User manual & repair guide
MB-BOX
Ref : 36.159xx.00
Acknowledgement...................................................P.2
Safety Warnings.........................................................P.2
Related accessories ..............................................P.2
Equipment description..........................................P.2
Technical characteristics........................................P.3
Electrical characteristics.........................................P.3
Description of the markings used.....................P.4
Installation instructions..........................................P.5
Connection...................................................................P.6
Indicators and buttons............................................P.6
Use..................................................................................P.7
Software........................................................................P.7
Terms and conditions.............................................P.10
Warranty terms.........................................................P.10

L’innovation française depuis 1965
P. 2
L’innovation française depuis 1965
Designation Reference
120Ω BUS CAN termination 0D.CRD399
Micro-Fit / M12 (NMEA) adapter 0D.CRD630
USB-card micro SD adapter 0R.INF420
USB-C / RJR45 adapter 0R.INT430
GPS antenna - 5M cord 0I.CED522
Power harness 0D.CRD310
Equipment description
The MB-BOX is a complete and scalable solution similar to a home automation box consisting of the physical MB-BOX box and,
optionally, dedicated applications. It can be integrated into land vehicles as well as boats, it centralizes all installation data, controls
equipment and carries out maintenance operations, all remotely and worldwide thanks to the 'application.
Acknowledgement
Thank you for your purchase and we hope that this product is entirely satisfactory.
Before you being using the product, we recommend that you read the following instructions carefully.
This manual explains how to use and install the product according to the use for which it was intended.
Safety warnings
IMPORTANT: Do not dismantle the device
Any contact with the components inside the product can cause injuries.
In the event of a malfunction, only a qualied technician is authorized to repair the device.
IMPORTANT: In the event of an impact
If the product falls or suers violent impacts, immediately contact a qualied person to make sure that the device is working
properly.
IMPORTANT: Unpacking the equipment
After unpacking the product, make sure that it is complete and in good condition: if in doubt, immediately contact someone with the
required professional qualication.
IMPORTANT: Unpacking the equipment
Do not leave any part of the packaging within the reach of children or irresponsible people.
Related accessories

L’innovation française depuis 1965
P. 3
L’innovation française depuis 1965
MB-BOX
REFERENCE 36.159xx.00
POWER SUPPLY 9-32 V DC
PERIPHERAL DEVICES
1 Ethernet port
3 USB ports
2 independent CAN networks (4 connectors)
1 connector for 2 inputs and 1 output
1 SIM card holder
MOTHERBOARD 1.2GHz processor, 8GB eMMC storage,
1GB of RAM (Option 16GB and 32GB of storage)
BUS CAN 4 x 6-way Micro-Fit type connectors
2 separate CAN BUS
COMMUNICATION LTE-M1
GPS GNSS
BLUETOOTH Bluetooth 5.0
WIFI 2.4 GHz, 5.0 GHz IEEE 802.11 b/g/n/ac
OS Linux
I/O
1 analog input with wake-up function (0 – 32VDC)
1 npn type digital input with wake-up function
1 output 0.5A
USB
2x USB 2.0:
1 USB-C
and
1 USB A* on front panel
Where
1 mini USB HSAUTOLINK* OTG
*Both USB ports cannot be used
at the same time
FIRMWARE VERSION V8.00 or higher
ENVIRONMENTAL CONDITIONS
Indoor use
Altitude up to 2000m
Operating temperature: 0 to +50°C
Relative humidity: 0 to 93% - non-condensing
Protection index: IP20
FIXING DISTANCE 128x87mm
WEIGHT 0,25 Kg
STANDARDS EN 60945
DIMENSIONS (LXLXH)150 x 95 x 25 mm
NOMINAL VOLTAGE (VDC)9-32 VDC
OWN CONSUMPTION 45 mA
2.4GHZ WI-FI CONNECTED 180mA @12V
GPS RECEPTION 204 mA @12V
Electrical characteristics
Characteristics

L’innovation française depuis 1965
P. 4
L’innovation française depuis 1965
USB
ON/OFF
LTE-M ANTENNAS
AND WIFI INTEGRATED
ETHERNET PORT
USB-C
INPUT/OUTPUT
CONNECTOR
POWER
CONNECTOR
GPS
NETWORK 2
CAN (CAN1)
NETWORK 1
CAN (CAN0)
SIM CARD
CONNECTOR
AUTOLINK MINI USB
MB BOX
1 Entrée numérique (-)
MOS
Alimentation VDC
CONTROLEUR
CAN 1 SCHEIBER
CAN 2
Ecran de
navigation
12/24VDC
2A
1 Entrée analogique
0,5A max
USB1
Carte SIM
Antenne
WIFI
Antenne
LTE-M
USB2
USB3
Antenne
GPS
ou
Description of the markings used
VVolt
AAmpere
ou DC Direct current

L’innovation française depuis 1965
P. 5
L’innovation française depuis 1965
FIXING: 2 SCREWS 2.9X19MM
MOUNTING DISTANCE: 137mm
95
150
Front view
Prole view Back view
25
ETHERNET
USB-C
ANTENNE
CAN 1 CAN 0
POWER SUPPLY
I/O
USB-C
Installation instructions
• This device must be placed in a place protecting it from any risk of water splashing. Install in a ventilated location
• Do not install on supports that are sensitive to heat, such as carpet or PVC ooring, etc.
• The product must be installed away from heat and humidity
!WARNING: Connection/disconnection with power on
Do not perform connection or disconnection with power on.

L’innovation française depuis 1965
P. 6
L’innovation française depuis 1965
Connection
1Connect power
• by an external power supply
using the 2-way connection:
Connect the ETHERNET port to the screen or
the HUB of your installation
or
120Ω
termination
CAN
cable
2
3
4
Connect 2 right CAN connectors to the SCHEIBER network
Connect 2 CAN connectors to the partner network
The 2 networks CAN1 and CAN0 are distinct.
Screw the GPS antenna (optional)
2
3
4
"Power ON" button, a short press on this button
switches on the MB-Box or performs a soft reset if
the MB-Box is already on. A long press on Power ON
exports logs to a USB key.
"SW-WIFI" button,
When pressing the SW-WIFI button briey (<5s), the
MB-Box resets the WIFI conguration parameters to
factory mode:
SSID=scheiber-01
Password = scheiber
During a long press (>5s) on the SW-WIFI button, the
MB-Box performs the following actions:
If WIFI is disabled:
Lighting of the WIFI LED in xed mode
Conguring WIFI in server mode
Activation of the WIFI interface
Conguring the IP address of the WIFI interface
If WIFI is activated in server mode:
Turning o the WIFI LED
Disabling the WIFI interface
If WIFI is activated in hotspot mode:
Turning o the WIFI LED
Conguring WIFI in server mode
Restarting the WIFI interface
Conguring the IP address of the WIFI interface
Lighting of the WIFI LED in xed mode
Edit this section
SW-ON-OFF (powerOFF button at the bottom)
The "Power o" button, one press turns o the MB-
Box, it restarts if a Wake-Up entry is active in the
installation.
1- ON/OFF light, xed light for about 15 seconds
when loading the bootloader, then ashing during the
initialization phase
2- LTE LED, ashing:
LTE network search
on ---- ----
| | | |
o -------- -------- --------
MB-Box connected to the LTE network
on -------- -------- --------
| | | |
o ---- ----
3- Wi-Fi indicator,
the indicator is ON when Wi is activated
ashing light: Hotspot mode activated
4- Mode LED, the LED ashes green when the CAN
BUS 0 is active, the LED ashes red when the CAN BUS
1 is active.
Indicators and buttons
SW-ON-OFF
Mode
SW-WIFI
indicator ON/OFF
SCHEIBER networkPartner network
GROUND
+BAT
1
GROUND
Analog
input
Digital input (-)
On/O output
Power ON
CAN
cable
CAN
cable

L’innovation française depuis 1965
P. 7
L’innovation française depuis 1965
Software
Web browser compatibility
Use
Le produit MB-BOX est disponible avec plusieurs services :
Remote Services:
- Client application, dashboard, remote control
- Congurations, settings
- Software update
- Maintenance
- Provision of data in the cloud via an API
- Data storage
Embedded services:
- Customer app
- Congurations, settings
- Software update
- Maintenance
- Data storage
Non-exhaustive list, depending on the options chosen by customers and available or to come
Operation is guaranteed with Chrome, we recommend its use.

L’innovation française depuis 1965
P. 8
L’innovation française depuis 1965
LAND VERSION
Example of a remote application compatible with the MB BOX
9:31
Connect to your boat
Scheiber
Remote control
Email
••••••••
Password
Remember me
Connection
Password forgotten ?
Login screen
9:31
Batteries
25,8 V
-5,5 A
Motor
28,2 V
12 A
40%
Inside
ON/OFF
Data updated in real time
80%
Lighting
Leisure
Side
Fridge
NAUTICAL VERSION
9:31
25,8 V
-5,5 A
28,2 V
12 A
40%
93%
80%
ON/OFF
Data updated in real time
80%
Batteries
Side
Motor
Tanks
Front fuel
Rear fuel
Kitchen fridge
Menu access
Favorites
(displayed on
home page)
Access to settings
3 states depending
on data refresh:
ACTION :
click on the orange banner to
wake up the installation and
refresh the data
Dashboard
ACTIONS :
swipe down: refresh data
slide to the right: menu display
swipe left: access settings
9:31
Batteries
25,8 V
-5,5 A
Motor
28,2 V
12 A
40%
Inside
ON/OFF
Data updated in real time
80%
Lighting
Leisure
Side
Fridge
a
B
ord
25,8 V
-5,5 A
M
oteur
28,2 V
12 A
F
uel avant
Réservoirs
Dashboard
Tanks
Temperature
Alarms
Batteries
ON / OFF
Surveillance
Power up ...
Data updated 10 days ago
Data updated in real time

L’innovation française depuis 1965
P. 9
L’innovation française depuis 1965
9:31
Alarms
Quarry bilge pump
VHF Battery
Port fire extinguisher
Starboard fire extinguisher
Forward bilge pump
Right now
History
Data updated in real time
9:31
25,8 V
-5,5 A
28,2 V
12 A
40%
80%
Batteries
09%
V
HF
22,7 V
-4 A
On-board
Motor
Data updated in real time
9:31
ON/OFF
Fridge fly
Deck lights
Kitchen refrigerator
Data updated in real time
9:31
80%
Tanks
Front fuel
Back fuel
Pure water
19%
93%
Data updated in real time
9:31
Temperatures
Square
Port cabin
Starboard cabin
20.5°C
19°C
19.5°C
Data updated in real time
Examples of feature pages
Active alarms are put
at the top of the list
Non-exhaustive list, customization possible.

L’innovation française depuis 1965
P.10
L’innovation française depuis 1965
Terms and conditions
The manufacturer cannot be held responsible and accepts no responsibility in the event of harm to persons or property due to
improper use and in reference to the warnings provided in this manual.
SCHEIBER reserves the right to change the characteristics of its products in the interest of its customers. The manual supplied with this
product must not be reproduced, transmitted, stored in a search system or translated into any language, in full or in part, by any means,
without the prior written consent of SCHEIBER.
Although every eort has been made to provide you full and accurate information in this manual we ask that you inform the SCHEIBER
representative of your country in case of any error or omission we may have overlooked.
SCHEIBER reserves the right to change the characteristics of the hardware and software described in these manuals at any time and
without prior notice.
WARRANTY SUBJECT:
The company SCHEIBER warranties all its products’ range against failures or masked-failures according to the article 1641 and followings
of the Civil Code. Repairs and replacement of the equipment during the warranty period do not change terms or time of this warranty
which is of 2 years. Repairs and replacement of the faulty parts under warranty are made only on presentation of the invoice which
certies the warranty beginning date.
WARRANTY DOES NOT APPLY:
This warranty can not be applied in case of misuse, wrong installation, repair by anyone else than a SCHEIBER authorised technician,
damage arising from improper use (fuses replaced by another value), utilisation in an unsuitable environment or if the equipment has
suered from physical damages through handling, transport. It does not cover calibration or verication due to the normal age of the
components. Warranty modalities: The equipment freight will be charged to the customer. If the returned equipment is not conform,
our company considers it has the right to refuse the free repair and proposes an estimate.
RESPONSIBILITY LIMITS:
In any case, the company SCHEIBER will not be held responsible for direct damages or damages not due to the normal use of the
equipment. In case of a dispute arising between the parties, the case shall be submitted to the French Right to the court specied by
the company SCHEIBER.
Warranty terms & after-sales

2 Bellevue,
85120 • Saint-Pierre du Chemin
France
Phone : [phone]
[email protected]
www.scheiber.fr
Question ?
[e-mail]
Problem ?
[e-mail]
L’innovation française depuis 1965
