schmersal SHG Quick guide

FR Vous trouverez la version
actuelle du mode d’emploi dans
votre langue nationale officielle
sur l’Internet,
www.schmersal.net.
ES Encontrará el manual de
instrucciones actual en su
idioma oficial de la UE en
nuestra página de Internet
www.schmersal.net.
NL U vindt de huidige versie van de
gebruikshandleiding in uw
officiële landstaal op het Inter-
net, www.schmersal.net.
IT Il manuale d‘istruzioni aggior-
nato nella vostra lingua (lingua
ufficiale UE) è scaricabile in
Internet all‘indirizzo
www.schmersal.net.
JP EU公用語で書かれた最新の取扱
説明書は,インターネッ
(www.schmersal.net) からダウ
ンロードできます。
EN Operating instructions. . . . . . . . . . . . .pages 1 to 4
Translation of the original operating instructions
1
SHG/SCG/SDG
Operating instructions
Safety switch
EN
1. About this document
1.1 Function
This operating instructions manual provides all the information you
need for the mounting, set-up and commissioning to ensure the safe
operation and disassembly of the safety switchgear. The operating inst-
ructions must be available in a legible condition and a complete version
in the vicinity of the device.
1.2 Target group: authorised qualified personnel
All operations described in this operating instructions manual must
be carried out by trained specialist personnel, authorised by the plant
operator only.
Please make sure that you have read and understood these operating
instructions and that you know all applicable legislations regarding
occupational safety and accident prevention prior to installation and
putting the component into operation.
The machine builder must carefully select the harmonised standards to
be complied with as well as other technical specifications for the selec-
tion, mounting and integration of the components.
1.3 Explanation of the symbols used
Information, hint, note:
This symbol is used for identifying useful additional information.
Caution: Failure to comply with this warning notice could
lead to failures or malfunctions.
Warning: Failure to comply with this warning notice could
lead to physical injury and/or damage to the machine.
1.4 Appropriate use
The products described in these operating instructions are developed to
execute safety-related functions as part of an entire plant or machine. It
is the responsibility of the manufacturer of a machine or plant to ensure
the proper functionality of the entire machinery or plant.
The safety switchgear must be exclusively used in accordance with the
versions listed below or for the applications authorised by the manufac-
turer. Detailed information regarding the range of applications can be
found in the chapter "Product description".
1.5 General safety instructions
The user must observe the safety instructions in this operating instruc-
tions manual, the country-specific installation standards as well as all
prevailing safety regulations and accident prevention rules.
Further technical information can be found in the Elan cata-
logues or in the online catalogue on the Internet: www.elan.de
The information contained in this operating instructions manual is provi-
ded without liability. Subject to technical modifications.
If multiple safety components are wired in series, the Perfor-
mance Level to EN ISO 13849-1 will be reduced due to the
restricted error detection under certain circumstances. The
entire concept of the control system, in which the safety com-
ponent is integrated, must be validated to EN ISO 13849-2.
There are no residual risks, provided that the safety instructions as well
as the instructions regarding mounting, commissioning, operation and
maintenance are observed.
Content
1 About this document
1.1 Function..............................................1
1.2 ..................1
1.3 Explanation of the symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.4 Appropriateuse........................................1
1.5 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.6 Warningaboutmisuse...................................2
1.7 Exclusionofliability.....................................2
2 Product description
2.1 Orderingcode .........................................2
2.2 Specialversions........................................2
2.3 Destinationanduse.....................................2
2.4 Technicaldata.........................................2
2.5  .....................................2
3 Mounting
3.1 General mounting instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
3.2 Dimensions ...........................................3
4 Electrical connection
4.1 General information for electrical connection. . . . . . . . . . . . . . . . . .3
4.2 Contactvariants........................................3
5 Set-up and maintenance
5.1 Functionaltesting.......................................3
5.2 Maintenance ..........................................3
6 Disassembly and disposal
6.1 Disassembly...........................................3
6.2 Disposal..............................................3
7 Appendix
7.1 EC Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
9.2010 / Index: 350/10 / Teile-Nr. 1021119_EN

2
Operating instructions
Safety switch SHG/SCG/SDG
EN
1.6 Warning about misuse
In case of inadequate or improper use or manipulations of the
safety switchgear, personal hazards or damage to machinery
or plant components cannot be excluded. The relevant requi-
rements of the standard EN 1088 must be observed.
1.7 Exclusion of liability
We shall accept no liability for damages and malfunctions resulting from
defective mounting or failure to comply with this operating instructions
manual. The manufacturer shall accept no liability for damages resul-
ting from the use of unauthorised spare parts or accessories.
For safety reasons, invasive work on the device as well as arbitrary re-
pairs, conversions and modifications to the device are strictly forbidden;
the manufacturer shall accept no liability for damages resulting from
such invasive work, arbitrary repairs, conversions and/or modifications
to the device.
2. Product description
2.1 Ordering code
This operating instructions manual applies to the following types:
SHG
➀
/
➁
No. Option Description
➀
01 Head positioned to the front
02 Head positioned to the left
03 Head positioned to the right
04 Head positioned to the rear
➁
103/90 1 NC/1 NO slow action
220/110 2 NC slow action
92/90 1 NC/1 NO snap action
SCG
➀
/
➁
No. Option Description
➀
01 Head positioned to the front
02 Head positioned to the left
03 Head positioned to the right
04 Head positioned to the rear
➁
103 1 NC/1 NO slow action
220/110 2 NC slow action
92/90 1 NC/1 NO snap action
SDG
➀
/
➁
No. Option Description
➀
01 Head positioned to the front
02 Head positioned to the left
03 Head positioned to the right
04 Head positioned to the rear
➁
1103 2 NC/1 NO slow action
3330 3 NC slow action
3440 3 NC gradually slow action
1044 1 NC/2 NO slow action
Only if the information described in this operating instructions
manual are realised correctly, the safety function and therefo-
re the compliance with the Machinery Directive is maintained.
2.2 Special versions
For special versions, which are not listed in the order code below 2.1,
these specifications apply accordingly, provided that they correspond to
the standard version.
2.3 Destination and use
The SHG, SCG, SDG safety switch has been designed to prevent, in
conjunction with the control part of a machine, movable safety guards
from being opened before hazardous conditions have been eliminated.
Safety switches can only be used for applications, in which
the hazardous condition is terminated without delay (e.g. run-
on movements) when the safety guard is opened.
When the safety guard is opened, the NC contacts are positively ope-
ned and the NO contacts are closed.
The user must evaluate and design the safety chain in accordance with
the relevant standards and on the required safety level.
2.4 Technical data
Standards: IEC 60947-5-1; EN ISO 13849-1;
EN 1088; BG-GS-ET-15
Enclosure: Aluminium
Actuator: Steel
Contact material: Silver
Protection class: IP67
Contact types: Change-over contact with double break,
type Zb or 2 NC or 3 NC contacts,
with galvanically separated contact bridges
Switching system: A IEC/EN 60947-5-1; slow action or
snap action, positive break NC contact
Termination: Screw terminals
Cable type: solid wire
Cable section: 0.5 … 2.5 mm²
Cable type: stranded wire
Cable section: 0.5 … 1.5 mm²,
with conductor ferrules
Cable entry: M20 × 1.5 ; SCG and SDG 3 × M20 x 1.5
Actuating speed: 0.2 m/s
Actuating frequency: max. 1200 operations/h
Mechanical life: > 1 million operations
Ambient temperature: 
Utilisation category: AC-15, DC-13
Ie/Ue:8 A / 230 VAC; 5 A / 24 VDC;
6 A / 230 VAC; 4 A / 24 VDC only snap action
Ui:400 V
Uimp:2.5 kV
Ithe:10 A
Us:24 VAC / DC 110 / 230 VAC
Max. fuse rating: 10 A gG D-fuse
2.5 Safety classification
Standards: EN ISO 13849-1
B10d (NC contact): 2,000,000
B10d (NO contact) at 10% ohmic contact load: 1,000,000
Service life: 20 years
MTTF
B d x x
hs/h3600
d
10d op op
op
n
0,1 x nop tcycle
(Specifications can vary depending on the application-specific parame-
ters hop, dop and tcycle as well as the load.)
-
ning Torque 0.8 Nm.

3
SHG/SCG/SDG
Operating instructions
Safety switch
EN
3. Mounting
3.1 General mounting instructions
Four mounting holes are provided for fixing the switch. The safety
switch must not be used as end stop. The safety switch can be moun-
ted in any position. The mounting position however is chosen so that
the components are protected against soiling and damages. In case of
painting activities, the components must be covered. The supplied fi-
xing material must be used. If a different actuating direction is required,
the four screws of the actuating head must be loosened. Turn the actu-
ating head in the desired direction and retighten the screws (tightening
torque 0.5 Nm). The default screws installed in the actuating head can
be replaced with the supplied tamperproof screws.
Mounting of the actuators: See mounting instructions actuators.
Please observe the remarks of the standards EN ISO 12100,
EN 953 and EN 1088.
3.2 Dimensions
All measurements in mm.
SHG...
16
40
43
M20x1,5
25,2
103
60
5,5
71
30
40
5,5
7,5
31
SCG...
25,2
78
31
39,5
50
88
120
16
3xM20x1,5 43
5,5
SDG...
25,2
39,5
50
31
110
120
152
16
3xM20x1,5 43
5,5
4. Electrical connection
4.1 General information for electrical connection
The electrical connection may only be carried out by autho-
rised personnel in a de-energised condition.
The contact labelling can be found in the wiring compartment of the
switch. For the cable entry, suitable cable glands with an appropriate
degree of protection must be used. After wiring, dust and soiling must
be removed from the wiring compartment.
4.2 Contact variants
Contacts are shown with safety guard closed.
SHG..103
SHG../92/90
SCG../103
SCG../92
SHG../220/110
SCG../220
11
23
12
24
11
21
12
22
SDG../1103 SDG../3330
SDG../3440
SDG../1044
11
21
33
12
22
34
11
21
31
12
22
32
11
23
33
12
24
34
5. Set-up and maintenance
5.1 Functional testing
The safety function of the safety components must be tested. The
following conditions must be previously checked and met:
1. Check the free movement of the actuating element.
2. Check the integrity of the cable entry and connections.
3. Check the switch enclosure for damage.
5.2 Maintenance
A regular visual inspection and functional test, including the following
steps, is recommended:
1. Check the free movement of the actuating element.
2. Remove particles of dust and soiling.
3 Check cable entry and connections.
Damaged or defective components must be replaced.
6. Disassembly and disposal
6.1 Disassembly
The safety switchgear must be disassembled in a de-energised condi-
tion only.
6.2 Disposal
The safety switchgear must be disposed of in an appropriate manner in
accordance with the national prescriptions and legislations.

4
Operating instructions
Safety switch SHG/SCG/SDG
EN
SHG;SCG;SDG-B-EN
7. Appendix
The currently prevailing Declaration of Conformity can be
downloaded from the Internet: www.elan.de
7.1 EC Declaration of conformity
Name of the safety component: SHG; SCG; SDG
Description of the safety component: Positive break position switch with separate
actuator for safety functions
Harmonised EC-Directives: 2006/42/EC EC-Machinery Directive
Person authorized for the compilation of the
technical documentation:
Ulrich Loss
Möddinghofe 30
42279 Wuppertal
Elan Schaltelemente GmbH und Co. KG
Im Ostpark 2, D - 35435 Wettenberg
Postfach 11 09, D - 35429 Wettenberg
 
 
E-Mail: [email protected]
Internet: http://www.elan.de
Place and date of issue: Wettenberg, September 10, 2009
Authorised signature
Heinz Schmersal
Managing Director
EC Declaration of conformity
Translation of the original
declaration of conformity
valid as of December 29, 2009
Elan Schaltelemente GmbH & Co. KG
Im Ostpark 2, 35435 Wettenberg
Germany
Internet: www.elan.de
We hereby certify that the hereafter described safety components both in its basic design and const-
ruction conforms to the applicable European Directives.
