SC&T KM03 User manual

Smart Cabling & Transmission Corp. V1.0
USB/Keyboard Mouse Extender Series
User Manual
Model : KM03
Keyboard & Mouse CAT5e Extender 600 meter

1
User Manual
KM03
Int roduct i on
KM03 is a USB extender that can use a cost-effective Ethernet cable to carry the signal, allowing users to
control the remote PC via a keyboard and a mouse. It's an ideal solution for classroom projector
systems, boardroom systems, collaborative PC systems, and medical information systems.
Feat ures
Extends USB Keyboard and mouse over one CAT5e UTP cable.
Signal extension up to 600M.
No external power required for TX unit
No external power required for Both sides when the transmission distance is less than 30M.
Inst al l at i on Vi ew
LEDIndi cati on
Power LED (Blue) Power ON /OFF
RJ45 LED: Green ON/OFF Data Link
Orange ON/OFF Normal/Abnormal status
Panel Vi ew
KM03R
KM03T

2
User Manual
KM03
Troubl eshoot i ng
1. The connection wiring must connect power and CAT5e cable first, and then connect to your
keyboard and mouse. Otherwise it may cause failed connection.
2. This product only works with keyboard and mouse, not able to compatible with any other USB
devices.
3. Compatible with USB 1.1 specifications.
Speci f i cat i on
ITEM NO.
KM03T
KM03R
Support
Compliance
USB 1.1
Max. Transmission Distance
600M
Ports & Interfaces
Data Input
1 x USB Type A
1 x RJ45
Data Output
1 x RJ45
1 x USB Type A
Power
Power Supply
DC 5V 1A
Power Consumption
500mA
Ambient Temperature
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
67 x 87 x 27mm
53 x 25 x 20.7mm & 180mm cable
Weight
130g
26g
