SC&T UE03H User manual

USB/Keyboard Mouse Extender Series
User Manual
Model : UE03H
USB 3.2 Gen1 CAT6a Extender 100m

1
User Manual
UE03H
Introduction
UE03H is a USB 3.2 Gen1 extender designed to carry USB signals using CAT6a/7 Ethernet cable. It is totally
backward compatible with USB 2.0 & USB 1.x devices. It is perfect for multiple applications including
devices such as USB cameras, touch panels, and any other USB devices.
Features
●USB 3.2 Gen1 up to 5Gbps
●Transmission distance up to 100m with CAT6a cable
●No power needed at device side (UE03HR)
●Max power supply 5V/1.5A at Device side (UE03HR), does not support QC(Quick Charge), PD(Power
Delivery)
●RS232 optional extension
●Compatible with USB 2.0 and USB 1.x devices
●USB Type-C port on both sides
●Plug & Play
●Small & compact, easy to install
●Low power consumption
●Multiple mounting options (Wall/Rack & Din Rail)
Application Diagram
USB Extension for General Purposes

2
User Manual
UE03H
USB Extension for Security/Monitoring
USB Extension for Video Conferencing
USB Extension for Video Capture
USB Extension using DisplayLink

3
User Manual
UE03H
Panel View
UE03HT
Interface
Description
1
HDBaseT
To connect to UE03HR
2
RS232
To connect to RS232-command-controllable device
(needs Terminal Block to RS232)
3
USB Type-C
To connect to USB 3.2 Gen1 source
4
Power/Link LED
Refer to LED Indicator

4
User Manual
UE03H
UE03HR
Interface
Description
1
DC Jack
To plug in DC 12V power adapter
2
Console
To update FW (needs 3.5mm jack cable to UART)
3
RS232
To connect to RS232-command-controllable device
(needs Terminal Block to RS232)
4
HDBaseT
To connect to UE03HT
5
USB Type-C/Type-A
To connect to USB device, compatible with USB 3.2 Gen1 / 2.0 / 1.1 / 1.0
6
Power/Link LED
Refer to LED Indicator

5
User Manual
UE03H
LED Indication
Interface
LED Color
Status
Power
(Green)
On
Power On
Off
Power Off
Link
(Blue)
On
RJ45 Linked
Off
RJ45 Unlinked
RS232 Pin Define
Transmission Distance
See Caution, point 6
Cable Type
Transmission Distance
CAT6a
83G02HD105
100m
USB Read & Write Speed
Testing Condition
Using CAT6a cables and CrystalDiskMark software, testing the read and
write speed of USB flash drives. PC：i5-12400 RTX3060Ti
ESD310C USB
3.2/Type C
256GB
SanDisk
SDDDC3 (Type
A) (USB 3.0)
SanDisk
SDDDC3 (Type
C) (USB 3.0)
SanDisk Ultra
Flair USB 3.0
64GB (Type A)
(USB 3.0)
KINGSTON
(Type A) (USB
3.0)
Read
Write
Read
Write
Read
Write
Read
Write
Read
Write
100m 83G02HD105
439.58
MB/s
437.74
MB/s
152.18
MB/s
65.84
MB/s
155.16
MB/s
65.49
MB/s
162.16
MB/s
52.43
MB/s
136.56
MB/s
11.31
MB/s

6
User Manual
UE03H
Caution
1. This product is designed for indoor applications. If it is desired for outdoor use, please install
additional equipment for waterproof protection and surge protectors to prevent damages
caused by lighting.
2. Do not put anything on the power and system cables, place them where they cannot be
stepped on. Please be sure there is nothing resting on any cables.
3. Avoid using this product close to water places, or near high temperature devices such as
radiators, stoves, etc.
4. Shut down the power supply and unplugged all equipment immediately if:
A. water or any kind of liquid has been spilled into the product;
B. the product has been damaged by external force;
C. the product does not operate normally as this manual indicates;
D. Please contact us for further repair if above conditions happen.
5. We strongly recommend using high quality CAT6a, CAT7 UTP/STP/FTP cable. Improper installation
may cause unstable connection.
6. The transmission distance may differ by cable or construction quality. Using CAT6a, CAT7 cable
between transmitter and receiver, the transmission distance can reach up to 100 meters.
7. This extender does not support video & audio transmission (DP alternate mode).
8. RS232 does not support hardware handshake.
9. The USB-Type C port on the device side does not support power delivery mode.

7
User Manual
UE03H
Technical Specification
UE03H
UE03HT
UE03HR
Compliance
Standard
USB 3.2 Gen1
USB 2.0
USB 1.1
USB 1.0
Max. Transmission
Distance
100m over CAT6a/7
Data Rate
USB 3.2 Gen1 up to 5Gbps bidirectional
Ports & Interfaces
USB Data
1 x USB Type-C
3 x USB Type-A
1 x USB Type-C
Transmission Medium
1 x RJ45
1 x RJ45
RS232
1 x 3-Pin Terminal Block
1 x 3-Pin Terminal Block
Console
1 x 3.5mm Phone Jack
Power
Power Supply
USB 5V
12V 1.5A
Power Consumption
2W
2.76W (No include USB device)
Power Saving
1.6W
1.8W
Ambient Temperature
Operation
0 to 55°C
Storage
-40 to 80°C
Operating Altitude
2000m
Humidity
Up to 95%
Physical Characteristics
Dimension
50 x 93 x 32mm
87 x 123 x 32mm
Weight
128g
259g

8
User Manual
UE03H
Installation
Installed on Wall
Step 1 Same way as “Installed on a Platform”, but need to put screw plugs into the pilot hole before
inserting the screws (leave 2mm space from the platform)

9
User Manual
UE03H
Installed on a DIN-rail
Step 1 Use machine screws to fix a DIN-rail mounting plat on the side of your product
Step 2 Install your product on a DIN-rail as following instruction
Installed on a Rack
Step 1 Lock machine screws in the rack
Step 2 Put your products on the rack

10
User Manual
UE03H
Step 3 Push the products to the other side of the rack

11
User Manual
UE03H
Step 4 Install the rack in a cabinet
