SC&T SP007 User manual

Smart Cabling & Transmission Corp. V1.0
Surge Protector Series
User Manual
Model : SP007
HD-SDI Surge Protector

1
User Manual
SP007
Introduction
SP007 is a surge protector designed to protect a valuable SDI device from high voltage surge, with video
bandwidth up to 2.97G.
Features
Supports 3G-SDI, and HD-SDI video formats
Supports video bandwidth at 270M, 1.5G, 2.97G.
Response time less than 1 ns.
Installation View
Application
CATV System
Antenna of Television
Video Cassette Recorders
FM receivers
HD Cameras and HD DVR/Monitors
HD-SDI video camera
Cable
Link cable recommend to use high quality 75ΩCoaxial Cable & BNC connector , to use low quality coaxial
cable may case signal loss and effect transmission distance and reliability.
Coaxial Cable
SP007
BNC
MALE
BNC
FEMALE
BNC
MALE
BNC
FEMALE
SP007
Note:
For ensuring the unit can protect
equipments, the cable must be
connected to ground.
SDI DVR or
TV Monitor
HD-SDI
Source

2
User Manual
SP007
Specification
ITEM NO.
SP007
Support
Video Bandwidth
270M to 2.97Gb/s
Insertion Loss
1.1dB@ 2.97Gb/s
Max Clamping Voltage
25V
Response Time
Less than 1ns
Resist Surge
8KV (Max)
Ports & Interfaces
Equipment End
1 x BNC Male (75Ω)
Cable End
1 x BNC Female (75Ω)
Ambient Temperature
Operation
-10 to 75℃
Storage
-40 to 90℃
Humidity
Up to 90%
Physical Characteristics
Dimensions
75.5 x 25.4 x 25.4mm
Weight
70g
