Scan Cool SHC 2000 User manual

Operating Manual
Circulator
SHC 2000
40 80
160
120
0
© Copyright 2009 – version November 2009.
LaboGene ApS
Nøglegårdsvej 20
Vassingerød
DK-3540 Lynge.
Tel: [phone]; Mobil: [phone];
Fax: [phone]
Mail: [e-mail];
9.900.900.719 SHC2000-manual-111609

SHC 2000
2
Congratulations!
You have made an excellent choice.
ScanCool thanks you for the trust you have placed in us.
This operating manual has been designed to help you gain an understanding of the
principles of operating and possibilities of our circulators. For optimum utilization of all
functions, we recommend that you thoroughly study this manual prior to beginning
operation.
Unpacking and checking
Unpack the circulator and accessories and check for damages incurred during transit.
These should be reported to the responsible carrier, railway, or postal authority, and a
request for a damage report should be made. These instructions must be followed fully
for us to guarantee our full support of your claim for protecting against loss from
concealed damage. The form required for filing such a claim will be provided by the
carrier.

SHC 2000
9.900.900.719 SHC2000-manual-111609 3
TABLE OF CONTENTS
Operating manual ..........................................................................................................4
Description.................................................................................................................4
Operator responsibility – Safety recommendations...................................................4
Technical specifications.............................................................................................7
Operating instructions....................................................................................................9
1. Operating controls and functional elements...........................................................9
2. Safety notes for the user......................................................................................10
3. Preparations.........................................................................................................10
3.1. Installation........................................................................................................10
3.2. Bath fluids.....................................................................................................11
3.3. Tubing ..........................................................................................................12
3.4. Adjusting the pump flow...................................................................................13
4. Operating procedures ..........................................................................................13
4.1. Power connection.............................................................................................13
4.2. Switching on / Start - Stop................................................................................14
4.3. Setting the temperatures..................................................................................14
4.4. Automatic / non-automatic start mode .............................................................15
4.5. Sensor calibration.............................................................................................15
4.6. Timer function...................................................................................................17
4.6.1. Setting the time ........................................................................................17
4.6.2. Timer operation........................................................................................17
5. Safety installations according to IEC 61010-2-010..............................................18
5.1. Excess temperature protection ........................................................................18
5.2. Low liquid level protection................................................................................18
6. Troubleshooting guide / Error messages.............................................................19
7. Safety recommendations .....................................................................................21
8. Cleaning / repairing the unit.................................................................................22

SHC 2000
4
Operating manual
Description
The circulators SHC 2000 are designed for temperature application to specific fluids in
a bath tank.
The circulators are operated via the splash-proof keypad. The implemented
microprocessor technology allows to set and to store the setpoint that can be
indicated on the LED temperature display.
The PID temperature control adapts the heat supplied to the thermal requirements
of the bath.
Safety installations conforming to IEC 61010-2-010.
The excess temperature protection is a safety installation independent from the
control circuit.
The safety value is set using a tool (screwdriver).
If the low level protection device is triggered, a complete shutdown of the heater
and circulating pump is effected.
The circulator conforms to the relevant requirements specified by European
guidelines.
The circulators are not conceived for direct temperature application to
food and luxury articles or pharmaceutical and medico-technical products.
Direct temperature application means: Unprotected contact of the object
with the bath medium (bath fluid).
Operator responsibility – Safety recommendations
The products of ScanCool warrant a safe operation if installation, operation and
maintenance is carried out according to common safety regulations. This section
informs you about potential dangers that may arise from operating the circulator and
also mentions the most important safety precautions
Persons:
The operator is responsible for the qualification of the personnel operating the units.
The operator should be constantly informed about the dangers involved with their job
activities as well as preventive actions.
Make sure all persons expected to carry out operation, installation and maintenance of
the unit read and understand the safety information and operating instructions.
When using hazardous materials, the circulator may only be operated by persons that
are absolutely familiar with these materials and the circulator. These persons must be
fully aware of possible risks.
If you have any questions concerning the operation of your unit or the information in
this manual, please contact us!

SHC 2000
9.900.900.719 SHC2000-manual-111609 5
Contact ScanCool
Nøglegaardsvej 20
Vassingerød
3540 Lynge Denmark
Handling:
You received a product conceived for industrial use. Nevertheless, avoid strikes to the
housing, vibrations and damages to the keypad foil (keys, display) or contamination.
Make sure the product is regularly checked for proper condition. Regularly check (at
least every 2 years) the proper condition of the mandatory, warning, prohibition and
safety labels.
Take care that the mains supply features a low impedance to avoid any negative
affects on the instrument being operated in the same mains.
This unit is designed for operation in a controlled electromagnetic environment. This
means that transmitting devices (e.g. cellular phones) should not be used in the
immediate vicinity.
Magnetic radiation may influence other units with components susceptible to magnetic
fields
(e.g. a monitor). We recommend to keep a minimum distance of 1 m.
Permissible ambient temperature: max. 40 °C, min. 5 °C.
Permissible relative air humidity: 50 % (40 °C).
Do not store in an aggressive atmosphere. Protect from contaminations. Do not expose
to sunlight.
Operation:
Only qualified personnel is authorized to perform configuration, installation,
maintenance and repairs of the circulator.
Routine operation can also be carried out by untrained personnel who should however
be instructed by trained personnel. The summarized user guidance (short manual) and
the specification table with information on individual parameters are sufficient for this.
Use:
The bath can be filled with flammable materials. Fire hazard!
There might be chemical dangers depending on the bath medium used.
Observe all warnings for the used materials (bath fluids) and the respective instructions
(safety data sheets).
Insufficient ventilation may result in the formation of explosive mixtures. Only use the
unit in well ventilated areas.
Only use recommended materials (bath fluids). Only use non-acid and non corroding
materials.
When using hazardous materials, the user must attach the enclosed safety labels to
the front of the unit so they are well visible: The yellow warning label W09 (danger
area) and the blue mandatory label M018 or Semi S1-0701 Table A1-2 #9 (Carefully
read the user information prior to beginning operation).

SHC 2000
6
Warning label W09:
Colours: yellow, black
Danger area.
Attention! Observe instructions.
(operating manual, safety data sheet)
Mandatory label M018
Colours: blue, white
Carefully read the user information prior to
beginning operation
Scope: EU
Semi S1-0701
Table A1-2 #9
Carefully read the user information prior to
beginning operation
Scope: NAFTA
Particular care and attention is necessary because of the wide operating range.
There are thermal dangers: Burn, scald, hot steam, hot parts and surfaces that can be
touched.
Warning label W26:
Colours: yellow, black
Hot surface warning.
(The label is put on by ScanCool )
Observe the instructions in the manuals for instruments of a different make that you
connect to the circulator, particularly the respective safety recommendations. Also
observe the pin assignment of plugs and technical specifications of the products.
Disposal:
The product may be used with oil as bath fluid. These oils fully or partially consist of
mineral oil or synthetic oil. For disposal, observe the instructions in the safety data
sheets.
Please observe the regulations for disposal which are effective in the country of
operation.
Valid in EU countries
Directive 2002/96/EC of the European Parliament and of the Council
of 27 January 2003 on waste electrical and electronic equipment
(WEEE).
This directive requires electrical and electronic equipment marked
with a crossed-out trash can to be disposed of separately in an
environmentally friendly manner.
Contact an authorized waste management company in your country.
Disposal with household waste (unsorted waste) or similar collections
of municipal waste is not permitted!

SHC 2000
9.900.900.719 SHC2000-manual-111609 7
Technical specifications
SHC 2000
Working temperature range °C 20 ... 150
Operating temperature range °C -35 ... 150
Temperature stability °C ±0,01
Temperature selection digital
Temperature indication LED
Resolution °C 0.1
Temperature control PID
Heater wattage (at 230 V) kW 2,0
Heater wattage (at 115 V) kW 1,0
Pump capacity
Flow rate. l/min at 0 bar 15
Pressure maxbar at 0 liter 0,35
Overall dimensions (W×D×H) cm 13×16×33
Usable bath depth cm 8 ... 20
Weight kg 4,1
Ambient temperature °C 5 ... 40
Mains power connection 230 V/50 Hz V/ Hz 190-253 / 50
Current input at 230 V A 9
Mains power connection230 V/60 Hz V/ Hz 190-253 / 60
Current input at 230 V A 9
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input at 115 V A 9
All measurements have been carried out at:
rated voltage and frequency operating temperature: 70 °C
ambient temperature: 20 °C bath fluid: water
Technical changes without prior notification reserved.

SHC 2000
8
Safety installations according to IEC 61010-2-010:
Excess temperature protection adjustable from 0 °C ... 170 °C
Low liquid level protection float switch
Classification according to DIN 12876-1 class III
Alarm message optical + audible (permanent)
Environmental conditions according to IEC 61 010-1:
Use only indoor.
Altitude up to 2000 m - normal zero.
Ambient temperature: +5 ... +40 °C (for storage and transportation)
Air humidity:
Max. rel. humidity 80 % for temperatures up to +31 °C,
linear decrease down to 50 % relative humidity at a temperature of +40 °C
Protection class according to IEC 60 529 IP21
Power supply: corresponds to Class I; according to VDE 0106 T1
not for use in explosive atmosphere
Max. mains fluctuations of ±10 % are permissible.
Overvoltage category II
Pollution degree 2
Standards for interference resistance
EN 61326: 1997 + A1: 1998 + A2: 2001 + A3: 2003
Emitted interferences
The unit adheres to the threshold values for emitted interferences
according to table 3.
Interference resistance
The unit conforms to the requirements according to table B.1.

SHC 2000
9.900.900.719 SHC2000-manual-111609 9
Operating instructions
1. Operating controls and functional elements
Front view Rear view
40 80
160
120
0
1
7
15
A
M
P
15
A
M
P
8
9
1 Mains power switch, illuminated
2 Edit keys (increase/decrease setting)
3 Enter key (store)
4 LED temperature display, menu indication
5 Control indicator –Heating
6 Control indicator – Alarm
7
4
080
160
120
0Adjustable excess temperature protection according
to IEC 61010-2-010
Rear view
8
15
A
M
P
Mains circuit breakers (resettable) 15 A
9 Mains power cable with plug

SHC 2000
10
2. Safety notes for the user
In addition to the safety warnings listed above, warnings are posted
throughout the manual. These warnings are designated by an exclamation
mark inside an equilateral triangle. „Warning of a dangerous situation
(Attention ! Please follow the documentation).“
The danger is described according to an alarm keyword.
Read and follow these important instructions.
Warning:
Describes a possibly highly dangerous situation. If this is not avoided,
serious injury and danger to life could result.
Caution:
Describes a possibly dangerous situation. If this is not avoided, slight or
minor injuries could result.
A warning of possible damage can also be contained in the text.
Notice:
Describes a possibly harmful situation. If this is not avoided, the product or
anything in its surroundings can be damaged.
3. Preparations
3.1. Installation
Caution:
Securely fix the immersion circulator. The heater may not be in contact
with the wall of the bath tank. Keep a distance of at least 15 mm.
Units not adequately fixed may drop into the bath tank.
Danger of electric shock!
First pull out the power plug to disconnect the unit from the power supply
net. Then take the immersion circulator out of the bath tank.
Make a service technician check the instrument before it is used again.

SHC 2000
9.900.900.719 SHC2000-manual-111609 11
3.2. Bath fluids
Caution:
Carefully read the safety data sheet of the bath fluid used, particularly
with regard to the fire point!
If a bath fluid with a fire point of ≤65 °C is used, only supervised
operation is possible.
Water:
The quality of water depends on local conditions.
Ferrous water can cause corrosion - even on stainless steel.
Chloric water can cause pitting corrosion.
No liability for use with water.
Danger of freezing at working temperatures <5 °C.
Recommended bath fluids:
Bath fluids Temperature range
Water 5 °C ... 80 °C
Mixture water/glycol -30 °C ... 50 °C
Silicon oil -40 °C to 150 °C
The maximum permissible viscosity is 30 mm2/s
Notice:
Please contact ScanCool before using other than recommended bath
fluids. ScanCool takes no responsibility for damages caused by the
selection of an unsuitable bath fluid.
Unsuitable bath fluids are liquids which e.g.
•are very highly viscous
(much higher than 30 mm2/s [30 cSt] at the respective working
temperature)
•have corrosive characteristics or
•tend to cracking.
Caution:
The temperature controlling i.e. of fluids in a reactor constitutes normal
circulator practice.
We do not know which substances are contained within these vessels.
Many substances are:
•inflammable, easily ignited or explosive
•hazardous to health
•environmentally unsafe
i.e.: dangerous
The user alone is responsible for the handling of these substances!

SHC 2000
12
The following questions shall help to recognize possible dangers and to
reduce the risks to a minimum.
•Are all tubes and electrical cables connected and installed?
Note:
sharp edges, hot surfaces in operation, moving machine parts, etc.
•Do dangerous steams or gases arise when heating?
Is an exhaust needed when working?
•What to do when a dangerous substance was spilled on or in the unit?
Before starting to work, obtain information concerning the substance
and determine the method of decontamination.
3.3. Tubing
•Recommended tubing:
Temperature range
CR® tubing
Viton tubing -20 °C ... 120 °C
-50 °C ... 200 °C
Warning: Tubing:
At high working temperatures the tubing used for temperature
application and cooling water supply represents a danger source.
A damaged tubing line may cause hot bath fluid to be pumped out within
a short time.
This may result in:
•Burning of skin
•Difficulties in breathing due to hot atmosphere
Safety recommendations
•Employ suitable connecting tubing.
•Make sure that the tubing is securely attached.
•Avoid sharp bends in the tubing, and maintain a sufficient distance
from surrounding walls.
•Regularly check the tubing for material defects (e.g. for cracks).
•Preventive maintenance: Replace the tubing from time to time.

SHC 2000
9.900.900.719 SHC2000-manual-111609 13
3.4. Adjusting the pump flow
1
2
The pump flow is pre-adjusted in the factory and can be
modified to suit user requirements.
•Using a screwdriver turn the screw (1) anti-clockwise
by 360 °.
•Using flat pliers turn the marking of the slide (2) to the
desired position.
•Tighten the screw.
Examples:
external 80
%
internal100
%
internal 20 %
A
B
D
C
Internal applications in the bath
A 100 % internal bath circulation
(for large bath tanks)
B Reduced internal bath circulation
(for smooth surface of bath fluid)
External/internal applications
C 40 % external discharge,
60 % internal circulation
(for large bath tanks)
D 80 % external discharge,
20 % internal circulation
(for small bath tanks)
Caution: Securely attach all tubing to prevent slipping.
4. Operating procedures
4.1. Power connection
Caution:
Only connect the unit to a power socket with earthing contact
(PE – protective earth)!
We disclaim all liability for damage caused by incorrect line voltages!
Check to make sure that the line voltage matches the supply
voltage specified on the identification plate.

SHC 2000
14
4.2. Switching on / Start - Stop
•Switching on:
Turn on the mains power switch (1).
LThe unit performs a self-test. All segments of the 4-digit LED
temperature DISPLAY and all indicator lights will illuminate
(as illustrated on the left).
The display "OFF" indicates the unit is ready to operate
(standby mode).
Start:
•Press enter for about 4 seconds.
The LED temperature DISPLAY indicates the actual bath
temperature.
Stop:
•Press enter for about 4 seconds.
4.3. Setting the temperatures
Factory setting:
25 °C
LSetting can be carried out in the start/stop condition.
1. Press one of the keys for a short moment. The
setpoint value instead of the actual value is indicated on the
display for about 8 seconds. The value can now be changed.
2. Change value:
Press to set a higher value.
Press to set a lower value.
Keep the keys depressed for the value to change fast.
3. Press enter to store the value.

SHC 2000
9.900.900.719 SHC2000-manual-111609 15
4.4. Automatic / non-automatic start mode
Keep depressed enter and
turn on the circulator with the mains power switch.
For a short while the LED temperature DISPLAY indicates the
effective start mode:
AUTOSTART on.
AUTOSTART off.
NOTE:
The circulator has been configured and supplied by ScanCool
according to N.A.M.U.R. recommendations. This means for the
start mode, that the unit must enter a safe operating state after
a power failure (non-automatic start mode). This safe operating
state is indicated by „OFF“ on the LED temperature display. A
complete shutdown of the main functional elements such as
heater and circulating pump is effected simultaneously.
Should such a safety standard not be required, the
AUTOSTART function (automatic start mode) may be activated,
thus allowing the start of the circulator directly by pressing the
mains power switch or using a timer.
Warning:
For supervised or unsupervised operation with the AUTOSTART function,
avoid any hazardous situation to persons or property.
The circulator does no longer conform to N.A.M.U.R. recommendations.
Take care you fully observe the safety and warning functions of the
circulator.
4.5. Sensor calibration
40 80
160
120
0
•Calibration of the working sensor is performed at a
temperature of 30 °C.
•Place the circulator for example on a 5 litres stainless
steel bath and fill the bath with deionized water.
•Set the safety temperature to approx. 80 °C.
•Place a calibrated thermometer (resolution: 0.01 °C) in
the middle of the bath to measure the actual bath
temperature.

SHC 2000
16
1. Turn on the circulator with the mains switch.
2. Start the unit
Press enter for about 4 seconds.
3. Start the calibration:
Press the hidden key and the key at the same time.
The controller attempts to heat up to the working
temperature (30 °C).The LED temperature DISPLAY
indicates the actual bath temperature.
4. When the working temperature is reached, wait until the
circulator maintains a constant bath temperature
(after about 3 minutes).
28.87°C
5. Read the bath temperature from the calibrated
thermometer and set the rounded value on the circulator.
(example: 28.87 °C rounded to 28.9 °C).
•Setting the temperature
Press one of the keys for a short moment.
The setpoint value instead of the actual value is
indicated on the display. The value can now be
changed.
•Change value:
Press to set a higher value.
Press to set a lower value.
Keep the keys depressed for the value to change fast.
•Press enter to store the value.
•For a short while the LED temperature DISPLAY
indicates the message „CAL“.
LNotice:
If the determined value is bigger than the tolerance limit
of ±5 °C, the value is ignored for the input!

SHC 2000
9.900.900.719 SHC2000-manual-111609 17
4.6. Timer function
With the timer function the operating time can be limited to an
allowed time.
4.6.1. Setting the time
LThe setting can only be made in the Stop status.
1. Calling the timer function:
Hold the Enter key pressed and activate the edit key
shortly. The time which was set last, is shown.
2. Setting the time:
Activate key to set a higher value .
Activate key to set a lower value .
Activate the key shortly for single step, hold the key pressed
for quick enumeration.
3. Store the set value with the Enter key .
Example: 120 minutes
Factory setting:
Max. time:
33 h 19 min.
LThis time remains stored until something is changed.
4.6.2. Timer operation
•Starting the timer:
Hold the Enter key pressed and activate the edit key
shortly.
LThe bath temperature is shown. In case of timer operation the
comma in the display is blinking. The set time is counted up
to zero. When the time has elapsed, the circulator stops.
•Interrupting the timer / Failure of power supply voltage:
If there is a power failure, or if the unit is switched off at the
mains switch, the circulator memorizes the position of the
timer. When the power supply is switched on again, the
circulator only works off the remaining time.
•Canceling the timer operation:
Press the key for approx. 4 seconds.
The timer can be restarted.
Timer operation

SHC 2000
18
5. Safety installations according to IEC 61010-2-010
5.1. Excess temperature protection
This safety installation is independent of the control circuit.
When the temperature of the bath fluid has reached the
safety temperature, a complete shutdown of the heater and
pump is effected.
The alarm is indicated by optical and audible signals
(continuous tone) and on the LED-DISPLAY appears the
error message "Error 14".
40 80
160
120
0
Setting range: 0 °C to 160 °C
•Using a screwdriver turn the setting screw to the desired
value.
Recommendation:
Set the excess temperature protector at 5 to 10 °C above the
working temperature setpoint.
Warning:
The excess temperature protection should be set at least 25 °C below
the fire point of the bath fluid used.
In the event of wrong setting there is a fire hazard!
We disclaim all liability for damage caused by wrong settings!
5.2. Low liquid level protection
This safety installation is independent of the control circuit.
If the low liquid level protection device (according to IEC
61010-2-010) is triggered, a complete shutdown of the heater
and circulating pump is effected.
The alarm is indicated by optical and audible signals
(continuous tone) and on the LED-DISPLAY appears the error
message "Error 01".
LTurn off the unit with the mains switch, refill bath fluid and
turn the unit on again!
Warning:
For refill always use the same bath fluid type that is already in the bath.
Bath oils must not contain any water contaminants. Explosion hazard at
higher temperatures!
Recommendation:
Only replenish bath fluids at a bath temperature of below 70 °C!

SHC 2000
9.900.900.719 SHC2000-manual-111609 19
Notice:
Check the safety installations at least twice a year!
•Excess temperature protection according to IEC 61010-2-010
With a screwdriver turn back the adjustable excess temperature
protection until the shut-down point (actual temperature).
•Low level protection according to IEC 61010-2-010
To check the function of the float, it can be manually lowered with a
screwdriver for example.
6. Troubleshooting guide / Error messages
+8Whenever the microprocessor electronics registers a failure, a
complete shutdown of the heater and circulating pump is
performed. The alarm light " " illuminates and a continuous
signal tone sounds.
The LED temperature display indicates the cause for the alarm in
form of a code.
Press enter to quit the audible signal.
•The circulator is operated without bath fluid, or the liquid level
is insufficient.
Replenish the bath tank with the bath fluid.
•Tube breakage has occurred (insufficient filling level due to
excessive bath fluid pumped out). Replace the tubing and
replenish the bath tank with the bath fluid.
•Cable of the working temperature sensor interrupted or short-
circuited.
•Defect of the working or excess temperature sensor.
Working temperature and excess temperature sensors report
a temperature difference of more than 25 °C.
•Error in A/D converter

SHC 2000
20
•The excess temperature value lies below the working
temperature setpoint.
Set the excess temperature to a higher value.
•Cable of the excess temperature sensor interrupted or short-
circuited.
After eliminating the malfunction, press the mains power switch off
and on again to cancel the alarm state.
If the unit cannot be returned to operation, contact an authorized
service station.
Disturbances that are not indicated.
The electronic pump motor is overload-protected by an electronic
current limiter. If viscosity of the bath fluid is or becomes too high,
the motor stops running.
15
A
M
P
Mains circuit breakers (resettable) 15 A.
