Scantech Vega V-1010BT User manual

U s e r ’ s M a n u a l
V-1010BT Wireless Handheld Linear
Imager Bar code Scanner

User’s Installation and Configuration
Manual
Copyright © 2012, Scantech-ID BV.
This manual is copyrighted, with all rights reserved. Under the copyright
laws, this manual may not, in whole or in part, be copied, photocopied,
reproduced, translated or converted to any electronic medium or machine
readable form without prior written consent of Scantech-ID BV.
Limited Warranty
Under all circumstances this manual should be read attentively, before
installing and/or using the product. In no event shall Scantech-ID BV be
liable for any direct, indirect, special, consequential or incidental
damages arising out of the use or inability to use this documentation or
product, even if advised of the possibility of such damages. In particular,
Scantech-ID BV shall not be liable for any hardware, software, or data that
is stored or used with the product, including the cost of repairing,
replacing or recovering the above. Scantech-ID BV reserves the right to
change parts of the device at any time without preceding or direct
announcement to the client.
Scantech-ID BV reserves the right to revise this manual, and to make
changes in the contents without obligation to notify any person or entity
of the revision or change. A serial number appears on the product. Make
sure that this official registration number has not been removed. It should
be used whenever servicing by Scantech-ID BV or an authorized Scantech
dealer is necessary.
Notice: The manufacturer shall not be liable for technical or
editorial errors or omissions contained herein; nor for
incidental or consequential damages in connection with the
furnishing, performance or use of the publication
V2.0 Feb. 2012

Table of contents
Table of contents ..................................... 3
INTRODUCTION .......................................... 1
CHAPTER 1 PRODUCT SAFETY............................. 2
1.1 Safety & Caution ......................... 2
1.2 FCC Warning .............................. 3
CHAPTER 2 GENERAL DESCRIPTION........................ 4
2.1 Use of the V-1010BT ...................... 4
CHAPTER 3 INSTALLATION OF THE V-1010BT............... 5
3.1 V-1010BT Unpacking ....................... 5
3.2 V-1010BT Cradle Installation ............. 6
3.3 V-1010BT Setup Bluetooth Communication ... 7
3.3.1 Pairing.................................... 7
3.3.2 Setup SPP Master Mode Communication........ 7
3.3.3 Setup SPP Slave Mode Communication......... 9
3.3.4 Setup HID Slave Mode Communication......... 9
3.3.5 Sleep Mode................................. 9
3.3.6 Batch Mode................................ 10
3.3.7 Out of Range.............................. 10
CHAPTER 4 CONFIGURING THE V-1010BT.................. 11
4.1 Preface ................................. 11
4.1.1 Changing Scanner Settings with Programming
Codes .......................................... 11
4.1.2 Programming Flow Chart.................... 12
4.2 Set All Default Parameter ............... 13
4.3 General Process ......................... 13

4.3.1 Abort Configuration ...................... 14
4.3.2 Recall ................................... 14
4.3.3 Version Information ...................... 14
4.4 Cradle Interface Selection...............14
4.4.1 Interface ................................ 14
4.5 Bluetooth Scanner Setup..................15
4.5.1 Preface .................................. 15
4.5.2 Scanner Mode ............................. 15
4.5.3 *** Batch Mode (“***” means “Quick Setting
Label”, The function can be executed directly by
scanning barcode instead of doing the general
programming process.)............................. 16
4.5.4 Out of Range ............................. 16
4.5.5 Sleep Mode ............................... 16
4.5.6 Scanner Pincode Mode ..................... 17
4.5.7 Scanner Pincode Setup .................... 17
4.6 Bluetooth Cradle Setup...................18
4.6.1 Cradle Pincode Mode ...................... 18
4.6.2 Cradle Pincode Setup ..................... 18
4.7 Scanner Operation........................18
4.7.1 Reading Mode ............................. 18
4.7.2 Beeper Option............................ 19
4.7.3 Reading Level ............................ 20
4.7.4 Accuracy Scan ............................ 20
4.7.5 Sensitivity of Continuous Reading ........ 20
4.7.6 Reverse Output Characters ................ 21
4.8 RS232 Mode Parameters....................21
4.8.1 Baud Rate ................................ 21
4.8.2 Data/Stop Bits ........................... 22

4.8.3 Parity.................................... 22
4.8.4 Handshaking............................... 23
4.9 Keyboard Wedge Mode Parameters .......... 24
4.9.1 Terminal Type............................. 24
4.9.2 Country/Language.......................... 25
4.9.3 Upper/Lower Case.......................... 26
4.9.4 Capslock Detection........................ 26
4.9.5 Character by ALT Method................... 27
4.9.6 Select Numerical Pad...................... 27
4.9.7 Interscan Code Delay...................... 27
4.10 Output Characters ....................... 28
4.10.1 Select Terminator......................... 28
4.11 Code Type ............................... 29
4.11.1 Barcode Selection......................... 29
4.12 UPC/EAN/JAN Parameters .................. 32
4.12.1 Reading Type.............................. 32
4.12.2 Supplemental Setup........................ 34
4.12.3 Check Digit Transmission.................. 34
4.13 Code 39 Parameters ...................... 35
4.13.1 Type of Code.............................. 35
4.13.2 Check Digit Transmission.................. 35
4.13.3 Output Start/Stop Character............... 36
4.13.4 Decode Asterisk........................... 36
4.13.5 Setup Code Length......................... 36
4.14 Code 128 Parameters ..................... 38
4.14.1 Reading Type.............................. 38
4.14.2 Check Digit Transmission.................. 38
4.14.3 Append FNC2............................... 38

4.14.4 Setup Code Length ........................ 39
4.15 Interleave 2 of 5 Parameters.............40
4.15.1 Check Digit Transmission ................. 40
4.15.2 Setup Number of Character ................ 40
4.15.3 Brazilian Banking Code ................... 41
4.15.4 Setup Code Length ........................ 41
4.16 Industrial 2 of 5 Parameters.............43
4.16.1 Reading Type ............................. 43
4.16.2 Check Digit Transmission ................. 43
4.16.3 Setup Code Length ........................ 43
4.17 Matrix 2 of 5 Parameters.................45
4.17.1 Check Digit Transmission ................. 45
4.17.2 Setup Code Length ........................ 45
4.18 CODABAR/NW7 Parameters...................47
4.18.1 Setup Start/Stop Characters upon
Transmission...................................... 47
4.18.2 Transmission Type of Start/Stop .......... 47
4.18.3 Setup Code Length ........................ 48
4.19 Code 93 Parameters.......................50
4.19.1 Check Digit Transmission ................. 50
4.19.2 Setup Code Length ........................ 50
4.20 Code 11 Parameters.......................51
4.20.1 Check Digit Transmission ................. 51
4.20.2 Setup Code Length ........................ 52
4.21 MSI/Plessey Code Parameters..............54
4.21.1 Check Digit Transmission ................. 54
4.21.2 Setup Code Length ........................ 54
4.22 Telepen Parameters.......................56
4.22.1 Type of Code ............................. 56

4.22.2 Check Digit Transmission.................. 56
4.22.3 Setup Code Length......................... 56
4.23 GS1 Databar Omnidirectional Parameters .. 58
4.23.1 Check Digit Transmission.................. 58
4.23.2 Application ID............................ 58
4.23.3 Symbology ID.............................. 58
4.24 GS1 Databar Limited Parameters .......... 59
4.24.1 Check Digit Transmission.................. 59
4.24.2 Application ID............................ 59
4.24.3 Symbology ID.............................. 59
4.25 GS1 Databar Expanded Parameters ......... 60
4.25.1 Symbology ID.............................. 60
CHAPTER 5 MISCELLANEOUS PARAMETERS.................. 61
5.1 Bar Code ID ............................. 61
5.1.1 Default Barcode ID........................ 61
5.1.2 User Define Code ID....................... 62
5.2 Preamble and Postamble Insertion ........ 64
5.2.1 Setup Insertion........................... 64
5.2.2 Insertion Set Number...................... 65
5.2.3 Code Type for Insertion................... 66
5.2.4 Position to Be Inserted................... 68
5.2.5 Characters to Be Inserted................. 68
5.3 Character Deletion ...................... 68
5.3.1 Deletion Set Number....................... 70
5.3.2 Code Type for Deletion.................... 70
5.3.3 Position to Be Deleted.................... 72
5.3.4Number of Characters to Be Deleted........ 72

APPENDIXES ............................................73
A. Decimal Value Table......................73
B. ASCII Value Table.........................74
C. ASCII Table..............................75
D. Function Key Table.......................81
C. Technical Specifications.................82
D. Scan Map.................................84
E. LED Indicator Status.....................85
F. Test Symbologies.........................86
G. Quick Configuration......................88

1
INTRODUCTION
V-1010BT is a cutting-edge gun-type barcode scanner
which is designed specifically for retail market. To the
brand new series of V-1010BT, we add on more user-
friendly functions with detachable interface cable that
makes it easier to be operated by the customers.
Speaking of the performance, this scanner supports
middle to long range mode.V-1010BT which supports the
reading depth up to 50 centimeters, and the scan rate is
up to 500 scans per second by its own smart detection.
In short, V-1010BT is absolutely a high performance gun-
type scanner which provides the customer with the most
cost-effective solution in the market. It is perfectly
suitable and definitely the best choice for any
retailers using POS environment.
The V-1010BT comes with the same top quality as all
other Scantech-ID products. So at a very competitive
price the same quality and performance of more expensive
products is available. Due to the high MTBF times of
every component a long and service free operation time
is secured.
The V-1010BT is available in different interface types,
RS232, Keyboard Wedge, USB HID or Virtual comport
interface, so there is always a solution to connect the
V-1010BT to your POS system.

2
CHAPTER 1 PRODUCT SAFETY
1.1 Safety & Caution
1. Please read the following safety statement carefully.
2. Please preserve this user’s manual for reference
sometime.
3. Before cleaning the V-1010BT, the users must cut off
all AC power. Do not use liquid or spray type of
detersive to clean the V-1010BT. Please use dampish
cotton cloth to clean the V-1010BT.
4. The outlet must set nearby the V-1010BT for
connecting power easily.
5. Keep the V-1010BT dry to avoid short circuit.
6. During installation you must fix the equipment at
solid table to avoid damage caused by falling.
7. Before inserting power please ensure the voltage is
healthy to the equipment.
8. For safety please tie wire well and don’t put
anything on the wire.
9. If you don’t use this equipment for long time, please
cut off the power to avoid damage from surge power.
10. Don’t spray any liquid on this scanner because it may
cause a fire or short circuit.
11. Please do not open the equipment. For safety only the
qualified serviceman can open the equipment.
12. If there are the following situations please contact
the qualified serviceman to check this equipment.
(a) The damage of wire or pin of power supply.
(b) Some Liquid infiltrate into the equipment.
(c) The equipment has been exposed to wet
environment.
(d) The equipment can’t work well.
(e) The equipment has any obvious damage, making the
V-1010BT working abnormally.
13. Don’t store the V-1010BT at the temperature lower
than -20°C (-4°F) or higher than +70°C (158°F) to
avoid any damage.

3
1.2 FCC Warning
This equipment complies with the requirements in Part
15 of FCC.
Any operation must comply with the conditions below:
(a)The equipment will not cause any severe interference.
(b)The equipment can avoid any interference from
environment.
Statement:
This product is classified as B class product.
In environment this product may cause some
interference. In this situation the user may
do something to avoid interference.

4
CHAPTER 2 GENERAL DESCRIPTION
2.1 Use of the V-1010BT
The V-1010BT is very ergonomic and modern designed and
very user friendly. It can be connected to your POS or
Host system trough a RS232, Keyboard Wedge or USB cable.
To read a bar code, simply press the red trigger button
and aim the beam to the bar code. It needs to position
the beam to fall across all bars in the 1D barcodes. You
will hear one beep and the green LED indicator will light
on after scan successfully.
The programming of the V-1010BT is very easy. You can
setup the V-1010BT by scan all necessary programming
codes that meet applications. Thanks to the powerful
decoding software, the V-1010BT can decode all major 1D
codes.

5
CHAPTER 3 INSTALLATION OF THE V-
1010BT
3.1 V-1010BT Unpacking
Unpack the V-1010BT as follows:
1. Take the V-1010BT and its accessories out of the box.
2. Remove the packing material.
3. Check the packing list to make sure you have received
all of the items ordered.
3.1 Standard Shipment Package:
a. V-1010BT Linear Barcode Scanner
b. Bluetooth Cradle
c. Communication Cable(RS-232,keyboard wedge or USB)
d. Power Adaptor
e. Product Compact Disc
4. Visually inspect the V-1010BT and accessories for any
evidence of physical damage.
5. If anything is missing or appears to be damaged,
immediately contact your dealer.
ATTENTION
Store the packing material and boxes: it should
be used whenever the V-1010BT is transported
for service.

6
3.2 V-1010BT Cradle Installation
To setup your V-1010BT scanner with Bluetooth technology,
please follow the steps.
1. Connect the supplied communication cable at the
bottom side of the cradle.
2. Connect the other side of the communication cable
to the right connector of your POS or HOST system.
3. Plug the external power supply into the power jack
on the bottom of the cradle.
4. Plug the power supply into the AC outlet.
5. Turn on your POS or HOST system.

7
3.3 V-1010BT Setup Bluetooth Communication
3.3.1 Pairing
Pairing refers to when a V-1010BT scanner has been linked
or paired to a specific cradle by scanning that cradle’s
Bluetooth MAC address code. This Bluetooth MAC address
code is unique for each cradle. This address code is
located on the bottom side of the cradle. The pairing of
a V-1010BT scanner to a cradle is one to one. Only one V-
1010BT scanner can be paired to a cradle at any point in
time.
3.3.2 Setup SPP Master Mode Communication
To setup the communication between the V-1010BT scanner
and the cradle, follow the steps:
1. The V-1010BT scanner must scan “SPP Master Mode”
barcode to set the V-1010BT scanner in Master mode.
2. Scan the Bluetooth MAC address code located on the
bottom of the cradle.
3. When the Bluetooth MAC was successfully scanned,
scanner will initiate with 3 short beep sounds. Blue
LED will blink followed by a long beep sound.
4. Wait approximately five seconds, for completing the
connection process. Blue LED will slow flash on
scanner for connecting the cradle.
5. If successful, the blue LED on the cradle will be on.
6. If the connections failed, the blue LED on scanner
will be off, and the cradle indicators blinking blue
LED.

8
ATTENTION
The V-1010BT scanner must be charged for a
minimum of 8 hours before the scanner can be
placed in full operation for the first time.
The scanner LED will indicate in red when the
scanner is charged.
After the battery is full, the green LED on
scanner will be on. The charge green LED will
be off when the scanner leaving from cradle.
If the battery power of the V-1010BT is too
low, the V-1010BT will indicate red LED and
beeper warning.
It is important to know that the V-1010BT scanner will
only communicate with the cradle whose unique Bluetooth
MAC address was last scanned.
If a cradle is paired with the V-1010BT scanner, another
V-1010BT scanner can’t be paired with that cradle until
the original connection is interrupted.
If you pair a second V-1010BT scanner to an in-use cradle,
the cradle’s connection to the first V-1010BT scanner
will be interrupted and the connection will be re-
established with the second V-1010BT scanner.
Bluetooth MAC
Address

9
3.3.3 Setup SPP Slave Mode Communication
To setup the communication between the V-1010BT scanner
and Bluetooth SPP profile application device, follow the
steps.
1. The V-1010BT scanner must scan “SPP Slave Mode”
barcode, to set the V-1010BT scanner in Slave mode.
2. When control the Bluetooth device to search the
scanner, enter pin code (default 00:00:00) to setup
comport.
3. When V-1010BT scanner is successful connected, the
scanner Blue LED will also blink followed by a long
beep sound. Blue LED will slow flash to finish the
setup.
3.3.4 Setup HID Slave Mode Communication
To setup the communication between the V-1010BT scanner
and Bluetooth HID profile application device, follow the
steps.
1. The V-1010BT scanner must scan “HID Slave Mode”
barcode, to set the V-1010BT scanner in HID Slave
mode.
2. When control the Bluetooth device to search the
scanner, enter pin code to setup pair. You can scan
number barcode on Appendix B.”ASCII VALUE TABLE”
number 0~9 to setup.
3. When V-1010BT scanner is successful connected,
scanner Blue LED will also blink followed by a long
beep sound. Blue LED will slow flash to finish the
setup.
3.3.5 Sleep Mode
The V-1010BT scanner enters sleep mode to save battery
energy, when the V-1010BT scanner is used for 1 minute or
10 minute time. During sleep mode all the functions and
connection will be halted. After press the red trigger
button the scanner will wake up and reconnect the
communication with the cradle or Bluetooth device.

10
3.3.6 Batch Mode
This batch mode is enabled when you have scanned “Batch
Mode on”. The scanned data is stored in the memory of the
SG700BT scanner instead of being transmitted. You can
delete the last scanned bar code data by scanning “Delete
Last Data” bar code. This function is disabled when you
scan “Batch Mode OFF”.
When scan bar code “Batch Data Output”, the stored
scanned data will be immediately transmitted to the host.
When scan barcode “Batch Data Clear”, all stored scanned
data will be erased from memory.
The capacity of this memory depends on the scanned data.
The memory size is approximately 30,000 sets of EAN13 bar
code type.
3.3.7 Out of Range
When “Out of Range” function is enabled, and the scanner
is working at out of transmission range, the scanned data
will be stored to out-of-range memory. Memory size is
approximately 25,000 sets of EAN13 bar code type
The all stored data will be transmitted to device when
the link is reconnected, and the all data store in out-
of-range memory will be cleared.

11
CHAPTER 4 CONFIGURING THE V-1010BT
4.1 Preface
How to configure the V-1010BT.
The barcode programming feature gives the possibility to
change the V-1010BT scanner settings with programming
labels.
4.1.1 Changing Scanner Settings with
Programming Codes
You can setup your V-1010BT by scan all necessary
programming codes that meet applications.
In order to change the scanner settings please follow the
sequence below:
1. Power up the scanner.
2. Open the scanner programming mode by scanning
“Start Configuration”.
3. Change scanner settings by scanning any of the
programming code that meet applications.
4. Close the scanner programming mode by scanning
“End Configuration”.
5. Save configuration by scanning “Save Parameters”.
An Example:
For changing the Baud rate to 38400 the following codes
must be scanned successively:
Start ConfigurationBaud Rate 38400End configuration
Save Parameters
After reading a valid programming code the scanner, will
give three high beep and the green LED indicator will
light on.

12
By scanning “Set All Default” label, the settings will go
back to the factory default settings.
4.1.2 Programming Flow Chart
Start
Configuration
Recall
Parameters
Set all Default
Interface
Selection
Communication
Parameters
Bar codes
Parameters
Misc. Parameters
etc.
End
Configuration
Abort
Configuration
Save
Parameters
