Schaefer VAF8000A/A-3/B-3 Assembly instructions

OWNER’ MANUAL
AFETY IN TRUCTION
Please read and keep these instructions with the fan.
MODEL: VAF8000A/A-3/B-3
For use in Non-Explosive/Non-Flammable environments only.
Purchase Date: ___________________ Serial No. ___________________
Dealer: ______________________________________
1.800.779.3267 • www.schaeferfan.com
PROBLEM
Unit will not run.
Unit runs but f n
m kes loud scr ping
noise.
Unit runs but
vibr tes
excessively.
Unit runs but f n
does not turn.
Unit runs briefly,
then shuts off on
overlo d.
CAUSE
1No power to unit.
2) Switch not on.
3) Switch is faulty.
4) Faulty / Broken cord or motor wire.
1) Unit has been severely jolted causing fan to
rub against housing.
2) Unit has been severely jolted causing
housing to deform.
1) Severe jolt has bent motor shaft causing
unit to be out of balance.
2) Fan blade damaged.
3) Dirt build up on one side of fan blade.
1) Fan is jammed against housing.
2) Capacitor wire has broken/come loose,
capacitor has failed.
3) Housing has been damaged such that it
presses on the fan blade.
1) otor bearings are failing, or motor has
developed an internal electric fault.
2) Intake grill and/or exhaust grill is obstructed.
3) Excessive duct length.
SOLUTION
1) Plug unit in. Check circuit breaker.
2) Place in "ON" position.
3) Replace switch.
4) Perform continuity check, using volt/amp meter,
Repair/replace faulty/broken wire.
1) Remove motor and replace damaged motor
mounts.
2) Replace housing/unit as necessary.
1) Remove and replace motor. Replace fan blade if
necessary.
2) Replace fan blade.
3) Clean fan blade.
1) Remove motor and replace damaged motor
mounts. Replace fan blade if necessary.
2) Repair/replace wires/capacitor as necessary.
3) Replace housing/unit as necessary.
1) Replace motor.
2) Remove obstruction.
3) Reduce duct length to recommended maximum.
AMERIC AXIAL FAN TROUBLESHOOTING
CAUTION: All service procedures should be executed with the unit unplugged.
©2012 Schaefer Ventilation Equipment. All rights reserved.
M-VAF8000A/A-3/B-3
Item P rt# E ch Description
1 RING-VAF8000 2 Duct Ring 20" ABS
2 Guard-VAF8000 2 Wire Guard 20"
4 HSG-VAF8000 1 Housing Blue VAF8000
5 CS253 1 Motor 5HP 3Ph
CS251 1 Motor 5HP 1Ph
6 BLD-VAF8000-60 1 60 Hz Fan Blade Assembly
BLD-VAF8000-50 1 50 Hz Fan Blade Assembly
7 MTRVN-VAF8000 2 Motor Mount Primary Vane
8 SECVN-VAF8000 4 Secondary Vane
9 0B51624X1HZ 12 Bolt 5/16"-24 x 1" Hex Zinc
10 0B1420X114HZ 24 Bolt 1/4"-20x1-1/4" Hex Zinc
11 SWPNL-VAF8000 1 Switch Mount Panel
12 0RF212OD 4 Rubber Foot
13 0RIVET6-8A-B 20 Rivet 3/16"x1/2"G ABA
14 CORD-12/4-20 1 Power Cord Black 20'
15 0MS- TA725S10A 1 Motor Starter 440V 10A 3Ph
0MS- TA725S16A 1 Motor Starter 220V 16A 3Ph
0MS- TA725S25A 1 Motor Starter 220V 25A 1Ph
16 0W1132X114Z 6 Washer 11/32"x1-1/4"x1/8" Z
17 0W14X1Z 4 Washer 1/4" x 1" Zinc
18 0GS T-8000 TA7 1 Gasket Power Panel
19 0S- T7AYTG2 1 Operator Switch
20 0FLEXPVC12 3 1/2" Flexible PVCConduit
Item P rt# E ch Description
21 SHAC LE58-6500G 1 Shackle 5/8" Screw Pin
22 0WNJ1420R 4 Well Nut J1420 Rubber
23 0NY51624Z 12 Nylock 5/16"-24 Zinc
24 MSBOX-VAF8000 1 Motor Starter Box
25 0B1420X112HZ 12 Bolt 1/4"-20x1-1/2" Hex Zinc
26 DINRAIL-3 1 DIN Rail 35mm x7.5mm Zinc
27 0NY1420Z 32 Nylock 1/4"-20 Zinc
28 0W14STDZ 48 Washer 1/4" USS
29 0W14SAE 40 Washer 1/4" SAE
30 0CFLT12 2 Conduit Fitting 1/2" Snap In
31 CONNECTOR34 1 Cordgrip Liq. Tight 3/4" NPT
0LNROMEX34 1 Lock Nut for 3/4" Cord Grip
0ORING214SQ 1 O-Ring 214 Square
32 0WIL10STDZ 2 Washer Internal Lock #10 Z
0RGTERM1210-10 1 Ring Terminal #10 12-10 AWG
33 0B1032X58PHRHZ 4 Bolt 10-32x5/8" Rnd Head Z
0B1032X12SCS 2 Bolt 10-32x1/2" SC Screw Z
0W10X58SS 2 Washer Fender #10
0NY1032Z 3 Nylock 10-32 Zinc
LABELVAF8000440 1 Label VAF8000 440V

SCHAEFER LIMITED WARRANTY
If you are the original purchaser of a new Americ Vane Axial Fan from Schaefer, then you are entitled to a
limited warranty subject to the terms and conditions set forth herein. To qualify for the limited warranty you
must complete the enclosed registration card and mail it to Schaefer within (30) days of the purchase, so that
there is a record of your purchase. Schaefer's limited warranty is for the replacement or repair of any part that
proves to be defective in workmanship or materials for a period of one (1) year from the date of purchase by
the original purchaser. During the first year, Schaefer will provide all parts necessary to correct any defects,
free of charge. This limited warranty extends only to the original purchaser who retains ownership of the Fan.
This limited warranty is not transferable to any subsequent purchaser or second-hand user.
The limited warranty extends only to the repair or replacement of parts found upon Schaefer's examination to
be defective. Unless any part or assembled unit replaced hereunder is returned, freight pre-paid, together with
a letter describing the problem to Schaefer or an authorized Schaefer dealer, this limited warranty will be void
and of no effect.
This warranty is limited to ninety (90) days for labor from the date of the purchase. Thereafter, any labor costs
incurred will be charged to the customer at the prevailing hourly rate.
This limited warranty shall not extend to a product that has been used in an improper manner, or that has been
disassembled, altered or improperly maintained. Nor shall this limited warranty apply if the Fan has been
subjected to corrosive chemicals, improper voltage, unauthorized repairs, fire, flood, abnormal wear or any
causes beyond Schaefer's control.
This limited warranty does not apply if the serial number has been removed, obliterated or defaced.
Schaefer Ventilation reserves the right to make changes to the Vane Axial Fan in design, materials or
specifications as necessary and without prior notice. Schaefer shall not be obliged to make alterations or
modifications to existing products previously manufactured.
To obtain replacement parts pursuant to this limited warranty, you must write to Schaefer or call
[phone] to receive an authorization number. Replacement parts will not be provided unless the
customer first provides the serial number of the Fan and also receives an authorization number from
Schaefer.
OTHER THAN THE FOREGOING LI ITED WARRANTY, THERE ARE NO FURTHER WARRANTIES OR
ANY AFFIR ATIONS OF FACT OR PRO ISES BY SCHAEFER WITH RESPECT TO THE VANE AXIAL FAN.
THE DURATION OF ANY I PLIED WARRANTIES ARE LI ITED TO THE TER S OF THE ABOVE LI ITED
WARRANTY. SO E STATES DO NOT ALLOW LI ITATIONS ON HOW LONG AN I PLIED WARRANTY
AY LAST, SO THE ABOVE LI ITATIONS AY NOT APPLY TO YOU. WITHOUT LI ITING THE
GENERALITY OF THE FOREGOING, SCHAEFER EXPRESSLY DISCLAI S ANY INFRINGE ENT OR ANY
AFFIR ATIONS OF FACT OR QUALITY NOT EXPRESSLY CONTAINED HEREIN. SCHAEFER
VENTILATION AND ITS AFFILIATES NEITHER ASSU E NOR AUTHORIZE ANY PERSON TO ASSU E
FOR THE ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS. THERE
ARE NO OTHER WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
IN NO EVENT SHALL SCHAEFER VENTILATION BE LIABLE FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DA AGES, OR FOR LOSS OF PROFITS OF ITS CUSTO ERS OR USERS OF
PRODUCT. SO E STATES/JURISDICTIONS DO NOT ALLOW THE EXCLUSIONS OR LI ITATIONS OF
INCIDENTAL OR CONSEQUENTIAL DA AGES, SO THE ABOVE LI ITATIONS AY NOT APPLY TO YOU.
THIS LI ITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU AY ALSO HAVE OTHER
RIGHTS WHICH VARY FRO STATE TO STATE.
1
2
64
27
29
25
21
27 28
10 9
28
23
8
13
7
30
30
516
20
22
14
31
33
19
26
33
24
15
18 11
12
25
17
VAF8000 PICTORIAL BREA DOWN

INTRODUCTION
Congratulations...on your selection of a new Vane Axial Fan from Schaefer Ventilation. Our goal is to provide
you with the very best in high performance air ventilators. Reading this Owner's anual will help you achieve
the maximum benefit from your portable air ventilator. If you do not understand any portion of this anual
please contact Schaefer or your authorized Schaefer dealer for proper assistance prior to operating this Fan.
Do not allow anyone to operate the Vane Axial Fan without first reading the Operator's anual and becoming familiar with its
operation. Schaefer has endeavored to provide you with the finest equipment available for providing air for portable
ventilation purposes. The possibility does exist, however, that the Vane Axial Fan can be subjected to applications not
intended by Schaefer. Misuse nd/or mis pplic tion of the V ne Axi l F n c n le d to the possibility of serious
d m ge, injury or even de th. Anyone operating the Vane Axial Fan should refer to current OSHA job safety and health
rules and regulations pertaining to the construction industry, with a particular emphasis on 29 CFR 1910, which contains
rules governing Permit-Required Confined Spaces for General Industry.
Record the V ne Axi l F n model nd seri l number in the sp ce provided below.
Model No.____________________ Seri l No. ________________________ D te Purch sed ______________________
All specifications are general in nature and are not intended for specific application purposes. Schaefer accepts no
responsibility for variations which may be evident in actual products, specifications, pictures and descriptions contained in
this publication.
MAINTENANCE
DANGER
ALWAYS SHUT OFF THE FAN AND UNPLUG IT FROM ITS POWER SOURCE TO PREVENT ACCIDENTAL STARTING
AND THE POSSIBILITY OF ELECTRICAL SHOCK AND/OR ELECTROCUTION. BE SURE THE FAN BLADE HAS
STOPPED ROTATING BEFORE PLACING ANY OBJECTS OR FINGERS NEAR THE FAN GRILL.
1. Visually check all fasteners and individual components for loose or broken parts. Tighten or replace items as required,
with genuine, factory approved replacement parts only.
2. Keep the Fan blade clean from debris. Accumulation of dust, dirt, paint, etc. on the Fan blade will throw the blade rotation
out of balance, resulting in damage. To clean the Fan blade, be sure the plug is disconnected and the blade has stopped
rotating. Remove one grill and wipe blade and interior shell housing clean of debris with a damp cloth and mild liquid soap.
Dry all parts thoroughly. DO NOT PRESSURE WASH THE FAN. Replace grill prior to next operation.
DANGER
DO NOT OPERATE THE FAN WITHOUT THE INLET AND OUTLET GRILL PROPERLY IN PLACE.
3. Contact Schaefer directly for Fan maintenance or repair not described in this manual (or if you are unsure whether main-
tenance is required.) at Tel# [phone] or at www.schaeferfan.com.
SERVICE
1) Refer to the TROUBLESHOOTING GUIDE in this anual.
MOTOR SPECIFICATIONS GENERAL INFORMATION & DIMENSIONS
(A) (A-3) (B-3)
Voltage 230V AC-- 230V AC-- 440V AC-- Type Axial
Frequency 60/50 Hz 60/50 Hz 60/50 Hz Duct adapter 20.5" dia. (52 cm)
Phase Single Three Three Height 27.5" (69.8 cm)
Electric otor 5 HP 5 HP 5 HP (.75kw) Width 25.5" (64.7 cm)
Current (amps) 21.2 13.0 6.5 Length 27.5" (69.8 cm)
R.P. 3250 3450 3450 Weight 119 lbs (53.97 kg)
Free Air (cfm) N/A 9968 9968 (282.3 ³)
ax S.P. 6.1" 6.1" 6.1" (68mmlaq)
AIR FLOW RATES
(A-3) (B-3)
Feet Description CF ³/ in CF ³/ in
Free Air 9968 282.3 9968 282.3
25' duct Straight 9379 265.6 9379 265.6
25' duct 1-90° bend 7193 203.7 7193 203.7
25' duct 2-90° bends 6726 190.5 6726 190.5
50' duct Straight 8664 245.3 8664 245.3
75' duct Straight 8313 235.4 8313 235.4
The published flow rates are intended to serve only as a reference. anufacturing tolerances, duct type and specific
operat-ing parameters will affect the overall flow rate(s) for each particular Fan.
CAUTION
THE AIR FLOW RATE DECREASES AS THE LENGTH OF DUCT INCREASES FOR BOTH BLOWING AND
SUCTION APPLICATIONS. AIR FLOW RATES WILL VARY WITH SPECIFIC DUCT TYPES AND
MANUFACTURES.

AFETY PRECAUTION
DANGER
THE FAN IS DESIGNED FOR PORTABLE AIR VENTILATION PURPOSES ONLY. THE FAN IS NOT DESIGNED
FOR TRANSPORTING LIQUID OR SEMI-SOLID MATERIALS. THE ELECTRIC MOTOR AND FAN HOU ING ARE
NOT DE IGNED FOR OPERATION IN AN EXPLO IVE OR FLAMMABLE ATMO PHERE. OPERATION OF
THE FAN IN AN EXPLO IVE OR FLAMMABLE ATMO PHERE MAY RE ULT IN PROPERTY DAMAGE,
PER ONAL INJURY OR EVEN DEATH. INCORRECT USE OF THE FAN CAN RESULT IN AN ELECTRICAL
SHOC AND/OR ELECTROCUTION. ALWAYS OPERATE THE FAN IN COMPLIANCE WITH CURRENT OSHA
AND NATIONAL ELECTRIC CODE REGULATIONS.
DANGER
INCORRECT USE OF THE FAN CAN RESULT IN PROPERTY DAMAGE, PERSONAL INJURY OR EVEN DEATH.
TO REDUCE THIS RIS , GIVE COMPLETE AND UNDIVIDED ATTENTION TO THE JOB AT HAND. AN
ENVIRONMENT ATMOSPHERE CONSTANTLY CHANGES; THEREFORE, IT'S RECOMMENDED THAT AIR
MONITORING/ GAS DETECTION EQUIPMENT BE USED FREQUENTLY. IF TESTS SHOW THAT THE
ATMOSPHERE QUALIFIES AS A HAZARDOU LOCATION (AN AREA WHERE THE POSSIBILITY OF
EXPLOSION AND FIRE IS CREATED BY THE PRESENCE OF COMBUSTIBLE LIQUIDS, FLAMMABLE GASES,
VAPORS, DUST, FIBERS, FLAMES OR FILINGS.) DO NOT U E THI FAN. READ AND UNDERSTAND THE
FOLLOWING PREPARATION ITEMS AND GENERAL SAFETY INFORMATION.
PREPARATION
1) Become familiar with the Fan operations before utilizing this Fan. Read and understand all Cautions and Warn-
ings in this Manual. Refer to current OSHA publications for complete job safety and health rules and regulations
(CFR 1926 and 1910).
2) Confirm that the Fan is in its original, factory configuration and has not been modified in any manner.
3) Minors should not be allowed to operate the Fan. Close attention is necessary when used, especially when used
near children or animals.
4) Guard against the possibility of back-related injuries. Always lift the Fan with leg muscles and not with the back.
5) Periodically inspect the Fan visually for damaged or worn parts. Check for loose and/or broken parts. Be sure that
the Fan and accessories are in good working condition before operating.
6) now how to stop the Fan quickly in an emergency. Turn unit off at (on/off) switch located on side of unit or
unplug Fan from power supply.
7) Based upon customer country standards, customer to supply suitable plug to conform to their specific country’s
requirement.
GENERAL AFETY INFORMATION
1) Never place the Fan in standing water because of extreme shock hazard.
2) Never allow air intake grill to become blocked.
3) Never discharge flammable solvents or kerosene based chemicals through the Fan air intake grill.
4) Do not use the Fan in areas where flammable or combustible liquids, gases, vapors, dust, fibers or filings
may be present.
5) Never put any object in the air intake grill.
6) Never run the Fan outside when it is raining. Never store the Fan outdoors.
7) Do not use the Fan as a toy.
8) Use the Fan only with a properly grounded outlet.
9) Unplug the Fan from outlet when not in use and before servicing.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any
solid state speed control device.
GENERAL AFETY INFO. (Continued)
10) Do not use the Fan with a damaged cord or plug. Do not pull or carry the Fan by its cord, do not use cord as a
handle, do not close a door on the cord and do not pull cord around sharp edges or corners. eep cord away from
heated surfaces. Do not unplug the Fan by pulling on cord, grasp the plug and not the cord. Do not handle the plug
or cord with wet hands.
11) eep hair, loose clothing, fingers and all parts of the body away from the air intake grill.
12) Do not allow water inside the motor. If the motor becomes wet for any reason, unplug the Fan and thoroughly
dry it before using again.
13) Never remove the ground from the power cord or plug, as this may result in electrical shock or electrocution.
Removing the ground would void the warranty.
14) If the Fan has been dropped, left outdoors, dropped into water, etc...,please thoroughly inspect it prior to use.
If the Fan is not working or if you have a question about its safe operation, do not operate it. Contact Schaefer
Ventilation directly at [phone] or at www.schaeferfan.com.
OPERATION
1) Your new Fan comes to you completely assembled and ready to operate. Upon removing the Fan from its carton,
inspect it for any possible damage in transit.
2) Before operating the Fan, please read all the safety Precautions and General Safety Information about the proper
and safe use of the Fan.
3) Assess your job site. Certain job site locations are classified as being hazardous because the atmosphere may
contain gas vapor or dust in explosive quantities.
DANGER
THE ELECTRIC MOTOR AND FAN HOU ING ARE NOT DE IGNED FOR OPERATION IN AN EX-
PLO IVE AND/OR FLAMMABLE ATMO PHERE OF ANY CLA OR GROUP. OPERATION OF
THE FAN IN AN EXPLO IVE OR FLAMMABLE ATMO PHERE MAY RE ULT IN PER ONAL IN-
JURY OR DEATH.
4) Locate a properly grounded outlet.
5) Prior to plugging the Fan into a grounded outlet, inspect the inlet and outlet grills and remove debris which may
restrict airflow movement. Never operate the Fan without the inlet and outlet grills properly secured and in place.
Never replace the grills with other than factory supplied replacement units.
6) Note the directional airflow indicator on the external shell. This is the way the air moves.
7) Place the Fan on secure footing to prevent it from shifting while in use.
8) ) Do not stand directly in front of and/or face the Fan outlet. Personal injury can result from
being struck by debris thrown at a relatively high velocity from the Fan blade.
9) When ducting is required, do not install duct while Fan is in operation. Place duct lip over
the Fan duct adapter, secure firmly, and note direction of the airflow.
10) When duct is used, be aware that the airflow rate decreases as the length of duct increases. Airflow rates will
vary with specific duct types and manufactures.
11 ) Position Fan air inlet away from walls and other obstructions to allow for maximum air intake.
12) For safe operation, use the Fan only in combination with thorough gas detection tests and continual
retesting.
DANGER
ALWAY A UME A CONFINED PACE WORK AREA I CONTAMINATED UNTIL IT HA BEEN
PROVEN AFE FOR WORK PER ONNEL. NEVER ENTER A CONFINED PACE WORK AREA
UNTIL IT HA BEEN THOROUGHLY TE TED WITH APPROPRIATE GA DETECTION
EQUIPMENT AND PROVEN AFE FOR WORK PER ONNEL.
