insert it into
the bottom of the cartridge
to pull ink through the line
until a small amount of it
reaches the reservoir.
Remember to match the
right color ink to its
corresponding cartridge
chamber. Once the tube is
filled, there is no way to
undo it!

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
11
7. Once ink is in the
reservoir, pinch together the
clamp that’s connected to
the tube on the outside of
the box. This will ensure
that no more ink will pull into
the reservoir until you are
ready for it.
8. Repeat Steps 6 & 7 for
each cartridge.
9. Place the lid back onto the Quick Connect II™ ink box and gently
place the cartridges on top of the box while you are completing the
printer setup.
Printer Set-up for the D88
1. Turn the printer on, lift the lid,
and press the ink button 6.
2. The cartridge bay will shift
into the remove position. Lift the
bay lid and remove any installed
cartridges.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
12
3. Install the cartridge chips into the slot on the front of the cartridge bay.
Note: The chip has an up arrow on the back of it showing which
way it should go in the printer.
4. Insert the plastic cross bar into
place by sliding the notched end into the back of the chip holders as
shown.
5. Gently slide the cartridges
through the hole in the cartridge
cover. Start with the black
cartridge on the left and attach the
cartridges in this order:
(from left to right)
Black, Cyan, Magenta,
and Yellow

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
13
6. Obtain the foam block,
place it on top of the
cartridges, and close the
cartridge cover. Be careful
not to pinch the tubes when
closing the cover.
7. Obtain the long tube holder
and remove the tabs from the
back exposing the adhesive.
Place the tube holder in the
flat gray area just beneath the
buttons on the printer.
8. Slide tubing into the holder
for placement.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
14
9. Position the tubing so that the
black line on it lines up with the
edge of the tube holder.
Note: This will leave enough slack
so that the cartridge bay can easily
slide from one side of the printer to
the other without creating tension
on the tubes.
10. Obtain the short tube holder
and remove the tabs from the
back exposing the adhesive.
Attach it to the left hand side of
the printer where the tubes hang
down to meet the Quick Connect
II™ ink box. Slide tubes into the
holder for placement.
11. Unclamp the end of each tube so that you are ready for printing.
10. Press the ink button to move the print head back to the ink cartridge
parked position.
Congratulations! You’ve
successfully installed a D88
Quick Connect II ink system
and printer.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
15
Tips:
Make sure you install Power Driver from the
CD that came with your Quick Connect II
system. Refer to the Power Driver
documentation and video tutorial on how to
use Power Driver.
Perform a nozzle check from Power Driver. A few cleanings
may be necessary to get a good nozzle check.
You may want to remove the printer lid or leave it open at all
times.
You may have a little air in your lines but this will clear after a
few prints.
If you are going to leave your system without using it for
several days you should clamp your lines with the tube
clamps.
Do not raise the ink box higher than the printer

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
16
Installing SubliJet IQ™ Cartridges
1. Ensure the printer power is on and that the green light is not blinking.
2. Open the printer cover and
lower the output tray.
3. Shake each cartridge 4 to 5 times and
remove it from its packaging.
4. Press the Ink Button for one second to move the cartridge holder into
the change cartridge position.
Ink Button Paper Feed
Button Powe
r

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
17
5. Open the cartridge cover.
6. Squeeze the tab at the back of the Epson cartridge as you lift it out of
the printer. Remove all Epson cartridges from the cartridge holder.
Do not hold the Ink Button for
more than 2 seconds or the
printer will clean the print head.

Sawgrass Technologies, Inc. SubliJet IQ®Getting Started Guide for the EPSON Stylus D88
18
7. Insert the SubliJet IQ cartridges into the cartridge holder, ensuring
they are firmly seated.
8. When the SubliJet IQ cartridges are in place, close the cartridge
cover.
9. Close the printer cover and press the ink button for one second. The
printer will move the print head to the parked position and charge the ink
delivery system with the SubliJet IQ inks.
