• Adjustthecablesoitdoesnotgetsnagged.
• Securetheproducttothemountingbracketbylocating
thescrewsthroughthe“L”shapedslots(3)intheceiling
coverandtighteningthescrews.
• Replacefuseorcircuitbreakerandswitchon.Yourlight
isnowreadyforuse.
• Whenchangingabulb,alwaysswitchoffatthemains
andallowthebulbtocoolbeforehandling.Disposeof
usedbulbscarefully.Donotexceedthewattagestated
oruseadifferentshapebulbfromthatindicatedonthe
fitting.
• Useasoftclothtohandlebulbs,avoiddirectlytouching
thebulbsasthiswillshortentheirlife.
• Removebulbbyturningaquarterturnanticlockwiseand
pullingout.
• Pushthebulbgentlyintothelampholderandtwista
quarterturnclockwisetoengagepins.
Commissioning
Fitting/replacing bulbs
Instructionleaflet
Grove Four Light Spotlight
EL-10047
www.saxbylighting.com
Foryoursafety,alwaysswitchoffthesupplybeforechanginglightbulbs,orcleaning.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilitiesexist.
CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
SaxbyLightingLtd.LS90SE
Werecommendcleaningwithasoftdrycloth.
Donotusesolventsorabrasivecleanersasthesecould
damagethefinish.
Glassparts–Wipecleanwithadampcloth.Donotuse
abrasivematerialsasthesewilldamagethefinish.
50W GU10
Mains Halogen
Iss.225092015

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeandsatisfactory
operationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
This is a Class 1 product and must be earthed.
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensureother
personscannotrestoretheelectricalsupplywithoutyour
knowledge.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteofthe
connections.
Alwaysusethecorrecttypeandwattagebulb.Exceeding
thebulbwattagewilldamagetheproduct.
Whenchangingabulb,alwaysswitchoffatthemainsand
allowtheoldbulbtocooldownbeforehandling.Dispose
ofusedbulbscarefullyandresponsibly.
Thisproductissuitablefordimmingwhenusedin
conjunctionwithadimmablelamp.Pleaseensure
verificationofdimmingabilitieswiththelamp
manufacturepriortouse.
Specification
Voltage: 240V50Hza.c.
Lamp: 4x50WGU10Halogen
IPrating: 20
Layout
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingtheexisting
fitting,carefully note the position of each set of wires.
• Undothescrews(1)holdingthefixingbracketinplace
andsetaside.
• Holdthebracket(2)inplaceandmarkthepositionof
theholes.Ensurethattheproductislevel.
• Ensuretheceilingiscapableofholdingtheweightof
theproduct.Takecaretoavoiddamaginganyconcealed
wiringandpipes.Ensurethereisajoistatthepointof
fixingtosupporttheweightoftheproduct.
Installation
Wiring
Havingcorrectlyidentifiedthewiringfromyourexistinglight
fitting,pullthewirethroughtheholeandconnecttothe
connectionblockinsidetheproductinthefollowingway:
Check that...
• Youhavecorrectlyidentifiedthewires.
• Theconnectionsaretight.
• Noloosestrandshavebeenleftoutoftheconnection
block.
• Whencompleted,ensurethattherearenobareorloose
strandsofwireexposed,andcoverallexposedareasof
theconnectionblockwith2layersofinsulationtape.
• Planthedesiredlayoutofthisfittingcarefully,ensuring
thecableswillreachthedistancebetweenthejunction
boxandthelightfitting.
• Avoidlocatinganycablesinpositionsthatwouldcause
ahazard.Positioncablesandjunctionboxes(not
supplied)awayfromareaswheretheymaybeatrisk
frombeingcut,trappedordamaged.
• Themainssupplycablemusthaveaminimumcross
sectionalareaof1.0mm².
• Thisproductmustbemountedoutofarmsreach.
SUPPLY
NEUTRAL
LIGHT FITTING
BLUE(N)
EARTH(GREEN/YELLOW) GREEN/YELLOW
BROWN(L)
SWITCHEDLIVE
FOURTHTERMINALBLOCKPROVIDED
FORLOOPTERMINATIONIFNECESSARY
0.5m Spotlightsgiveaconcentratedbeamoflightandmustnotbepositionedanycloserthan0.5M(50cm)to
theilluminatedsurface.
3
