SCANTOOL PFS1
HAND SHEARER OPERATION MANUAL
EC declaration of conformity
hereby declares that
SCANTOOL PFS 1 HAND SHEARER are manufactured in accordance with the provisions
of the COUNCIL DIRECTIVE of 17. May 2006 (2006/42/EC) –The Machinery Directive
(order no. 561 of 25 June 1994 with subsequent amendments)
2006/42/EC: Directive on machinery-safety
2004/108/EC: Directive on Electromagnetic Compatibility
2006/95/EC: Low Voltage Equipment Safety directive
Also on accordance with:
The council directive of 19 February 1973 (73/23/EEC) –The Low Voltage Directive
–with later amendments (order no. 797 of 30 August 1994)
The council directive of 3 May 1989 (89/336/EEC) –The EMC Directive –with later
amendments (order no. 796 of 5 December 1991 with subsequent amendments)
SCANTOOL A/S
Industrivej 3-9
9460 Brovst
Denmark
www.scantool.com
Ph: +45 98 23 60 88
Fax.: +45 98 23 61 44
Please read this manual carefully before install and operation.
1. Usage
This machine is suitable for shearing carbon steel plate and bar. It can be used to
shear non-ferrous metal or plastic and bar.
2. Main technical specification
3. Installation and caution
3.1 Installation
3.1.1 Please check whether the part of this machine are fully equipped and
not damaged to the parts list or part figure.
3.1.2 This machine should be mounted on hard ground or specific place
(not supplied).
3.1.3 Please leave plenty room around the machine for your easy operating,
in order to avoid injury.
3.1.4 Please remove the anti-rust grease on processing surfaces and some
parts included with kerosene.
3.2 Caution
3.2.1 Please read the manual before operation and make yourself
understand its structure and principle completely.
3.2.2 Please do not operate the material width and thickness than table list
max.range.
3.2.3 When you shear the plate or bar which list in above table, you must
be used lengthen handle in order to increase force.
3.2.4 Please do not touch the blade during operation.
4. Operation and maintenance
This machine is pre-adjusted before out of factory. When you want to shear,
please raise handle (9#), the upper blade (4#) will put up, insert the workpiece,
then lower the handle (9#) to shear.
Before you shearing, you can adjust disc (12#) to press the workpiece.
5. Lubricate the rotaing parts of the machine every day.
6. Parts list
