SC&T SP004 User manual

Smart Cabling & Transmission Corp.
V1.0
Surge Protector
User Manual
Model : SP004
UTP Data Surge Protector Terminal Connector

1
User Manual
SP004
Introduction
SP004 is a surge protector designed to protect data signal from high voltage surges..
Features
Resolution up to 4K.
Response time less than 1 ns..
SP004 UTP Data Surge protection Device Terminal Connector
Terminal connector to terminal connector.
Perfect for video or data signal protection
Installation View
Application
CATV System
Antenna of Television
Video Cassette Recorders
FM receivers
Video Cameras and monitors
Multiplexers and Quad Processor
Note
For ensuring the unit can
protect equipments, the cable
must be connected to ground.

2
User Manual
SP004
Specification
ITEM NO.
SP004
Support
Response Time
Less than 1ns
Max. Surge Voltage
4 KV
Surge Life
300 times (100A per surge)
Normal Resistance Across Coax
Approx, 0Ω
Band Pass
0 to 1 GHz
Power Passing Capability
AC/ DC 130V, 65 Vrms@10 A
Insertion Loss
Less than 0.2 dB
Return Loss (75Ω)
16dB
Ports & Interfaces
Equipment End
1 x 2-pin Terminal Block
Cable End
1 x 2-pin Terminal Block
Ambient Temperature
Operation
-10 to 75℃
Storage
-40 to 90℃
Humidity
95%
Physical Characteristics
Dimensions
82.5 x 25.4 x 25.4mm
Weight
60g
