Scag Power Equipment RS-ZT User manual

MODEL
OPERATORS MANUALOPERATORS MANUAL OPERATORS MANUALOPERATORS MANUAL
OPERATORS MANUAL
THIS MANUAL CONTAINS THE OPERATING
INSTRUCTIONSANDSAFETYINFORMATION
FOR YOUR SCAG ACCESSORY. READING
THISMANUALCANPROVIDEYOUWITH AS-
SISTANCE INMAINTENANCE AND ADJUST-
MENTPROCEDURESTOKEEPYOUR ACCES-
SORY PERFORMING TO MAXIMUM EFFI-
CIENCY. THE SPECIFIC MODELS THAT THIS
BOOKCOVERSARECONTAINEDONTHEIN-
SIDE COVER. BEFORE OPERATING YOUR
MACHINE, PLEASE READ ALL THE INFOR-
MATION ENCLOSED.
PART NUMBER 03029
RS-ZT
SC5062G

FAILURE TO FOLLOW SAFE OPERATING PRACTICES
MAY RESULT IN SERIOUS INJURY.
* Keep all safety shields in place.
* Beforeperforming anymaintenance orservice, stopthe machineand
remove the spark plug wire.
* Ifa mechanismbecomesclogged,stopthe enginebefore cleaning.
* Keephands, feetand clothingaway frompower-driven parts.
* Readthis manualcompletely aswellastheOperator's Manualthat came
withyour mower.
* Keepothers off thetractor(only oneperson ata time).
REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!
Hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of the personnel involved in the op-
eration, transport, maintenance, and storage of the equipment.
WARNING
Thismanualcoverstheoperatinginstructions
and illustratedparts listfor:
RS-ZT with a serial number of 28570001-28579999
RS-ZT with a serial number of 3690001-3699999
RS-ZT with a serial number of 4610001-4619999
Alwaysuse theentire serialnumberlistedonthe serialnumber
tagwhen referringtothis product.

®
TABLE OF CONTENTS
I
SUBJECT PAGE
Introduction..............................................................................................................1
SafetyandOperatingInstructions.......................................................................1
AssemblyInstructions...........................................................................................2-4
HardwareList.........................................................................................................5
IllustratedPartsList.............................................................................................. 6-7
LimitedWarrantyStatement..................................................................InsideBackCover
Equipment & Engine
Training Council
c
MEMBER
WE SUPPORT OPE
TECHNICIAN
CERTIFICATION

1
INTRODUCTION
Thismanualhasbeenpreparedtoprovidethe
informationyouneedtocorrectlyassemble,
operateandmaintainthisattachment.Readit
carefullyandkeepitforfuturereference.Should
youeverneedrepairpartsorservice,contactyour
authorizedScagServiceDealer.
Anyreferencemadeinthismanualconcerningthe
RHorLHsidesaredeterminedwiththeoperator
inthenormaloperatingposition.
Thereplacementofanypartonthisproductby
otherthanthemanufacturer'sauthorized
replacementpartmayadverselyaffectthe
performance,durabilityorsafetyofthisproduct.
SAFETY AND OPERATING
INSTRUCTIONS
Toavoidpersonalinjury,itisimperativethatall
safetyinstructionsbeobserved.
Yoursulkywasbuilttothehigheststandardsinthe
industry.However,theuseofaridingsulky,when
attachedtoawalkbehind mower, isonlyassafe
astheoperator.Carelessness or erroronthepart
oftheoperatormayresultinseriousbodilyinjury.
Pleasereadandfollowtheseinstructionsonsafe
operation,andbecertainanyoneusingthissulkyis
familiarwiththeserules.
1. Read this technical manual and the technical
manual that is supplied with the machine this
attachment is used on. A replacement manual
isavailable by sendingcomplete model and
serial number to:
Scag Power Equipment
1000 Metalcraft Dr.
P.O. Box 152
Mayville, WI 53050
2. Do not operate this sulky on steep slopes.
3. Do not run over rocks, holes or other
obstructions that may make the sulky
unstable.
4. Always keep both hands on the steering
controls when using the mower with the sulky
attached.
5. When operating the mower in reverse, make
certain that there are no obstructions behind
you.
6. Have a first time operator practice driving the
mower and sulky in an open, level area before
operating under actual mowing conditions.
7. Before leaving the sulky seat:
lDisengagebladeclutch
lEngage both neutral locks
lPull speed control lever to neutral
lApply the parking brake
lWait for all movement to stop

2
ASSEMBLY INSTRUCTIONS
-Note-
Before assembling and connecting this
accessory to your machine, turn the engine
off, remove the key, and remove the spark
plug wire from the engine.
1. Remove all crating and packing materials.
Lay out the mounting hardware according to
the “where used” list on page 5.
2. Bolt the hitch bracket onto the rear of the
engine deck using (3) three 3/8-16 x 1-1/4"
bolts and (3) three 3/8-16 elastic stop nuts.
The bolts must be installed from the inside
facing out.
-Note-
If you are mounting the hitch bracket to an
older machine with only two holes on
the rear of the engine deck, you may use the
hitch bracket to locate the third hole.
Bolt the hitch bracket to the existing two
holes and mark the third hole using a
center punch. Unbolt the hitch bracket and
drill a 13/32" hole at the mark for the
third hole. You are now ready to mount the
hitch bracket.
3. Mount the hitch ball onto the hitch bracket
using the 3/4" lock washer and the 3/4"-16
hex nut.
4. Mount the wheel assemblies onto the wheel
spindles. Place the 1" wheel spacers onto the
wheel spindles, and install the "E" clip on to
each of the wheel spindles.
-Note-
There will be more wheel spacers in the
hardware package than you will use. Install
the appropriate sized wheel spacers onto the
wheel spindle to remove the back and forth
movement of the wheel assemblies with the
“E” clip installed.
5. Mount the sulky frame on the hitch ball and
secure in place by pushing down the locking
lever on the coupler.
-Note-
When performing steps 5 through 8 keep in
mind that the (3) three tie rods will have
one end that has RH threads and one end
that has LH threads.
Included in the hardware package are:
l (3) three LH threaded 1/2 x 1/2-20
ball joints.
l (3) three LH threaded 1/2-20 jam
nuts.
l (2) two RH threaded 1/2 x 1/2-20
ball joints.
l (1) one RH threaded 5/8 x 1/2-20
ball joint.
l (3) three RH threaded 1/2-20 jam
nuts.
6. Screw (2) two LH threaded 1/2-20 jam nuts
onto (2) two LH threaded 1/2 x 1/2-20 ball
joints.
7. Screw (2) two RH threaded 1/2-20 jam nuts
onto the (2) two RH threaded 1/2 x 1/2-20
balljoints.
8. There are three tie rods included in the sulky
assembly. The two shorter ones are the
wheel tie rods and the longer one is the
steering tie rod.
9. Screw the (2) two LH 1/2 x 1/2-20 ball
joints with jam nuts into the LH threaded
ends of the wheel tie rods. Screw the RH
1/2 x 1/2-20 ball joints with jam nuts into the
other wheel tie rod ends.

3
13. Bolt one end of the other wheel tie rod
below the lever on the right wheel spindle.
Place a 1/2" ball joint spacer between the ball
joint and wheel spindle lever. Secure using a
1/2-13 x 2" bolt and a 1/2-13 elastic stop
nut. (See figure 2)
14. Place the other end of the tie rod coming
from the left wheel above the larger lever of
the steering bellcrank located in the center of
the sulky frame. Place the other end of the
tie rod coming from the right wheel below
the larger lever of the steering bellcrank.
Place (2) two 1/2" ball joint spacers between
the (2) two ball joints and the steering
bellcrank lever. Secure using a 1/2-13 x 3
1/4" bolt and a 1/2-13 elastic stop nut. (See
figure 2)
15. Screw the remaining LH and RH threaded
1/2-20 jam nuts onto the remaining two ball
joints.
Figure 1
10. On the (2) two wheel tie rods, adjust the ball
joints on the tie rods so that you will get
12- 7/8” distance between the center of the
holes on the ball joints. (See figure1)
11. Tighten the (4) four jam nuts on the ball
joints against the tie rod ends to prevent
turning of the ball joints on the tie rods.
12. Bolt one end of a wheel tie rod above the
lever on the left wheel spindle. Place a 1/2"
ball joint spacer between the ball joint and
wheel spindle lever. Secure using a 1/2-13 x
2" bolt and a 1/2-13 elastic stop nut.
(See figure 2)
12 7/8"
WHEEL TIE ROD ADJUSTMENT
SC502G
Figure 2
SC503G
WHEEL TIE ROD
WHEEL TIE ROD
1/2" SPACER
1/2" SPACER
LEFT WHEEL
SPINDLE LEVER
RIGHT WHEEL
SPINDLE LEVER
CENTER
STEERING LEVER

4
21. Mount the seat onto the seat plate. Place the
(4) four 3/8" flat washers between the seat
and plate. Secure using (4) four 5/16-18 x 3/
4" bolts and (4) four 5/16" lock washers.
22. Mount the seat and seat plate to the seat
spring using (2) two 3/8-16 x 1" bolts and
(2) two 3/8" lock washers.
23. Attach the arm rests to the seat back and use
set screws to adjust arm rests until they are
horizontal.
-Note-
A final adjustment may be required on the
tie rods for the sulky wheels to be aligned
straight with the SWZ machine and to have
proper toe-in adjustment. To adjust the tie
rods, loosen the two jam nuts and turn the
tie rod tube to lengthen or shorten the tie
rod. Retighten jam nuts.
24. The two sulky wheels should have a 1/16"
toe-in adjustment. To make this adjustment,
adjust the two wheel tie rods.
25. Start the engine and drive the mower with
the sulky attached. If the sulky does not
track straight behind the mower, you must
adjust the streeing rod so that the wheels are
even with the mower.
-Note-
For operator comfort the handles on the
SWZ should be raised to the highest
position. Refer to the SWZ's technical
manual for this adjustment.
-Note-
To move the sulky when not attached to the
mower, you must lock the wheels in a
forward position. The wheels can be
locked in the forward position by inserting
the ring pin through the holes in the sulky
frame and the steering bellcrank.
16. On the steering tie rod, adjust the ball joints
on the tie rod so that you will get 32-1/2”
distance between the center to center holes
on the ball joints. (See figure 3)
17. Tighten the jam nuts on the ball joints
against the tie rod ends to prevent turning of
the ball joints on the tie rods.
18. Connect the 1/2 x 1/2-20 end of the steering
tie rod to the small lever on the steering
bellcrank. Place a 1/2" spacer between the
ball joint and steering lever and secure using
a 1/2-13 x 2" bolt and a 1/2-13 elastic stop
nut.
19. Mount the 5/8 x 1/2-20 end of the tie rod to
the pin on the hitch bracket and secure with
the small quick pin.
20. Mount the seat spring and reinforcement seat
spring above the sulky frame and mount the
lower support plate below the sulky frame.
Secure using the (2) two 7/16-14 x 4" bolts,
(2) two 7/16" flat washer and (2) two 7/16-
14 elastic stop nuts.
-Note-
There are extra bolt holes to choose from
when mounting the seat spring to the sulky
frame and mounting the seat and seat plate
to the seat spring. Choose the ones that
will provide the most comfort for the
individual users.
32 1/2"
STEERING TIE ROD ADJUSTMENT
SC504G
Figure 3

5
04001-08
04001-19
04001-32
04001-22
04001-89
04001-72
04001-90
04040-11
04041-11
04041-14
04042-05
04030-03
04030-04
04020-08
04020-15
04021-09
04021-07
04021-11
04050-08
04062-01
4
2
3
2
2
3
1
2
4
4
4
4
2
3
3
5
4
2
2
1
Hex HD Bolt, 5/16-18 x 3/4"
Hex HD Bolt, 3/8-16 x 1"
Hex HD Bolt, 3/8-16 x 1-1/4"
Hex HD Bolt, 3/8-16 x 2-3/4"
Hex HD Bolt, 7/16-14 x 4"
Hex HD Bolt, 1/2-13 x 2"
Hex HD Bolt, 1/2-13 x 3-1/4"
Washer, 7/16"
Washer,3/8-1-1/2"O.D.
Washer,1.00-1-1/2"O.D.
Washer,1.00-1-3/4"O.D.
Lockwasher, 5/16"
Lockwasher, 3/8"
Nut,1/2-20
Nut, 1/2-20 LH
Nut, 3/8-16 Elastic Stop
Nut, 1/2-13 Elastic Stop
Nut, 7/16-14 Elastic Stop
1" "E" Clip
Hair Pin Cotter, .094 x 1.625
(4) Seat to Plate
(2) Seat Plate to Spring
(3) Hitch Brkt to Mower
(2) Coupler to Tongue
(2) Seat Spring to Tongue
(3) Tie Rod Ends
(1) Tie Rod End
(2) Seat Spring to Tongue
(4) Seat to Plate
(4) Spindles
(4) Spindles
(4) Seat to Plate
(2) Seat to Plate Spring
(3) Tie Rod Ends
(3) Tie Rod Ends
(3) Hitch Brkt to Mower
(2) Coupler to Tongue
(4) Tie Rod Ends
(2) Seat Spring to Tongue
(2) Spindles
(1) Ring Pin
Part Number Qty. Description Where Used
Where Used List

6
RS-ZT SULKY
SC505G
31
28
28A 35
32 33
34
30
30
35
29
36 12 11 40 9
6
7
85
7
39
47
46
49
49
6
45
851
47
46
11 48
9
40
3
2
8
15
16
44
6
12
5
27
25
24
21
18
22
23
43
20
19
14
2
17
53
50
54
13
52 11
10
9
8
37
6
12
5
38
3
4
1
26
41
50
56
57
39
55
42 50

7
RS-ZT SULKY
Ref. Part
No. Number Description Ref. Part
No. Number Description
29 48014-02 Arm Rest Kit
30 48014-03 Arm Rest
31 04001-08 Hex Head Bolt, 5/16-18 x 3/4"
32 48014-04 Mounting Bracket, RH
33 48014-05 Mounting Bracket, LH
34 48014-07 Back Strap
35 * Set Screw, 3/8-16 x 3/4" Flat Point
36 04001-90 Hex Head Bolt, 1/2-13 x 3-1/4"
37 04042-05 Flat Washer, 1"
38 04041-14 Flat Washer, 1"
39 04050-08 "E" Clip, 1"
40 43206 Tie Rod
41 481395 Hitch Ball, 1-7/8"
42 45828 Hitch Bracket
43 45210 Seat Plate
44 45378 Wheel Spindle, RH
45 45379 Wheel Spindle, LH
46 48100-08 Bronze Bearing
47 04041-14 Flat Washer
48 04050-12 "E" Clip
49 48114-04 Grease Fitting
50 04021-09 Elastic Stop Nut, 3/8-16
51 48260-01 Wheel Assembly
52 481394 Ball Joint (RH Thread) 5/8 x 1/2-20
53 04030-08 Lockwasher, 3/4"
54 04020-21 Hex Nut, 3/4-16
55 04001-22 Hex Head Bolt, 3/8-16 x 2-3/4"
56 04021-09 Elastic Stop Nut, 3/8 - 16
57 481396 Coupler, 1-7/8"
1 46879 Sulky Frame
2 48100-01 Bronze Bearing
3 04041-17 Flat Washer
4 45377 Steering Bellcrank
5 04001-72 Hex Head Bolt, 1/2-13 x 2"
6 43041 Ball Joint Spacer
7 48542 Ball Joint (RH Thread), 1/2-20
8 04021-07 Elastic Stop Nut, 1/2-13
9 04020-08 Hex Nut, 1/2-20
10 43207 Tie Rod, Long
11 04020-15 Hex Nut (L.H. Thread), 1/2-20
12 48664 Ball Joint (L.H. Thread), 1/2-20
13 04001-32 Hex Head Bolt, 3/8-16 x 1-1/4"
14 04066-02 Quick Pin, 3/16" dia
15 04067-02 Ring Pin
16 04062-01 Hair Pin, .094 x 1.625
17 04001-89 Hex Head Bolt, 7/16-14 x 4"
18 04021-11 Elastic Stop Nut, 7/16-14
19 42968 Lower Support Plate
20 48648 Reinforcement Seat Spring
21 48649 Seat Support Spring
22 04001-19 Hex Head Bolt, 3/8-16 x 1"
23 04030-04 Lock Washer, 3/8"
24 04001-08 Hex Head Bolt, 5/16-18 x 3/4"
25 04030-03 Lock Washer 5/16"
26 04040-11 Flat Washer, 7/16"
27 04041-11 Flat Washer, 3/8"
28 48592 Seat Assembly
28A 48592-01 Seat
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
-Note-

LIMITEDLIMITED
LIMITEDLIMITED
LIMITED WW
WW
WARRANTY- COMMERCIAL AARRANTY- COMMERCIAL A
ARRANTY- COMMERCIAL AARRANTY- COMMERCIAL A
ARRANTY- COMMERCIAL ACCESSORCCESSOR
CCESSORCCESSOR
CCESSORYY
YY
Y
AnypartoftheScagcommercialaccessorymanufacturedbyScagandfound,inthereasonablejudgmentofScag,
tobedefectiveinmaterialorworkmanship,willberepairedorreplacedbyanAuthorizedScagServiceDealerwithout
chargefor parts and labor.
TheScagaccessory, includingany defective part, mustbereturnedtoan Authorized Scag ServiceDealerwithin
thewarranty period. Theexpense of delivering the accessory to the dealer for warranty work and the expense of
returningitbacktotheownerafterrepairorreplacementwillbepaidforbytheowner. Scag’sresponsibilityinrespect
toclaimsislimitedtomakingtherequiredrepairsorreplacements,andnoclaimofbreachofwarrantyshallbecause
forcancellationorrescissionofthecontractofsaleofanyScagmachine. Proofofpurchasewillberequiredbythe
dealer to substantiate any warranty claim. All warranty work must be performed by an Authorized Scag Service
Dealer.
Thiswarrantyis limited to 90daysfromthe date of originalretailpurchase for any Scagaccessorythat is used for
commercialpurposes,oranyotherincome-producing purposeincludingrentaluse.
Thiswarrantydoesnotcover any accessory that hasbeensubjecttomisuse,neglect, negligence, or accident, or
thathasbeenoperatedinanywaycontrarytotheoperating instructionsasspecifiedintheOperator'sManual. The
warranty does not apply to any damage to the accessory that is the result of improper maintenance, or to any
accessory or parts that have not been assembled or installed as specified in the Operator's Manual.
Thewarranty doesnot cover any accessory that has been altered or modified. In addition, the warranty does not
extendto repairs made necessary bynormal wear, or by theuse of parts or accessorieswhich, in the reasonable
judgment of Scag, are either incompatible with the Scag mower or adversely affect its operation, performance or
durability. This warranty does not cover engines and electric starters, which are warranted separately by their
manufacturer.
ScagPowerEquipmentreservestherighttochangeorimprovethedesignofanyaccessorywithoutassumingany
obligation to modify any accessory previously manufactured.
All other implied warranties are limited in duration to the 90 day warranty period. Accordingly, any such implied
warrantiesincludingmerchantability,fitness for a particularpurpose,orotherwise,are disclaimed in theirentirety
aftertheexpiration of the appropriateninetyday warrantyperiod. Scag’s obligation under thiswarrantyis strictly
andexclusivelylimitedtotherepairorreplacementofdefectivepartsandScagdoesnotassumeorauthorizeanyone
toassumeforthemanyotherobligation. Somestatesdonotallowlimitationsonhowlonganimpliedwarrantylasts,
so the above limitation may not apply to you.
Scagassumesnoresponsibilityforincidental,consequentialorotherdamagesincluding,butnotlimitedto,expense
forgasoline,oil,expenseofdeliveringthemachinetoanAuthorizedScagServiceDealerandexpenseofreturning
itbacktotheowner,mechanic’straveltime,telephoneortelegramcharges,rentalofalikeproductduringthetime
warrantyrepairs arebeing performed,travel, loss or damage to personal property, loss of revenue, loss of use of
the mower, loss of time, or inconvenience. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

PART NO. 03029
PRINTED 6/98
PRINTED IN USA
©1998
SCAG POWER EQUIPMENT
DIVISION OF METALCRAFT OF MAYVILLE, INC
