SC&T HE01ERK User manual

Smart Cabling & Transmission Corp. V1.0
HDMI Extender
User Manual
Model : HE01ERK
Passive HDMI CAT5e Extender

1
User Manual
HE01ERK
Introduction
HE01ERK is an HDMI extender that uses an Ethernet cable to extend HDMI signal with transmission
distance up to 70 meters and resolution up to 1080p. The RX unit has a built-in HDMI connector that allows
the receiver to directly connect to an HDMI display without any external power required.
Features
Supports HD-TVI, AHD, HDCVI, PAL, NTSC, SECAM video formats.
Resolution up to 1080p@60Hz.
Signal extension up to 70M.
No external power required.
Built-in micro USB port as a redundant power supply.
Installation
Panel Review
HE01SET HE01SER
Connect 5V power adapter via HE01SET built-in micro USB when HDMI source doesn’t provide enough
power to the receiver.
LED Indication:
Green: Power on/off
Yellow: Reserve

2
User Manual
HE01ERK
Transmission Chart
The transmission distance will be affected by DVR/NVR or cable quality.
HE01SET to HE01SER
Resolution
Distance based on CAT5e
1920x1200
40M
1920x1080
40M
1280x1024
60M
1280x 720
70M
1024 x768
70M
Supported Resolution
1920x1200@60Hz
1920x1080@60Hz
1680x1050@60Hz
1600x1200@60Hz
1600x900@60Hz
1440x900@60Hz
1280x1024@60Hz
1280x960@60Hz
1280x800@60Hz
1280x720@60Hz
1024x768@60Hz
800x600@60Hz
Cable
1. It is recommended using high quality CAT5e/6 UTP cable, especially when transmission range
over 30M.
2. It is not recommended using STP or flat cable, which may cause video loss.
RJ45 Define
Video Link (use TIA/EIA-568-B)
1. Orange-white
TMDS DATA2 +
2. Orange
TMDS DATA2 -
3. Green-white
TMDS CLOCK + / HDMI 5V
4. Blue
TMDS DATA1 +
5. Blue-white
TMDS DATA1 -
6. Green
TMDS CLOCK - / GND
7. Brown-white
TMDS DATA0 +
8. Brown
TMDS DATA0 -

3
User Manual
HE01ERK
Caution:
1. The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, ovens,
mobile phones, radio equipment, high voltage, power line.
2. Working distance will be variety based on different equipment.
3. The wiring must be straight through, do not circle the cable to avoid crosstalk interference.
4. HDCP is not supported.
5. HE01ERK isn’t networking product, thus please do not connect with any Ethernet device to avoid
any damage.
Package Contents:
1 x HE01SET (Transmitter)
1 x HE01SER (Receiver)
1 x Micro USB to DC plug cable

4
User Manual
HE01ERK
Specification
ITEM NO.
HE01SET
HE01SER
Support
Video Bandwidth
2.25 Gbps (HDMI 1.3)
Resolution
Up to 1920x1200@60hz
Input TMDS Video Signal
1.2 Vp-p
Input DDC Signal
5 Vp-p (TTL)
Transmission Distance
40M@1920x1200, 70M@1280x720
Ports & Interfaces
HDMI Connector
HDMI Type A
Link Connector
RJ45 x 1
Power
Power Connector
Micro USB x 1
Power Supply
5V 1Amp (Optional)
Ambient Temperature
Operation
-10 to 65℃
Storage
-20 to 85℃
Humidity
up to 85%
Physical Characteristics
Dimensions
57.5 × 24 × 20.2mm
Weigh
20g
