OWNER’S MANUAL
SAFE Y INS RUC IONS
Please read and keep these instructions with the fan.
MODEL: VAF1500A/B
For use in Non-Explosive/Non-Flammable environments only.
Purchase Date: ___________________ Serial No. ___________________
Dealer: ______________________________________
1.800.779.3267 • www.schaeferfan.com
Item Part# Each Description
1 0SMS8X12PPHSS 4 Screw #8 x 1/2" PPH SS
2 SWP TASY-V15A 1 Switch Plate Cord Kit 115V
(capacitor not included)
SWP TASY-V15B 1 Switch Plate Cord Kit 230V
(capacitor not included)
0CAP10UF350V 1 Capacitor 115V
0CAP7UF400V 1 Capacitor 230V
CORD-16/3-20NA 1 Cord 115V North America
CORD-16/3-20EU 1 Cord 230V European
CONNECTOR-PG11 1 Cord Strain Relief
0RSSPST20A 1 Rocker Switch
0RSCAP 1 Rocker Switch Cover
3 HSG-VAF1500 1 Shell Housing Yellow
0RG38X1316X38 1 Rubber Grommet 3/8"
4 0BM3-0.5X25HHSS 4 Bolt M3x.5 25mm
5 0WM3SS 4 Washer M3 SS
6 0RF78OD 4 Rubber Foot 7/8" OD
7 0WNM3-0.5HT 4 Well Nut M3x.5
8 0NY832Z 6 Nut Nyloc 8-32
9 0W8SAE 6 Washer #8 SAE
10 GUARD-VAF1500 2 Wire Guard 10"
11 0S832X1PPHZ 6 Screw 8-32 x 1" PPH
12 0W8SAE 6 Washer #8 SAE
13 0RIVET6-8A-B 9 Rivet 3/16" x 1/2" G
14 CS2141 1 Motor 1/4 HP 115V 60 Hz
CS2141-50 1 Motor 1/4 HP 230V 50 Hz
B ADE-VAF1500 1 Fan Blade 8" 5 Wing
0RC-VAF15 1 Retainer Clip
0PIN-VAF15 1 Spring Pin
15 RING-VAF1500 2 Duct Ring 10" to 8"
PROBLEM
Unit will not run.
Unit runs but fan
makes loud scraping
noise.
Unit runs but
vibrates excessively.
Unit runs but fan
does not turn.
Unit runs briefly,
then shuts off on
overload.
CAUSE
1) No power to unit.
2) Switch not on.
3) Switch is faulty.
4) Faulty / Broken cord or motor wire.
1) Unit has been severely jolted causing fan to
rub against housing.
2) Unit has been severely jolted causing
housing to deform.
1) Severe jolt has bent motor shaft causing
unit to be out of balance.
2) Fan blade damaged.
3) Dirt build up on one side of fan blade.
1) Fan is jammed against housing.
2) Capacitor wire has broken/come loose,
capacitor has failed.
3) Housing has been damaged such that it
presses on the fan blade.
1) Motor bearings are failing, or motor has
developed an internal electric fault.
2) Intake grill and/or exhaust grill is obstructed.
3) Excessive duct length.
SOLUTION
1) Plug unit in. Check circuit breaker.
2) Place in "ON" position.
3) Replace switch.
4) Perform continuity check, using volt/amp meter,
Repair/replace faulty/broken wire.
1) Remove motor and replace damaged motor
mounts.
2) Replace housing/unit as necessary.
1) Remove and replace motor. Replace fan blade if
necessary.
2) Replace fan blade.
3) Clean fan blade.
1) Remove motor and replace damaged motor
mounts. Replace fan blade if necessary.
2) Repair/replace wires/capacitor as necessary.
3) Replace housing/unit as necessary.
1) Replace motor.
2) Remove obstruction.
3) Reduce duct length to recommended maximum.
AMERIC AXIAL FAN TROUBLESHOOTING
CAUTION: All service procedures should be executed with the unit unplugged.
UNITED KINGDOM CORDS ONLY
WARNING
THIS APPLIANCE MUST BE EARTHED. IMPORTANT!
The wire of this mains lead are colored in
accordance with the following code:
B UE---- NEUTRA
BROWN---- IVE
YE OW / GREEN---- EARTH
As the colors of the wires in the mains lead of this
appliance may not correspond with the colored markings
identifying the terminals in your plug proceed as follows:
The wire colored brown must be connected to the terminal
marked with the letter — — or colored red.
The wire colored blue must be connected to the terminal
marked with the letter —N— or colored black.
The wire colored yellow/green must be connected to the
terminal marked with the letter E or Ensure that your
machine is connected correctly. If you are in any doubt
consult a qualified electrician.
This appliance must be protected by a 13A fuse if a 13A
(B.S. 1363) plug is used or if any other type of plug is
used, by a 5A fuse either in the plug or adapter or at the
distribution board.
©2012 Schaefer Ventilation Equipment. All rights reserved.
M-VAF1500A/B
(Refer to item # on pictorial breakdown)

SCHAEFER LIMITED WARRANTY
If you are the original purchaser of a new Americ Vane Axial Fan from Schaefer, then you are entitled to a
limited warranty subject to the terms and conditions set forth herein. To qualify for the limited warranty you
must complete the enclosed registration card and mail it to Schaefer within (30) days of the purchase so that
there is a record of your purchase. Schaefer's limited warranty is for the replacement or repair of any part that
proves to be defective in workmanship or materials for a period of one (1) year from the date of purchase by
the original purchaser. During the first year, Schaefer will provide all parts necessary to correct any defects,
free of charge. This limited warranty extends only to the original purchaser who retains ownership of the Fan.
This limited warranty is not transferable to any subsequent purchaser or second-hand user.
The limited warranty extends only to the repair or replacement of parts found upon Schaefer's examination to
be defective. Unless any part or assembled unit replaced hereunder is returned, freight pre-paid, together with
a letter describing the problem to Schaefer or an authorized Schaefer dealer, this limited warranty will be void
and of no effect.
This warranty is limited to ninety (90) days for labor from the date of the purchase. Thereafter, any labor costs
incurred will be charged to the customer at the prevailing hourly rate.
This limited warranty shall not extend to a product that has been used in an improper manner, or that has been
disassembled, altered or improperly maintained. Nor shall this limited warranty apply if the Fan has been
subjected to corrosive chemicals, improper voltage, unauthorized repairs, fire, flood, abnormal wear or any
causes beyond Schaefer's control.
This limited warranty does not apply if the serial number has been removed, obliterated or defaced.
Schaefer Ventilation reserves the right to make changes to the Vane Axial Fan in design, materials or
specifications as necessary and without prior notice. Schaefer shall not be obliged to make alterations or
modifications to existing products previously manufactured.
To obtain replacement parts pursuant to this limited warranty, you must write to Schaefer or call
[phone] to receive an authorization number. Replacement parts will not be provided unless the
customer first provides the serial number of the Fan and also receives an authorization number from
Schaefer.
OTHER THAN THE FOREGOING IMITED WARRANTY, THERE ARE NO FURTHER WARRANTIES OR
ANY AFFIRMATIONS OF FACT OR PROMISES BY AMERIC WITH RESPECT TO THE VANE AXIA FAN.
THE DURATION OF ANY IMP IED WARRANTIES ARE IMITED TO THE TERMS OF THE ABOVE IMITED
WARRANTY. SOME STATES DO NOT A OW IMITATIONS ON HOW ONG AN IMP IED WARRANTY
MAY AST, SO THE ABOVE IMITATIONS MAY NOT APP Y TO YOU. WITHOUT IMITING THE
GENERA ITY OF THE FOREGOING, SCHAEFER EXPRESS Y DISC AIMS ANY INFRINGEMENT OR ANY
AFFIRMATIONS OF FACT OR QUA ITY NOT EXPRESS Y CONTAINED HEREIN. SCHAEFER
VENTI ATION AND ITS AFFI IATES NEITHER ASSUME NOR AUTHORIZE ANY PERSON TO ASSUME
FOR THEM ANY OTHER OB IGATION OR IABI ITY IN CONNECTION WITH ITS PRODUCTS. THERE
ARE NO OTHER WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
IN NO EVENT SHA SCHAEFER VENTI ATION BE IAB E FOR SPECIA , INCIDENTA OR
CONSEQUENTIA DAMAGES, OR FOR OSS OF PROFITS OF ITS CUSTOMERS OR USERS OF
PRODUCT. SOME STATES/JURISDICTIONS DO NOT A OW THE EXC USIONS OR IMITATIONS OF
INCIDENTA OR CONSEQUENTIA DAMAGES, SO THE ABOVE IMITATIONS MAY NOT APP Y TO YOU.
THIS IMITED WARRANTY GIVES YOU SPECIFIC EGA RIGHTS, AND YOU MAY A SO HAVE OTHER
RIGHTS WHICH VARY FROM STATE TO STATE.
VAF1500 PICTORIAL BREAKDOWN

INTRODUCTION
Congratulations on your selection of a new Vane Axial Fan from Schaefer Ventilation. Our goal is to provide
you with the very best in high performance air ventilators. Reading this Owner's Manual will help you achieve
the maximum benefit from your portable air ventilator. If you do not understand any portion of this Manual,
please contact Schaefer, or your authorized Schaefer dealer for proper assistance prior to operating this Fan.
Do not allow anyone to operate the Vane Axial Fan without first reading the Operator's Manual and becoming familiar with its
operation. Schaefer has endeavored to provide you with the finest equipment available for providing air for portable
ventilation purposes. The possibility does exist, however, that the Vane Axial Fan can be subjected to applications not
intended by Schaefer. Misuse and/or misapplication of the Vane Axial Fan can lead to the possibility of serious
damage, injury or even death. Anyone operating the Vane Axial Fan should refer to current OSHA job safety and health
rules and regulations pertaining to the construction industry, with a particular emphasis on 29 CFR 1910, which contains
rules governing Permit-Required Confined Spaces for General Industry.
Record the Vane Axial Fan model and serial number in the space provided below.
Model No. Serial No. Date Purchased
All specifications are general in nature and are not intended for specific application purposes. Schaefer accepts no
responsibility for variations which may be evident in actual products, specifications, pictures and descriptions contained in
this publication.
MAINTENANCE
DANGER
ALWAYS SHUT OFF THE FAN AND UNPLUG IT FROM ITS POWER SOURCE TO PREVENT ACCIDENTAL STARTING
AND THE POSSIBILITY OF ELECTRICAL SHOCK AND/OR ELECTROCUTION. BE SURE THE FAN BLADE HAS
STOPPED ROTATING BEFORE PLACING ANY OBJECTS OR FINGERS NEAR THE FAN GRILL.
I. Visually check all fasteners and individual components for loose or broken parts. Tighten or replace items, as required,
only with genuine, factory approved replacement parts.
2. Keep the Fan blade clean from debris. Accumulation of dust, dirt, paint, etc. on the Fan blade will throw the blade rotation
out of balance resulting in damage. To clean the Fan blade, be sure the plug is disconnected and the blade has stopped
rotating. Remove one grill and wipe blade and interior shell housing clean of debris with a damp cloth and mild liquid soap.
Dry all parts thoroughly. DO NOT PRESSURE WASH THE FAN. Replace grill prior to next operation.
DANGER
DO NOT OPERATE THE FAN WITHOUT THE INLET AND OUTLET GRILL PROPERLY IN PLACE.
3. Contact Schaefer directly for Fan maintenance or repair not described in this manual (or if you are unsure whether
maintenance is required.) at Tel# [phone], or at www.schaeferfan.com.
SERVICE
1) Refer to the TROUB ESHOOTING GUIDE in this Manual.
MOTOR SPECIFICATIONS GENERAL INFORMATION & DIMENSIONS
AB
Voltage 115V AC-- 230V AC-- Type Axial
Frequency 60 Hz 50Hz Duct adapter 8" dia. (203 mm)
Phase Single Single Height 18.5" (470 mm)
Electric Motor 1/4 HP 1/4 HP Width 12.5" (318 mm)
Current (amps) 2.5 1.3 ength 18.5" (470 mm)
R.P.M 3000 2260 Weight 18 lbs (8.1 kg)
Free Air (cfm) 877 (24.8 m3 ) 749 (21.2 m3)
Max S.P. 1.5" 1.5"
AIR FLOW RATES
(115V AC) (230V AC)
Feet Description CFM M³/Min CFM M³/Min
Free Air 877 24.8 749 21.2
15' duct Straight 610 17.3 510 14.4
25' duct Straight 597 16.9 508 14.4
25' duct 1-90° bend 533 15.1 464 13.1
25' duct 2-90° bends 508 14.4 435 12.3
40' duct Straight 518 14.7 460 13.0
50' duct Straight 460 13.0 443 12.5
The published flow rates are intended to serve only as a reference. Manufacturing tolerances, duct type, and specific
operating parameters will affect the overall flow rates(s) for each particular Fan.
CAUTION
THE AIR FLOW RATE DECREASES AS THE LENGTH OF DUCT INCREASES FOR BOTH BLOWING AND
SUCTION APPLICATIONS. AIR FLOW RATES WILL VARY WITH SPECIFIC DUCT TYPES AND
MANUFACTURES.

SAFE Y PRECAU IONS
DANGER
THE FAN IS DESIGNED FOR PORTABLE AIR VENTILATION PURPOSES ONLY. THE FAN IS NOT DESIGNED
FOR TRANSPORTING LIQUID OR SE I-SOLID ATERIALS. HE ELEC RIC MO OR AND FAN HOUSING ARE
NO DESIGNED FOR OPERA ION IN AN EXPLOSIVE OR FLAMMABLE A MOSPHERE. OPERA ION OF
HE FAN IN AN EXPLOSIVE OR FLAMMABLE A MOSPHERE MAY RESUL IN PROPER Y DAMAGE,
PERSONAL INJURY OR EVEN DEA H. INCORRECT USE OF THE FAN CAN RESULT IN AN ELECTRICAL
SHOCK AND/OR ELECTROCUTION. ALWAYS OPERATE THE FAN IN CO PLIANCE WITH CURRENT OSHA
AND NATIONAL ELECTRIC CODE REGULATIONS.
DANGER
INCORRECT USE OF THE FAN CAN RESULT IN PROPERTY DA AGE, PERSONAL INJURY OR EVEN DEATH.
TO REDUCE THIS RISK, GIVE CO PLETE AND UNDIVIDED ATTENTION TO THE JOB AT HAND. AN
ENVIRON ENT AT OSPHERE CONSTANTLY CHANGES; THEREFORE, IT'S RECO ENDED THAT AIR
ONITORING/ GAS DETECTION EQUIP ENT BE USED FREQUENTLY. IF TESTS SHOW THAT THE
AT OSPHERE QUALIFIES AS A HAZARDOUS LOCA ION (AN AREA WHERE THE POSSIBILITY OF
EXPLOSION AND FIRE IS CREATED BY THE PRESENCE OF CO BUSTIBLE LIQUIDS, FLA ABLE GASES,
VAPORS, DUST, FIBERS, FLA ES OR FILINGS.) DO NO USE HIS FAN. READ AND UNDERSTAND THE
FOLLOWING PREPARATION ITE S AND GENERAL SAFETY INFOR ATION.
PREPARA ION
1) Become familiar with the Fan operations before utilizing this Fan. Read and understand all Cautions and
Warnings in this anual. Refer to current OSHA publications for complete job safety and health rules and
regulations (CFR 1926 and 1910).
2) Confirm that the Fan is in its original, factory configuration and has not been modified in any manner.
3) inors should not be allowed to operate the Fan. Close attention is necessary when used, especially when used
near children or animals.
4) Guard against the possibility of back-related injuries. Always lift the Fan with leg muscles and not with the back.
5) Periodically inspect the Fan visually for damaged or worn parts. Check for loose and/or broken parts. Be sure that
the Fan and accessories are in good working condition before operating.
6) Ground the motor securely. The (U.S.) Fan utilizes a NE A 5-15P plug. It is designed to operate ONLY from a
grounded, 115 volt nominal AC~, 60Hz, single phase power source that utilizes a NE A 5-15R receptacle. The 230
volt, 50Hz Fan (VAF1500B) comes with a power cord having no end connector. The customer must provide a plug
suitable for use with grounded receptacles at their location.The use of a ground fault circuit interrupter (GFCI) gives
additional on the job protection from electrical shock hazards caused by ground faults in commercial, industrial and
residential applications.
7) Know how to stop the Fan quickly in an emergency. Turn unit off at (on/off) switch located on side of unit or
unplug Fan from power supply.
GENERAL SAFE Y INFORMA ION
1) Never place the Fan in standing water because of extreme shock hazard.
2) Never allow air intake grill to become blocked.
3) Never discharge flammable solvents or kerosene based chemicals through the Fan air intake grill.
4) Do not use the Fan in areas where flammable or combustible liquids, gases, vapors, dust, fibers or filings
may be present.
5) Never put any object in the air intake grill.
6) Never run the Fan outside when it is raining. Never store the Fan outdoors.
7) Do not use the Fan as a toy.
8) Use the Fan only with a properly grounded outlet.
9) Unplug the Fan from outlet when not in use and before servicing.
WARNING: o reduce the risk of fire or electric shock, do not use this fan with any
solid state speed control device.
GENERAL SAFE Y INFO. (Continued)
10) Do not use the Fan with a damaged cord or plug. Do not pull or carry the Fan by its cord, do not use cord as a
handle, do not close a door on the cord, and do not pull cord around sharp edges or corners. Keep cord away from
heated surfaces. Do not unplug the Fan by pulling on cord, grasp the plug and not the cord. Do not handle the plug
or cord with wet hands.
11) Keep hair, loose clothing, fingers and all parts of the body away from the air intake grill.
12) Do not allow water inside the motor. If the motor becomes wet for any reason, unplug the Fan and thoroughly
dry it before using again.
13) Never remove the ground from the power cord or plug as this may result in electrical shock or electrocution.
Removing the ground would void the warranty.
14) If the Fan has been dropped, left outdoors, or dropped into water, etc...,please thoroughly inspect it prior to use.
If the Fan is not working or if you have a question about its safe operation, do not operate it. Contact Schaefer
Ventilation directly at [phone] or at www.schaeferfan.com.
OPERA ION
1) Your new Fan comes to you completely assembled and ready to operate. Upon removing the Fan from its carton,
inspect it for any possible damage in transit.
2) Before operating the Fan, please read all the safety Precautions and General Safety Information about the proper
and safe use of the Fan.
3) Assess your job site. Certain job site locations are classified as being hazardous because the atmosphere may
contain gas vapor or dust in explosive quantities.
DANGER
HE ELEC RIC MO OR AND FAN HOUSING ARE NO DESIGNED FOR OPERA ION IN AN
EXPLOSIVE AND/OR FLAMMABLE A MOSPHERE OF ANY CLASS OR GROUP. OPERA ION
OF HE FAN IN AN EXPLOSIVE OR FLAMMABLE A MOSPHERE MAY RESUL IN PERSONAL
INJURY OR DEA H.
4) Locate a properly grounded outlet.
5) Prior to plugging the Fan into a grounded outlet, inspect the inlet and outlet grills and remove debris which may
restrict airflow movement. Never operate the Fan without the inlet and outlet grills properly secured and in place.
Never replace the grills with other than factory supplied replacement units.
6) Note the directional airflow indicator on the external shell. This is the way the air moves.
7) Place the Fan on secure footing to prevent it from shifting while in use.
8) Do not stand directly in front of and/or face the Fan outlet. Personal injury can result from
being struck by debris thrown at a relatively high velocity from the Fan blade.
9) When ducting is required, do not install duct while Fan is in operation. Place duct lip over
the Fan duct adapter, secure firmly and note direction of the airflow.
10) When duct is used, be aware that the airflow rate decreases as the length of duct increases. Airflow rates will
vary with specific duct types and manufactures.
11 ) Position Fan air inlet away from walls and other obstructions to allow for maximum air intake.
12) For safe operation, use the Fan only in combination with thorough gas detection tests and continual
retesting.
DANGER
ALWAYS ASSUME A CONFINED SPACE WORK AREA IS CON AMINA ED UN IL I HAS BEEN
PROVEN SAFE FOR WORK PERSONNEL. NEVER EN ER A CONFINED SPACE WORK AREA
UN IL I HAS BEEN HOROUGHLY ES ED WI H APPROPRIA E GAS DE EC ION
EQUIPMEN AND PROVEN SAFE FOR WORK PERSONNEL.
